DashCam User Manual
MODEL: S3
Camera Requirements
Class 10 or higher Micro SD/SDHC memory card. Supported memory sizes range from 8GB to
256GB (not included).
Card Recommendations
Kingston Canvas Go! Micro SD
SanDisk High Endurance Micro SD
NOTE: Please don't use SanDisk Ultra cards with our cameras.
I.Product Overview
This product is a HD vehicle travelling video recorder which supports FHD 1080P camera shooting
and has a clear night view effect. It is mainly used for car-borne video recording. Please read this
manual carefully prior to use and keep it properly. We hope this product can satisfy your need
and serve you for long!
II. Product Structure and Description
1. Bracket 2. Car charger interface 3. Menu key 4. Up key 5. Down key
6. OK key 7. Bracket lock 8. Speaker 9. MIC 10. Camera Lens
11. USB 12. Reset key 13. Video indicator light (blue) 14. Charging indicator
light(red) 15. Display screen 16. Micro SD(TF) card slot 17. Power key
Power key: In power off mode, press and hold it for 3 seconds to turn on the unit, press and hold
it again for 3 seconds to turn off the unit. In power on mode, press it to turn off/on the screen.
Menu key: In video recording mode or standby mode, press it to enter main menu; in video
playback or photo playback mode, press and hold it to enter “ File Management” menu; in
submenu directory, press it to return to the previous directory.
Up key: In function selection, system settings and file selection, press it to select upward; in video
recording mode, press it to turn off/on sound recording.
Down key: In function selection, system settings and file selection, press it to select downwards;
in video recording mode, press it to lock current video(15 second).
OK key: In standby mode, press it to start video recording, and press it again to stop recording; in
Capture mode, press it to take a picture; in function selection, system settings and menu
selection mode, press it to confirm; In video playback mode, press it to play the video.
Car charger interface: Connect to the power supply to charge the machine.
USB: Connect to the computer via the mini-USB cable.
Reset key: Press it to reset and restart the system automatically.
Charging indicator light: When external power is plugged in, the red LED turns on, indicating that
the battery is being charged; the red LED turns off when the battery is fully charged.
III.Product Features
Recording: Insert the Micro SD card before use. Then the machine will start the video
automatically when it is connect the power supply. Press the OK key to stop the video.
Video playback: Press the Menu key to into the menu interface. Select the“Video”and press
the OK key to into video playback mode. Press the Up/Down key to select the video file which
you want to play it, then press the OK key to play it. Press the OK key to stop the play in video
playback mode. Press the Up/Down key to fast-forward or rewind in video playback mode.
Loop recording: This product allows loop recording and avoids frame lost.
Gravity sensor: The unit integrates built-in acceleration sensor; if a serious collision occurs, the
recorder will lock the current video when the accident occurs, while the lock icon appears on the
screen, and the locked image won’t be overwritten.
Parking monitor: Enable Parking monitor. In power off mode, the unit will turn on and start
recording automatically and protect the current file when it is subject to vibration; if there is no
operation within a minute, it will automatically shut down.
Remark：This function needs to be used with special power cable (OSBOO Mini-USB Hardwire
Kit )
Date & Time setting: Before using the first time or if date or time is inaccurate, please adjust the
date or time manually. Press the Menu key to enter the menu interface, press Up/Down key to
select "Date/time", and press OK key to enter date and time adjust interface. Then press OK key
to select "Year", "Month", "Date", "Hour", "Minute” or "Second",and press Up/Down key to
modify the figure. After the setting is completed, press Menu key to confirm and return to the
directory of upper level.
Micro SD card format: Enter the main menu, select “Settings” and press the OK key to enter.
Select “Format” in Settings Menu and select the “Yes” to format the Micro SD card.
IV.Installation Guide
1.Turn off the engine of the vehicle.
2.Insert the Micro SD (TF) card into the Micro SD (TF) slot of the DashCam.
3.Fix the DashCam on the front windshield of the vehicle with a bracket.
4.Insert the car charger into the car cigarette lighter.
5.Connect the Dash Cam to the car charger with a USB extension cable.
[Note] In wiring, lay the USB extension cable along the edge of the windshield of the vehicle as
shown in the figure:
6.Adjust the position of the lens and ensure that the lens is parallel to the ground.
7.Start the engine to check if the device is installed correctly.
[Note] After the device is installed correctly, the video indicator light (blue) will be on. And the
device will be started and enter the video recording state, and the video indicator light will flicker
in blue.
V. Specifications
Product Brand
OSBOO
Product Name
Dash Cam
Product Model
S3
Display Screen
2.0 inch, Resolution 960x240
DSP
NOVATEK NT96650
Video Resolution
1920×1080P, 30FPS
Image Sensor.
Sony Exmor IMX323
Camera Lens
140 degree ultra wide angle lens and WDR
Storage
Micro SD card, Class 10, from 8GB to 256GB (not included)
Languages
English/German/French/Spanish/Italian/Portuguese/Chines
e/Japanese/Russian
Power Supply
USB2.0,5V, 1.5A
Battery Capacity
170 mAh
Te mp era tu re Re si stance
-5°(F) to 160°(F) storage temperature
VI. Caution
1.Use the dedicated power adaptor prepared by our company, for using an unqualified adaptor
may be harmful to the product, or even burn the product.
2.Do not use the product in a humid and high temperature environment.
3.Keep the lens clean lest the video recording effect be affected.
4.To safeguard your lawful rights and interests, do not dismantle the product without
authorization.
5.Abide by the laws of the country where the user is, and do not use the product for any illegal
usage, or the consequence shall be borne by the user.
VII. Troubleshooting
Scenes
Fault
Reason/Solution
During
Installation
Bracket falls off
easily
Remove the dust-proof film on the bracket before installation
and keep the glass in the adsorption position clean
Image is blurred
The front windshield has a reflective effect. Please adjust the
tilt angle of the recorder according to the mounting position of
the bracket
Daytime and
night effects vary
widely
The transmittance of commonly used front windshield
insulation film ranges from 68% to 80%, which will affect the
video effect in daytime and night
The recorder is
often powered
off
Please adjust the rotation angle of the charger according to the
car model, and avoid the position of loose structure
During
Boot
Unable to start
Check if the car charger indicator is on; if not, please re-plug
the charger and press the Reset key to reboot
Boot screen
stops, screen is
black and keys
are invalid
Press the Reset key to reboot
Replace the Micro SD memory card (Class 10 Micro SD memory
card recommended)
Recording
video
Video recording
isn’t
automatically
started at boot
Check if there is a Micro SD memory card inserted
Re-plug the Micro SD memory card after power off
Format or replace the Micro SD memory card
Video recording
is aborted
Press the OK key to start the recording manually
Format the Micro SD memory card
Replace the Micro SD memory card (Class10 Micro SD memory
card recommended)
There is no sound
in the video
Check if it is in silent mode (whether the red LED is on)
In video recording mode, press the UP key to turn on or off the
sound recording function
Video is blurred
Check if the lens protection film is removed
Check if the windshield or recorder lens is dirty
Recording time is
wrong
Please go to the menu and set the exact time
Connecting
to PC
Can’t find an
external storage
device
Replace the USB computer cable or use other USB interface
Thank you for your purchase! Hope this device can give you the best surprise! Your satisfaction is
our biggest wish! Any good ideas, please contact our online store. Thank you!
