PCR17BT

USER MANUAL

E-2

CAUTION

DO NOT EXPOSE TO DRIPPING

OR SPLASHING LIQUIDS!

NOTE: CAUTION SYMBOLS ARE PRINTED ON BOTTOM OF UNIT.

PLEASE REFER TO INSTRUCTION MANUAL.

CAUTION: INVISIBLE LA SER RADIATION WHEN OPEN A ND INTERLOCKS DEFEATED. AVOID EXPOSURE TO BEAM.

VORSICHT: UNSICHTB ARE L ASERSTRAHLUNG TRITT AUS, WENN DECKEL GEÖFFNET UND WENN SICHERHEITSVERRIEGELUNG

ÜBERBRÜCK T IST. NICHT DEM STRAHL A USSETZENI.

VARNING: OSYNLIG L ASERSTRÁLNING NÄR DENNA DEL ÄR ÖPPNA D OCH SPÄ RR ÄR URKOPPLAND. STRÁLEN ÄR FARLIG.

ADVARSEL: USYNLIG LASERSTRÁLING VED ÁBNING. NÁR SIKK ERHEDSAFB RYDERE ER UDE AF FUNKTION. UNDGÁ

UDS/ETTELSE FOR STRÁLING.

ATTNENZIONE: RADIONS LASER INVISIDILE. NON GUARDA RE DIRETTAMENTE NEL LA SORGENTE DEL L ASER.

ACHTUNG: LASERLINSE NICHT BERÜHREN UNSICHTBA RER LASERSTRA HL.

AVISO: A L ENTE NUNCA DEVE SER TOCADA.

PLEASE NOTE: YOU WILL FIND THE

RATING LABEL FOR THIS PRODUCT

LOCATED ON THE BOTTOM OF THE UNIT.

CAUTION: GROUNDING OR POLARIZATION. THE PRECAUTIONS SHOULD BE TAKEN

SO THAT THE WIDER BLADE OF THE AC PLUG MUST MATCH THE SLOT IN

RECEPTACLE "WALL SOCKET".

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS

APPLIANCE TO DRIPPING OR SPLASHING LIQUIDS.

THE AC/DC ADAPTOR IS USED AS THE DISCONNECT DEVICE AND IT SHALL REMAIN

READILY OPERABLE. TO COMPLETELY DISCONNECT THE POWER INPUT, THE

AC/DC ADAPTOR OF THE APPARATUS MUST BE DISCONNECTED FROM THE MAINS

COMPLETELY. THE AC/DC ADAPTOR SHOULD NOT BE OBSTRUCTED OR SHOULD BE

EASILY ACCESSED DURING INTENDED USE.

The lightning flash and arrowhead within the triangle is a warning sign

alerting you of "dangerous voltage" inside the product.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING:

To reduce the risk of electric shock, do not remove cover (or back). No

user-serviceable parts inside. Refer servicing to qualified service personnel.

CAUTION:

The exclamation point within the triangle is a warning sign alerting you of

important instructions accompanying the product.

THE APPARATUS SHOULD NOT BE EXP OSED TO DRIPPIN G OR SPLAS HING AND NO OBJE CTS

FILLE D WITH LIQUIDS SHOULD BE PLA CED ON THE APPARATUS.

UNDER THE INFLUENCE OF ELE CTROSTATIC PHENOMENON,

THE PRODUCT MAY MALF UNCTION AND USER TO POWER RESET.

THE MARK ING AND RATING LABE L IS LOCATED AT BOTT OM ENCL OSURE OF THE APPARATUS.

- KEEP MINIMUM DISTANCES (5cm) AROUND THE APPARATUS OF SUFFICIENT

VENTILATION.

- NO NAKED FLAME SOURCES, SUCH AS LIGHTED CANDLES, SHOULD BE PLACED

ON THE APPARATUS.

- THE USE OF APPARATUS IN MODERATE CLIMATES.

Elegant Alarm Clock Radio

E-4

E-3

AC OPERATION (EXTERNAL AC-DC POWER ADAPTOR)

- THIS SET IS EQUIPPED WITH A "DC-JACK" CAPABLE OF ACCEPTING

AC-ADAPTORS WITH A RATING OF DC = 5V, 2A, AND WITH A PLUG

WITH THE FOLLOWING POLARITIES AS SHOWN (CENTER POSITIVE) :

- PLEASE USE ONLY THE SUPPLIED AC-ADAPTOR TO OPERATE THE

UNIT. USE OF OTHER ADAPTORS MAY DAMAGE THE UNIT OR CAUSE

IT TO MALFUNCTION.

- PLUG THE TAIL END OF THE AC-ADAPTOR INTO THE DC-JACK (SOCKET)

ON THE REAR OF THE UNIT.

- INSERT THE PLUG OF THE AC-ADAPTOR INTO A WALL OUTLET WITH AC-POWER.

- PRESS THE "ON/ OFF" KEY TO SWITCH ON THE UNIT.

- THIS UNIT IS DESIGNED TO OPERATE WITHOUT EVER BEING TOTALLY POWERED

"OFF". IT WILL EITHER BE "ON" OR IN "STANDBY MODE".

- IN STANDBY MODE, THE BACK-LIGHT OF THE DIGITAL DISPLAY WILL BE DIMMED

BUT THE DISPLAY WILL SHOW THE CURRENT TIME (CLOCK FUNCTION).

- ANYTIME DURING STANDBY MODE, YOU CAN SWITCH "ON" THE UNIT BY PRESSING

THE "ON/ OFF" KEY.

- SAVE ENERGY BY SWITCHING THE SYSTEM TO "STANDBY" MODE WHEN NOT IN USE.

POWER SUPPLY

DIMMER FUNCTION

THIS SET HAS A DIMMER FUNCTION TO ADJUST THE BRIGHTNESS LEVEL

OF THE DISPLAY BACKLIGHT. SIMPLY ADJUST IT AS DESIRED BY PRESSING

THE SNOOZE/ DIMMER KEY REPEATEDLY (HI-BRIGHTNESS / LOW-BRIGHTNESS / OFF)

THE DISPLAY BACKLIGHT WILL ALWAYS RETURN TO HI-BRIGHTNESS AS THE DEFAULT,

AFTER THE UNIT BEEN RESET.

DIGITAL CLOCK FUNCTION

- THE SET HAS A BUILT-IN DIGITAL CLOCK.

(THE DISPLAY WILL CONTINUOUSLY SHOW THE CURRENT TIME).

HOW TO SET CORRECT TIME:

SWITCH UNIT TO "STAND-BY" MODE

PRESS & HOLD CLK SET KEY FOR 3 SECOND S DISPLAY SHOWS

HOUR OR HOUR (FLASHING)

12H 24H

PRESS BACK OR NEXT KEY TO SELECT 12-HOUR OR

24-HOUR CLOCK DISPLAY SYSTEM & PRESS CLK SET KEY TO CONFI RM YOUR

SELECTION.

PRESS REPEATEDLY TO SET

THE CORREC T HOUR IN THE DISPLAY & PRESS TO CONFI RM.

BACK OR NEXT KEY

CLK SET KEY

CORREC T TIME IS NOW SET & WILL BE SHOWN IN THE DISPLAY.

PRESS REPEATEDLY TO SET

THE CORREC T MINUTE IN THE DISPLAY & PRESS TO CONFIRM.

BACK OR NEXT KEY

CLK SET KEY

1. Device rear support stand

2. Slot for placing your Device

(Smartphone / Tablet)

3. LED Display

4. Back key

5. Next key

6. Memory key

7. On/ Off key

8. Vol - / AL. Mode key

9. Vol+ / CLK Set key

10. Function key

11. Play/ Pair key

12. Snooze/ Dimmer key

13. USB output charger port

14. Aux-Input socket

15. DC Input socket (DC 5V )

16. Headphones socket

17. FM antenna wire

LOCATION OF CONTROLS

FRONT VIEW:

BACK VIEW:

TOP VIEW:

456 7

8 9 10 11

- - -

OPERATION

ALARM FUNCTION

- THIS SET IS EQUIPPED WITH 2 ALARM MODES: BUZZER RADIO.

BEFORE SETTING THE ALARM, MAKE SURE TO SET THE CLOCK (SEE "DIGITAL

CLOCK FUNCTION" IN THE PREVIOUS SECTION) .

AND

PREPARE FOR THE ALARM SETTINGS

2. PRESS AND HOLD AL. MODE KEY UNTIL

THE DISPLAY WILL NOW SHOW:

3. PRESS BACK KEY OR NEXT KEY TO REACH THE HOUR

OF THE DESIRED WAKE UP TIME THEN PRESS AL. MODE KEY TO CONFIRM.

THE DISPLAY WILL NOW SHOW:

. PRESS THE ON/OFF KEY TO PUT THE SET INTO "STANDBY" MODE

00 00

H OU R (F L A SH IN G)

M IN U TE S

(F L A SH IN G )

8 00

A. " AL ARM" SETTING

E-6E-5

SNOOZE FUNCTION

- WHENEVER THE ALARM COMES O N, IT CAN B E TEMPORARILY SUSPENDED

FOR A SHORT PERIOD OF 9 MINUTES, BY PRESSING THE “ SNOOZE/ DIMMER”

KEY ONCE.

- THE ALARM WILL THEN AUTOMATICALLY COME ON AGAIN AFTER THE 9 MINUTES

“SNOOZE” PERIOD HAS ENDED.

- THE P ROCEDURE CAN BE REPEATED F OR APPROXIMATELY 90 MINUTES FROM

ORIGINAL ALARM WAKE-UP TIM E.

2. THE SET WILL NOW AUTOMATICALLY SWITCH "ON" AT THE WAKE-UP TIME AS YOU

HAVE CHOSEN, AS LONG AS THE ALARM FUNCTION IS "ACTIVE".

3. TO TURN OFF THE UNIT AFTER IT HAS AUTOMATICALLY SWITCHED ON,

SIMPLY PRESS THE ON/OFF KEY ONCE. THIS WILL SWITCH OFF THE SET

BUT WILL NOT CLEAR THE ALARM SETTINGS, AND THE SET WILL SWITCH ON

AGAIN AUTOMATICALLY ON THE NEXT DAY AT EXACTLY THE SAME PRESET TIME.

4. TO DEACTIVATE THE ALARM, PRESS & RELEASE THE AL-MODE KEY. THE

ALARM SYMBOL "AL" DISAPPEARS FROM THE DISPLAY.

5. TO ACTIVATE THE ALARM AGAIN, REPEAT THE PROCEDURE OF "ALARM TIME

SETTING" AS DESCRIBED.

ONCE THE DESIRED SOURCE IS READY, PRESS THE ON/ OFF KEY TO PUT THE

SET INTO STANDBY MODE AND THEN SHORT PRESS THE AL. MODE KEY

REPEATEDLY TO SELECT THE SOURCE AS DESIRED.

B. "ALARM" MODE SETTING

NOW SELECT THE SOURCE THAT YOU WISH THE UNIT TO PLAY AT THE "WAKE UP"

TIME AS BELOW:

FOR RADIO :

PRESS THE ON/ OFF KEY TO SWITCH ON THE SET (DISPLAY BACKLIGHT WILL

BE "ON").

TUNE IN THE DESIRED STATION.

*REMARK: = BUZZER ALARM / = RADIO

1. THE ALARM TIME IS NOW FULLY PROGRAMMED AND THE ALARM SYMBOL WILL

APPEAR TO INDICATE THAT THE ALARM FUNCTION IS "ACTIVE".

(DISPLAY SHOWS AS FOLLOWS) C U R R EN T T IM E

12:00 A L A RM SY MB O L

A L

F M S Y M B O L

MINS 80

MINS 70

MINS 60

MINS 50

MINS OFF*

MINS 30

MINS 20

MINS 10

MINS

- THIS SET HAS A SPECIAL SLEEP TIMER FUNCTION WHICH CAN AUTOMATICALLY

SWITCH OFF THE UNIT. THIS IS USEFUL FOR SLEEPING TO MUSIC AT NIGHT.

- AT ANY TIME WHILE THE UNIT IS OPERATING, PRESS & HOLD

THE SNOOZE/ DIMMER KEY

UNTIL THE "SL" SYMBOL FLASHES, THEN PRESS THE SNOOZE/ DIMMER KEY

REPEATEDLY TO CHOOSE THE AUTOMATIC POWER OFF TIME.

(*OFF MEANS SLEEP TIMER IS DEACTIVATED)

AUTOMATIC POWER OFF SLEEP FUNCTION

BLUETOOTH® WIRELESS PLAYBACK

THE UNIT CAN WIRELESSLY STREAM AUDIO FROM ANY BLUETOOTH® DEVICE

WITHIN 30 FEET.

SIMPLY PAIR THE DEVICE AND ENJOY WIRELESS PLAYBACK AND CONTROL FROM

YOUR BLUETOOTH® DEVICE.

PREPARE THE UNIT:

- PRESS THE ON/STANDBY KEY TO TURN THE UNIT ON.

- PRESS THE FUNC. KEY UNTIL BT SYMBOL APPEASRS.

- THE LED INDICATOR WILL FLASH TO INDICATE THE UNIT IS ON AND WAITING

FOR PARING.

- THE LED INDICATOR WILL KEEP REMAIN LIT WHEN PAIRED.

*NOTE ONLY ONE DEVICE CAN BE PAIRED AT ANY GIVEN TIME.

PREPARE YOUR PHONE OR OTHER BLUETOOTH DEVICE:

- TURN ON THE BLUETOOTH® FUNCTION, THIS IS USUALLY FOUND UNDER GENERAL

SETTINGS OR OPTIONS.

*PLEASE REFER TO YOUR DEVICE’S MANUAL FOR FURTHER BLUETOOTH® DETAILS.

MAKE THE CONNECTION:

- GO TO YOUR DEVICE’S BLUETOOTH® SETTINGS

- ADD OR SEARCH FOR DEVICES

- IF ASKED FOR A PASS CODE, ENTER “0000”

*THIS IS A ONE-TIME EVENT PER DEVICE. TO PAIR YOUR UNIT TO ANOTHER DEVICE,

REPEAT THE ABOVE PREPARATION AND CONNECTION STEPS.

4. PRESS BACK KEY OR NEXT KEY TO REACH THE

MINUTES OF THE DESIRED WAKE UP TIME, THEN PRESS THE AL. MODE KEY

TO CONFIRM.

5. ADJUST THE VOLUME LEVEL AS DESIRED (FROM LEVEL 03-30)

BY PRESSING VOL. UP + OR VOL. DN - KEY. PRESS THE AL. MODE KEY

TO CONFIRM.

OPERATIONOPERATION

- AT ANYTIME DURING PLAYBACK, PRESS THE KEY TO PAUSE

OPERATION. PRESS AGAIN TO RESUME OPERATION AT THE SAME TRACK &

POSITION.

- AT ANYTIME DURING PLAYBACK, “PRESS AND RELEASE” THE NEXT OR BACK KEY :

OR TO SKIP BACKWARDS OR FORWARDS BY ONE TRACK,

AS DESIRED.

- PRESS THE PLAY/PAIR KEY TO START PLAYBACK.

PLAY/PAIR

MUSIC PLAYBACK IN BLUETOOTH® MODE

DISABLING THE CONNECTION:

TO UNPAIR A BLUETOOTH® DEVICE THAT IS ALREADY PAIRED, PRESS AND HOLD

THE PAIR KEY FOR A FEW SECONDS.

VOLUME CONTROL:

INCREASE AND DECREASE VOLUME USING THE VOLUME UP AND VOLUME DOWN

KEYS ON THE UNIT OR USING THE VOLUME CONTROLS ON YOUR BLUETOOTH®

ENABLED DEVICE.

*NOTE THAT IF THERE IS NO PLAYBACK, ENSURE THAT NEITHER THE UNIT NOR

YOUR BLUETOOTH DEVICE ARE SET TO ZERO VOLUME AND THE CORRECT DEVICE

FOR PLAYBACK IS PAIRED.

E-8

MANUAL FREQUENCY ADJUSTMENT (SCAN MODE)

- PRESS (AND IMMEDIATELY RELEASE) THE BACK KEY OR NEXT KEYS TO

“SCAN” (MANUALLY ADJUST) THE RADIO FREQUENCY “UP” OR “DOWN” BY 1-STEP

AT A TIME.

- THE RADIO DIGITAL DISPLAY WILL INDICATE THE EXACT FREQUENCY AT EACH

STEP’S POSITION.

- WHEN A DESIRED FREQUENCY OR STATION IS REACHED. IT CAN BE SAVED INTO

ONE OF THE “MEMORY” POSITIONS. (SEE “RADIO MEMORY” SECTION).

E-7

- PRESS THE "ON/ OFF" KEY ONCE TO SWITCH ON THE UNIT.

- PRESS THE FUNCTION KEY REPEATEDLY UNTIL THE DISPLAY SHOWS "FM".

- EXTEND AND ADJUST THE FM-WIRE ANTENNA TO OBTAIN THE BEST RECEPTION.

- USE THE PLAY/ PAIR KEY TO SELECT THE DESIRED MODE (STEREO/ MONO).

IN SOME CASES, WHERE RECEPTION IS POOR, IT MAY BE ADVISABLE TO

SELECT “MONO” MODE, TO IMPROVE CLARITY OF THE RADIO SIGNAL.

AUTOMATIC FREQUENCY ADJUSTMENT (SEEK MODE)

- PRESS AND HOLD (FOR 2 SECONDS) THE BACK KEY OR NEXT KEYS TO

“SEEK” (AUTOMATICALLY ADJUST) THE RADIO FREQUENCY “UP” OR “DOWN” TO

THE NEXT AVAILABLE RADIO STATION.

- THE RADIO DIGITAL DISPLAY WILL INDICATE THE EXACT FREQUENCY OF THE NEXT

STATION THAT IS FOUND.

- WHEN A DESIRED STATION IS REACHED. IT CAN BE SAVED INTO ONE OF THE

“MEMORY” POSITIONS. (SEE “RADIO MEMORY” SECTION).

USING THE AUDIO LINE IN CONNECTION (AUX-INPUT)

- YOU CAN CONNECT THE AUDIO OUTPUT OF AN EXTERNAL DEVICE SUCH AS A MP3

PLAYER TO THIS UNIT, TO LISTEN TO THE SOUND OF THAT DEVICE THROUGH

THE HIGH QUALITY AMPLIFIER OF THIS MUSIC SYSTEM.

- TO CONNECT THE EXTERNAL DEVICE PLEASE USE A STANDARD STEREO HEADPHONE

(3.5MM TO 3.5MM PLUGS) CABLE TO CONNECT THE "HEADPHONE-OUT OR AUDIO

LINE-OUT" OF THE DEVICE TO THE AUX-INPUT SOCKET OF THIS UNIT.

- SELECT THE FUNCTION TO "AUX IN" BY PRESSING THE FUNCTION KEY ONCE.

- SWITCH ON THE EXTERNAL DEVICE (eg. MP3-PLAYER).

- START PLAYBACK OF THE EXTERNAL DEVICE AND ADJUST THE VOLUME CONTROL

OF THE UNIT TO THE DESIRED LEVEL.

- REMEMBER TO SWITCH OFF THE UNIT AND THE EXTERNAL DEVICE WHEN YOU ARE

FINISHED USING THE EXTERNAL DEVICE.

- SWITCH BACK TO BLUETOOTH® MODE ANYTIME BY PRESSING THE FUNCTION KEY

AGAIN.

ELECTRONIC VOLUME CONTROL

- THIS UNIT USES AN ELECTRONIC VOLUME CONTROL .

- TO INCREASE OR DECREASE THE LOUDNESS OF UNIT, PRESS

THE VOLUME UP (VOL +) OR VOLUME DOWN (VOL -) KEYS RESPECTIVELY.

- RELEASE THE KEY WHEN VOLUME LEVEL IS AT THE DESIRED LOUDNESS.

- SOMETIMES, ESPECIALLY DURING LISTENING TO THE RADIO, YOU MAY NOTICE

A "CLICK-CLICK-CLICK" (REPEATING) SOUND WHEN YOU ARE INCREASING OR

DECREASING THE VOLUME. THIS IS A NORMAL CONDITION & THE SOUND WILL

DISAPPEAR WHEN YOU RELEASE THE VOLUME KEY (WHEN YOU REACH THE

DESIRED VOLUME LEVEL).

(PUSH BUTTON TYPE)

OPERATION OF RADIO

RADIO MEMORY (STATION PRESET MEMORY STORAGE)

- AT ANY TIME, THE CURRENTLY DISPLAYED STATION OR FREQUENCY CAN BE

STORED INTO ONE OF THE MEMORY POSITIONS.

- PRESS MEMORY KEY UNTIL "P01" FLASHES IN THE DISPLAY.

- PRESS BACK AND NEXT KEYS TO SELECT DESIRED

MEMORY POSITION. (THERE ARE TOTAL 20 MEMORY POSITIONS).

- PRESS MEMORY KEY ONCE TO SAVE THE SELECTED STATION INTO THE

SELECTED MEMORY POSITION.

- TO RECALL ANY SAVED MEMORY, SIMPLY PRESS MEMORY KEY ONCE THEN

SELECT THE MEMORY POSITIONS BY PRESSING BACK AND NEXT KEYS

THE SAVED RADIO-BAND WILL BE RECALLED.

- TO CLEAR THE MEMORY OF ANY POSITION, SIMPLY SAVE A NEW STATION TO THE

SAME MEMORY POSITION.

USB CHARGING FUNCTION

SPECIFICATIONS

POWER SUPPLY : ............ DC 5V , 2A THOUGH BUILT-IN DC JACK

EXTERNAL AC-DC POWER ADAPTOR 100-240V ~ 50/60Hz

SPEAKER : ........................ SPEAKER 2" x 2

FREQUENCY : .................. FM 87.5 - 108 MHz

THIS UNIT IS EQUIPPED WITH A DC 5V USB CHARGING PORT ON THE BACK PANEL.

TO UTILIZE THIS FEATURE, SIMPLY CONNECT THE DEVICE YOU WOULD LIKE TO

CHARGE (EG. SMARTPHONE OR TABLET) TO A SUITABLE USB CABLE AND PLUG IT

INTO THE USB CHARGING PORT. (THIS FUNCTION IS ONLY ACTIVE WHEN THE UNIT

IS PLUGGED INTO AN AC ADAPTOR). THE EXTERNAL DEVICE WILL BE CHARGED

AUTOMATICALLY WHEN IT IS SUCCESSFULLY CONNECTED, EVEN DURING PLAYBACK.

- - -

OPERATIONOPERATION

Table des matières

Autres manuels Palsonic Radio-réveil

Palsonic

Palsonic PCR77USB Manuel utilisateur

Manuels Radio-réveil populaires d'autres marques

Denver

Denver CRQ-105 Manuel utilisateur

Audiovox

Audiovox CE90 Manuel utilisateur

Sony

Sony Dream Machine ICF-C763L Manuel utilisateur

Sanyo

Sanyo DMP-P6 Manuel utilisateur

RCA

RCA RPC100 Manuel utilisateur

Yamaha

Yamaha ISX-80 Manuel utilisateur

Pyle

Pyle PLMR20W Manuel utilisateur

Blaupunkt

Blaupunkt CR7BK Manuel utilisateur

Philips

Philips AJ3180 Manuel utilisateur

HoMedics

HoMedics SS-5500-2EU Manuel utilisateur

RCA

RCA RC66i Manuel utilisateur

Versaudio

Versaudio Vers Manuel utilisateur

SOUNDMASTER

SOUNDMASTER UR8100 Manuel utilisateur

Audiovox

Audiovox CE90 Manuel utilisateur

Jensen Audio

Jensen Audio JCR-222 - AM/FM Projection Alarm Clock Radio Manuel utilisateur

Roberts

Roberts ChronoDAB Manuel utilisateur

AEG

AEG MRC 4132 BT Manuel utilisateur

Tokai

Tokai TC-155 Manuel utilisateur
