Panasonic AK-UB300 Manuel utilisateur

Operating Instructions

Excerpted Version

Installation Instructions provided

Multi-Purpose Camera

Model No. AK-UB300G

DVQX1197ZA

SS1016HM0 -YI

Printed in Japan

Before operating this product, please read the instructions carefully and save this manual for future use.

ENGLISH

Excerpted Version

Before using this product, be sure to read “Read this rst!” (page 4, pages 20 to 23).

This manual is an excerpted version of the full Operating Instructions.

For more information, please visit the Panasonic website (http://pro-av.panasonic.net/en/manual/

index.html), and refer to the Operating Instruction (HTML).

ENGLISH

DEUTSCH

Bitte lesen Sie sorgfältig die „Bitte lesen Sie zuerst diesen Hinweis!“ vor der Nutzung dieses Produkts.

(Seite 5, Seiten 24 bis 25).

Weitere Informationen nden Sie auf der Panasonic-Webseite (http://pro-av.panasonic.net/en/manual/

index.html) und in der Bedienungsanleitung (HTML).

FRANÇAIS

Avant d’utiliser cet appareil, assurez-vous de lire la section « Lire ces informations en premier ! » (page 6,

pages 26 à 28).

Pour de plus amples informations, visiter le site Web de Panasonic (http://pro-av.panasonic.net/en/

manual/index.html) et consulter le mode d’emploi (HTML).

ITALIANO

Prima di utilizzare il prodotto, assicurarsi di leggere “Leggere prima quanto segue!” (pagina 7, pagine 29

a 30).

Per maggiori informazioni, per favore visitare il sito web Panasonic (http://pro-av.panasonic.net/en/

manual/index.html), e fare riferimento alle istruzioni per l’uso (HTML).

ESPAÑOL

Antes de usar este producto, asegúrese de leer “Lea esto primero” (página 8, páginas 31 a 33).

Si desea obtener más información, visite el sitio web de Panasonic (http://pro-av.panasonic.net/en/

manual/index.html) y consulte las instrucciones de funcionamiento (HTML).

Installation Instructions

Pages 4 to 19

Operating Instructions

Pages 20 to 47

български Посетете следния уебсайт относно информация за безопасността и важни

уведомления за продукта.

Hrvatski Za sigurnosne informacije i važne obavijesti o proizvodu posjetite sljedeću

internetsku stranicu.

Čeština Na následujícím webu najdete bezpečnostní informace a důležité poznámky k

tomuto produktu.

Dansk Besøg følgende webside for sikkerhedsinformation og vigtige bemærkninger

vedrørende produktet.

Nederlands Ga naar de volgende website voor veiligheidsinformatie en belangrijke meldingen

over het product.

Eesti Toodet puudutava ohutusteabe ja oluliste märkuste saamiseks külastage järgmist

veebilehte.

Suomi Käy seuraavalla verkkosivulla saadaksesi turvallisuustietoja ja tärkeitä tietoja liittyen

laitteeseen.

Ελληνικά Για πληροφορίες σχετικά με θέματα ασφάλειας και σημαντικές ειδοποιήσεις που

αφορούν το προϊόν σας, επισκεφτείτε τον ιστότοπο που ακολουθεί.

Magyar A termékkel kapcsolatos biztonsági információkért és fontos értesítésekért látogasson

el az alábbi weboldalra.

Latviešu Lai iegūtu informāciju par drošību un skatītu svarīgus paziņojumus par šo produktu,

apmeklējiet tālāk norādīto tīmekļa vietni.

Lietuvių Jei reikia saugos informacijos ir svarbių pranešimų apie gaminį, apsilankykite toliau

nurodytoje svetainėje.

Polski Informacje o bezpieczeństwie i ważne informacje o produkcie znajdują się w

poniższej witrynie internetowej.

Português Consulte o seguinte website para as informações de segurança e importantes

noticações sobre o produto.

Română Vizitați următoarea pagină web pentru informaţii de securitate și noticări importante

cu privire la produs.

Slovensky Pre bezpečnostné informácie a dôležité oznámenia súvisiace s produktom navštívte

túto webovú stránku.

Slovenščina Za varnostne informacije in pomembna obvestila v zvezi z izdelkom obiščite

naslednje spletno mesto.

Svenska Besök följande webbplats för säkerhetsinformation och viktiga meddelanden om

produkten.

http://pro-av.panasonic.net/en/manual/index.html

fMicrosoft®, Windows®, Windows® 7, Windows® 8, Windows® 8.1, Windows® 10, Internet Explorer®,

ActiveX®, and DirectX® are registered trademarks or trademarks of Microsoft Corporation in the United

States, Japan, and/or other countries.

fApple, Mac, and OS X are trademarks of Apple Inc., registered in the United States and other countries.

fIntel®, Intel®, and CoreTM are trademarks or registered trademarks of Intel Corporation or its subsidiaries

in the United States and/or other countries.

fAll other names, company names, product names, etc., contained in this instruction manual are

trademarks or registered trademarks of their respective owners.

fTransferring, copying, disassembling, decompiling, reverse engineering, and exporting in violation of

export laws of any software included with this product are strictly prohibited.

How to read this document

rIllustrations

fIllustrations of the camera, menu screens, and other items, may vary from the actual products.

fScreenshots are used according to guidelines provided by Microsoft Corporation.

rConventions used in this manual

fWords and phrases in [ ] brackets indicate content displayed in the viewnder or monitor.

fWords and phrases in < > brackets indicate design text used on this camera, such as button names.

rReference pages

fReference pages in this document are indicated by (page 00).

rTerminology

fMicrosoft®Windows® 7 Professional SP1 32/64-bit is referred to as Windows 7.

fMicrosoft®Windows® 8 Professional 32/64-bit is referred to as Windows 8.

fMicrosoft®Windows® 8.1 Professional 32/64-bit is referred to as Windows 8.1.

fMicrosoft®Windows® 10 Professional 32/64-bit is referred to as Windows 10.

fWindows® Internet Explorer® 8.0, Windows® Internet Explorer® 9.0, Windows® Internet Explorer® 10.0,

and Windows® Internet Explorer® 11.0 are referred to as Internet Explorer.

fThe format displayed in the 2160/** is referred to as the UHD mode.

fThe format displayed in the ***/** CROP is referred to as the UHD CROP mode.

fThe format displayed in the 1080/**, 720/** is referred to as the HD mode.

Read this rst!

indicates safety information.

WARNING:

To prevent injury, this apparatus must

be securely attached to the oor/wall in

accordance with the installation instructions.

WARNING:

Installation should only be performed by

qualied installation personnel.

Improper installation may result in the entire

apparatus falling down and causing injury.

Bitte lesen Sie zuerst diesen Hinweis! DEUTSCH

Bitte lesen Sie zuerst diesen Hinweis!

ist die Sicherheitsinformation.

WARNUNG:

Um Verletzungen zu verhüten, muss dieser

Apparat gemäß der Installationsanleitung

sicher am Boden bzw. an der Wand

befestigt werden.

WARNUNG:

Die Installation darf nur durch qualiziertes

Personal ausgeführt werden.

Fehlerhafte Installation kann zum

Herunterfallen des Gerätes und zu

Verletzungen führen.

FRANÇAIS Lire ces informations en premier !

Lire ces informations en premier !

Informations concernant la sécurité.

AVERTISSEMENT:

Pour éviter tout risque de blessures,

l’appareil doit être solidement xé

au plancher/mur conformément aux

instructions d’installation.

AVERTISSEMENT:

L’installation ne doit être effectuée que par

du personnel d’installation qualié.

Une mauvaise installation peut avoir pour

conséquence la chute de l’appareil et

provoquer des blessures.

Leggere prima quanto segue! ITALIANO

Leggere prima quanto segue!

sono le informazioni sulla sicurezza.

AVVISO:

Per prevenire ferite, questo apparecchio

deve essere montato saldamente al

pavimento/muro in conformità alle istruzioni

di installazione.

AVVISO:

L’installazione deve essere realizzata

unicamente da tecnici qualicati.

Un’installazione incorretta può risultare

nella caduta dell’apparecchio con

conseguenti danni alle persone.

ESPAÑOL Lea esto primero

Lea esto primero

indica información de seguridad.

ADVERTENCIA:

Para evitar heridas, este aparato debe

estar rmemente instalado al piso/pared

de acuerdo con las instrucciones de

instalación.

ADVERTENCIA:

La instalación solamente debe llevarla a

cabo personal cualicado.

Una instalación incorrecta podría provocar

la caída del dispositivo y causar lesiones.

Installation Instructions Contents

Read this rst! 4

Bitte lesen Sie zuerst diesen Hinweis! 5

Lire ces informations en premier ! 6

Leggere prima quanto segue! 7

Lea esto primero 8

Before installing 10

Drop prevention measure 10

Installation 11

Example where the camera is mounted on a ceiling 12

Example where the camera is mounted on a wall 13

Example of mounting the camera onto a xture or tripod made by another manufacturer 15

Example where the camera is mounted from top 16

Mounting the lens 17

Using external DC power supply 18

External dimensions 19

Before installing

Drop prevention measure

Take the drop prevention measure by attaching the drop prevention wire to the mounting screw hole.

Mounting the camera to the pan head

Prepare a commercially available drop prevention wire when mounting this unit to the pan head.

Mounting the camera to anything other than the pan head

Prepare the drop prevention wire and camera mounting xture when attaching to anything other than the

pan head.

1 Drop prevention wire (optional): 1

Always use the drop prevention wire.

A drop prevention wire is available as an optional accessory. Use with as small slack as allowed by the

installation location or the installation method.

Secure wire diameter of 2 mm or more, length of 300 mm (11 13/16 inches) or less, and strength of the

mounting section of 2000 N or more when using a commercially available drop prevention wire. Also,

separately prepare the mounting screw matching the mounting specication.

6.4 mm

4.5 mm

6.4 mm

4.5 mm

2 mm

Length of the wire (300 mm) (11 13/16 inches)

Installation sideCamera side

11 mm

fWire length 300 mm (11 13/16 inches): Parts number (DVDW1001ZA)

2 Camera mounting screws (procured locally): 2

Size: 1/4-20 UNC or 3/8-16 UNC

Camera mounting fixture

7–9 mm

Consider the thickness of the camera mounting xture for the length.

3 Installation side wire mounting screw (M6 or M4) (procured locally): 1

Use an anchor bolt at the installation location and secure the strength of ten times of the entire weight.

4 Flat washers (procured locally): 2 (for mounting the camera)

For 1/4 inch screw or 3/8 inch screw

5 Spring washers (procured locally): 2 (for mounting the camera)

For 1/4 inch screw or 3/8 inch screw

6 Camera mounting xture (procured locally): 1

Prepare the xture with material and shape that can withstand the entire weight of the camera and the

lens.
