Panacom BL-1354HS Manuel utilisateur
BL-1354HS User Manual
BL-1354HS Manual del Usuario
Pg. 3
BL-1354HSHS - USER MANUAL
Thanks for purchasing PANACOM BL-1354HSHS. Please read this manual
carefully before using the headset, which is the best guideline offering best
service.
GETTING STARTED
• Remove the Bluetooth headphones & accessories from the box.
• Remove all packaging from the Bluetooth headphones.
• Place the packaging inside the box to either store or dispose of safely.
In the Box
• Bluetooth Headphones
• USB Charging Cord
• 3.5mm AUX Cord
• Instruction Manual
Features
• Enjoy music wirelessly
• Easy to switch between calls and music, you will not miss the incoming
call whilst listening to music
• Answer & end a call at click of a button.
• Redial last number
• Volume Control
• Media Control (pause/play, previous track/next track)
• Every time the Bluetooth headphones is turned on, it connects to last
connected device automatically
Pg. 4
Safety Instructions
Read this manual carefully before putting the appliance into operation and
keep this manual for future reference.
• Do not use the unit with wet hands.
• To minimize the risk of re or electrical shock, avoid operating in wet
conditions such as rain or humidity. Do not operate around water (e.g.
bathroom, swimming pool, etc.)
• Do not insert any metal object into the device.
• To avoid a static charge, do not use the device in an extremely dry
climate.
• Do not attempt to repair the device yourself.
Functions
1 Previous track
2 Play/Pause
3 Next track
4 LED indicator
5 Power on/off switch
6 Micro USB charging port
7 3.5mm AUX input jack
8 Volume up
9 Volume down
Charging Instructions
This Bluetooth headphones comes with a built in rechargeable battery.
Before using it for the rst time we recommend you charge the battery fully.
Only use the supplied USB cable to charge the Bluetooth headphones.
Pg. 5
1. Connect the USB cable to the USB port on the unit.
2. Connect the other end of the USB cable to a USB port on a PC or an
AC/DC adapter. The LED indicator turns red to indicate that the battery is
being charged. When the battery is fully charged, the red LED indicator will
turn off.
Pairing the Bluetooth headphones with Bluetooth devices
1. Turn off the headphones. Make sure the headphones is power off before
going to the next step.
2. Turn on the headphones.
3. Turn on your Bluetooth enabled device and activate the Bluetooth function.
4. Search for the Bluetooth device, “BL-1354HS” will show up.
5. Pair your Bluetooth enabled device with BL-1354HS. If a password is
needed, type in “0000”. After the BL-1354HS is paired with your device,
connect it to your device.
Tips:
Once the headphones is paired and connected to your Bluetooth device, it
automatically connect the next time as long as the Bluetooth on your device
is turned on.
Control a phone call via headphones
Answer a call: Short press the Phone button.
End a call: Short press the Phone button.
Reject a call: Press and hold the Phone button for
around 2 seconds.
Redial the last number: Press the phone button twice quickly.
Pg. 6
Using AUX input
The AUX input function allows you to use your headphones without using
the battery and the Bluetooth connection.
Note: Please switch off the headphones when using AUX input.
Care and Maintenance
Read the following recommendations before using the Bluetooth
headphones. Following these you will be able to enjoy the product for many
years.
• Do not expose the Bluetooth headphones to liquid, moisture or humidity to
avoid the product’s internal circuit being affected.
• Don’t use abrasive cleaning solvents to clean the Bluetooth headphones.
• Do not expose the Bluetooth headphones to extremely high or low
temperature as this will shorten the life of electronic devices, destroy the
battery or distort certain plastic parts.
• Don’t dispose of the Bluetooth headphones in a re as it will result in an
explosion.
• Don’t expose the Bluetooth headphones to contact with sharp objects as
this will cause scratches and damage.
• Don’t let the Bluetooth headphones fall on the oor. The internal circuit
might get damaged.
• Don’t attempt to disassemble the Bluetooth headphones as it may get
damaged if you are not professional.
In case the Bluetooth headphones doesn’t function properly, send it to the
store you bought it. The staff will help you to the problem.
Pg. 7
Specifications
Bluetooth version: 3.0 + EDR
Bluetooth proles: HSP, HFP, A2DP and AVRCP
Bluetooth operating distance: 10 meters (equal to 33 feet)
Frequency range: 2.4-2.48GHz
Frequency response: 100Hz-20kHz
Distortion: ≤1%
Microphone sensitivity: -40db
Working time: Music time 6 hours, talk time 10 hours
Charging input power: DC 5V
Charging time: Approx 3 hours
Unit size: 150*175*53mm
Unit weight Approx: 164g
Note: Battery life & charging time may vary, based on usage & types of
devices used.
Pg. 8
Pg. 9
BL-1354HSHS - MANUAL DEL USUARIO
Gracias por comprar un PANACOM BL-1354HSHS. Por favor, lea
atentamente este manual antes de utilizar el auricular, que es la mejor guía
para que su producto ofreczca el mejor servicio.
PRIMEROS PASOS
• Retire los auriculares y accesorios Bluetooth de la caja.
• Retire todo el embalaje de los auriculares Bluetooth.
• Coloque el empaque dentro de la caja ya sea tienda o retirarla de forma
controlada.
En la caja
• Auriculares Bluetooth
• Cable USB para carga
• Cable AUX de 3.5 mm
• Manual de instrucciones
Características
• Disfruta de la música de forma inalámbrica
• Fácil de cambiar entre llamadas y música, para que no se pierda la llamada
entrante mientras escucha música
• Responder y nalizar una llamada al pulsar un botón
• Volver a marcar el último número
• Control de volumen
• Control de Medios (reproducir / pausar, siguiente pista / anterior pista)
• Cada vez que los auriculares Bluetooth están encendidos, se conecta al
último dispositivo conectado de forma automática
Pg. 10
Instrucciones de seguridad
Lea atentamente este manual antes de poner el aparato en marcha y guarde
este manual para futuras consultas.
• No utilice la unidad con las manos mojadas.
• Para minimizar el riesgo de incendio o descarga eléctrica, evite operar en
condiciones de lluvia o humedad. No utilice cerca del agua (por ejemplo,
cuarto de baño, piscina, etc)
• No introduzca objetos de metal en el dispositivo.
• Para evitar una carga estática, no utilice el dispositivo en un clima
extremadamente seco.
• No intente reparar el aparato usted mismo.
Funciones
1 Pista anterior
2 Play / Pause
3 Pista siguiente
4 Indicador LED
5 Encendido / apagado
6 Carga micro USB
7 AUX de 3,5 mm
8 Subir volumen
9 Bajar volumen
Instrucciones de carga
Estos auriculares Bluetooth vienen con una batería recargable incorporada.
Antes de utilizarlo por primera vez, le recomendamos que cargue la batería
completamente. Utilice sólo el cable USB suministrado para cargar los
