ORIGO TF-B35 Manuel utilisateur

使用說明書

Instruction Manual

TF-B35

無葉涼夏扇

Bladeless Tower Fan

*使用風扇前，請先細閱使用說明，並請妥善保存以便將來翻閱。

*Read all instructions carefully before using the FAN , and keep this instruction for

furture reference when necessary.

Important Safety Information

重要安全提示

拔除插頭時不可拉扯電源線，必須緊握插頭

，把插頭拔出。

Do not pull the power cord to disconnect

from power source. Always grasp the plug

to pull out.

請使用獨立插座。使用萬能插頭或拖板，容

易發生危險。

Avoid using extension cord as it may

overheat and casue fire.

使用風扇前，請確定規格標貼上所示的額

額定電壓與當地供電電壓相同。如有疑問

可向供應商查詢。

Before using the Fan, check if the

voltage marked on the rating label

corresponds to the mains at your

home.

220-240V~ 50Hz

包裝物料並非玩具，不可讓小孩玩耍。

Do not let children play parts of

package.

打開包裝，檢查風扇。如發現產品有損

壞，請勿使用及即時聯絡供應商。

Open the package and ensure that the

Fan is undamaged. In case of doubt

do not use the FAN and contact your

your supplier.

必須按照使用說明指示操作風扇，否則可

能引致產品損壞、短路、火警或人命損傷

。

Use this Fan only as described in

this manual. Any other use not

recommended by the manufacturer

may casue fire, electrical shock or

injury to persons.

使用風扇前，請先細閱使用說明。

Read all instructions carefully before

using the Fan.

本機不是為體質、感覺或智力有障礙人士(包

括小孩)或缺乏經驗及知識者使用，除非他們

曾經接受負責安全人士的監督或指示，大人應

指導小孩不可把玩電器。

This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities, or

lack of experience and knowledge, unless

they have been given supervision or

instruction concerning use of the appliance

by a person responsible for their safety.

Children should be supervised to ensure

that they do not play with the appliance.

無葉涼夏扇

bladeless tower fan

Important Safety Information

重要安全提示

不可在潮濕或有積水的環境使用，不可將

風扇擺放於浴缸或大型溶器上面。

The Fan is not intended for use in wet

or damp locations. Never locate the

Fan where it may fall into a bathtub or

other water container.

請保持清潔以維持風扇處於良好狀態(詳

細請參閱清理及維護部份)。

Keep the Fan clean to maintain in good

condition (refer to maintenance

section).

切勿將

風扇

擺放在發熱源頭或火源附近。

Do not place the

Fan

near a source

of heat or fire.

警告：清理前必須先拔除電源插頭。若電

源線損壞，必須交由製造商或其代理指定

維修服務中心檢查及修理。

WARNING: To avoid danger of electric

shock, unplug from outlet when not

in use and before cleaning. If the

power cord is damaged, it must be

replaced by the manufacturer, its

service agent or similarly qualified

persons in order to avoid hazard.

本風扇不適用於室外及作工業用途。

This Fan is intended for household

use ONLY and not for industrial or

outdoor use.

非使用風扇時請拔除插頭，切斷電源。

Do not leave the Fan unattended.

Always unplug the Fan when not

in use.

切勿將任何異物放入風扇內；或阻擋風扇

出風口及入風口，皆因以上一切行為均可

能導致風扇損壞。

Do not insert any objects into the Fan

as it may cause an electric shock or

damage. Do not block or tamper with

the Fan in any manner while it is in

operation.

警告：開/關鍵不應作為切斷電源的用途。

WARNING: The On/Off switch should

not be used as the sole means of

disconnecting power. Always unplug

the power cord before servicing or

moving the unit.

如須移動風扇，請先拔除插頭切斷電源。

Always disconnected the Fan from the

power supply when moving it from

one location to another.

本產品含有可回收材料，不可把本產

品作為未分類廢物。請聯繫當地就近

指定回收點。

This product contains recyclable

materials. Do not dispose this

product as unsorted municipal

waste. Please contact your local

municipality for the nearest collection

無葉涼夏扇

bladeless tower fan

Main Parts

各部名稱

插頭

Plug

Air Inlet & Filter

入風口及濾淨網

LED Display

LED顯示屏

Control Panel

控制面板

底座

Base

電源線

Power Cord

Air Outlet

出風口

無葉涼夏扇

bladeless tower fan

Function Setting

功能設定

1. Place the Fan on a stable and flat surface. Plug the Power Cord into an 220-240V~

electrical outlet. The LED will display the current room temperature.

4. 送風模式 (MODE) : 按送風模式鍵，設定所需送風模式：常風、自然風或睡眠風。

4. MODE: Press the button to set the Fan as Normal, Natural or Sleep mode.

5. 左右送風：按下左右送風鍵，風扇以自動左右搖擺模式送風。如欲停止自動左右

5. OSC(LEFT/RIGHT): Press the button to allow the Fan to LEFT/RIGHT oscillate the

搖擺送風，再按此鍵一次。

wind direction. To stop the oscillation, press the button again.

將風扇擺放於穩固的平面上，將插頭插入交流電壓220-240V~的獨立插座。室內溫

3. 風速 (SPEED) : 按風速設定鍵，設定所需風速：1, 2, 3, 4, 5或6檔。

風扇可使用機身頂部按鍵操控(如圖1)，或改用遙控器操控。

3. SPEED: Adjust the Fan speed to the desired level: 1, 2, 3, 4, 5 or 6 by pressing

button.

The Fan may be operated by the control panel located on top of the Fan (as shown in

2. POWER: Turn the Fan ON by pressing the button, the Fan will start at speed (1).

圖1

Figure 1

開/關(POWER) : 按開/關鍵，風扇以(1)檔風速啟動。

Figure 1) or by your remote control.

度顯示同時亮起。

6. 定時設置(TIMER) : 按下定時設置鍵，選定12個不同的自動關機時間，分別為1

至12小時。

6. TIMER: Pressing the button to set desired auto power off time, There are 12 time

intervals, from 1-hour to 12-hour .

無葉涼夏扇

bladeless tower fan

TIMER

OSC

POWER

SPEED

MODE

Remote Control

遙控器

Maintenance

清理及維護

警告：不使用風扇時，經常保持拔除電源，及切勿將風扇浸於水或其他液體中。在清潔本風扇前，先將風

扇關掉及把電源線從插座拔出。

Housing: Clean the outside of the Fan with a soft cloth. To remove presistent dirt, wipe down with

a cloth that has been dampened with warm soapy water.

外殼：清理時切勿將風扇浸於水或其他液體中。使用濕潤軟布抹清潔，頑固污垢可用軟布沾上含肥皂的溫水

抹擦。

注意：切勿使用含有腐蝕性的清潔劑或溶液清理風扇。

儲存：連同使用說明，把風扇存放於清涼及乾爽的地方。

WARNING: ALWAYS UNPLUG THE POWER CORD BEFORE MOVING OR SERVICING. DO NOT IMMERSE

THE FAN IN WATER! BEFORE CLEANING, MAKE SURE THAT THE UNIT HAS BEEN SWITCHED OFF AND

IT IS UNPLUGGED FROM THE MAIN OUTLET.

CAUTION: Do NOT use gasoline, benzene, thinner, harsh

cleaners, etc., as they will damage the Fan. NEVER use

ALCOHOL or any other SOLVENTS.

濾淨網：將外框上方螺絲鬆脫，取出外框及濾淨網，使用濕潤軟

布抹擦清潔。清潔後放回濾淨網並用螺絲鎖緊外框，才可使風扇。

Filter Net: Loose the screws and pull the filter cover out.

Clean the filter with a soft damp cloth, place back the

filter and fix the filter cover with the screws after cleaning.

STORAGE: Store the Fan with these instructions in the

original box in a cool and dry place.

無葉涼夏扇

bladeless tower fan

. 遙控器操作與機頂按鍵相同。1

1. All the functions performed by the Remote Control work are

indentical to Control Panel.

2. Battery replacement: Install one 3V lithium battery.

2. 更換電池: 使用一枚3伏特鋰電池。

TIMER

OSC

MODEMODEMODE

POWER

SPEED

TF-B35

Bladeless Tower Fan

警告

請把電池放在兒童碰不到的地方，如果孩子吞下電池，需立即致電咨詢醫生。

不要對電池進行充電或隨意棄置在有火源的地方。

應保持電池存放於乾燥，陰涼的地方。

以正確的方向插入電池。

電池的處理 - 請按相關地區的法律規定處理曾經使用的電池。

WARNING

1. Keep batteries out of reach of children. Should a child swallow a battery,

consult a doctor immediately.

2. Do not recharge or dispose in fire.

3. Keep in a dry and cool place.

4. Insert battery in rigdt direction.

Battery disposal - Please dispose the used battery per municipal or

provincial law.

涼夏扇

Crudus Tower Fan

無葉涼夏扇

bladeless tower fan

Specification

技術規格

型號 Model Number

電源 Power Supply

額定功率 Rated Power

包裝尺寸 Package Dimension

TF-B35

220-240V~ 50Hz

45W

290 x 240 x 930 mm

Origin Map

源澤地圖

辦公時間

10:30am - 12:30pm (星期一至五)

02:30pm - 05:30pm (星期一至五)

10:30am - 12:30pm (星期六)

(星期日及公眾假期休息)

OFFICE HOURS

10:30am - 12:30pm (Mon to Fri)

02:30pm - 05:30pm (Mon to Fri)

10:30am - 12:30pm (Saturday)

(Closed on Sunday and Holiday)

無葉涼夏扇

bladeless tower fan

產品保用証一年自攜服務

產品: 無葉涼夏扇

型號: TF-B35

此產品由購買日期起計算，本公司將根據下列條款及細則，提供一年保養服務(商業用享3個月)

1. 於購買後一年內，經本公司技術員判斷為正常運作下損壞之產品，

憑零售商之正式發票可獲免費維修和/或零件更換。

2. 以下情況不被包括在保養範圍內：

- 若產品是因為濫用、錯誤使用、疏忽及/或意外而遭致損壞；

- 未經授權之自行處理、維修及/或改裝；

- 任何機殼、面蓋、底座，濾淨網以及遙控器。

3. 需要檢查或維修時，請將產品送往本公司服務中心，並於修理妥當後自行取回。

4. 更換後之任何損壞零件，均屬本公司所有。

5. 本保養服務只適用於香港特別行政區。

6. 顧客必須同時出示零售商之正式發票，方可得到免費維修服務。

服務中心

源澤市務有限公司

香港新界葵涌青山公路403號(近華星街12號)匯城集團大廈21樓H室

電話: 2156 8238

www.origo.hk

*** 額外3個月保用: 凡於購買產品後10天內完成網上登記，即可免費延長保用期3個月，即15個月免費保用(商業用途

除外)。請即登入網站: www.origo.hk

Warranty Card(1 year carry-in)

Item : Bladeless Tower Fan

Model : TF-B35

This product is warranted for 1year (commercial use for 3 months) from the date of purchase under the

following conditions:

1. For any defect, in the judgment of our technician, if it is caused under normal use, we are responsible for

repairing the product, and/or replacing parts at free of charge.

2. This warranty DOES NOT apply to:

- If the product has been damaged through abuse, misuse, negligence or accidents;

- Unauthorized repair, alteration/modification ;

- Housing, cover, base, filter, remote control or its accessories. .

3. The customer is requested to bring the unit to and from our Service Centre whenever

service is needed.

4. Any defective parts, which had been replaced, shall be of our property.

5. This warranty is valid in H.K.S.A.R. only.

6. Please show the Invoice to get free service.

***Extra 3 months warranty: just complete Online Warranty Registration within 10 days from the date of

receipt, free warranty will be extended to 15 months (not applicable to commercial use). Please enter our

website: www.origo.hk

Service Centre

ORIGIN MARKETING LIMITED

Unit H, 21/F., Reason Group Tower (nearby 12 Wah Sing Street), 403 Castle Peak Road, Kwai Chung, N.T., Hong Kong.

Tel: 2156 8238

www.origo.hk
