oticon Vigo Pro Manuel utilisateur
RITE Power (Receiver In The Ear)
INSTRUCTIONS FOR USE
Thank you
Thank you for choosing our product as your means to better hearing.
To support your efforts, we have put great care and attention into making sure that your
new hearing instruments are of the highest quality and that they are easy to use and
maintain.
We recommend that you read this manual carefully to achieve the maximum benefit of
your new hearing instruments.
Congratulations on your decision to actively improve your hearing with today’s most
advanced hearing technology in the market.
Contents
Instrument view RITE Power with Power Dome 4
Instrument view RITE Power with Power Mould 5
Changing batteries 6
Turning your instrument ON and OFF 8
Left/Right ear marking 9
Putting on your instrument 10
Push-button 11
Programs (Optional) 13
Volume Control (Optional) 15
Stand-by (Optional) 16
Tamper-resistant battery door (Optional) 18
Telecoil (Optional) 19
Auto Phone (Optional) 20
DAI (Direct Audio Input) 22
Caring for your hearing instrument 24
Daily Maintenance Power Mould 27
Daily maintenance with Domes 30
Changing the dome 31
Seven easy steps to better hearing 34
Common problems and their solutions 40
Warnings Yellow Pages
IMPORTANT NOTICE
Please familiarise yourself with the entire contents of this booklet before using your
hearing instruments. It contains instructions and important information about the use
and handling of your hearing instruments and batteries.
4 5
Instrument view
RITE Power with Power Mould
Sound outlet + wax
protection system
Ventilations openings Battery door
Push-button
Microphone openings
Instrument view
Rite Power with Power Dome
Your ear piece
Power Domes:
8mm 10mm 12mm Plus dome
Battery door
Push-button
Speaker
Sound outlet
Microphone openings
6 7
Changing batteries
Your hearing instrument battery size is 312.
A worn out battery should be removed immediately and
disposed of according to local regulations.
When the battery power is low, you will hear beeps.
This pre-warning starts when the battery has only a few hours
of operation left. The pre-warning will be repeated in moderate
intervals to indicate it is time to change the battery.
If the battery runs out the instrument turns off. When that
happens, beeps are played to indicate that the instrument
is no longer operating.
This is not an indication of a malfunction.
To replace the battery, follow these instructions:
Open the battery door completely by pushing the raised edge on the bottom of the•
instrument. To assist with the handling of the batteries, the magnet placed at the end
of the MultiTool can be used.
Remove the sticky label from the + side of the new battery.•
The new battery may be inserted by using the magnetic end of the MultiTool.•
Ensure that the positive (+) marking faces the positive (+) sign printed on the battery
door. Close the battery door.
Any moisture on the battery surface should be
wiped off before use. When you change the battery,
it will take a few seconds before the battery works
to full capacity.
MultiTool
8 9
Turning your instrument ON and OFF
Turn ON your hearing instrument by closing the battery door completely with the battery
in place. When the battery door is closed the instrument will start up by playing a jingle.
This indicates that the battery is working and the instrument is operating.
Turn OFF your hearing instrument by opening the battery door slightly until a click is felt.
To preserve the battery, make sure your hearing instrument is switched off when you are
not wearing it.
IMPORTANT NOTICE
Open the battery compartment
fully to allow air to circulate
whenever you are not using your
hearing instrument, especially
at night!
ON OFF
Click Click
Left/Right ear marking
Hearing instruments are fitted to the uniqueness of each ear, which means if you have
two instruments then your left hearing instrument is programmed differently from your
right. That is why it is important to distinguish between the left hearing instrument and
the right.
In order to easily identify whether it is the left ear or right ear instrument, colour
markings may be applied inside the battery door.
A blue dot marks the LEFT instrument.
A red dot marks the RIGHT instrument.
10 11
Putting on your instrument
Place the speaker, with the ear piece attached, into your ear
first (1) and then place the instrument behind your ear (2).
If the instrument has a Power Mould as ear piece, make sure
it is positioned in the ear so it perfectly fits the ergonomics
of the ear canal in a tight and comfortable way.
Make sure that the ear piece is placed so that the tube
follows the contour of the skin.
1
2
Push-button
Your hearing instrument has an ergonomic designed push-button for volume adjustment
and switching between different programs.
The push-button can be activated by pressing either the upper part (UP) or the lower
part (DOWN).
UP
DOWN
12 13
The push-button on your hearing instrument can be programmed to one of functionalities.
Left Right
Programme shift:
Press shortly to change programme.
Volume control:
Press shortly to adjust the volume.
Both volume control and programme shift:
Press shortly to adjust the volume and press long (about 2 seconds)
to shift programme.
To be filled out by your Hearing Care Professional!
Programs (Optional)
Your hearing instrument can have up to 4 different programs.
When switching between the different programs, your hearing instrument will beep.
The number of beeps will indicate which programme you are using.
eOne beep, when you switch to programme 1
ee Two beeps, when you switch to programme 2
eee Three beeps, when you switch to programme 3
eeee Four beeps, when you switch to programme
14 15
Press the upper part to go forwards in the programme cycle e.g from P-P.
Press the lower part to go backwards in the programme cycle e.g from P-P.
Below you can see a description of the programs available in your hearing instrument.
Prg. 1:
Prg. 2:
Prg. 3:
Prg. 4:
Using 2 instruments
If you have two instruments the push-button on one instrument can be programmed to
change the program on both hearing instruments. This means, when you adjust the program
for one instrument, it automatically adjust the other.
Forward
Backward
Volume Control (Optional)
The volume control allows you to adjust the volume in specific listening situations to
the level you feel comfortable with.
To increase volume, shortly press the upper part of the push-button.
To decrease volume, shortly press the lower part of the push-button.
When the hearing instrument is turned on, it starts up at a preferred volume level.
When adjusting the volume control to the preferred level, this is indicated by a beep.
Using 2 instruments
If you have two instruments the push-button on one instrument can be programmed to
adjust the volume on both hearing instruments. This means, when you adjust the volume
for one instrument, it automatically adjust the other.
16 17
Stand-by (Optional)
Push the button for a minimum of seconds to set the instrument in stand-by mode.
To reactivate the instrument, push the button briefly again.
Use the stand-by function if you need to silence the instrument while you have
the instrument on.
Note: pushing either side of the button will
set the instrument on stand-by.
IMPORTANT NOTICE
Do not use the stand-by function as a switch off as the hearing instrument still draws
current from the battery in this mode.
Push for
seconds
18 19
Tamper-resistant battery door (Optional)
This is strongly recommended for infants, small children and people with
learning difficulties.
Instructions
To lock the battery door:
Make sure the door is completely closed. Use the screwdriver in
the MultiTool to turn the tamper-resistant screw to locked position.
To unlock the battery door:
Use the screwdriver in the MultiTool to turn the tamper-resistant screw
to unlocked position. The battery door can be opened as usual.
Important Notice: Do not force the battery door beyond its fully opened
position. Insert the battery correctly. Excessive force can deform the
battery door, which will reduce its tamper resistant effectiveness.
Telecoil (Optional)
The telecoil is a receiver for audio signals transmitted from an inductive loop installation.
The telecoil is meant for telephone conversations and for loop systems in e.g. theatres,
churches or lecture rooms.
The telecoil is activated by using the push-button. When activated, you will hear
a certain number of beeps corresponding to the telecoil programme.
See “Programs” for where the telecoil programme is placed.
