Thank you for purchasing this product.

Please read these instructions carefully before using this

product, and save this manual for future use.

Operating Instructions

Blu-ray Disc™ Recorder

Model No. DMR-UBT1

Software (Firmware) Update

To support the latest features, it’s very

important you install the latest updates

to maintain proper operation of your unit.

For details, refer to “Software

(Firmware) Update” (>45) or

http://panasonic.jp/support/global/cs/

(This site is in English only.)

until

2018/09/06

DMRUBT1EC-TQBS0291_eng.book 1 ページ２０１８年８月２日　木曜日　午前１０時８分

TQBS0291

Safety precautions

Unit

• To reduce the risk of fire, electric shock or

product damage,

– Do not expose this unit to rain, moisture,

dripping or splashing.

– Do not place objects filled with liquids, such as

vases, on this unit.

– Use the recommended accessories.

– Do not remove covers.

– Do not repair this unit by yourself. Refer

servicing to qualified service personnel.

– Do not let metal objects fall inside this unit.

– Do not place heavy items on this unit.

AC mains lead

• To reduce the risk of fire, electric shock or

product damage,

– Ensure that the power supply voltage

corresponds to the voltage printed on this unit.

– Insert the mains plug fully into the socket

outlet.

– Do not pull, bend, or place heavy items on the

lead.

– Do not handle the plug with wet hands.

– Hold onto the mains plug body when

disconnecting the plug.

– Do not use a damaged mains plug or socket

outlet.

• The mains plug is the disconnecting device.

Install this unit so that the mains plug can be

unplugged from the socket outlet immediately.

Unit

• This unit utilizes a laser. Use of controls or

adjustments or performance of procedures other

than those specified herein may result in

hazardous radiation exposure.

• Do not place sources of naked flames, such as

lighted candles, on this unit.

• This unit may receive radio interference caused

by mobile telephones during use. If such

interference occurs, please increase separation

between this unit and the mobile telephone.

• This unit is intended for use in moderate

climates.

Placement

• Place this unit on an even surface.

• To reduce the risk of fire, electric shock or

product damage,

– Do not install or place this unit in a bookcase,

built-in cabinet or in another confined space.

Ensure this unit is well ventilated.

– Do not obstruct this unit’s ventilation openings

with newspapers, tablecloths, curtains, and

similar items.

– Do not expose this unit to direct sunlight, high

temperatures, high humidity, and excessive

vibration.

WARNING CAUTION

DMRUBT1EC-TQBS0291_eng.book 2 ページ２０１８年８月２日　木曜日　午前１０時８分

TQBS0291 3

Batteries

• Danger of explosion if battery is incorrectly

replaced. Replace only with the type

recommended by the manufacturer.

• Mishandling of batteries can cause electrolyte

leakage and may cause a fire.

– Do not mix old and new batteries or different

types at the same time.

– Do not heat or expose to flame.

– Do not leave the battery(ies) in a car exposed

to direct sunlight for a long period of time with

doors and windows closed.

– Do not take apart or short circuit.

– Do not recharge alkaline or manganese

batteries.

– Do not use batteries if the covering has been

peeled off.

– Remove batteries if you do not intend to use

the remote control for a long period of time.

Store in a cool, dark place.

• When disposing of the batteries, please contact

your local authorities or dealer and ask for the

correct method of disposal.

Supplied accessories

Please check and identify the supplied

accessories.

(Product numbers are correct as of August 2018.

These may be subject to change.)

• Do not use AC mains lead with other equipment.

Insert batteries

(Inside of product)

Remote control (N2QAYB001114):1pc.

Batteries for remote control: 2 pcs.

AC mains lead: 1pc.

RF coaxial cable: 1pc.

Restriction on use of unauthorized copied content

This unit adopts the following technology for copyright

protection.

Cinavia Notice

This product uses Cinavia technology to limit the use of

unauthorized copies of some commercially-produced film

and videos and their soundtracks. When a prohibited use

of an unauthorized copy is detected, a message will be

displayed and playback or copying will be interrupted.

More information about Cinavia technology is provided at

the Cinavia Online Consumer Information Center at

http://www.cinavia.com. To request additional information

about Cinavia by mail, send a postcard with your mailing

address to:

Cinavia Consumer Information Center, P.O.

Box 86851, San Diego, CA, 92138, USA.





R6/LR6, AA

(Alkaline or manganese batteries)

DMRUBT1EC-TQBS0291_eng.book 3 ページ２０１８年８月２日　木曜日　午前１０時８分

TQBS0291

Table of contents

Safety precautions . . . . . . . . . . . . . . . . . . . . . 2

Supplied accessories . . . . . . . . . . . . . . . . . . . 3

Getting started

Unit and media care . . . . . . . . . . . . . . . . . . . . 5

Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Remote Control . . . . . . . . . . . . . . . . . . . . . . . 8

Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Watching broadcasts

Watching broadcasts . . . . . . . . . . . . . . . . . . 11

Recording

Recording TV programmes . . . . . . . . . . . . . 13

Timer recording . . . . . . . . . . . . . . . . . . . . . . 15

FUNCTION MENU . . . . . . . . . . . . . . . . . . . . 18

Keyword Recording . . . . . . . . . . . . . . . . . . . 19

Using the external HDD (USB HDD) . . . . . . 21

Playing back

Playing contents on the HDD . . . . . . . . . . . . 22

Playing contents on the media . . . . . . . . . . . 26

Playback (Skip, Manual Skip etc.) . . . . . . . . 27

4K Networking . . . . . . . . . . . . . . . . . . . . . . . 29

Playback menu

(Repeat Play, Remaster etc.). . . . . . . . . . . . 30

Deleting/Editing

Deleting/Editing contents . . . . . . . . . . . . . . . 32

Copying

Copying contents . . . . . . . . . . . . . . . . . . . . . 35

Network

Network Service . . . . . . . . . . . . . . . . . . . . . . 42

TV Anywhere . . . . . . . . . . . . . . . . . . . . . . . . 42

Home Network feature . . . . . . . . . . . . . . . . . 42

Other functions

VIERA Link. . . . . . . . . . . . . . . . . . . . . . . . . . 45

Software (Firmware) Update . . . . . . . . . . . . 45

Other operations (Entering text etc.) . . . . . . 46

Setup

Basic Settings . . . . . . . . . . . . . . . . . . . . . . . 48

Reference

Troubleshooting guide . . . . . . . . . . . . . . . . . 56

Main unit . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Specifications . . . . . . . . . . . . . . . . . . . . . . . . 63

HDD and media information. . . . . . . . . . . . . 64

Licenses. . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Panasonic Corporation, a company having its registered office of 1006,

Oaza Kadoma, Kadoma City, Osaka 571-8501, Japan, automatically

collects personal data such as IP address and/or Device ID from your

device as soon as you connect it to the Internet. We do this to protect

our customers and the integrity of our Service as well as to protect the

rights or property of Panasonic.

You have a right of access, rectification and objection to in certain

circumstances, a right of erasure, restriction of processing, data

portability and a right to object to other forms of processing. If you wish

to exercise any of the above rights and/or wish to know more about the

processing of your personal data in this context, please refer to the full

text of our privacy policy displayed at the support page of your device,

http://av.jpn.support.panasonic.com/support/global/cs/bd/privacy/ or

contact our customer communications/support number or address

described in the Pan European Guarantee included in your device box

to send you the full text of our privacy policy.

About descriptions in these operating

instructions

• Pages to be referred to are indicated as “>±±”.

• Images are for illustration purpose, contents may change

without notice.

DMRUBT1EC-TQBS0291_eng.book 4 ページ２０１８年８月２日　木曜日　午前１０時８分

TQBS0291 5

Unit and media care

• The HDD is a high precision recording

instrument and is easily susceptible to damage.

Therefore, be careful of the following points

while the unit is turned on, otherwise the HDD

and the recorded content may be damaged:

– Do not subject the unit to any vibration and

shock.

– Do not remove the AC mains lead from the

household mains socket.

• The HDD is a temporary storage device

– It is recommended to save the recorded

content on a disc or to keep the original data or

CDs that they were copied from.

– If you notice a problem with the HDD such as

repetitive strange sounds, immediately save

(backup) all content and request service. If you

continue using the HDD with a problem, the

unit or the recorded content will be damaged.

• If the HDD or USB HDD is damaged, the

recorded content cannot be recovered.

• Do not place on anything that generates heat

like a Set Top Box, etc.

When condensation occurs, without turning

the unit on, let the unit adjust to the room

temperature and wait 2–3 hours until

condensation is gone.

Before moving the unit, ensure the disc tray is

empty.

1 Switch the unit to standby. (Wait until “BYE”

disappears from the display.)

2 Remove the AC mains lead from the

household mains socket.

3 Move only after the unit has come to a

complete stop (approx. 3 minutes) in order to

avoid subjecting to vibration and shock. (Even

after the unit is switched to standby, the HDD

continues operating for a short time.)

• Wipe with a soft, dry cloth.

• Never use alcohol, paint thinner, benzine or

chemically treated cloth to clean this unit.

• Use the lens cleaner (not supplied) to clean the

unit’s lens.

The registration of the USB HDD may be

cancelled in the process of repairing this unit.

You can use the USB HDD again by

re-registering, but all recorded content already on

the USB HDD will be lost. In such cases, the

recorded content (data) cannot be recovered.

This unit may contain private information. Before

disposing of or transferring this unit, perform the

following to delete the data:

– Format HDD (>50)

– Shipping Condition (>55)

• Do not touch the recorded surface of the discs.

• Wipe with a damp cloth and then wipe dry.

• Do not attach labels or stickers to discs.

• Do not use disc cleaning sprays, benzine,

thinner, static electricity prevention liquids or

any other solvent.

• Do not use the following discs:

– Discs with exposed adhesive from removed

stickers or labels (rental discs, etc.).

– Discs that are badly warped or cracked.

– Irregularly shaped discs, such as heart

shapes.

Getting started

HDD/USB HDD handling care

Setup precautions

When moving the unit

Cleaning

When requesting this unit for repair

To dispose or transfer this unit

Media handling

DO DO NOT

DMRUBT1EC-TQBS0291_eng.book 5 ページ２０１８年８月２日　木曜日　午前１０時８分

TQBS0291

Connection

The unit can be played back 4K contents when this unit is connected to a compatible TV.

∫Enjoying 4K output

• To enjoy images in 4K (50p/60p), you need an HDMI cable that supports 18 Gbps.

Please use HDMI cables 5.0 meters or less.

• If you connect this unit to a 4K-compatible TV and perform “Easy Setting”, 4K will be

automatically selected. (>9)

• To view broadcasts, programmes or Ultra HD Blu-ray content in 4K/HDR format, a TV that supports

HDCP2.2, 4K (50p/60p) 4:4:4, and HDR signals is necessary.



• Keep the RF coaxial cables as far away as possible from other cables.

• Before making any connections, please disconnect all the units from AC power.

(Connect the AC mains lead after making all connections.)

• Use the HDMI cables. (18 Gbps)

• When the unit is not to be used for a long time

To save power, unplug it from the household mains socket. This unit consumes a small amount of

power, even when the unit is in standby. (>63)

Basic connections

VHF/UHF

RF IN

HDMI

This unit’s rear panel

Household mains socket

(220 V to 240 V AC, 50 Hz)

AC mains lead

(supplied)

• Connect only after all other

connections are complete.

To th e A e r i a l

Aerial cable

RF coaxial cable

(supplied)

HDMI cable

(18 Gbps)

DMRUBT1EC-TQBS0291_eng.book 6 ページ２０１８年８月２日　木曜日　午前１０時８分

TQBS0291 7

∫Enjoying video with a 4K-compatible TV and audio with a 4K-compatible amplifier

∫Enjoying 4K video by connecting a non-4K compatible amplifier

4K images can be played back when this unit is connected to a 4K compatible TV.

• This connection only supports up to 5.1ch.

• To connect a TV and amplifier with an HDMI cable, connecting terminals on both the TV and amplifier

must be ARC-compatible.



• To enjoy Dolby Atmos® or DTS:X® (>51)

• About ARC:

When using a TV or an amplifier/receiver that does not display “ARC” on the HDMI terminal, it is necessary to connect the TV

and the amplifier/receiver with a digital audio cable to enjoy the TV audio on the amplifier/receiver.

When this unit is connected to the network, you can enjoy network functions (Network Service, TV

Anywhere, etc.).

After you make the LAN cable/Wireless LAN connection, the network setting is needed. (>10, Easy

Network Setting)

• Use category 5 or above straight LAN cables (STP) when connecting to peripheral devices.

Wireless LAN connection (>10, Easy Network Setting)

• The unit is not compatible with public wireless LAN services.

Amplifier/receiver/sound bar connections

Network connection

LAN cable connection

HDMI IN

(ARC)

HDMI OUT

(ARC)

HDMI IN

HDMI cable

(18 Gbps)

HDMI cable

(18 Gbps)

Amplifier/receiver/

sound bar

(4K-compatible)

HDMI OUT

(ARC)

HDMI IN

(ARC)

HDMI IN

OPTICAL OPTICAL

Amplifier/receiver/

sound bar

HDMI cable

(18 Gbps) HDMI cable

Optical cable

Broadband router, etc. Internet

LAN (ethernet) cable

DMRUBT1EC-TQBS0291_eng.book 7 ページ２０１８年８月２日　木曜日　午前１０時８分

TQBS0291

Remote Control

Instructions for operations are generally described using the remote control.

1Transmit the remote control signal

• Point it at remote control signal sensor on

this unit. (>62)

2Switch the unit from on to standby or vice

versa

3Select channels and programme numbers,

etc./Enter numbers or characters

4Switch to the previously watched channel

(>13)

5Manual skip when playing back programmes

etc. (>27)

-10s: Skip approx. 10 seconds backward

+60s: Skip approx. 1 minute forward

6Basic operations for recording and play,

REWIND LIVE TV/PAUSE LIVE TV (>13)

7Show Information (>12, 24, 27)

8Selection/OK,

Frame-by-frame (>27)

9Show Video Menu (To play recorded

programme), Top Menu, Pop-up Menu (>23)

:Show OPTION menu (>30, 32, 34)

;Colour buttons (red, green, yellow, blue)

(Use in accordance with instruction on the

screen.)

<Select audio (>12, 28)

=Select drive (HDD, Disc or USB)

>TV operation buttons (>11)

INPUT AV: Select the video input. (>11)

?Start recording (>13)

@Channel select (>11)/Change pages in the

Video Menu screen etc.

ASwitching to the radio channel list (>13)

BShow the Timer Recording screen

[To check the timer programme (e.g., delete or

edit etc.)] (>16)

CShow NETFLIX screen (>42)

(NETFLIX can be accessed directly.)

DShow the Network Service screen (>42)

EExit the menu screen

FShow the TV Guide screen (>15)

GShow the FUNCTION MENU screen (>18)

HReturn to previous screen

IShow subtitles (>12, 28)

JShow Teletext (>12)

PAGE

INPUT

VOL

RETURN

OPTION

DRIVE SELECT

AUDIO

REC

TEX

10s

+60s

INTERNET

REWIND LIVE T

abc

jkl

tuv

ghi

qrs

def

mno

xyz

STATUS

EXIT

SLOW

RADIO/

x1.3

PAUSE LIVE TV

PROG/

CHECK

LAST VIEW





















































DMRUBT1EC-TQBS0291_eng.book 8 ページ２０１８年８月２日　木曜日　午前１０時８分

TQBS0291 9

Settings

Before use, perform the initial setup of the unit.

Preparation

Turn on the TV, then select the appropriate AV

input to suit the connections to this unit.

1Press [Í] on the remote control or [Í/I] on

this unit.

2Follow the on-screen instructions to continue

with the settings.

• For details about “PIN Entry” (>55)

3Auto Setup will start automatically.

• If the clock setting screen appears, set the

time manually (>55, Clock).

• When connected to a 4K compatible TV

(>right)

4Set Quick Start to “On”, “Off” or “Timer

Setting for Quick Start”, then press [OK].

When “Easy Setting has been completed.”

appears, Easy Setting is completed.

• Select “Yes” to proceed to Easy Network

Setting.

• Select “No” to finish the Easy Setting.

To restart setup (>48, Auto Setup)

To view the list of tuned channels

(>11, Using Channel List)

To stop partway

Press [RETURN ].



• If tuning is cancelled partway through, it may not be

possible to receive the channels. Restart setup again.

When connected to a 4K compatible TV,

connection setting to 4K TV below is displayed.

The screen above does not appear for a non-4K

compatible TV.

1 Press [OK] to start the setting.

A black screen appears for a few seconds and

then a message appears.

2 Select “Yes” and press [OK].

Connection to 4K TV is successful.

(Go to next step of “Easy Setting”.)

When the following screen appears:

“Yes”: Next setting is displayed.

“No”: Connection setting to 4K TV starts again.

(Retry the setup process.)



• To reconnect this unit to a 4K-compatible TV after

connecting this unit to a 2K-compatible TV and completing

“Easy Setting”, set “4K(50p/60p) Output” to “4K(50p/60p)

4:4:4” or “4K(50p/60p) 4:2:0”. (>52)

Easy Setting

When connected to a 4K compatible TV

4K(50p/60p) Output

Start connection check with your 4K TV.

Once connection check is started and if the video is not displayed

correctly, please wait for the next display. The connection check

could take up to 30 seconds to display the new message screen.

Press OK.

RETURN

4K(50p/60p) Output

Is this message displayed correctly ?

RETURN

Yes No

4K(50p/60p) Output

Connection check is finished.

Cannot connect with 4K.

Please check if the HDMI connected

device and cable are compatible with 4K.

Move on to the next setting ?

Select “Yes” for the next setting.

Select “No” to set again.

RETURN

Yes No

DMRUBT1EC-TQBS0291_eng.book 9 ページ２０１８年８月２日　木曜日　午前１０時８分

TQBS0291

After completing “Easy Setting”, you can continue

with “Easy Network Setting”.

Follow the on-screen instructions to establish

your connection settings.

Select “Wired” or “Wireless”, then press [OK].

LAN cable connection (“Wired”)

Follow the on-screen instructions to apply your

connection settings.

Wireless LAN connection (“Wireless”)

Before beginning wireless connection setup

• Obtain your network name (SSID§1).

• If your wireless connection is encrypted, please

be sure that you know your encryption key.

• The default SSID§1, Password (Key) etc., may

be printed on the router.

Then follow the on-screen instructions and apply

the settings.

Search for wireless network:

The available wireless networks will be displayed.

Select your network name and press [OK].

– If your network name is not displayed, search

again by pressing the red button on the remote

control.

– Stealth SSID§2 will not be displayed. Enter the

SSID manually by using “Wireless Settings”.

(>52)

• If your wireless network is encrypted, Encryption

Key input screen will be displayed.

Input the encryption key of your network.

PUSH button method§3:

If your wireless router supports the PUSH button

method§3, you can easily perform the settings by

pressing Link button on it.

1 Press the green button on the remote control.

2 Press Link button or corresponding button of

wireless router until the lamp starts flashing.

• For details, refer to the operating instructions

of wireless router.

3 Press [OK].

To restart Easy Network Setting

Perform “Easy Network Setting” in “Basic

Settings”. (>52)

To redo settings individually

If “Easy Network Setting” did not work properly or

when you change the settings individually,

perform “Network Settings” in “Basic Settings”.

(>52)

Check security before using Home Network

function

If you set “Home Network function” to “On”, all

connected devices on the same network can

access this unit. Ensure that the router for your

home network has adequate security system to

prevent unauthorised access.

Easy Network Setting

SSID XXXXXXXXXXXX

KEY XXXXXXXXXXXX

PIN XXXXXXXXX

e.g.,

In your use of internet functions

Your use of internet-enabled functions and

software updates must follow the rules set forth

in the “Terms and Conditions of Use”.

Please review “Terms and Conditions of Use”

and “Privacy Policy” carefully and confirm your

understanding of “Privacy Policy” and agreement

to the “Terms and Conditions of Use” by

checking the box and select “OK”.

(>54, Legal Notices)

e.g.,

Link button

DMRUBT1EC-TQBS0291_eng.book 10 ページ２０１８年８月２日　木曜日　午前１０時８分

Autres manuels pour DMR-UBT1

Table des matières

Autres manuels Panasonic Lecteur Blu-ray

Panasonic

Panasonic DMP-UB300 Instructions d'installation et d'entretien

Panasonic

Panasonic DMP-BD55; DMP-BD35 Manuel utilisateur

Panasonic

Panasonic UltraHD DP-UB450 Manuel utilisateur

Panasonic

Panasonic DMP-BD10 - Blu-Ray Disc Player Manuel utilisateur

Panasonic

Panasonic DPUB9000GN1 Manuel utilisateur

Panasonic

Panasonic Diga DMR-PWT520 Manuel utilisateur

Panasonic

Panasonic DMP-BD30 Manuel utilisateur

Panasonic

Panasonic DMP-BDT330 Manuel utilisateur

Panasonic

Panasonic DMP-BDT460 Manuel utilisateur

Panasonic

Panasonic DMR-UBC90 Manuel utilisateur

Panasonic

Panasonic DMP-BDT110EG Manuel utilisateur

Panasonic

Panasonic DMP-BDT384 Manuel utilisateur

Panasonic

Panasonic DMR-HWT250 Manuel utilisateur

Panasonic

Panasonic DIGA DMR-BW850 Manuel utilisateur

Panasonic

Panasonic DMR-BW500G Manuel utilisateur

Panasonic

Panasonic DPUB820GNK Manuel utilisateur

Panasonic

Panasonic DMP-BDT110GA Manuel utilisateur

Panasonic

Panasonic DMP-BDT225 Manuel utilisateur

Panasonic

Panasonic DMPBD10A - BD/DVD PLAYER Manuel utilisateur

Panasonic

Panasonic DMPBDT100 - 3D BLU-RAY DISC PLAYER Manuel utilisateur

Panasonic

Panasonic DMP-BDT184 Caractéristiques techniques

Panasonic

Panasonic DMP-BDT460 Manuel utilisateur

Panasonic

Panasonic DMP-BD55; DMP-BD35 Manuel utilisateur

Panasonic

Panasonic DMP-BDT110 Manuel utilisateur

Manuels Lecteur Blu-ray populaires d'autres marques

Samsung

Samsung BD-F5900 Manuel utilisateur

Philips

Philips BDP3380K Manuel utilisateur

Samsung

Samsung BD-P4600 Manuel utilisateur

Sharp

Sharp BD-HP17U - AQUOS 1080p Blu-ray DiscTM Player Manuel utilisateur

Pioneer

Pioneer BDP-140 Manuel d'installation et d'exploitation

Samsung

Samsung BD-D8200A Manuel utilisateur

LG HLX50W Manuel utilisateur

Sony

Sony BDP-S300 - Blu-Ray Disc Player Manuel utilisateur

Marantz

Marantz UD9004 Manuel utilisateur

LG BD611 Manuel utilisateur

Marantz

Marantz BD7004 Guide de démarrage rapide

Kogan

Kogan KABRP3DWFIA Manuel utilisateur

Toshiba

Toshiba BDX2700 Manuel utilisateur

Samsung

Samsung BD-E5400 Manuel utilisateur

Samsung

Samsung BD-F5100 Manuel utilisateur

Philips

Philips BDP7100 Manuel utilisateur

LG UBK80.DUSALLK Manuel utilisateur
