Output Technology 2100 Series Mode d’emploi

2100 Series Printers

Replacement Parts Catalog



1993, OUTPUT TECHNOLOGY CORPORATION

reproduced, translated, reduced to any electronic medium or machine readable form without prior

consent, in writing, from Output Technology Corporation.

TRADEMARKS

Xcelite is a registered trademark of Cooper Industries.

Output Technology Corporation

2310 North Fancher Road — Spokane, WA 99212-1381

(509) 536-0468

USA

We suggest you use genuine Output Technology Corporation supplies and authorized service

centers. Contact us at —

Voice: (509) 536-0468 — Fax: (509) 533-1280

For service, please have your printer model and serial numbers handy — these are located on the

back of the printer.

Output Technology maintains a Bulletin Board System (BBS) service. In the U.S.A., call (509) 533-

1217 to access our BBS service for the very latest, up-to-date drivers, firmware, pricing,

maintenance and troubleshooting aids, and application information. Also, you can contact us at —

FTP: ftp.output.com/public/output

WWW: http://www.output.com

Part No: 066-00405-02

Rev. F

February 10, 1998

CTS 046-00291-00-E

2100 Parts Catalog 2/10/98 1

GENERAL

This catalog contains itemized lists of all servicing aids, supplies, expendables, and field

replaceable parts for all models of the printer. Ordering information is provided for field replaceable

units (FRUs). FRUs are illustrated at the end of this publication.

Parts are listed in the following tables —

Customer Replaceable Units (CRUs) and Miscellaneous, Page 2

Field Replaceable Units (FRUs), Page 3

FRU illustrated parts breakdown drawings —

Enclosure, Pages 10 and 11

Base Assembly, Pages 12 and 13

Twinax/Coax Option, Page 14

Printer Mechanism, Page 15

Printhead Carriage, Pages 16, 17, and 18

ORDERING INFORMATION

To order a field replaceable unit (FRU), proceed as follows:

1. Find the appropriate FRU item number from the illustrations at the end of this publication.

2. From the FRU table on Page 3, match the FRU item number to the FRU part number.

3. Obtain the serial number of your printer (on the back of the printer).

22/10/98 2100 Parts Catalog

4. If applicable, have your Visa or MasterCard number and expiration date ready, and then

contact Output Technology Corporation by phone, fax, or mail:

2310 North Fancher Road

Spokane, WA 99212-1381

Phone: (509) 536-0468

Fax: (509) 533-1280

To order customer replaceable units (CRUs) or other miscellaneous items, select from the

following table and then continue as directed in Step 4 above.

CUSTOMER REPLACEABLE UNITS (CRUs) AND MISCELLANEOUS

Part Number Description Qty Per Printer

Customer Replaceable Units (CRUs)

088-00001-XX

116-00026-XX

116-00027-XX

21XXC100

Cord, Power, Domestic

Fuse, 6.25A.

Fuse, 3.15A.

Ribbon Cartridge (2-Pack)

Training and Publications

066-00123-XX

066-00124-XX

066-00133-XX

066-00144-XX

066-00408-XX

066-00405-XX

066-00425-XX

046-00228-XX

Twinax Interface Reference

Coax Interface Reference

Guide, Setup & Operation

Guide, Technical Reference

Manual, 21XX, Maintenance

Manual, 21XX, Parts Catalog

Manual, 21XX, Drawings

Training Video

N/A

N/A4

N/A5

N/A

Shipping

047-00013-XX Ship Kit 16

1For use at 100 vac or 120 vac.

2For use at 220 vac or 240 vac.

3Supplied with optional interface.

4Includes Replacement Parts Catalog (066-00405-XX) and Drawing Set (066-00425-XX).

5Also available along with Maintenance Manual (066-00408-XX).

6Original shipping container or its replacement is required for proper shipment of printer.

2100 Parts Catalog 2/10/98 3

FIELD SERVICE TOOLS (Recommended)

zScrewdrivers

- #1 Straight slot

- #2 Straight slot

- #1 Phillips

- #2 Phillips with 8-to-10-in. shaft, such as Xcelite® part number XST-102.

zHex Allen wrenches

1/16", 3/32", 7/64", 9/64", 5/32", 3/32"

zOpen end wrenches or sockets

5/16", 1/4", 7/16", 1/2"

zDiagonal cutters

zNeedle nose pliers

zC-ring and E-ring tools

zFeeler gauges

zDigital voltmeter

42/10/98 2100 Parts Catalog

FIELD REPLACEABLE UNITS (FRUs)

Model

Item Fig. FRU Part No. Description 2140 2160 2180

001-00093-XX

001-00095-01

001-00095-02

001-00147-XX

001-00166-XX

001-00277-XX

001-00287-XX

Sleeve, Ribbon Drive

Shim, Printhead .001 Thick

Shim, Printhead .002 Thick

Clamp, Ribbon Shield

Shield, Ribbon, Stainless

Clamp, Ribbon Shield

•

12.5

5b&c

002-00066-XX

002-00218-01

002-00218-02

002-00218-03

002-00248-XX

002-00259-XX

002-00260-XX

002-00261-XX

Spline, Ribbon Drive

Guide, Ribbon, Mach, Right

Guide, Ribbon, Mach, Middle

Guide, Ribbon, Mach, Left

Shield, Ribbon, Poly

Shield, Ribbon, Poly7

Shield, Ribbon, Poly

Bearing, Lower Carriage Shaft, Rulon II

•

7Can be used to replace 001-00277-XX.

2100 Parts Catalog 2/10/98 5

FRUs (Continued)

Model

Item Fig. FRU Part No. Description 2140 2160 2180

—

020-00020-10

020-00020-11

020-00020-12

020-00024-XX

020-00031-10

020-00031-11

020-00031-12

020-00039-XX

020-00056-03

020-00056-04

020-00060-05

020-00060-06

020-00060-07

020-00060-08

020-00064-05

020-00064-06

020-00064-07

020-00064-08

020-00080-XX

Cable, 44 Cond, Printhead, Ext 1

Cable, 44 Cond, Printhead, Ext 2

Cable, 44 Cond, Printhead, Ext 3

Cable, Interlock/Jam

Cable, Printhead, Carriage, #1

Cable, Printhead, Carriage, #2

Cable, Printhead, Carriage, #3

Cable, T-Connector, Twinax

Cable, Printhead, Carriage #1

Cable, Printhead, Carriage #2

Cable, Printhead, Carriage #1

Cable, Printhead, Carriage #2

Cable, Printhead, Carriage #3

Cable, Printhead, Carriage #4

Cable, 44 Cond, Printhead, Ext 1

Cable, 44 Cond, Printhead, Ext 2

Cable, 44 Cond, Printhead, Ext 3

Cable, 44 Cond, Printhead, Ext 4

Cable, Switch Panel

•

62/10/98 2100 Parts Catalog

FRUs (Continued)

Model

Item Fig. FRU Part No. Description 2140 2160 2180

37.5

021-00055-XX

021-00085-XX

021-00089-XX

021-00111-XX

021-00112-XX

021-00114-XX

021-00164-XX

021-00198-XX

021-00393-XX

021-00394-XX

021-00395-XX

Access Door, Paper

Transformer

Paper Feed Motor w/o Tractor Pulley8

Forms Compressor

PCB, Serial Interface w/o Firmware9

PCB, Coax10

Superfan

Access Door, Ribbon

Bearing/Bracket

•

035-00013-XX

035-00015-XX

035-00016-XX

Overlay, Keypanel, Standard11

Overlay, Keypanel, Twinax11

Overlay, Keypanel, Coax11

•

040-00052-XX

040-00062-XX

040-00086-XX

PCB, 4th Head Driver

PCB, Paper Jam Sensor12

PCB, Analog

•

8Includes motor and motor pulley. Also see 046-00141-XX.

9See 043-00040-XX for programmed EPROM. (046-00182-XX contains firmware.).

10 Optional interface includes EPROM 043-00054-XX.

11 Overlays are also included with the switch panel (046-00120-XX).

12 Also included in tractor kit (046-00084-XX). 040-00062-XX is not required if the FRU number of the analog PCB is

040-00086-XX or 046-00178-XX.

2100 Parts Catalog 2/10/98 7

FRUs (Continued)

Model

Item Fig. FRU Part No. Description 2140 2160 2180

54.3

54.5

043-00040-03

043-00045-02

043-00051-01D

043-00052-02

043-00053-00A

043-00053-01A

043-00054-00E

043-00080-00A

043-00120-00A

043-00121-00A

EPROM, Serial Interface, V3.0413

EPROM Set, V3.03

EPROM Set, V2.03

EPROM, Motor Controller, V3.00

EPROM Set, V1.00

EPROM Set, V2.00

EPROM, Coax Mother PCB, V1.04

EPROM, Motor Controller, V1.00

EPROM, I/O Twinax 2.3114

•

13 If the version of the serial interface EPROM is earlier than Version 3.04, you may have to replace either the serial interface PCB

assembly or the digital PCB assembly, or both, to use EPROM Version 3.04.

14 If the version of the twinax EPROM is earlier than Version 2.31, you may have to replace either the twinax PCB assembly or the

digital PCB assembly, or both, to use EPROM Version 2.31.

82/10/98 2100 Parts Catalog

FRUs (Continued)

Model

Item Fig. FRU Part No. Description 2140 2160 2180

62.3

62.5

70.5

5a&b

046-00084-XX

046-00119-XX

046-00120-XX

046-00121-XX

046-00132-XX

046-00137-XX

046-00141-XX

046-00178-XX

046-00179-XX

046-00181-XX

046-00182-XX

046-00186-XX

046-00193-XX

046-00255-XX

046-00279-XX

046-00892-XX

Tractor15

Printhead Carriage16

Switch Panel17

Carriage Motor

Printhead Carriage

Printhead, 21 Wire18 (includes shims)

Paper Feed Motor19

PCB, Analog

PCB, Digital20

PCB, Twinax I/O21

PCB, Serial Interface with Firmware22

Detent Lever23

Printhead Carriage24

Ribbon Drive Motor25

Platen26

Printhead, 21 Wire27 (includes shims)

•

15 Includes right tractor, left tractor with sensor, and paper jam sensor PCB.

16 Complete printhead carriage assembly with printheads.

17 Includes keypad, beeper, bezel, and standard, Twinax, and Coax overlays.

18 Printhead replaces 107-00014-XX.

19 Includes motor, motor pulley and tractor shaft pulley. Also see 021-00089-XX.

20 Does

not include programmed EPROM.

21 Optional interface does not include EPROM 043-00121-XX. If the version of the twinax EPROM on the PCB being replaced is

earlier than Version 1.28, you must replace the digital PCB assembly. The latest digital PCB assembly is 040-00056-01.

22 Includes programmed EPROM 043-00040-XX.

23 Includes adjustment lever, detent, and spring. Also included in platen kit (046-00279-XX).

24 Complete printhead carriage assembly with printheads.

25 Includes motor, shaft, and sleeve.

26 Includes platen, detent lever (046-00186-XX), cam follower, and adjustment lever.

27 Printhead replaces 107-00042-XX.
