Installation Guide

Home Network System

Full HD Camera

Model No. KX-HNC800EX

Thank you for purchasing a Panasonic product.

This document explains how to configure the camera and access it

using a mobile device. These steps must be followed before you can

use the camera. For details about how to use the camera, refer to the

User’s Guide (page 31).

Please read this document before using the unit and save it for future

reference.

In order to use this device, download the latest version of the [Home

Network] app.

Introduction

Accessory information ...............3

Important Information

About this system ......................6

For your safety ...........................6

Important safety instructions ......8

Security cautions .......................9

For best performance ..............10

Privacy and rights of portrait ....11

Other information .....................11

Setup

Part names and functions ........13

LED indicator ...........................14

Connections .............................15

Setup overview ........................17

Downloading the [Home Network]

app ...........................................18

Setting up the camera (initial

setup) .......................................19

Registering additional mobile

devices to the camera .............23

Registering the camera to your

hub ...........................................24

Resetting the camera ..............25

Appendix

Information about wireless

communication ........................26

Information about sensor

features ....................................27

Information about night vision

mode ........................................29

Wall mounting ..........................29

Adjusting the angle ..................29

Removing the stand .................30

Accessing the User’s Guide ....31

Specifications ..........................32

Limitations on the use of 5 GHz

communications .......................33

Open source software notice ...35

Software information ................35

Table of Contents

Accessory information

Supplied accessories

AC adaptor

Part number: S006AKV0500100

Other information

RDesign and specifications are subject to change without notice.

RThe illustrations in these instructions may vary slightly from the actual

product.

Trademarks

RmicroSDXC Logo is a trademark of SD-3C, LLC.

RiPhone and iPad are trademarks of Apple Inc., registered in the U.S.

and other countries.

RAndroid and Google Play are registered trademarks or trademarks of

Google Inc.

RMicrosoft, Windows, and Internet Explorer are either registered

trademarks or trademarks of Microsoft Corporation in the United

States and/or other countries.

RWi-Fi, WPA, and WPA2 are registered trademarks or trademarks of

Wi-Fi Alliance.

RAll other trademarks identified herein are the property of their

respective owners.

Notice

RThe camera supports microSD, microSDHC, and microSDXC memory

cards. In this document, the term “microSD card” is used as a generic

term for any of the supported cards.

Introduction

Integration with the Panasonic Home Network System

Although you can use the camera by itself, it can also be integrated into

the Panasonic Home Network System.

What is the Panasonic Home Network System?

The Panasonic Home Network System is a wireless system that uses

DECT technology to create a powerful network of devices, including

motion sensors, window/door sensors, smart plugs, etc., and allows you

to control them all with an easy-to-use app.

What are some example uses?

– Use the system’s sensors to trigger camera recording

Camera images can be recorded automatically when a door is

opened, when motion is detected, etc.

– Use the camera’s motion sensor to trigger the alarm system

You can receive a phone call and notification when the camera’s

motion sensor detects motion.

What do I need to get started?

Your HD camera (up to 16) and a KX-HNB600 hub. The hub joins all

system devices together using DECT technology, connects to your

home network via your wireless router, and can also connect to your

landline.

What other devices are available?

– Activity detection sensors, such as motion sensors and window/door

sensors

– Smart plugs, which can turn electric devices on when triggered by a

sensor or according to a schedule

– and more!

KX-HNB600KX-HNB600

Introduction

For information about the latest devices and bundles, visit the website

below.

Poland: www.panasonic.pl

Hungary: www.panasonic.com/hu

Czech: www.panasonic.com/cz

Slovakia: www.panasonic.com/sk

Croatia: www.panasonic.com/hr

Romania: www.panasonic.com/ro

Bulgaria: www.panasonic.com/bg

Other countries: www.panasonic.eu

Note:

RDevice availability and appearance may vary by region.

Introduction

About this system

RThis system is an auxiliary

system; it is not designed to

provide complete protection

from property loss. Panasonic

will not be held responsible in

the event that property loss

occurs while this system is in

operation.

RThis product should not be used

as substitute for a medical or

caregiver’s supervision. It is the

caregiver’s responsibility to stay

close enough to handle any

eventuality.

RThe system’s wireless features

are subject to interference,

therefore functionality in all

situations cannot be

guaranteed. Panasonic will not

be held responsible for injury or

damage to property that occurs

in the event of wireless

communication error or failure.

For your safety

To prevent severe injury and loss

of life/property, read this section

carefully before using the product

to ensure proper and safe

operation of your product.

WARNING

Power connection

RUse only the power source

marked on the product.

RDo not overload power outlets

and extension cords. This can

result in the risk of fire or

electric shock.

RCompletely insert the AC

adaptor/power plug into the

power outlet. Failure to do so

may cause electric shock and/

or excessive heat resulting in a

fire.

RRegularly remove any dust, etc.

from the AC adaptor/power plug

by pulling it from the power

outlet, then wiping with a dry

cloth. Accumulated dust may

cause an insulation defect from

moisture, etc. resulting in a fire.

RUnplug the product from power

outlets if it emits smoke, an

abnormal smell, or makes an

unusual noise. These

conditions can cause fire or

electric shock. Wait for the

product to stop emitting smoke,

then visit the following web

page and contact Panasonic for

support.

Poland: www.panasonic.pl

Hungary: www.panasonic.com/

Important Information

Czech: www.panasonic.com/cz

Slovakia: www.panasonic.com/

Croatia: www.panasonic.com/hr

Romania: www.panasonic.com/

Bulgaria: www.panasonic.com/

Other countries:

www.panasonic.eu

RUnplug from power outlets and

never touch the inside of the

product if its casing has been

broken open. Danger of electric

shock exists.

RNever touch the plug with wet

hands. Danger of electric shock

exists.

RDo not connect non-specified

devices.

Installation

RDo not use this product

outdoors.

RTo prevent the risk of fire or

electrical shock, do not expose

the product to rain or any type

of moisture.

RDo not place or use this product

near automatically controlled

devices such as automatic

doors and fire alarms. Radio

waves emitted from this product

may cause such devices to

malfunction resulting in an

accident.

RDo not allow the AC adaptor

cord to be excessively pulled,

bent or placed under heavy

objects.

RKeep small parts, such as

microSD cards, out of the reach

of children. There is a risk of

swallowing. In the event they

are swallowed, seek medical

advice immediately.

Operating safeguards

RUnplug the product from power

outlets before cleaning. Do not

use liquid or aerosol cleaners.

RDo not disassemble the product.

RNever put metal objects inside

the product. If metal objects

enter the product, turn off the

circuit breaker and contact an

authorised service centre.

Medical

RConsult the manufacturer of any

personal medical devices, such

as pacemakers or hearing aids,

to determine if they are

adequately shielded from

external RF (radio frequency)

energy. Wireless

communication features

operate between the

frequencies listed below, with a

peak transmission power of

100 mW.

2.412 GHz – 2.472 GHz

Important Information

5.180 GHz – 5.320 GHz

5.500 GHz – 5.700 GHz

5.745 GHz – 5.825 GHz

RDo not use the product in health

care facilities if any regulations

posted in the area instruct you

not to do so. Hospitals or health

care facilities may be using

equipment that could be

sensitive to external RF energy.

CAUTION

Installation and location

RNever install wiring during a

lightning storm.

RThe AC adaptor is used as the

main disconnect device. Ensure

that the AC outlet is installed

near the product and is easily

accessible.

RTo avoid the risk of

strangulation, keep the product

and the AC adaptor cord at

least 1 m from a child’s crib and

out of the reach of small

children.

RMount the product on the stable

location where the camera can

be adequately supported when

installing.

RDo not mount the product on

soft material. It may fall down,

break or cause injury.

RDo not mount the product on

the following materials: gypsum

board, ALC (autoclaved

lightweight cellular concrete),

concrete block, plywood less

than 25 mm thick, etc.

Preventing accidents and

injuries

RDo not put your ear(s) near the

speaker, as loud sounds

emitted from the speaker may

cause hearing impairment.

Important safety

instructions

When using your product, basic

safety precautions should always

be followed to reduce the risk of

fire, electric shock, and injury to

persons, including the following:

1. Do not use this product near

water for example, near a

bathtub, washbowl, kitchen

sink, or laundry tub, in a wet

basement or near a swimming

pool.

2. Use only the power cord

indicated in this document.

SAVE THESE INSTRUCTIONS

Important Information

Security cautions

Take appropriate measures to

avoid the following security

breaches when using this product.

– Leaks of private information

– Unauthorised use of this product

– Unauthorised interference or

suspension of the use of this

product

Take the following measures to

avoid security breaches:

RConfigure the wireless router

that connects your mobile

device to this product to use

encryption for all wireless

communication.

RYou may be vulnerable to

security breaches if the unit is

used with the login password,

disarm code, or PIN code, or

other settings at their default

values. Configure your own

values for these settings.

RDo not use passwords that

could be easily guessed by a

third party. If you keep a record

of your passwords, protect that

record. Change passwords

regularly.

RIf you lose your mobile device,

change the password used to

access this product.

RIf you enable the product’s auto

lock or similar security feature

on your mobile device.

RTake care when performing

important security related

operations, such as deleting

unit IDs.

RTo prevent disclosure of

personal information, enable

the screen lock or similar

security feature on your mobile

device.

RWhen submitting the product for

repair, make a note of any

important information stored in

the product, as this information

may be erased or changed as

part of the repair process.

RBefore handing the product

over to a third party for repair or

other purposes, perform a

factory data reset to erase any

data stored in the product and

remove the microSD card. Use

only trusted repair services

authorised by Panasonic.

RBefore disposing of the product,

perform a factory data reset to

erase any data stored in the

product. Remove and erase the

microSD card.

RIf your mobile device will no

longer be used with the product,

delete your mobile device’s

registration from the product

Important Information

and delete the corresponding

app from your mobile device.

RIf this product experiences a

power outage, its date and time

setting may become incorrect.

Confirm the date and time

setting and correct it if

necessary.

Additionally, note the following.

RCommunications may be

interrupted depending on

network conditions and wireless

signal quality.

RThis product may be used in

ways that violate the privacy or

publicity rights of others. You

are responsible for the ways in

which this product is used.

For best

performance

Product location/avoiding noise

This product uses radio waves to

communicate with a wireless

router.

RFor maximum coverage and

noise-free communications,

place this product:

– at a convenient, central

location with no obstructions

between this product and the

wireless router.

– away from electronic

appliances such as TVs,

radios, personal computers,

wireless devices, or other

phones.

– facing away from radio

frequency transmitters, such

as external antennas of

mobile phone cell stations.

(Avoid putting this product on

a bay window or near a

window.)

RCoverage and transmission

quality depends on the local

environmental conditions.

RIf the transmission quality is not

satisfactory, move this product

to another location.

Environment

RKeep the product away from

electrical noise generating

devices, such as fluorescent

lamps and motors.

RThe product should be kept free

from excessive smoke, dust,

high temperature, and vibration.

RDo not expose this product to

direct sunlight or other forms of

powerful light such as halogen

lights for long periods of time.

(This may damage the image

sensor.)

RDo not place heavy objects on

top of the product.

Important Information

Table des matières

Autres manuels Panasonic caméscope

Panasonic

Panasonic HC-V110 Manuel utilisateur

Panasonic

Panasonic AJSPX800 - P2 CAMCORDER Manuel utilisateur

Panasonic

Panasonic HDC-HS200 Manuel utilisateur

Panasonic

Panasonic HDC-SD600 Manuel utilisateur

Panasonic

Panasonic PV-DV102PN Manuel utilisateur

Panasonic

Panasonic AG-CX10 Manuel utilisateur

Panasonic

Panasonic AJ-HDX400E Manuel utilisateur

Panasonic

Panasonic NV-VZ55PN Manuel utilisateur

Panasonic

Panasonic NV-GS70EG Manuel utilisateur

Panasonic

Panasonic HC-V380 Instructions d'installation et d'entretien

Panasonic

Panasonic GPKS1000 - INDUSTRIAL COLOR CAM Manuel utilisateur

Panasonic

Panasonic AGDP800 - CAMERA/RECORDER3CCD Manuel utilisateur

Panasonic

Panasonic NV-DS77B Manuel utilisateur

Panasonic

Panasonic POVCAM AG-UMR20 Manuel d'utilisation et d'entretien

Panasonic

Panasonic AJHVF27BG - HD EVF - MULTI-LANG Manuel utilisateur

Panasonic

Panasonic AG-AC130A Series Manuel utilisateur

Panasonic

Panasonic PV-GS83 - Palmcorder Camcorder - 680 KP Manuel utilisateur

Panasonic

Panasonic AG-AC160A Series Manuel utilisateur

Panasonic

Panasonic HC-V100M Manuel utilisateur

Panasonic

Panasonic HC-V700 Caractéristiques techniques

Panasonic

Panasonic NV-MX500B Manuel utilisateur

Panasonic

Panasonic SDR-H20EE Manuel utilisateur

Panasonic

Panasonic Palmcorder PV-DV92 Manuel utilisateur

Panasonic

Panasonic DIGITAL Palmcorder PV-GS29 Manuel utilisateur

Manuels caméscope populaires d'autres marques

Toshiba

Toshiba CAMILEO Z100 Manuel utilisateur

Canon

Canon RC 260 Manuel utilisateur

Sony

Sony Handycam DCR-DVD7E Manuel utilisateur

Brinno

Brinno TimeLapse TLC200 Manuel utilisateur

JVC

JVC GR-SXM68AC Guide de démarrage rapide

Insignia

Insignia NS-DCC5HB09 - Camcorder - 720p Manuel utilisateur

MYDLINK

MYDLINK DCS-6100LH Manuel utilisateur

Sony

Sony video Hi8 Handycam CCD-TR555 Manuel utilisateur

SECURECOM

SECURECOM V-5014B Manuel utilisateur

Sharper Image

Sharper Image U-VIDEO Manuel utilisateur

JVC

JVC AA-V15EG Manuel utilisateur

Canon

Canon LEGRIA HV40 Manuel utilisateur

Sony

Sony Handycam DCR-VX2000 Manuel utilisateur

RCA

RCA CC616 Manuel utilisateur

ATIK Cameras

ATIK Cameras Horizon Manuel utilisateur

Sony

Sony Handycam HDR-CX580V Manuel utilisateur

Sharp

Sharp ViewcamZ VL-Z8H Manuel utilisateur

Philips

Philips M620/21 Manuel utilisateur
