Ovislink Live-FSH16T+ Manuel utilisateur

Live-FSH16T+

Fast Ethernet Switch

16 × 10/100Mbps

NWay 10/100BASE-TX

Fast Ethernet Switch

with VLAN function

Live-FSH16T+ V.2.1

October , 2002

User’s Manual

Trademarks

OvisLink and OvisLink Logo are registered trademarks of OvisLink Corp. Other product

names and company names are trademarks or registered trademarks of their respective

owners.

FCC Warning

This equipment has been tested and found to comply with the requirements for a Class A

digital device, pursuant to Part 15 of the FCC Rules. These requirements are designed for

reasonable protection against harmful interference when the equipment operating in a

commercial environment. This equipment can generate and radiate electromagnetic energy

and, if not installed and used in accordance with this guide, may cause significant

interference with radio communication. Operation of this equipment in a residential area is

likely to cause interference to household appliances, in which case the user will be required

to amend at his or her own expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this product may cause radio

interference, in which case the user may be required to take adequate preventive measures.

Disclaimer

Contents in this manual are subject to changes without prior notice.

About this

User’s Manual

This User’s Manual aims at helping users to know the key features of

Live-FSH16T+ Fast Ethernet Switch and to install it in a 10/100BASE-TX

Fast Ethernet Local Area Network (LAN).

Table of Contents

TABLE OF CONTENTS ........................................................................................I

1PRODUCT OVERVIEW ........................................................................1

Introduction....................................................................................................................... 1

16× 10/100Mbps ports Fast Ethernet Switch with Per-port VLAN function ................. 1

Port-based VLAN for Instant Connectivity and Workgroup Privacy............................. 1

Per-port VLAN Configuration via a selection switch..................................................... 1

Store-and-Forward Architecture against Packet Loss..................................................... 1

Active Flow Control ....................................................................................................... 2

Full Wire Speed .............................................................................................................. 2

System/Port Status Information at a Glance ................................................................... 2

What is VLAN? ................................................................................................................. 2

Defining VLAN .............................................................................................................. 2

Port-based VLAN ........................................................................................................... 2

Table Maintenance via Signaling.................................................................................... 3

Product Features............................................................................................................... 4

Basic Features ................................................................................................................. 4

Advanced Features.......................................................................................................... 4

2PREPARATION BEFORE INSTALLATION.........................................5

Unpack the Package.......................................................................................................... 5

The Front Panel.................................................................................................................6

The Rear Panel..................................................................................................................6

Live-FSH16T+ Fast Ethernet Switch User’s Manual V2.1

Table of Contents

Station Ports (Port #1 to #16).......................................................................................... 6

DC Power Jack................................................................................................................ 6

VLAN mode switch ........................................................................................................ 7

3INSTALLATION OF THE SWITCH.......................................................8

Quick Installation..............................................................................................................8

3 Steps to Quick Installation........................................................................................... 8

Desktop Installation .......................................................................................................... 8

Installation on Wall........................................................................................................... 9

Cabling Requirements ...................................................................................................... 9

Cable requirement for 100BASE-TX Port...................................................................... 9

Straight-through cabling ................................................................................................. 9

Connecting to Power....................................................................................................... 11

4EXPANDING YOUR NETWORK........................................................12

Connectivity Rules .......................................................................................................... 12

10 Mbps Connection (10BASE-T) ............................................................................... 12

Twisted-pair 100Mbps Connection (100BASE-TX) .................................................... 12

Connecting to another Switch/Hub ............................................................................... 13

Straight-through Cable Connection for Switch-to-Switch/hub Connection ................. 13

Transmission Modes ....................................................................................................... 14

Station Ports (10/100BASE-TX Transmission)............................................................ 14

LAN Micro segmentation through Switching Technology.......................................... 14

Benefits of VLAN ............................................................................................................ 14

Advantage of VLAN Switching over Routing.............................................................. 14

Virtual Workgroups ...................................................................................................... 15

Centralized Server Farms.............................................................................................. 15

Live-FSH16T+ Fast Ethernet Switch User’s Manual V2.1

Table of Contents

Higher Performance and Reduced Latency .................................................................. 15

Ease of Administration ................................................................................................. 15

Saving Costs.................................................................................................................. 15

Routing between VLANs.............................................................................................. 15

Security ......................................................................................................................... 16

Reduction of Routing for Broadcast Containment........................................................ 16

Infrastructural VLANs .................................................................................................. 16

5LED INDICATORS..............................................................................18

Comprehensive LEDs ..................................................................................................... 18

System LED .................................................................................................................. 18

Station Port LEDs ......................................................................................................... 18

Power LED ...................................................................................................................... 18

VLAN LEDs .................................................................................................................... 19

Station Port LEDs ........................................................................................................... 19

Link/Act LED ............................................................................................................... 19

FDX/Col LED............................................................................................................... 19

100M ............................................................................................................................. 19

6VLAN CONFIGURATIONS....................................................................20

VLAN Mode Switch........................................................................................................ 20

VLAN Modes................................................................................................................... 20

VLAN1: 15-VLANs mode ........................................................................................... 20

VLAN Example using 15-VLANs mode...................................................................... 21

VLAN2: 14-VLANs mode ........................................................................................... 22

VLAN Example using 14-VLANs mode...................................................................... 22

APPENDIX A: PRODUCT SPECIFICATIONS .................................................23

APPENDIX B TROUBLESHOOTING...............................................................25

iii

Live-FSH16T+ Fast Ethernet Switch User’s Manual V2.1

Table of Contents

Figures

Fig. 2-1 Package Content................................................................................................ 5

Fig. 2-2 Front Panel ........................................................................................................ 6

Fig. 2-3 Rear Panel ......................................................................................................... 7

Fig. 2-4 VLAN mode switch .......................................................................................... 7

Fig. 3-1 Desktop installation........................................................................................... 8

Fig. 3-2 Bottom View of the Switch (showing mounting holes).................................... 9

Fig. 3-3 10/100BASE-TX pin assignments for RJ-45 connector ................................. 10

Fig. 3-4 Pin assignments for straight-through cabling.................................................. 10

Fig 3-5 Connecting the Switch to power outlet ............................................................ 11

Fig. 4-2 Routing between VLANs through a layer-3 Switch/Router ......................... 16

Fig. 5-1 Front-panel LED indicators............................................................................ 18

Fig 6-1: VLAN Mode Switch ....................................................................................... 20

Figure 6-2 VLAN1: 15-VLANs Mode Example........................................................... 21

Figure 6-3 VLAN2: 14-VLANs Mode Example........................................................... 22

Live-FSH16T+ Fast Ethernet Switch User’s Manual V2.1

Table of Contents

Tables

Table 3-1 Cabling type for 10BASE-T/100BASE-TX................................................. 10

Table 5-1 Station Port LEDs......................................................................................... 19

Table 5-1: 15–VLANs mode ......................................................................................... 21

Table 5-2: 14–VLANs mode ......................................................................................... 22

Live-FSH16T+ Fast Ethernet Switch User’s Manual V2.1

1 Product Overview

1Product Overview

Introduction

16× 10/100Mbps ports Fast Ethernet Switch with Per-port VLAN

function

Live-FSH16T+ Fast Ethernet Switch is an auto-sensing and auto-negotiating 10/100ABSE-TX

Fast Ethernet Switch with VLAN and Priority capability. Its sixteen 10/100Mbps station ports

provide 10/100Mbps connections to Ethernet/Fast Ethernet network.

Live-FSH16T+’s unique switching fabric provides full wire speed for all ports. With auto-sensing,

Live-FSH16T+ automatically detects the speed of the devices you plug into, and routes the

incoming data to its destination. Its auto-negotiating function allows existing devices running at

different speeds to communicate easily within the same network.

Live-FSH16T+ also supports VLAN and Priority functions as briefly described in the following

sections:

Port-based VLAN for Instant Connectivity and Workgroup

Privacy

VLAN ensures instant connectivity and workgroup privacy. Since each station port can be

configured to whichever VLAN group, it offers utmost flexibility for workgroup assignment as to

ensure workgroup privacy. For those ports that join a VLAN, it offers instant connectivity without

further configuration efforts from network administrator. Members of a same VLAN group will be

included within a same broadcast domain, and will feel exactly as they are on the same network

segment (though they might not belong to the same physical network segment).

Per-port VLAN Configuration via a selection switch

With a selection switch in the back panel, user can set the switch in operate in either 14 or

15-VLANs mode. In “14-VLANs mode”, every port is in its own VLAN group sharing Port 1 and

Port 2. In “15-VLANs mode”, every port is in its own VLAN group sharing Port 2.

Store-and-Forward Architecture against Packet Loss

When network is under heavy traffic, the shared memory buffer in the switching devices might yield

incorrect detections due to overfed memory buffer. This setback can happen either when data is

transmitted in IEEE802.3x Full Duplex or Back Pressure Flow Control mode. To solve this problem,

Live-FSH16T+ utilizes a fixed memory buffer allocation with Store-and-forward transmission to

ensure an effective buffer allocation for each port.

Store-and-forward transmission controls data flow from transmitting to receiving nodes with the

receiving buffer threshold adjusted to an optimal value, thus guaranteeing against all possible packet

losses.

Live-FSH16T+ Fast Ethernet Switch User’s Manual V2.1

1 Product Overview

Active Flow Control

Live-FSH16T+ Fast Ethernet Switch implements in full duplex mode a flow control that is

compliant with the IEEE 802.3x standard. While in half duplex mode, it employs an optional Back

Pressure Flow Control to stall the incoming data when port buffers are saturated. With this flow

control mechanism, it can be ensured that frames dropped during transmission are reduced to a

minimum.

Full Wire Speed

Live-FSH16T+’s Full Wire Speed feature provides high-end performance for departmental and

workgroup environments at a fraction of the cost of similar devices. Typically, this feature was

found only in high-end switches designed to handle huge corporate networks. With bandwidth needs

and network efficiency concerns, Live-FSH16T+’s switching fabric design is the perfect answer for

bandwidth enhancement solution.

System/Port Status Information at a Glance

There are 2 sets of LEDs on the front panel: System LEDs and Station Port LEDs.

The System LEDs consist of the Power, VLAN1, and VLAN2 LEDs. Power LED shows Power

On/Off status of the switch. The VLAN1(15-VLANs) and VLAN2(14-VLANs) show the VLAN

configuration status

The Station Port LEDs reveal the link status, half/full duplex transmission, 10/100Mbps speed

mode and the collision status of each station port.

For detailed LED information, refer to Chapter 5, LED Indicators.

What is VLAN?

Defining VLAN

What is VLAN? Since VLAN solutions and implementations are still very vendor-specific, to define

precisely what VLANs will certainly arouse controversy. Nevertheless, most would agree that a

VLAN can roughly be equated as a broadcast domain. More specifically, VLANs can be seen as a

group of end stations, perhaps on multiple physical LAN segments, which are not constrained by

their physical location and can communicate as if they were on a common LAN.

There are several ways to define VLAN membership: port grouping, frame tagging, MAC-layer

grouping, network-layer grouping, IP multicast grouping, etc. Live-FSH16T+ utilizes

port-grouping (port-based VLAN) for the implementation of VLAN in your network.

Port-based VLAN

Live-FSH16T+ simplified the VLAN setup by implementing the most common used VLAN

configuration with a selection switch. The two VLAN modes of Live-FSH16T+ allows users to put

each port in separate VLAN groups while able to share common resources. Users can choose either

14-VLANs or 15-VLANs group. In 14-VLANs mode, each port is in its own VLAN group with

Port 1 and Port 2 as sharing ports. In 15-VLANs mode, each port is in its own VLAN group with

Port 2. The sharing ports are ports that are shared by all VLAN groups for common resources such

Live-FSH16T+ Fast Ethernet Switch User’s Manual V2.1

Table des matières

Autres manuels Ovislink Routeur réseau

Ovislink

Ovislink AirLive GW-300NAS Manuel utilisateur

Ovislink

Ovislink WHR-609N Manuel utilisateur

Ovislink

Ovislink EVO-WR54ADSL-2 Manuel utilisateur

Ovislink

Ovislink AirLive Ether-FSH2400NS Manuel utilisateur

Ovislink

Ovislink AirLive Live-5G Manuel utilisateur

Ovislink

Ovislink Air Live WT2000ARM Manuel utilisateur

Ovislink

Ovislink AirLive WIAS-1000G Manuel utilisateur

Ovislink

Ovislink AirLive Live-FSH16T+v2 Manuel utilisateur

Ovislink

Ovislink Air Live WN-220R Manuel utilisateur

Ovislink

Ovislink Ether-GSH4T Manuel utilisateur

Ovislink

Ovislink OV504WN Manuel utilisateur

Ovislink

Ovislink OV604V Manuel utilisateur

Ovislink

Ovislink OV504WN Manuel utilisateur

Ovislink

Ovislink OV604VB Manuel utilisateur

Ovislink

Ovislink OV704WVG Manuel utilisateur

Ovislink

Ovislink Air Live GW-300R Manuel utilisateur

Ovislink

Ovislink Air Live IE-840POE Manuel utilisateur

Ovislink

Ovislink OV804WVA Manuel utilisateur

Ovislink

Ovislink OV303R6 Manuel utilisateur

Ovislink

Ovislink EVO-DSL SERIES Manuel utilisateur

Ovislink

Ovislink AirMax5N Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
