Optoma H55 Manuel utilisateur

English

Usage Notice

Precautions ...........................................................................................2

Introduction

Product Features...................................................................................3

Package Overview ................................................................................4

Product Overview..................................................................................5

Main Unit ..........................................................................................5

Panel Control....................................................................................6

Connection Ports..............................................................................6

Full function wireless remote controller.............................................7

Installation

Connecting the Projector .......................................................................8

Powering On/Off the Projector...............................................................9

Power On the Projector ....................................................................9

Power Off the Projector ....................................................................10

Adjusting the Projected Image...............................................................11

Adjusting the Projector Height ..........................................................11

Adjusting the Projector Zoom/Focus.................................................12

Adjusting Projection Image Size .......................................................12

User Controls

Panel Control & Remote Control............................................................13

On-Screen Display Menus ....................................................................16

How to Operate ................................................................................16

Image-I (Computer mode) ................................................................17

Image-I (Video mode).......................................................................18

Image-II (Computer mode) ...............................................................19

Image-II (Video mode)......................................................................20

Audio................................................................................................21

Language .........................................................................................21

Management.....................................................................................22

Appendices

Troubleshooting.....................................................................................23

Changing the Lamp ...............................................................................25

Specifications ........................................................................................26

Compatibility Modes ..............................................................................27

Table of Contents

English

Usage Notice

Precautions

Follow all warnings, precautions and maintenance as recommended in this

user’s guide to maximize the life of your unit.

Warning- Do not look into the lens. The bright light may hurt your eyes.

Warning- To reduce the risk of fire or electric shock, do not expose this

product to rain or moisture.

Warning- Please do not open or disassemble the product as this may cause

electric shock.

Warning- When changing the lamp, please allow unit to cool down, and follow

all changing instructions.

Warning- This product will detect the life of the lamp itself. Please be sure to

change the lamp when it shows warning messages.

Warning- After changing a new lamp, please reset the lamp life from OSD

menu.

Warning- Before switching off the product, please keep the cooling fan

running for a few minutes.

Warning- When connecting the projector to computer, please turn on the

projector first.

Warning- To reduce the risk of injury to the eyes, do not look directly into the

laser light on the remote control and do not point the laser light into

anyone’s eyes. This remote control is equipped with a Class II laser

that emits radiation.

Warning- When the lamp reaches the end of its life, it will burn out and may

make a loud popping sound. If this happens, the projector will not

turn back on until the lamp module has been replaced. To replace the

lamp, follow the procedures listed under “Changing the Lamp”.

Do:

vTurn off the product before cleaning.

vUse a soft cloth moistened with mild detergent to clean the display

housing.

vDisconnect the power plug from AC outlet if the product is not being

used for a long period of time.

Don’t:

vBlock the slots and openings on the unit provided for ventilation.

vUse abrasive cleaners, waxes or solvents to clean the unit.

vUse under the following conditions:

- Extremely hot, cold or humid environment.

- In areas susceptible to excessive dust and dirt.

- Near any appliance generating a strong magnetic field.

- Place in direct sunlight.

English

Product Features

This product is an XGA single chip 0.7” DLPTM projector. The

outstanding features of it are listed as follows:

uTrue XGA, 1024 x 768 addressable pixels

u6.4 lbs (2.9 kgs) compact design

u1000 ANSI Lumens high brightness

uHigh contrast ratio 1000 : 1

uSingle chip DLPTM technology

uPureProgressiveTM processing technology for artifact-free film

materials.

uHDTV compatible (480P,1080i,720P)

uNTSC/NTSC4.43/PAL/PAL-M/PAL-N/SECAM and

HDTV compatible

uHigh-tech DVI connection for digital and analog video

connectivity

uFull function wireless remote controller

uMultimedia audio integration

uUser friendly multilingual on-screen display menu

uAdvanced electronic keystone correction

uUser friendly control panel

uLuxurious carrying case included

uSXGA compression and VGA, SVGA re-sizing

u200 Watts user replaceable UHP lamp

uMac compatible

Introduction

English

Package Overview

This projector comes with all the items shown below. Check to make sure

your unit is complete. Contact your dealer immediately if anything is

missing.

RS232 Cable

S-Video Cable

VGA Cable

Wireless Remote Controller

Carrying Case

Audio Cable Jack/RCA

DVI to D-Sub Cable

Battery x 2User’s Guide

Introduction

Composite Video Cable

34 5

Projector with lens cap

D-Sub to RCA Cable for

HDTV/Component

User’s Manual Power Cord

(According to Country)

English

Main Unit

Product Overview

Introduction

1. Panel Control

2. Power Connector & Power Switch

3. Connection Ports

4. Focus Ring

5. Zoom Lens

6. Zoom Ring

7. Speaker

8. Remote Control Receiver

9. Elevator Button

10. Elevator Foot

910

English

Introduction

Panel Control

Connection Ports

1 RS232 Input Connector

2. Audio Input for Video

3. Composite Video Input Connector

4. S-Video Input Connector

5. Audio Input for DVI

6. DVI Input Connector

7. Audio Input for Computer

8. PC Analog Signal/HDTV/Component Video Connector

9. Audio Output Connector

10. 12V Relay Connector

11. Power Switch

12. Power Connector

810

1. Lamp Warning LED

2. Temperature Warning LED

3. Volume

4. Mute

5. Menu (On/Off)

6. Four Directional Select Keys

7. Enter

8. Zoom

9. Re-sync

10. Source

11. Power /Standby

English

Full Function Wireless Remote Controller

Re-sync

Video Source

Four Directional Select

Keys

S-Video Source

16:9/4:3 Aspect Ratio

Backlight

Introduction

Power

Computer Source

HDTV Source

Freeze

Color Temperature

Brightness

Contrast

Mute

Volume

Keystone Correction

Zoom

Enter

English

1. RS232 Cable

2. VGA Cable

3. S-Video Cable

4. Audio Cable Jack/RCA

5. Composite Video Cable

6. DVI to D-Sub Cable

7. D-Sub to RCA Cable for HDTV/

Component

Connecting the Projector

Installation

vTo ensure the projector works well with your computer, please configure the

display mode of your graphic card to make it less than or equal to 1024 X 768

resolution. Make sure timing of the display mode is compatible with the

projector. Refer to the “Compatibility Modes” section on page 27.

S-Video Output

Video Output 1

Digital Tuner Output

Antenna

RS232

AUDIO

VIDEO

S-VIDEO

AUDIO AUDIO AUDIO

DVI

COMPUTER

+12V RELAY

INPUT OUTPUT

RGB

RS232

English

Lens cap

Power / Standby

Installation

Powering On the Projector

1. Remove the lens cap.

2. Ensure that the power cord and signal cable are securely connected.

3. Turn on the main power switch on the side of the projector and allow the

projector to warm up for 1-2 minutes. 

4. Turn on the lamp by pressing “Power/Standby” button on the control

panel. 

The startup screen will display and count down for 20 seconds and the

Power/Standby indicator will light solid amber.

The “LAMP” LED indicator will light solid green.

5. Turn on your source (computer, notebook, or video player ,etc...) The

projector will detect your source automatically.

vIf the screen displays “No Signal” , please make sure the signal cables are

securely connected.

vIf you connect multiple sources at the same time, use the “Source” button on the

Remote Control or Panel Control to switch.

Power On/Off the Projector

vTurn on the projector first and

then the computer.

Power Switch

English

Installation

Powering Off the Projector

1. Press the “Power/Standby” button to turn off the projector lamp.

2. After pressing the “Power/Standby” button, you will see a message

“Power off the lamp?” on the on-screen display. Press the “Power/

Standby” button again to confirm. Otherwise the message will disappear

after 5 seconds.

3. “Power/Standby” LED indicator will light solid amber for about 30

seconds. After the “Power/Standby” indicator starts flashing, you can

turn off the main power switch on the side of the projector.

If you want to turn on the projector, you must press the “Power/

Standby”button within 90 seconds of the start of the indicator flashing.

4. Do not turn on the projector immediately following a power off

procedure.

vWhen the “LAMP” indicator flashs green for about 10 seconds, you will see a

message “Fan Fail” on the on-screen display. Please contact your local dealer or

Optoma service center.

vWhen the “TEMP” indicator lights solid orange, it indicates the projector

has been overheated. You will see a message “Over Temperature” on the on-

screen display. The projector will automatically shut itself down.

Under normal conditions, the projector can be switched on again for your

presentation. If the problem persists, you should contact your local dealer or

Optoma service center.

Autres manuels pour H55

Table des matières

Autres manuels Optoma Projecteur

Optoma

Optoma TX771 Manuel du propriétaire

Optoma

Optoma Theme Scene HD82 Manuel utilisateur

Optoma

Optoma DW312 Manuel utilisateur

Optoma

Optoma EP737 Manuel utilisateur

Optoma

Optoma TS350 Manuel utilisateur

Optoma

Optoma EP780 Manuel technique

Optoma

Optoma ML750ST-M Manuel utilisateur

Optoma

Optoma DS30 Manuel utilisateur

Optoma

Optoma TW675UST-3D Manuel utilisateur

Optoma

Optoma EH503 Manuel utilisateur

Optoma

Optoma EP732B Manuel utilisateur

Optoma

Optoma Optoma ThemeScene H77 Manuel utilisateur

Optoma

Optoma TX779 Manuel technique

Optoma

Optoma UDH60 Guide d'installation

Optoma

Optoma X351 Manuel utilisateur

Optoma

Optoma S321 Manuel utilisateur

Optoma

Optoma EP780 Manuel utilisateur

Optoma

Optoma EP 738 Manuel utilisateur

Optoma

Optoma Pico PK320 Manuel utilisateur

Optoma

Optoma TX773 Manuel utilisateur

Optoma

Optoma TX-330 Manuel d'installation et d'exploitation

Optoma

Optoma PlayTime PT105 Manuel utilisateur

Optoma

Optoma EH505-B Manuel utilisateur

Optoma

Optoma DP-3515 Manuel d'instructions

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur
