USER’S GUIDE
Model: OBHFCU
The features described in this user’s guide are subject to modifications without prior notice.
Smart Camera
Welcome...
to your new Oricom Smart Camera!
Thank you for purchasing the Smart Camera. If you have always
wondered what happens when you are away, wonder no more. Now
you can monitor your children, pets or property with this easy-to-use
system. You can install the App on your iPhone®/iPad® or devices for
Android™ and view the Camera’s video stream from your smart phone.
Please keep your original dated sales receipt for your records. For war-
ranty service of your Oricom product, you will need to provide a copy
of your dated sales receipt to conrm warranty status. Registration is
not required for warranty coverage.
For product related questions, please contact:
Australia:
(02) 4574 8888 / Monday - Friday 8am – 6pm AEST
New Zealand:
0800 674 266 / Monday - Friday 10am - 8pm NZST
Email: [email protected]
Visit www.oricom.com.au to download the User Guide with instructions,
answers to frequently asked questions, and more to help you get the most
from your product.
Inside the Box
• 1 x Camera Unit
• 1 x Magnetic Mount
• 1 x Power adaptor
• 1 x Quick Start Guide
Overview of Your Baby Unit
Important guidelines for installing your Smart Camera
• Use of other 2.4 GHz products, such as other wireless networks,
Bluetooth™ systems or microwave ovens may cause interference with
this product. Keep the Wi-Fi® Camera Unit away from these types of
products, or turn them OFF if they appear to be causing interference.
• Always ensure that you have a good Wi-Fi® connection available.
1. Photo Sensor (Night Vision Mode)
2. Camera Lens
3. Infrared LEDs (x 8, for night
vision)
4. High Sense Microphone
5. Magnetic mount
6. Power/Link indicatior
7. PAIR button
8. Night Light
9. Speaker
10. Power Socket
11. Temperature Sensor
1
2
4
5
3
11
10
9
8
7
6
4
Table of contents
Table of contents
1. Safety Instructions ............................................................................... 5
2. Getting Started ..................................................................................... 7
2.1 Connecting the Power Supply of the Camera Unit ...........................7
2.2 Fixing magnetic mount on the wall ...................................................7
2.3 Registration (Pairing).......................................................................... 8
3. Wi-Fi® Internet Viewing ....................................................................... 9
3.1 Minimum System Requirements ........................................................9
3.2 Getting started - Connecting Devices ...............................................9
3.3 Setup................................................................................................10
3.4 User Account and Camera Setup on Android™ or Apple devices. 10
3.4.1 Connect the Camera.............................................................10
3.4.2 Download HubbleClub for Partners App.............................. 10
3.4.3 Sign up with Hubble on your smart device...........................11
3.4.4 Add the Camera to your account ........................................12
4. Procedure for Resetting the Camera............................................ 15
5. Disposal of the Device (environment) ............................................ 15
6. Cleaning ................................................................................................. 16
7. Help.......................................................................................................... 17
8. General Information ........................................................................... 23
9. Technical Specifications .................................................................... 27
5
Safety Instructions
English
1. Safety Instructions
WARNING:
Strangulation Hazard: Children have
STRANGLED on cords. Keep this cord out of
the reach of children (more than 1m away).
Never use extension cords with AC Adaptors.
Only use the AC Adaptors provided.
6Safety Instructions
CAMERA UNIT SET UP & USE:
• Choose a location for the Camera Unit that will provide the best
view of your baby in his/her cot.
• Place the Camera Unit on a flat surface, such as a dresser, bureau
or shelf, or mount the Camera Unit on a wall securely using the
keyhole slots in the underside of the stand.
• NEVER place the Camera Unit or cords within the cot.
WARNING
This Smart camera is compliant with all relevant standards regarding
electromagnetic fields and is, when handled as described in the User’s
Guide, safe to use. Therefore, always read the instructions in this User’s
Guide carefully before using the device.
• Adult assembly is required. Keep small parts away from children when
assembling.
• This product is not a toy. Do not allow children to play with it.
• Keep this User’s Guide for future reference.
• Keep the cords out of reach of children.
• Do not cover the Smart camera with a towel or blanket.
• Do not use the Smart camera in damp areas or close to water.
• Do not install the Smart camera in extreme cold or heat, direct sunlight, or
close to a heat source.
• Only use supplied power adaptors. Do not use other chargers or power
adaptors as this may damage the device and battery.
• Do not touch the plug contacts with sharp or metal objects.
• Connect the power adaptors to easily accessible electrical sockets.
7
Getting Started
English
2. Getting Started
2.1 Connecting the Power Supply of the Camera Unit
• Insert the DC plug of the power
adaptor into the DC socket on the
back of the Camera Unit.
• Connect the other end of the power
adaptor to mains power.
• The Camera Unit turns on and the
power indicator lights in Green colour.
Note
Only use the supplied power adaptor
(DC5V/1000mA).
2.2 Fixing magnetic mount on the wall
Pair button
• Mark the position of the screw holes on the wall.
• Install wall anchors (Not provided) suitable for the wall type and
mounting screws if needed.
• Fasten the mounting screws (Not provided) on the wall.
• Position the cable behind the base as per image before hooking the
base on the wall.
8Getting Started
2.3 Registration (Pairing)
The smart camera is compatible with Oricom models OBH500/OBH430/
OBH650P and works as an accessory camera, to re-register your smart
camera, follow the procedures below:
1. Press the button to access the menu.
2. Press the <LEFT button or > RIGHT button until is highlighted, the
- (delete) / + (add) / (view) / (scan) menu will display.
3. Press the +UP button or - DOWN button to select + (add), and press
the button to conrm.
4. Camera 1/ 2/ 3/ 4will display. Press the +UP button or - DOWN
button to select the desired Camera, and press the button to start the
pairing process.
Note: If a camera is currently paired with the Parent Unit, its camera
location (with a * against it) cannot be selected for a new registration.
5. Press and hold the PAIR button on the back of the Baby Unit until
the Parent Unit nds the camera, beeps and PAIR OK appears on the
screen. The video from the camera will then appear.
Note:
A camera can only be registered to one Parent Unit at any one time.
9
Wi-Fi® Internet Viewing
English
3. Wi-Fi® Internet Viewing
3.1 Minimum System Requirements
Android™ System
• Version 8.0 or above
iPhone®/iPad® iOS
• Version 12.0 or above
High Speed (Wi-Fi®) Internet
• At least 0.6 Mbps upload bandwidth per camera (you can test your
internet speed on this site: http://www.speedtest.net)
3.2
Getting started - Connecting Devices
How does it work?
Access your
Camera locally
View your Camera from any
compatible device remotely
Wi-Fi RouterWi-Fi®
Camera
Hubble
Service
When a user tries to access the Camera, our Hubble server authenticates
the user’s identity and permits access to the Camera.
10 Wi-Fi® Internet Viewing
3.3 Setup
Connect the Wi-Fi® Camera to the Power Adaptor, then plug into mains power.
The Camera must be within range of the Wi-Fi® router with which you want to
connect. Make sure the password of the router is available for entering during
the in-app setup process.
Status of LED Indication:
- Pair / Setup state: LED is Flashing Green.
- Unconnected state: LED is Flashing Red.
- Connected state: LED is Solid Green.
Note: You can only setup via a compatible smartphone or tablet only.
3.4 User Account and Camera Setup on Android™ or Apple
devices.
What you need
• Wi-Fi® Camera Unit
• Power adaptor for the Camera
• Device with Android™ system version 8.0 and above
• Or iPhone®/iPad® with iOS version 12.0 and above
3.4.1 Connect the Camera
• Switch the parent unit off before connect the camera to Wi-Fi®.
• Connect the power adaptor to mains power and insert the plug into
the power socket on the back of the Camera Unit, DO NOT switch the
power on at the power point yet.
3.4.2 Download HubbleClub for Partners App
• Scan the QR code with your smart device
and download the HubbleClub for Partners
App from the App Store for iOS devices or
from the Google Play™ Store for Android™
devices.
• Install the HubbleClub for Partners App on
your device.
