OX PRO Series Manuel utilisateur
LASER LEVEL - USER MANUAL
SHIELDED CROSS LINE LASER
INDOOR/OUTDOOR & TILT MODE
WATER & DUST PROOF
RANGE UP TO 60M
OX-P502901
oxtools.com
oxtools.com
02
Thank you for purchasing OX’s Pro Series Laser Level. You
now own one of the most advanced laser tools available.
This manual will show you how to get the most out of your
laser tool.
APPLICATIONS
The OX Pro Series Laser Level is innovatively designed for a
very broad range of professional and DIY jobs, including:
■Aligning tiles, cabinets, borders, moldings and trimmings
■Doors and windows installation
■All types of DIY jobs, including hanging shelves, pictures
and more
NOTE: Keep this user manual for future reference.
LASER LEVEL - USER MANUAL 03
FEATURES 4
SAFETY INSTRUCTIONS 5-6
BATTERY INSTALLATION & SAFETY 7-8
OVERVIEW 9
OPERATING INSTRUCTIONS 10-12
MAINTENANCE 13
FIELD CALIBRATION TEST 14-19
SPECIFICATIONS 20
WARRANTY 21
CONTENTS
oxtools.com
04
■This laser tool is automatically determines the horizontal
and the vertical plans
■The laser projects intersecting horizontal and vertical lines
■Self-level in automatic mode when the laser is positioned
within its self-leveling range
■Visual and audible “out of leveling range” warning
■Pulse mode emits pulses that can be detected by a
detector
■The max. Detectable range of the laser in pulse mode is
60m (200')
■Manual mode allows angular layout/marking
■IP65 Rated for water and dust protection
■Locking mechanism to protect the pendulum during
transportation.
■¼" tripod adaptor
■Shock resistant rubber casing
■Compact size – fits in your toolbox
NOTE: This device contain precision components that
are sensitive to external shock, impact or drop that
may compromise its functionality – handle with care to
maintain its accuracy.
FEATURES
LASER LEVEL - USER MANUAL 05
WARNING
This product is emitting radiation that is classied as
class II according to EN 60825-1
The laser radiation can cause serious eye injury
■Do not stare into the laser beam
■Do not position the laser beam so that it
unintentionally blinds you or others.
■Do not operate the laser level near children or let
children operate the laser level.
■Do not look into a laser beam using magnifying
optical devices such as binoculars or a telescope, as
this will increase the level of eye injury.
WARNING This product contains lead in solder and
certain Electrical parts contain chemicals which are
known to the State of California to cause cancer, birth
defects or other Reproductive harm. (California Health &
Safety Code Section 25249.6 – Proposition 65)
NOTE: The green goggles are intended to enhance the
visibility of the laser beam. They will not protect your
eyes against laser radiation.
SAFETY INSTRUCTIONS
oxtools.com
06
■Do not remove or deface warning labels on the laser level
■Do not disassemble the laser level, laser radiation can
cause serious eye injury
■Do not drop the laser
■Do not use solvents to clean the laser
■Do not use in temperatures below –10°C or above 45°C
(14°F / 113°F)
■Do not operate the laser in explosive atmospheres such as
flammable liquids, gases or dust. Sparks from the tool can
cause ignition
■When not in use, turn off the power, engage the pendulum
lock and place the laser in the carrying pouch
■Make sure the pendulum lock mechanism is engaged
before transporting the laser
NOTE: If the pendulum lock mechanism is not
engaged before transportation, internal mechanical
damage can occur.
LASER LEVEL - USER MANUAL 07
1. Press on the latch and open the battery cover.
2. Insert 3 new AA batteries of the same brand, according to
the polarity diagram on the inside of the lid of the battery
compartment.
3. Reclose the battery cover.
NOTE: If the laser level will not be used for a long
period, remove the batteries from the battery
compartment. This will prevent batteries from leaking
and corrosion damage.
BATTERY INSTALLATION
& SAFETY
oxtools.com
08
WARNING Batteries can deteriorate, leak or explode,
and can cause injury or fire.
1. Do not shorten the battery terminals.
2. Do not charge Alkaline batteries.
3. Do not mix old and new batteries.
4. Do not dispose of batteries into household waste.
5. Do not dispose batteries in fire.
6. Defective or dead batteries must be disposed
according to local Regulations.
7. Keep the batteries out of reach from children.
LASER LEVEL - USER MANUAL 09
1. On/O Locking Switch
2. Laser output window
3. Keypad
a. Manual Mode button
b. Beam Selector button
c. Pulse Mode button
d. Manual Mode LED
e. Laser beam LED
f. Pulse mode LED
4. Battery cover
5. ¼" tripod mount
OVERVIEW
oxtools.com
10
Working in Automatic mode (self-leveling):
In automatic mode the laser level will level itself at a ±3° range
and will project horizontal or vertical beams or both beams
simultaneously.
1. Remove the laser from the case and place it on a solid flat,
vibration free surface or on a tripod.
2. Slide the locking switch #1 to the ON position – the laser
level will generate the crossed horizontal and vertical beams
and the green LED near the V/H button will light up.
3. Choose the beams that you want to work with by pushing
the Beam button V/H
4. If the initial slope of the laser is beyond ±3° and the
automatic mode is activated the laser lines will flash and a
beeping alarm will be heard. In this case reposition the laser
on a more leveled surface.
5. Before moving the laser level slide the locking switch #1 to
the OFF position, this will lock the pendulum and protect
your laser.
OPERATING INSTRUCTIONS
