ORBLON OCSS6 Manuel utilisateur
USER MANUAL
6-INCH MINI CHAINSAW
MODELS:OCSS6
Please read all safety rules and instructions carefully before operating this tool.
Dear Customer：
Product Questions or Concerns？Contact US：[email protected]
Product Information
Extended functions
Charging the Battery
The use and maintenance of battery tools
Safety Warnings for Charger
Product Diagram
How To Lubricate The Chain
Proper use of the chainsaw safety lock
How to Adjust The Chain Tightness
How to Replace The Chain
How to Replace The Chain
Troubleshooting
Chainsaw Safety Precautions
Wartung und Reinigung
Environment
Services
EN.01
EN.02
EN.03
EN.04
EN.05
EN.06
EN.07
EN.07
EN.08
EN.09
EN.10
EN.11
EN.12
EN.13
EN.13
EN.13
English
Product Information
Intended use
This tool is suitable for gardening pruning, shrub trimming, small
branch cutting, wood cutting, and is widely used in gardens, parks,
farms, highways, ranches, orchards, and greenhouses.
6 Inch Mini Chainsaw
Max. cuing diameter
Guide Plate Length
Weight
Power
Current
140mm
6 Inch
1.4KG
700W
35A
Battery Pack
Baery pack type
Baery Capacity
Charger Output
Charging Time
Working time
Li-lon
20V 3.0Ah 55Wh
21V 1.2A
2.5 H
1 H
Technical Specifications
EN.01EN.01
Extended functions
This product can be combined with a tall pole to form a Pole saw,
allowing you to use the most cost-effective cost to meet the needs
of users in different scenarios:
8-inch Chainsaw
Leaf Blower
Hedge Trimmer
Electric pruning shears
Electric pruning shears 4-inch Chainsaw
The package does not Include the high rod, tou can visit the
ORBLON brand in the amazon store to buy this ac cessory!
NOTE
EN.02
Charging the Battery
It is recommended to charge the new battery before using the electric
saw for the first time. Insert the output plug of the battery charger into
the chargingsocket of the battery, and then plug the charger into the
power outlet. The LED indicator on the charger will turn red during the
charging process and will turn green when the battery is fully charged.
It takes about 2 hours to fully charge the battery.
Indicator Light
Red
Green
Status
Charging
Full Charged
After the battery is fully charged remove the charger plug from the
outlet and remove the battery from the charger.
1. It is normal that the battery and charger heat up during charging.
2. It is recommended to charge the battery every 3 months during
long-term storage to perserve the full life-time of the battery.
3. It takes approximately 5 charging-discharging cycles to reach the
full capacity of a new or stored battery.
4. Please do NOT charge the fully-charged battery again after a few
minutes of use. This can potentially reduce the lifetime and efficiency
of the battery.
5. Please do NOT use damaged batteries, disassemble the charger
or the battery.
6. Do NOT charge the battery outdoor or in a humid environment.
7. When the battery is low, the cutting strength of the electric saw
will decrease, which is normal.
8. Do NOT store the battery in a humid environment.
EN.03
Battery Charging Jack
Lithium Battery Charger
The use and maintenance of battery tools
1. Try to use the battery provided by the manufacturer to connect the
device to use, to prevent the use of other batteries lead to the device
can not work properly, or even can burn the device.
2. Try to use the charger specified by the manufacturer for charging.
charger suitable for one battery pack may create a fire hazard when
used with another battery pack.
3. Do not disassemble the battery pack to prevent damage to the
battery or even the risk of short circuit.
4. Protect the battery from heat, such as continuous strong sun-light,
fire, water and moisture. Prevent the danger of explosion.
5. Use the chainsaw only with specifically designated battery packs.
Use of any other battery packs may create a risk of injury and fire.
6. When the battery pack is not in use, keep it away from other metal
objects, like paper clips, coins, keys, nails, screws or other small metal
objects that can make a connection from one terminal to another.
Shorting the battery terminals together may cause burns or fire.
7. Under abusive conditions, liquid may be ejected from the battery,
please avoid contact. If contact accidentally occurs, flush with water.
If liquid contacts eyes, seek medical help immediately. Liquid ejected
from the battery may cause irritation or burns.
CAUTION! RISK OF EXPLOSION!
Never charge non-rechargeable batteries!
Protect the rechargeable battery from heat,such as
continuous strong sun-light,fire,water and moisture.
Prevent the danger of explosion.
EN.04
Safety Warnings for Charger
Do not allow any liquid to come into contact with the charger.Danger
ofelectric shock may occur.
Do not place tools or chargers near the sink, washbasin, toilet,or any
other places near water.
Do not spill liquid of any kind on the chainsaw or the charger.Doing so
may short out parts, cause damage to the product andcreate the risk
of fire or electric shock.
The most suitable temperature to charge the battery packs are
between 68°F -77F. During charging, batteries must be placedin well
ventilated area.
The chainsaw is not to be used by persons (including children)with
reduced physical, sensory or mental capabilities, or lack ofexperience
and knowledge unless they have been givensupervisioninstructions.
Children must being supervised not to play with the appliance.
Donot recharge non-rechargeable batteries!
EN.05
Only insert the rechargeable battery once the device is completely
assembled.If the device is switched on accidentally,there is a danger
of injury.
NOTE
Product Diagram
Guide Bar
Battery Pack
Start Switch
Protective Baffle
Oil Storage Box
Chain Safety Button
Press
EN.06
When not using the chainsaw, please move the safety lock to the "Lock"
position to prevent accidental injuries.
NOTE
How To Lubricate The Chain
Vertical Ground Lubrication of chains
Press the Oil Box
1 2 3
1. Hold the chainsaw vertically with the blade facing down and press
the Oil Box once to allow the lubricant to flow along the chain.
2. Wait for the lubricant to spread along the chain, then start the
chainsaw and idle twice.
Proper use of the chainsaw safety lock
UNLOCK UNLOCKLOCK
EN.07
When the chain cannot be automatically tightened, it is necessary to
check if there are wood chips or foreign objects stuck between the
motor gears and th chain. Please clean them thoroughly before
readjusting.
NOTE
Our Safety Switch Advantages:
1. It can be easily operated by users, whether they prefer using their
left hand or right hand.
2. Our chainsaw only requires the safety lock to be released, allowing
the device to be operated by simply pressing the "Start" button. This
reduces hand fatigue and improves work efficiency compared to
traditional safety locks.
How to Adjust The Chain Tightness
If the chain comes loose during use, follow the steps below to
adjust the chain.
1. Lift up the cover nut handle.
EN.08
2. Rotate the nut counterclockwise to
loosen it, and the chain will automati-
cally lock in place (no need to remove
the nut, just loosen it). After the chain
is automatically locked, tighten the
nut clockwise.
