ORDERNO. VM0602006CE

Digital Video Camcorder

VDR-D100EB VDR-D100EG / VDR-D150E VDR-D150EB / VDR

-D150EE VDR-D150EF / VDR-D150EG VDR-D150EP / VDR-

D150GC VDR-D150GCS / VDR-D150GN VDR-D150SG / VDR-

D152EG VDR-D158GK

Vol. 1

Colours

(S)...................Silver Type

SPECIFICATIONS

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Unauthorized copying and distribution isaviolation of law.

1. Safety Precautions

1.1. General Guidelines

1. IMPORTANTSAFETY NOTICE

There are special components used inthisequipment which are

important for safety. These parts are marked byinthe

SchematicDiagrams, CircuitBoard Layout, Exploded Viewsand

Replacement Parts List. Itisessential that these critical parts

shouldbe replaced with manufacturer’sspecified parts to prevent

shock, fire, or other hazards. Donot modifythe original design

without permission of manufacturer.

2. AnIsolation Transformer shouldalwaysbe used during the

servicing of AC Adaptor whose chassisisnot isolated from the

AC power line. Use atransformer of adequate power rating as this

protects the technician from accidents resulting inpersonal injury

from electrical shocks. Itwill also protect AC Adaptor from being

damaged byaccidental shorting that mayoccur during servicing.

3. When servicing, observe the original lead dress. Ifashort circuit

isfound, replace all parts which have been overheated or

damaged bythe short circuit.

4. After servicing, see to itthat all the protective devices such as

insulation barriers, insulation papers shields are properly

installed.

5. After servicing, make the following leakage current checks to

prevent the customer from being exposed to shock hazards.

2. Warning

2.1. Prevention of Electro StaticDischarge (ESD)to Electrostatically

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Sensitive (ES) Devices

Some semiconductor(solidstate) devices canbe damagedeasilybystatic electricity. Such

components commonlyare calledElectrostaticallySensitive (ES) Devices. Examples of typical

ES devices are integratedcircuits and some field-effect transistors and semiconductor"chip"

components. The following techniques shouldbe usedtohelpreduce the incidence of

component damage causedbyelectrostatic discharge (ESD).

1. Immediatelybefore handling anysemiconductor component or

semiconductor-equipped assembly, drainoff anyESDon your

bodybytouching aknownearth ground. Alternatively, obtainand

wear acommerciallyavailabledischarging ESDwrist strap, which

shouldbe removed for potential shock reasons prior to applying

power to the unitunder test.

2. After removing an electrical assemblyequipped with ES devices,

place the assemblyon aconductive surface such as aluminum

foil, to prevent electrostaticcharge buildup or exposure of the

assembly.

3. Use onlyagrounded-tipsoldering iron to solder or unsolder ES

devices.

4. Use onlyan antistaticsolder removal device. Some solder

removal devices not classified as "antistatic(ESDprotected)" can

generate electrical charge sufficient to damage ES devices.

5. Donot use freon-propelled chemicals. These can generate

electrical charges sufficient to damage ES devices.

6. Donot remove areplacement ES device from its protective

package until immediatelybefore you are readyto install it. (Most

replacement ES devices are packaged with leads electrically

shorted together byconductive foam, aluminum foil or

comparableconductive material).

7. Immediatelybefore removing the protective material from the

leads of areplacement ES device, touch the protective material to

the chassisor circuitassemblyinto which the device will be

installed.

CAUTION :

Besure no power isapplied to the chassisor circuit, and observe

all other safetyprecautions.

8. Minimize bodilymotions when handling unpackaged replacement

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

ES devices. (Otherwise harmless motion such as the brushing

together of your clothes fabricor the lifting of your foot from a

carpeted floor can generate staticelectricity(ESD)sufficient to

damage an ES device).

2.2. Caution for AC Cord / (VJA0940 type)

2.2.1. Information foryoursafety

IMPORTANT

Yourattention is drawntothe fact that recording of pre-recordedtapes ordiscs orother

publishedorbroadcast material mayinfringe copyright laws.

WARNING

To reduce the risk of fire orshock hazard, do not expose this equipment torainormoisture.

CAUTION

To reduce the risk of fire orshock hazardand annoying interference, use the recommended

accessories only.

FOR YOUR SAFETY

DO NOTREMOVE THE OUTER COVER

To prevent electric shock, do not remove the cover. Nouserserviceable parts inside. Refer

servicing toqualifiedservice personnel.

2.2.2. Caution forAC Mains Lead

Foryoursafety, please readthe following text carefully.

This appliance is suppliedwitha mouldedthree-pinmains plug foryoursafetyand convenience.

A 5-ampere fuse is fittedinthis plug.

Shouldthe fuse needtobe replacedplease ensure that the replacement fuse has a rating of 5

amperes and it is approvedbyASTA orBSI toBS1362.

Check forthe ASRA mark orthe BSI mark on the bodyof the fuse.

If the plug contains a removable fuse coveryou must ensure that it is refittedwhenthe fuse is

replaced.

If you lose the fuse cover, the plug must not be useduntil a replacement coveris obtained.

A replacement fuse covercanbe purchasedfromyourlocal Panasonic Dealer.

If the fittedmouldedplug is unsuitable forthe socket outlet inyourhome thenthe fuse should

be removedand the plug cut off and disposedof safety.

There is a dangerof severe electrical shock if the cut off plug is insertedintoany13-ampere

socket.

If a newplug is tobe fittedplease observe the wiring code as shownbelow.

If inanydoubt, please consult a qualifiedelectrician.

2.2.2.1. Important

The wires inthis mains leadare colouredinaccordance withthe following code:

As the colours of the wires inthe mains leadof this appliance maynot correspond withthe

colouredmarkings identifying the terminals inyourplug, proceedas follows:

The wire whichis colouredBLUE must be connectedtothe terminal inthe plug whichis marked

withthe letterN orcolouredBLACK.

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

The wire whichis colouredBROWN must be connectedtothe terminal inthe plug whichis

markedwiththe letterLorcolouredRED.

Underno circumstances shouldeitherof these wires be connectedtothe earthterminal of the

three pinplug, markedwiththe letterE orthe EarthSymbol.

2.2.2.2. Before use

Remove the ConnectorCoveras follows.

2.2.2.3. Howtoreplace the Fuse

1. Remove the Fuse Cover with ascrewdriver.

2. Replace the fuse and attach the Fuse cover.

2.3. How to Replace the Lithium Battery

The lithiumbattery(ML-621S/F9D) is not suppliedas a service part and must be replacedas part

of the Cassette CoverUnit. (Referto“Disassembly and Assembly Instructions.")

NOTE:

ThisLithium batteryisacritical component. (Type No.:ML-621S/

F9DManufactured byPanasonic.)(Not supplied)

Itmust never be subjected to excessive heat or discharge.

Itmust therefore onlybe fitted inequipment designed specifically

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

for its use.

Replacement batteries must be of the same type and manufacture.

Theymust be fitted inthe same manner and location as the original

battery, with the correct polaritycontacts observed.

Donot attempt to re-charge the oldbatteryor re-use itfor anyother

purpose.

Itshouldbe disposed of inwaste products destined for burial

rather than incineration.

3. Service Navigation

3.1. Introduction

This service manual contains technical information whichwill allowservice personnel's to

understand and service this model. Please place orders using the parts list and not the drawing

reference numbers.

If the circuit is changedormodified, this information will be followedbysupplement service

manual tobe filedwithoriginal service manual.

Note 1:

1. VSK0561 isindicated on the AC Adaptor used inthe following

model:

VDR-D158GK.

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

However, the AC Adaptor replacement part number isDE-974HA

which shouldbe used when ordering.

2. VSK0561 isindicated on AC Adaptor used inthe following models:

VDR-D100EB, VDR-D100EG, VDR-D150E, VDR-D150EB, VDR-

D150EE, VDR-D150EF, VDR-D150EG, VDR-D150EP, VDR-D150GC,

VDR-D150GCS, VDR-D150GN, VDR-D150SG, and VDR-D152EG.

However, the AC Adaptor replacement part number isDE-974GB

which shouldbe used when ordering.

Note 2:

1. Thisservice manual does not containthe following information,

because of the impossibilityof servicing at component level.

A. SchematicDiagram, Block Diagram and P.C.B. layout of Main

P.C.B.

B. Parts List for individual parts of MainP.C.B.

2. The following categoryare recyclemoduleparts. Please send itto

Central RepairCenter.

A. *MainP.C.B. (LSEP8314P1/ LSEP8314Q1)

Whena part replacement is requiredforrepairing MainP.C.B., replace the assemblyparts.

3.2. About Lead Free Solder (PbF)

Distinction of PbF PCB:

PCBs (manufactured) using leadfree solderwill have a PbF stampon the PCB.

Caution:

-Pb free solder has ahigher melting point than standard solder;

Typicallythe melting point is50-70°F (30-40°C)higher.

Please use ahigh temperature soldering iron. Incase of the

soldering iron with temperature control, please set itto 700±20°F

(370±10°C).

-Pb free solder will tend to splash when heated too high (about

1100°F/600°C).

Whensoldering orunsoldering, please completelyremove all of the solderon the pins orsolder

area, and be sure toheat the soldering points withthe Pbfree solderuntil it melts enough.

4. Specifications

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

5. Location of Controls and Components

Followings are the Operation Guide forVDR-D100EB/D150EB as a sample.

Forothermodels, refertoeachoriginal Operation Guide.
