Palm Tungsten W Feuille d'instructions
READ THIS FIRST
Indicator
light
Stylus
Keyboard
Expansion
card slot
Power button/
Backlight on & off
Home
(Press to go to
Applications Launcher)
Wireless application/
Wireless power on & off
E-mail
Navigator
Address Book
Date Book
Function
IR port
Voice jack
PRODUCT CALL OUT
Congratulations on your purchase of a Palm™Tungsten™W
wireless integrated handheld and phone.
Here’s what you’ll do:
•Charge and set up your Tungsten™ W
wireless integrated handheld and
phone.
•Connect to the SingTel Mobile
network.
•Install SingTel Mobile applications
and Palm™Desktop software.
Important! Already use a Palm™
handheld?
•Synchronise your old handheld with your
computer so that the information is up-to-
date.
•Gotohttp://www.palm.com/support/tungstenw
andclicktheupgradelinktolearnhowto
smoothlytransferyourinformationtoyour
newhandheld.
Contents
USB HotSync®cradle
SIM card
SingTel IDEAS Configuration Card
Hands-free
headset
Palm™Desktop
software CD-ROM
Software Essentials
CD-ROM
Power
adapter
START HERE
a. Plug the adapter into an outlet and the cradle.
Note!
Your adapter must connect to the cradle cable, not to the cradle itself.
b. Place your Tungsten™ W handheld into the cradle.
c. Check that the charging indicator light is solid green. This means your
handheld is properly seated in the cradle and is being charged.*
d. Charge for a full two hours.
Connect and charge
1
When properly
seated, there is a
small gap between
the front of the
handheld and
the cradle
* Problems? See Troubleshooting on the other side
of this document.
START HERE
Set up your handheld
2
START HERE
Centre
a. Remove the handheld from the cradle.
e. Tap firmly the centre of at least
3 targets.
Note!
Your handheld turns off automatically
after one minute of inactivity. Press the
power button to turn it on again.
b. Press the power button.*
c. Remove the stylus.
d. Follow Setup instructions on
the screen.
* Problems? See Troubleshooting on the other side
of this document.
1. Tilt it forward. 2. Lift up.
Stylus
Power
button
Use stylus to tap
centre of target
Insert the SIM card
3
CONNECT TO THE SINGTEL MOBILE NETWORK
a. Turn off your handheld.
b. Open the access door and remove
the sample SIM card.
Your subscriber identity module (SIM) card contains your basic subscriber
information. SingTel Mobile also uses the SIM card to register and connect your
handheld to the SingTel Mobile GSM/GPRS network. The wireless applications
of your handheld cannot operate on the network without the SIM card.
Gold
contact
area
Gold
contact
area
c. Detach the SIM card from its plastic
holder (see Contents).
d. Slide the SIM card onto the access
door. Close the door.
c. To confirm the connection:*
(1) Check that the indicator light is
blinking green.
(2) Press Home . Tap the Mobile
icon . If your service is activated,
SingTel appears in the Mobile
application onscreen keypad.
Wireless button
a. Press and hold the Wireless button
until the Mobile dialog box appears.
b. Tap On in the Mobile dialog box.*
d. If you have a new service
subscription, a Welcome Activation
message appears on your handheld
screen within 24 hours.
4Turn on the Mobile application and
connect to the network
CONNECT TO THE SINGTEL MOBILE NETWORK
* Problems? See Troubleshooting on the other side
of this document
5Make a phone call
CONNECT TO THE SINGTEL MOBILE NETWORK
Button: Short press to
answer call, long press
to hang up
a. With the handheld on, insert the headset into the voice jack. This opens the
onscreen keypad used for dialling.
b. Place the earpiece in your ear.
c. Tap the number you want to dial.
d. Tap Dial. Earpiece
Voice jack
Blinking green
indicator light
6Install wireless applications from the
SingTel IDEAS Configuration Card
c. Follow the onscreen instructions to install the software.
d. When the Date & Time screen appears, tap the city displayed in Location.
Select Singapore from the list. Set the time and date.
e. Tap Date & Time in the upper-right corner of the screen. Select Network from
the list.
f. Tap Service. Select IDEAS WAP (GPRS) from the list. Enter your mobile
number as username and IDEAS password.
g. Tap Service again. Select IDEAS Internet (GPRS). Once again, enter your
mobile number as username and IDEAS password.
h. Remove the Configuration Card and replace the placeholder card. Go on to
step 7.
Icon
Notched
corner
a. Remove the placeholder card: Push lightly against the card to release it.
b. Insert the SingTel IDEAS Configuration Card as shown by the icon: Push the
card in. You feel the card lock and hear the system sound.
INSTALL SOFTWARE
Install Palm™Desktop software on
your computer
7
INSTALL SOFTWARE
* Windows NT & 95, and systems without USB
ports, require the Palm™ HotSync®Cradle-
Serial, SKU 10828U, sold separately.
†Problems? If installation or the HotSync®process
did not work, see Troubleshooting on the other
side of this document.
Use Palm™ Desktop software to enter appointments, addresses, and other
information. Then transfer the information to your handheld using the HotSync®
process. It’s the fastest way to enter lots of information.
Note!
You must install the version of
Palm™ Desktop software included
in this package.
a. Connect the USB HotSync®
cradle to the computer.*
b. Put the CD-ROM in the
CD-ROM drive.
Windows:
c. Follow the installation instructions
that appear on your computer
screen.†
Mac:
c.Double-clickthePalm™Desktop
Installericon.†
InstalladdsimportantfilestotheAdd- on
folderonyourcomputer.After Install,
openPalm™Desktopsoftware. Fromthe
HotSync®menu,selectInstall Handheld
Files.Transferthesefilesto your
handheld.
ImportantforMacupgraders!
DuringInstall,createanew username
foryournewhandheld. Donotuseyour
currentusername.
USB
