OUTSTORM MAXX Pro Manuel utilisateur
2
INTRODUCTION
Thanks for choosing the electric scooter
manufactured by us. Please read the manual
before using the product and keep the warranty
card properly. We wish you a pleasant, friendly
convenient and environmentally time with your
new scooter.
INSPECTION BEFORE RIDING
WARNING!
Please make sure to do inspection before riding:
1. Make sure the outer packing is neat
2. Make sure do not remove the barcode as
below. It is necessary to keep the barcode
when you ask for warranty service
3
3. Make sure the control panel can be turned
on
4. Make sure the brake grips working properly
5. Make sure the handlebar of the E-scooter is
not shaky
6. Make sure the seat is installed firmly (If any)
7. Make sure the horn working properly
8. Make sure the light system working properly
9. Make sure the Single and Dual drive switch
working properly
10. Make sure the Eco and Turbo mode switch
working properly
11. Make sure the folding mechanism working
normally
4
SAFETY PRECAUTIONS
SAFETY PRECAUTIONS
1. Wearing helmet, knee and elbow pads while
riding.
2. Please keep the speed below 25km/h or
obey traffic rules of your country.
3. The waterproof grade of our scooters is IP65.
Please won not be ride in rain or ride into
puddle. Battery damage caused by water do
not covered by warranty.
4. The E-scooter is for Adult only and for one
person riding only.
5. Please test the scooter first as long as you get
it (referring to warning above).
6. Make sure all screws are tightened up.
7. Do not charge the scooter indoors. In case of
a fire caused by charging the scooter indoors,
we will not cover any loss. Do not charge
your scooter overnight or without attention.
Please charge with the chargers provided by
our company. Our company will not assume
any responsibility for fire or battery
explosions caused by the use of other
chargers.
8. Watch out for potential obstacles that could
catch your wheel or force you to lose control
5
like sharp bumps, curbs, drainage grates, and
gaps (>5cm). Try to avoid going up or down
any steps higher than 5 cm.
9. Do not use this product below 0C°.
10. Please make sure both of your feet are on
the scooter and the kickstand is folded while
forwarding.Keep your hand on the handlebar
all the time.
11. Slow down your scooter when riding on wet,
slick, bumpy, uneven or rough surfaces.
12. Do not try to clean your scooter with a
waterhose nor any high pressure cleaner. Do
not allow your scooter to be immersed in
water. This may cause motor and circuit
failure.
13. Any modification of the scooter is prohibited
and will end your warranty. Our company can
not be held responsible for any damage
caused by modification of the scooter.
6
GET TO KNOW EACH PART
ELECTRIC SCOOTER ILLUSTRATION
Note
Some accessories may need to purchase
additionally.
7
CHECK ACCESSORIES AFTER UNPACKING
MAKE SURE YOU HAVE RECEIVED ALL
ACCESSORIES
1. Check if there is a tool kit
2. Check if there is two chargers
3. Check if there is voltage lock keys
4. Check if there is seat
5. Check if there is a manual
GSFFG
DA
GHGD
8
FOLDING OPERATION
HANDLE BAR FOLDING OPERATION
Step 1 Find the two folding Step 2 Pull the folding
Sleeves on the handlebar Sleeve and fold down
toward the Direction of
the arrow
Step3, repeat operation as Step 2
9
FOLDING OPERATION
POLE FOLDING
GKL;JKJG
Step 1 Pull down the safety Step 2 Hold the pole by
Lock One hand; Press down the
Red folding Lock by the
other hand; Then fold the
pole down
UNFOLDING OPERATION
Step 1 Push down the folding Step 2 Push back the
Lock, and Push back the Pole Safety Lock
At the same time
10
SEAT FOLDING
SEAT FOLDING
Step 1 Press folding switch under Step 2 Release and fasten
neath the seat to adjust it's angle the ring fast
the the the the the the the the the lock to adjust the height
the the the the the the the the the of the seat
Step 3 Release the retaining lock Step 4 Push the retaining
by pulling it upward. shaft inward to fold down
the the the the the the the the the sh the seat pole.
