Opticron Imagic IS 14x30 Guide d'installation

Models

10x30

12x30

14x30

Imagic IS

User Instructions and Warranty

North America

Features & Speciﬁcations

AMulti-stage rotating retractable

eyecup assembly

BDiopter adjustment ring

CAnchor points for connecting

binocular strap

DImage stabilization ON/OFF switch

Auto off (5 mins)

EWide band focusing (inﬁnity to

9.5 feet close focus)

Speciﬁcations 10x30 12x30 14x30

Code

Field (ft/1000yd)

Close Focus (ft)

Eye relief (mm)

IPD (mm)

HxW (in)

Weight (oz)

30730

270

9.5

54~74

5.9x4.6

18.8

30731

264

9.5

54~74

5.9x4.6

18.9

30732

231

9.5

54~74

5.9x4.6

Accessories (included)

Soft Case Rainguard Neoprene Strap and Anti-ﬂip Loop Microﬁber Cleaning

Cloth

Accessories (optional)

31018 Nylon Harness

with Quick Release

31048 Elastic Harness

with Quick Release

Binoculars can be a useful companion when traveling, going to sporting and leisure events or used as part of a

hobby such as birdwatching or astronomy. To help you get the best results from your equipment please read the

following instructions carefully.

Retractable rubber eyecups and wearing glasses

Imagic IS binoculars provide the full ﬁeld of view when wearing glasses. To get the maximum ﬁeld of view with

glasses on, turn the eyecup clockwise into the ‘down’ position. Remember to return them to the upright position if

you or anybody else wants to use them without glasses.

Adjusting to obtain a single picture

To adjust to match the spacing of your eyes, rotate the two eyepieces until a single

rounded picture is obtained.

Adjusting for maximum sharpness

Many people have slightly different vision between their eyes.

When using binoculars, this difference can be compensated for by setting the single eyepiece

adjustment located on the right hand side of the binocular below the eyepiece.

To set the binoculars correctly, close your right eye and look through the left eyepiece with

your left eye and using the center focus wheel - focus on an object of your choice until it is clear

and sharp. Next, close your left eye and look through the right eyepiece with your right eye. You

may ﬁnd the object being viewed is not absolutely sharp and this can be corrected by rotating the right hand side

adjustment ring (but without turning the center focus wheel) until the object being viewed becomes sharp. The

binoculars are now set and a perfectly clear and sharp image should be attainable when using both eyes together.

To focus at different distances simply rotate the center focus wheel.

User Instructions

Using the Image Stabilization System

The image stabilization system is controlled using the ON/OFF switch located on the top side of the main body. The

device will turn itself off if unused for 5 minutes.

Changing the Batteries

The Imagic IS is powered by 2x AAA 1.5V batteries located on the underside of the main body. To

change the batteries, pinch the end cap and pull out. Replace batteries and ﬁx the end cap back

into place. Please recycle used batteries at your local recycling center.

Care and cleaning. Binoculars require little maintenance but occasionally the outside surfaces of the eyepieces and

objective lenses will need cleaning. To avoid damaging these surfaces please read the following carefully.

(i) Gently remove excess dirt and dust using compressed air or a lens cleaning brush.

Caution: Hard and persistent rubbing of dirty surfaces can cause abrasive scratches on the surface of the glass

which may distort viewing.

(ii) Breathe on exposed glass surface and then wipe with an optical cleaning cloth (code 30277) in a circular motion

until the surface is clean again.

Do not attempt to dismantle the instrument as this will invalidate the guarantee.

Cold weather. In cold weather the external lens surfaces may steam up when moving the instrument from cooler air

outside to warmer air inside. If this happens, leave the instrument to stand for a few minutes until any condensation

evaporates.

WARNING Never under any circumstances use a binocular to view the Sun. Doing so may cause serious damage to

your eyes.

We hope you will get a great deal of pleasure from your Opticron Imagic IS binocular. If you have any problems or

damage the instrument in any way please contact our Service Department.

User Instructions

Warranty

Please keep this Warranty Card in a safe place

Model:........................................................................................................................................................................

Serial No:................................................................... Purchase Date: ...................................................................

Dealer:........................................................................................................................................................................

Opticron Imagic IS binoculars are of a very high quality both in their performance and construction and for your

peace of mind we offer a Premier Limited Lifetime Warranty.

The Premier Limited Lifetime Warranty covers optical and mechanical components as well as the outer protective

armor. Electronic image stabilization components and accessories such as neck straps, rainguards, dust caps, objective

lens covers etc. are covered by our Standard Warranty.

In the case of accidental damage or defects attributable to faulty parts or assembly we will assume responsibility for

the full costs of repair up to 5 years from the date of purchase. We reserve the right to decide whether defective

parts or products should be repaired or replaced.

The Premier Limited Lifetime Warranty does not cover loss, theft or deliberate damage to the instrument.

Registration

It is important you register your new purchase to activate your Premier Limited Lifetime Warranty. To register your

product and activate the warranty please visit www.opticronusa.com and complete the online Product Registration

Form.

Premier Limited Lifetime Warranties are available on new instruments purchased from participating dealers in North

America and are transferable. If you part with your instrument please make sure the new owner has a copy of your

original proof of purchase and re-registers their ownership at www.opticronusa.com.

Privacy

Opticron takes your privacy seriously and we do not share personal information with other companies.

Address: Unit 21, Titan Court, Laporte Way, Luton, LU4 8EF, UK

Email: [email protected]

Servicing & Repair:

If you have a problem with your product please visit the Help and Support section at www.opticronusa.com
