Opticron Aurora BGA Manuel utilisateur
Aurora BGA
User Instructions and
30 Year Guarantee
Models
8x42
10x42
Features & Specifications
ADioptre adjustment ring (click stop)
BLugs for connecting binocular lanyard
CWide band focusing (infinity to
1.8 metres close focus) with 500°
range for accurate focusing
DMulti-stage locking rotating retractable
eyecup assembly
ETextured rubber armouring for positive
handling with or without gloves
FIntegral tripod adapter socket -
unscrew to fit 31012 Binocular Tripod
Mount
C
F
E
B
A
D
Specifications 8x42 10x42
Product Code Bl 30490 30491
Product Code Gr 30492 30493
Product Code Bl/Gm 30494 30495
Field (m) 126 113
Min Focus (m) 1.8 1.8
Eyerelief (mm) 20 19
IPD (mm) 58~76 58~76
HxW (mm) 140x126 140x126
Weight (g) 654 663
Model featured: Black
Accessories (included)
Accessories (optional)
Leather Case 31020 Rainguard Removable Objective Lens Covers 31002 Neoprene Bungee Lanyard
31012 Binocular
Tripod Mount
BGA roof prism
models
40940 2.5x Universal Tele-Adapter (UTA) with 40941 connection ring
The Opticron UTA enables you to increase the magnification of your Aurora BGA binocular
by a factor of 2.5x using a simple push fit connection. Features include: ‘B’ specification
eyepiece for use with or without spectacles, twist type eyecup assembly and fully multi-
coated optics.
8x Binocular 8x Binocular with 2.5x UTA
giving 20x magnification
Naked eye
Binoculars can open up a whole range of new and exciting impressions
when travelling on holiday, taken to sporting and leisure events or used as
part of a hobby such as birdwatching or astronomy. To help you get the best
results from your equipment please read the following instructions carefully.
Adjusting to obtain a single picture. To adjust to the spacing of your eyes
simply rotate the two sides of the binocular around the centre hinge until a
single rounded picture is obtained when looking through both eyepieces.
Adjusting for maximum sharpness. Many people have slightly different
vision between their eyes. When using binoculars, this difference can be
compensated for by turning the dioptre adjustment ring located on the right
eyepiece tube.
To set the binoculars correctly, close your right eye and look through the
left eyepiece with your left eye and using the centre focus wheel - focus on
an object of your choice until it is clear and sharp. Next, close your left eye
and look through the right eyepiece with your right eye. You may find the
object being viewed is not absolutely sharp and this can be corrected by
rotating the dioptre adjustment ring (but without turning the centre focus
wheel) until the object being viewed becomes sharp. The binoculars are
now set and a perfectly clear and sharp image should be attainable when
using both eyes together. To focus at different distances simply turn the
centre focus wheel.
User Instructions
Retractable rubber eyecups and wearing glasses. Opticron Aurora BGA
binoculars provide the full field of view when wearing glasses. To get
the maximum field of view with glasses on, turn the eyecup clockwise
into the ‘down’ position. Remember to return them to the upright
position if you or anybody else wants to use them without glasses.
Care and cleaning. Binoculars require little maintenance but
occasionally the outside surfaces of the eyepieces and objective lenses
will need cleaning. To avoid damaging these surfaces please read the following carefully.
(i) Gently remove excess dirt and dust using compressed air or blower brush.
Caution: Hard and persistent rubbing of dirty surfaces can cause abrasive scratches on the surface of the glass
which may distort viewing.
(ii) Breathe on exposed glass surface and then wipe with an optical cleaning cloth (code 30277) in a circular motion
until the surface is clean again.
Do not attempt to dismantle the instrument as this will invalidate the guarantee.
Cold weather. In cold weather the external lens surfaces may steam up when moving the instrument from cooler air
outside to warmer air inside. If this happens, leave the instrument to stand for a few minutes until any condensation
evaporates.
WARNING Never under any circumstances use a binocular to view the Sun. Doing so may cause serious damage to
your eyes.
We hope you will get a great deal of pleasure from your Opticron Aurora BGA binocular. If you have any problems or
damage the instrument in any way please contact our Service Department.
User Instructions
Multi-stage locking rotating retractable eyecup
assembly
Opticron Aurora BGA binoculars are of a very high quality
both in their performance and construction.
We guarantee some parts in these instruments for up to 30
years under the following conditions:
(i) In the case of defects attributable to faulty processing
or materials, we will assume responsibility for the
labour and material costs during the first 10 years
after purchase. We reserve the right to decide whether
defective parts should be repaired or replaced.
(ii) During the next 20 years we will assume responsibility
for material costs only, charging corresponding labour
costs.
(iii) We will accept no liability for damage caused by
incorrect use, or for any repairs or actions which have
been carried out outside our firm.
(iv) Parts such as carrying straps, rubber eyecups, rubberised
coatings etc. are excluded from the guarantee.
This guarantee is in addition and does not affect your
statutory rights.
Please keep this Guarantee Card in a safe place
Guarantee
Registration
If you would like to register your purchase with us please complete the online Product Registration Form at
www.opticron.co.uk/Forms/registration_form.htm
Alternatively please telephone us during normal working hours on the numbers given. We will need the product
name and serial number (if applicable), purchase date and outlet, your name and postcode.
Registration is voluntary and failure to register will not diminish your rights under the guarantee.
Privacy
Opticron takes your privacy seriously and we do not share personal information with other companies.
AURORA30YR14
Address: Opticron, Unit 21, Titan Court, Laporte Way, Luton, Bedfordshire, LU4 8EF, UK
