Weather@Home Thermo

Bluetooth-enabled Thermometer

Model: EMR211

USER MANUAL

CONTENTS

Introduction .............................................................. 2

Overview ................................................................... 2

Front view .............................................................. 2

Rear view............................................................... 2

Remote Sensor (THN132N)................................... 3

Getting started.......................................................... 3

Insert batteries ....................................................... 3

Remote sensor.......................................................... 3

Sensor data transmission ...................................... 4

Temperature.............................................................. 4

Ice warning............................................................. 4

Reset.......................................................................... 4

Connect with your mobile device ........................... 5

Paring your Thermometer ...................................... 5

Settings.................................................................. 6

View current readings ............................................ 7

View history readings............................................. 7

Optional sensor for additional information ........... 7

Precautions............................................................... 8

Specifications........................................................... 8

About Oregon Scientific .......................................... 9

EU-Declaration of conformity.................................. 9

FCC statement.......................................................... 9

INTRODUCTION

Thank you for selecting our Oregon ScientificTM

Weather@Home Bluetooth-enabled Thermometer,

which has changeable display on indoor and outdoor

temperature.

NOTE Please keep this manual handy as you use

your new product. It contains practical step-by-step

instructions, as well as technical specifications and

warnings you should know about.

OVERVIEW

FRONT VIEW

1. Outdoor temperature reading (°C/°F)

2. Sensor channel indicator

3. : Sensor reception indicator

4. : outdoor remote sensor battery low

5. Indoor temperature reading (°C/°F)

6. : indoor remote sensor / main unit battery low

7. : BLE connection indicator

8. Ice alert LED indicator

REAR VIEW

RESETSET

1. 2. 3. 4

1. SET: select temperature unit (°C/°F); pair up

Bluetooth function

2. : select outdoor channels (1-5); search remote sensor

3. : select outdoor channels (1-5); auto-scan among sensors

4. RESET: reset the unit to default settings

5. Battery compartment

REMOTE SENSOR (THN132N)

1. LED status indicator

2. Wall mount hole

3. Battery compartment

4. RESET hole

5. CHANNEL switch

REFERENCE

Other supported sensors include models:

THGN328N, THGR328N, BTH sensor, THN318N.

GETTING STARTED

INSERT BATTERIES

1. Remove the battery compartment.

2. Insert the batteries, matching the polarities (+/-).

3. Press RESET after each battery change.

LOCATION MEANING

Outdoor temperature area Outdoor sensor batteries low

Indoor temperature area Indoor sensor batteries

low / main unit batteries low

REMOTE SENSOR

The main unit can collect data from up to 5 sensors.

To set up the sensor:

1. Open the battery compartment.

2. Select a channel then press RESET.

3. Close the battery door.

4. Place the sensor within 98 ft (30 m) of the main unit

using the table stand or wall mount.

TIP Ideal placements for the sensor would be in any

location on the exterior of the home at a height of not

more than 5 ft (1.5 m); and can shield it from direct

sunlight or wet conditions for an accurate reading.

1.5 m (5 ft)

NOTE Use alkaline batteries for longer usage and consumer

grade lithium batteries in temperatures below freezing.

SENSOR DATA TRANSMISSION

To search for a sensor:

1. Press or to select among 5 different outdoor

channels of remote sensors.

2. Press and hold for 2 seconds to enforce

researching for the selected sensor.

To auto-scan among sensors:

• Press and hold for 2 seconds to enable auto-scan

function for all 5 channels. The temperatures will be

displayed automatically in sequential order (Channel

1,2,3,4,5)

The sensor reception icon at the front of the main

unit shows the status:

ICON DESCRIPTION

Main unit is searching for

sensor(s).

A channel has been found.

The sensor cannot be found.

TIP The transmission range may vary depending on

many factors. You may need to place the sensor(s) in

different locations to get the best result(s).

TEMPERATURE

To select temperature unit:

• Press SET to select °C or °F for temperature readings.

ICE WARNING

If the channel 1 sensor falls from 37°F

to 28°F (3°C to -2°C), LED indicator in the front of the

main unit will ash continuously, and will stop ashing

once the temperature is out of this range.

• Press and at the same time to deactivate the

ice alert warning.

• The ice alert warning will be disable/enable again

when the temperature falls again from 37°F to 28°F

(3°C to -2°C).

NOTE As ice alert is only applicable to channel 1, to

prevent flashing of LED, select channel 2-5 on outdoor sensor.

RESET

Press RESET at the rear of the main unit to return to

the default settings.

CONNECT WITH YOUR MOBILE DEVICE

You can remotely set the thermometer and read the

weather information through Bluetooth 4.0 using your

mobile device with the downloaded application from

the Apple Store. To quickly nd the application, type

‘Weather@Home’ as keyword in the search engine.

Ensure your mobile device is compatible with iOS 5 or

Android 4.3 with Bluetooth®v4.0.

PAIRING YOUR THERMOMETER

First of all, you need to pair your thermometer with your

mobile device. will ash on the screen of the weather

station while pairing and be on after successful pairing.

To pair up a sensor:

At the rear of the main unit, press and hold SET for

2 seconds to enable a pair-up for the main unit.

1. Tap to enter SETTINGS screen.

2. Tap on STATION area.

3. Tap Pair Up. Searching… displays. If you want to

cancel the pairing, tap Cancel.

4. Once the pairing is successful, it will return to

STATION screen.

5. Tap on each channel to rename it. (Up to 20

characters including space are allowed). Tap

if completed. Tap to exit.

To remove sensor:

To remove any sensor from the weather station, Tap

Remove station on STATION screen, all the sensors

will be removed at the same time.

To reposition the sensors on screen:

1. On STATION screen, tap .

2. Press and hold at the right side of a sensor. Drag

it to your desired position.

3. Tap to conrm.

SETTINGS

You can set your weather station through the application,

such as measurement units.

The settings are as follows:

• Temperature

• Barometric (not available in EMR211)

• Rainfall (not available in EMR211)

• Wind speed (not available in EMR211)

• Altitude (not available in EMR211)

• Show unavailable sensor

• Automatically sync time

• Show Sea Level Pressure (not available in EMR211)

To select the measurement unit:

1. Tap to view the measurement unit options.

2. Tap on your desired unit.

3. Tap to go back to the previous screen.

VIEW CURRENT READINGS

You can directly view all the

temperature readings from

different sensors through the

application at a time. The

readings are on the HOME

screen.

NOTE If low battery icon

displays on the screen,

please replace the batteries for

the corresponding device.

To show unavailable sensor:

If the sensor is out of range, the readings are interrupted

and - - (dash mode) displays on the screen. If you do

not want to show the unavailable sensor:

• On SETTINGS screen, touch and slide the button to

right to turn on the function, or sliding to left to turn it off.

To automatically synchronize time:

Time and date on your weather station could be

automatically synchronized by your mobile device.

• On SETTINGS screen, touch and slide the button to

right to turn on the function, or sliding to left to turn it off.

VIEW HISTORY READINGS

You can view history through the application. The history

could also be presented in graphs (past 24 hours or

past 7 days).

To view the history:

1. Tap on your desired sensor area on the screen.

2. Tap to select your desired data or tap

to sort the data by date.

OPTIONAL SENSOR FOR ADDITIONAL

INFORMATION

By applying the sensor (Model: BTH Sensor) at the same

time, you can also view the following information using

your mobile device.

• Weather Forecast

• Air Pressure

• Outdoor Humidity

USE FUL REFERENCE The optional sensor (Model:

BTH Sensor) can be purchased from Oregon Scientific.

PRECAUTIONS

• Do not subject the unit to excessive force, shock,

dust, temperature or humidity.

• Do not cover the ventilation holes with any items

such as newspapers, curtains etc.

• Do not immerse the unit in water. If you spill liquid

over it, dry it immediately with a soft, lint-free cloth.

• Do not clean the unit with abrasive or corrosive materials.

• Do not tamper with the unit’s internal components.

This invalidates the warranty.

• Only use fresh batteries. Do not mix new and old batteries.

• Images shown in this manual may differ from the

actual display.

• When disposing of this product, ensure it is

collected separately for special treatment and not

as household waste.

• Placement of this product on certain types of wood

may result in damage to its nish for which Oregon

Scientific will not be responsible. Consult the

furniture manufacturer’s care instructions

for information.

• The contents of this manual may not be reproduced

without the permission of the manufacturer.

• Donotdisposeoldbatteriesasunsortedmunicipalwaste.

Collectionof suchwaste separatelyfor special treatment

is necessary.

• Please note that some units are equipped with a

battery safety strip. Remove the strip from the battery

compartment before rst use.

NOTE The technical specifications for this product and

the contents of the user manual are subject to change

without notice.

NOTE Features and accessories will not be available

in all countries. For more information, please contact

your local retailer.

SPECIFICATIONS

TYPE DESCRIPTION

MAIN UNIT

L x W x H 93 x 68 x 30 mm

(3.66 x 2.68 x 1.18 in)

Weight 96g (3.39 ounces) include battery

Temperature range -5°C to 50°C (23°F to 122°F)

Signal frequency 433 MHz

Power 2 x AAA batteries

Temperature range

for ice alert 3°C to -2°C

REMOTE THERMO SENSOR (THN132N)

L x W x H 96 x 50 x 22 mm

(3.78 x 1.97 x 0.87 in)

Weight 62g (2.22 ounces)

Transmission range 30 m (98 ft) unobstructed

Temperature range -20°C to 60°C (-4°F to 140°F)

Power 1 x UM-3 (AA) 1.5V batteries

ABOUT OREGON SCIENTIFIC

Visit our website www.oregonscientic.com to learn more

about Oregon Scientic products.

For any enquiry, please contact our Customer Services

at info@oregonscientic.com.

Oregon Scientic Global Distribution Limited reserves

the right to interpret and construe any contents, terms

and provisions in this user manual and to amend it, at

its sole discretion, at any time without prior notice. To

the extent that there is any inconsistency between the

English version and any other language versions, the

English version shall prevail.

EU-DECLARATION OF CONFORMITY

Hereby, Oregon Scientic, declares that Weather@ Home

ThermoBluetooth-enabled Thermometer (model: EMR211)

is in compliance with the essential requirements and

other relevant provisions of Directive 1999/5/EC. A copy

of the signed and dated Declaration of Conformity is

available on request via our Oregon Scientic Customer

Service.

COUNTRIES RTTE APPROVAL COMPLIED

All EU Countries, Switzerland CH

and Norway N

FCC STATEMENT

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1) This

device may not cause harmful interference, and (2) This

device must accept any interference received, including

interference that may cause undesired operation.

WARNING Changes or modifications not expressly

approved by the party responsible for compliance could

void the user’s authority to operate the equipment.

NOTE This equipment has been tested and found

to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against

harmful interference in a residential installation.

This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there

is no guarantee that interference will not occur in a

particular installation. If this equipment does cause

harmful interference to radio or television reception,

which can be determined by turning the equipment

off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

Consult the dealer or an experienced radio / TV

technician for help.

DECLARATION OF CONFORMITY

The following information is not to be used as contact for

support or sales. Please call our customer service number

(listed on our website at www.oregonscientic.com), or on

the warranty card for this product) for all inquiries instead.

Name: Oregon Scientic, Inc.

Address: 10778 SW Manhasset Dr.

UNIT B-2 Tualatin, Or 97062 USA

Telephone No.: 1-800-853-8883

Declare that the product

Product No.: EMR211

Product Name: Weather@Home Thermo

Bluetooth-enabled Thermometer

Manufacturer: IDT Technology Limited

Address: Block C, 9/F, Kaiser Estate,

Phase 1, 41 Man Yue St.,

Hung Hom, Kowloon,

Hong Kong

Table des matières

Autres manuels Oregon Scientific Thermomètre

Oregon Scientific

Oregon Scientific RMR803A Manuel utilisateur

Oregon Scientific

Oregon Scientific RMR683HG Manuel utilisateur

Oregon Scientific

Oregon Scientific EMR201 Manuel utilisateur

Oregon Scientific

Oregon Scientific RAR188A-BK Manuel utilisateur

Oregon Scientific

Oregon Scientific RMR382 Manuel utilisateur

Oregon Scientific

Oregon Scientific RMR112 Manuel utilisateur

Oregon Scientific

Oregon Scientific RAR232 Manuel utilisateur

Oregon Scientific

Oregon Scientific RAR213HG Manuel utilisateur

Oregon Scientific

Oregon Scientific SL101 Manuel utilisateur

Oregon Scientific

Oregon Scientific RAR188A Manuel utilisateur

Oregon Scientific

Oregon Scientific RMR683HGA Manuel utilisateur

Oregon Scientific

Oregon Scientific BAR122HGLA Manuel utilisateur

Oregon Scientific

Oregon Scientific RGR126 Manuel utilisateur

Oregon Scientific

Oregon Scientific THWR800 Manuel utilisateur

Oregon Scientific

Oregon Scientific EM-913 R Manuel utilisateur

Oregon Scientific

Oregon Scientific EMR963HG Manuel utilisateur

Oregon Scientific

Oregon Scientific RAR213HG Manuel utilisateur

Oregon Scientific

Oregon Scientific RMR686P Manuel utilisateur

Oregon Scientific

Oregon Scientific RMR112A Manuel utilisateur

Oregon Scientific

Oregon Scientific MTR101 Manuel utilisateur

Oregon Scientific

Oregon Scientific RMR262 Manuel utilisateur

Oregon Scientific

Oregon Scientific AW131 Manuel utilisateur

Oregon Scientific

Oregon Scientific BHGR618 Manuel utilisateur

Oregon Scientific

Oregon Scientific RAR186 Manuel utilisateur

Manuels Thermomètre populaires d'autres marques

Delton

Delton 981A Manuel utilisateur

Baker

Baker MM2P Manuel utilisateur

Tarmo

Tarmo 320281 Manuel utilisateur

Citizen

Citizen CTD 504 Manuel utilisateur

TFA

TFA 14.1500 Manuel utilisateur

Vive

Vive DMD1010 Manuel utilisateur

Gotemp

Gotemp THB4002 Manuel utilisateur

GREISINGER

GREISINGER G 1202 Manuel utilisateur

Amprobe

Amprobe TMD-53W Manuel utilisateur

Trotec

Trotec BP10 Manuel utilisateur

Radiance instruments

Radiance instruments RT616 Series Manuel utilisateur

Eurolec

Eurolec IR151 Manuel utilisateur

Scaneo

Scaneo TS42B Manuel utilisateur

Sper scientific

Sper scientific 800043 Manuel utilisateur

Microlife

Microlife NC 200 Mode d’emploi

Motorola

Motorola MBP69SN Guide de configuration

The MeatStick

The MeatStick The MeatStick Manuel utilisateur

Hama

Hama TH35-A Manuel utilisateur
