Panasonic DP-C213I Manuel utilisateur

Digital Color Imaging Systems

Operating Instructions

Before operating this machine, please carefully read this manual,

and keep this documentation in a safe place for future reference.

(Illustration shows optional accessories that may not be installed on your machine.) English

Model No.

DP-C354 / C264

Model No.

DP-C323 / C263 / C213

(For Copier)

Operating Instructions

The following Operating Instruction manuals are included with this machine. Please refer to the appropriate manual

and keep all manuals for future reference. If you lose the manual, contact the authorized Panasonic dealer.

Accessories

Operating Instructions (For Setting Up)

This manual contains essential information for setting

up the machine.

Operating Instructions (For Basic Operations)

This manual contains essential information for proper

operation of the machine.

It describes basic Copy, Print, Facsimile/Internet Fax,

Scan/Email, and other functions.

For a more detailed explanation of each function, please

refer to the Operating Instruction manuals included on

two CD-ROM as illustrated below.

Operating Instructions CD

Contains manuals with detailed information for Copy,

Facsimile/Internet Fax, Scan/Email Functions, Function

Parameters and User Authentication.

Document Management System CD

Contains the PDMS Application Software, and manuals

with detailed information for the Print function, and

PDMS Application software.

Operating Instructions CD

Copy Function

Describes how to make a Color Copy with

creative features.

Facsimile and Internet Fax

Function

(These functions are available when the

optional G3 Fax Board/ Internet Fax

Module is installed.)

Describes how to send/receive a

Facsimile/Internet Fax, or describes the

course of action to take when a trouble

message appears, etc.

Scan and Email Function

(Standard on DP-C354/C264, for DP-

C323/C263/C213 when the optional

Network Scanner/Email Module, Hard

Disk Drive, Main Memory, and Image

Memory are installed.)

Describes how to scan, and send an Email.

Function Parameters

Describes how to change the default

settings of each function using the Control

Panel of the machine.

User Authentication

Describes how to enable and use the user

authentication function.

Document Management System CD

Print Function

Describes how to print with color, change

default printer settings, or describes the

course of action to take when a problem

message appears, etc.

Application Software

Describes how to use the application

software.

Ex:Web Device Monitor, Panafax

Desktop, Document Manager/

Viewer, Client Device Monitor,

Network Config/Add Editor, Network

Setup Tool, Embedded Web

Launcher

Conventions

Icons

The following icons are used in this manual.

Notation

The following notations are used in this manual.

Icon Description

Indicates important information that must be read in detail.

Indicates reference Information.

Notation Description

For Keys and Buttons Hard buttons on the Control Panel are depicted as **** key, soft buttons on the Touch Panel are

depicted as “xxx”.

Ex:

Press the Start key and select “More Menus”.

Table of Contents

Chapter 1 Basic Menu Features

Basic Operation Procedure ................................................................................................. 6

Selecting the Color Mode .................................................................................................... 8

Full Color Mode............................................................................................ “Full Color”9

Black Mode ......................................................................................................... “Black”9

2 Color Mode.....................................................................................................“2 Color”10

1 Color Mode.....................................................................................................“1 Color”12

New Color Registration ............................................................................“Add Custom”14

Selecting Original Type and Adjusting the Density.............................................................. 16

Registering Quality Preset.........................................................................................“Save”18

Using Quality Preset............................................................................................... “Recall”20

Quality Adjusting.................................................................................................................. 22

Background .............................................................................. “Background Removal”24

BleedThrough.................................................................... “BleedThrough Prevention”25

Color Tone ..............................................................................................................“Tint”26

Contrast.......................................................................................................... “Contrast”27

Image Sharpness ........................................................................................“Sharpness”28

Saturation.................................................................................................... “Saturation”29

Color Balance........................................................................................“Color Balance”30

Proof Copying.................................................................................................... “Proof Set”32

Confirming/Editing the Selected Copy Features................................... “Confirm Settings”33

Storing a Job in Memory................................................................................“Preset Jobs”34

Recalling a Preset Job Stored in Memory ........................................................................... 35

Checking the Waiting to Copy Job ............................................................ “Output Queue”36

Displaying a List of All Jobs ............................................................................................ 36

Displaying a List of Copy Jobs ........................................................................................ 36

Deleting Copy Jobs ......................................................................................................... 37

Completion Notice ............................................................................. “Completion Notice”38

Chapter 2 More Menus Features

2-Sided Copy Mode................................................................. “2-Sided / Original->Copy”40

Basic Operation for the 2-Sided Copy Mode................................................................... 40

Copying 2-Sided original(s) Onto two separate sheets........................................“2 -> 1”41

Copying Facing Page Original to Two Separate Sheets................................... “2 Page”42

From 1-Sided Originals to 2-Sided Copies using Saddle Stitch (Booklet) .......“Booklet”43

Copying Mixed Size Originals from the ADF.......................................“Multi-Size Feed”45

Copying Special Originals (Thin Paper, etc.) from the ADF........“Job Build and SADF”47

Sort Mode..................................................................................................... “Sort / Finish”50

Zoom Mode............................................................................................... “Zoom / Effects”52

Variable Ratios .................................................................................................... “Zoom”52

Auto Zoom..................................................................................................“Auto Zoom”54

Effect Modes........................................................................................................................ 56

Setting a Blank Edge............................................................................................ “Edge”56

Eliminate Dark Inner Binding Shadows ................................................................“Book”58

Shift Image to Right, Left, Up or Down.............................................................. “Margin”59

Copying with Stamping..................................................................................“Stamping”61

Centering...................................................................................................... “Centering”70

Image Repeat........................................................................................ “Image Repeat”71

Insertion Modes ................................................................................. “Insertion / Overlay”72

Add a Cover Page to Copies...............................................................................“Cover”72

Inserts Blank/Copied Pages Between Copies ...................................... “Page Insertion”74

Inserts Blank Pages Between Transparency Film............ “Transparency Interleaving”76

Overlay Modes..................................................................................................................... 78

Overlaying an Image Onto the Copies .............................................................“Overlay”78

Overlay Copying with Registered Image ................................................“Form Overlay”81

File Edit............................................................................................................“File Edit”83

Chapter 3 Other Features

Making Copies with the ADF Opened.................................................................................. 88

Skyshot Mode.................................................................................................................. 88

Manual Skyshot Mode..................................................................................................... 89

Reserving the Next Copy Job While the Current Copy Job is Progressing ......................... 90

Interrupt the Current Copy Jobs to Make an Urgent Copy .................................................. 91

Chapter 4 Appendix

Combined Copy Functions .................................................................................................. 92

Index .................................................................................................................................... 94

Chapter 1 Basic Menu Features

Chapter 1

Basic Menu Features

Basic Operation Procedure

The machine automatically detects the original(s), and decides on which Copy Size, Black & White or

Color Copy Mode to use. If the detection fails, manually set the settings.

Place original(s).

zRefer to Placing Originals (Copy) in the

Operating Instructions (For Basic

Operations) of provided booklet.

Press the Copy key if the machine is

set to other function mode.

Select the required settings if

necessary.

zThe Original Size is detected, and a

corresponding Copy Size is automatically

selected.

zIf the orientation of the original and of the

copy paper are not the same, the original is

copied, and the image is automatically

rotated.

zWhen copying 8.5" x 11" size originals,

selecting 8.5" x 11" for the Copy Size

accelerates the continuous copying speed.

If the orientation is not the same between

the two settings, the copied image is

automatically rotated by 90 degrees.

zFor more details of Basic Menu screen, refer

to Chapter 1, Basic Menu Features (see

pages 8 to 39).

zWhen setting other features, refer to

Chapter 2, More Menus Features (see

page 40 to 87).

Ex: 2-Sided Copy, Sort/Finish, Zoom/

Effects, etc.

Face Up. Up to 85 sheets (20 lb).

Face Down. Align with top left

corner. Close ADF.

Chapter 1 Basic Menu Features

Enter the desired number of copies.

(Up to 999)

zWhen inputting a number 4 to 8 digits in

length, with the optional Fax Communication

Board installed; the machine interprets this

as a telephone number, and switches to Fax

Mode and displays the Number Pad screen.

Press the Start key.

zAfter finishing copying, press the Reset key

to return to the initial screen of the current

active mode.

Chapter 1 Basic Menu Features

Selecting the Color Mode

You can either copy in the machine selected color mode, or you can manually change it.

zThe default color mode settings can be changed. Refer to Copier Settings (For Key Operator) in the

Operating Instructions (For Function Parameters) on the provided CD-ROM.

zManually selected color mode settings will return to the default settings under the following conditions.

-IftheReset key is pressed.

- If Auto Reset Time interval has lapsed (default = 1 min).

- If the power is turned OFF.

Place original(s).

zRefer to Placing Originals (Copy) in the

Operating Instructions (For Basic

Operations) of provided booklet.

Press the Copy key if the machine is

set to other function mode.

Select “Quality Adj.”.

Select the desired Color Mode, and

then select “OK”.

Enter the desired number of copies.

Press the Start key.

zAfter finishing copying, press the Reset key

to return to the initial screen of the current

active mode.

Full color Monochrome

Full Color

Monochrome

2 Color

1 Color

Monochrome

1 Color

Ex: Full Color

•Auto:

The color original is copied in Full

Color, and the monochrome

original is copied in Black & White

by automatically detecting the

original’s color.

•Black (Monochrome) (see page 9)

•Full Color (see page 9)

•2 Color (see page 10)

•1 Color (see page 12)

Chapter 1 Basic Menu Features

Full Color Mode

Color original can be copied in Full Color.

Select “Full Color”, and then select

“OK”.

zTo display this screen, refer to steps 1 to 3 of

Selecting the Color Mode (see page 8).

zFor the following procedure, refer to steps 5

to 6 of Selecting the Color Mode (see page

8).

Black Mode

Color and Monochrome originals can be copied

in Black & White.

Select “Black”, and then select “OK”.

zTo display this screen, refer to steps 1 to 3 of

Selecting the Color Mode (see page 8).

zFor the following procedure, refer to steps 5

to 6 of Selecting the Color Mode (see page

8).

Full Color Full Color Full Color

Black & White

Chapter 1 Basic Menu Features

2 Color Mode

Color original can be copied in 2 Colors, which can be achieved by using Black & another specified

color.

The specified color can be selected from the basic colors (Red, Green, Blue, Yellow, Magenta, Cyan),

and registered colors.

When 2 Color Mode is selected, Original Type setting selection is not available.

Select “2 Color”.

zTo display this screen, refer to steps 1 to 3 of

Selecting the Color Mode (see page 8).

Select “Change Color”.

zThe color and the specified name are

displayed.

Select a color from the basic colors or

custom colors, and then select “OK”.



When selecting a color from the basic colors.



When selecting a color from the custom colors.

When registering a custom color, refer to

New

Color Registration (see page 14)

Ex: When copying a Full Color original in

Cyan and Black.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Panasonic Imprimante tout-en-un

Panasonic

Panasonic FP-D605 Manuel utilisateur

Panasonic

Panasonic DP-1510P Manuel utilisateur

Panasonic

Panasonic DP-C406 Manuel utilisateur

Panasonic

Panasonic DP-MB350 Manuel utilisateur

Panasonic

Panasonic DP-1810F Manuel utilisateur

Panasonic

Panasonic KX-PS8000 Manuel utilisateur

Panasonic

Panasonic Workio DP-2310 Manuel utilisateur

Panasonic

Panasonic WORKIO DP-C323 Manuel utilisateur

Panasonic

Panasonic DP-MB251CX Manuel utilisateur

Panasonic

Panasonic DP-C266 Manuel utilisateur

Panasonic

Panasonic Workio DP-8016P Manuel utilisateur

Panasonic

Panasonic DP-8020E Manuel utilisateur

Panasonic

Panasonic DP-4530 Manuel utilisateur

Panasonic

Panasonic KXFLB881 - Network Multifunction Laser... Mode d’emploi

Panasonic

Panasonic WORKIO DP-C354 Manuel utilisateur

Panasonic

Panasonic Workio DP-C405 Manuel utilisateur

Panasonic

Panasonic Panafax UF-7000 Instructions d'installation et d'entretien

Panasonic

Panasonic DP-MB310EU Manuel utilisateur

Panasonic

Panasonic Workio DP-C262 Manuel d'instructions et de sécurité

Panasonic

Panasonic WORKIO DP-C354 Manuel utilisateur

Panasonic

Panasonic WORKIO DP-8060 Manuel utilisateur

Panasonic

Panasonic Workio DP-C322 Manuel utilisateur

Panasonic

Panasonic Workio DP-C262 Manuel utilisateur

Panasonic

Panasonic DP-MB340 Manuel utilisateur

Manuels Imprimante tout-en-un populaires d'autres marques

Triumph Adler

Triumph Adler DC 2016 Manuel

Epson

Epson WorkForce WF-2510 Guide de l'utilisateur

Epson

Epson Stylus Scan 2000 Manuel d'installation et d'exploitation

Epson

Epson PictureMate Snap PM 240 Mode d’emploi

Konica Minolta

Konica Minolta bizhub C35 Manuel utilisateur

Brother

Brother MFC-J430w Manuel utilisateur

Konica Minolta

Konica Minolta BIZHUB 558 Manuel utilisateur

Lexmark

Lexmark MX710 Series Manuel

Brother

Brother MFC-9760 Manuel utilisateur

Lexmark

Lexmark XC8155 Manuel utilisateur

Lexmark

Lexmark X642E Manuel utilisateur

Sharp

Sharp MX-2310U Mode d’emploi

Aficio

Aficio 200 Manuel utilisateur

Canon

Canon ImageCLASS 2300 Manuel

Ricoh

Ricoh Pro C900 Manuel utilisateur

Lexmark

Lexmark X925 Manuel utilisateur

Brother

Brother Business Smart MFC-J4510dw Manuel utilisateur

Epson

Epson Stylus CX8400 Series Manuel utilisateur
