Opticon OPL9728 Manuel utilisateur
SCAN QUANTITY DEMO OPL9728 OPTICON
CAUTION: This user’s manual may be revised or withdrawn at any time without prior notice.
Version
User’s manual for Graphical scanning quantity demo application of OPL9728
Version: LFD24390
February 2003
Copyright 2002, Opticon Sensors Europe B.V.
All rights reserved.
Limited warranty and disclaimers
By opening the package of this product you agree to become bound by the liability and warranty
conditions as described below.
Under all circumstances this manual should be read attentively, before installing and or using the
product. In no event,
Opticon Sensors Europe will be liable for any direct, indirect, consequential or incidental damages
arising out of use or inability to use both the hardware and software, even if Opticon has been informed
about the possibility of such damages.
All Opticon products are warranted for a period of one year after purchase, covering defects in physical
media and physical documentation. The liability of Opticon is limited to replacement of defective media
or documentation.
Opticon will not be liable for modifications that are made by the customer. Opticon does not warrant that
the software is free of errors, or that it will meet any user’s particular standards, requirements, or needs.
Opticon will in no event be liable for any direct, indirect or incidental damages arising out of use of this
software.
Trademarks used are property of their respective owners.
TABLE OF CONTENTS - 3
SCAN QUANTITY DEMO OPL9728 OPTICON
Table of contents
TABLE OF CONTENTS 3
1. KEYS 4
2. THE MENU STRUCTURE 5
2.1 Scan Labels 6
2.2 Scroll data 8
2.3 System menu 9
2.4 Delete data 14
2.5 Send data 15
2.6 Version 16
3. DATA FORMAT 17
4. BATTERY 18
4.1. Battery charging 18
4.2. Battery near empty 19
4.3. Battery empty 19
SCAN QUANTITY DEMO APPLICATION - PAGE 4
SCAN QUANTITY DEMO OPL9728 OPTICON
1. Keys
The OPL9728 has full numeric keypad with some additional control keys.
The Q1 key (Up key) or with shift left key.
The Trigger key.
The Q2 key (Down key) or with shift right key.
While holding the shift key and pressing a
numeric key the alpha representative value is
displayed on the screen.
SCAN QUANTITY DEMO APPLICATION - PAGE 5
SCAN QUANTITY DEMO OPL9728 OPTICON
2. The Menu structure
The menu structure consists of several menu items. These items together
form the Main and submenus. To navigate through the menu’s the and
keys can be used. Item from the menu can be selcted by pressing the
ENT or the button. Direct selection of the menu is also possible by
pressing the numeric equivalent of the menu item.
Below is the schematic representation of the menu that is displayed in the
OPL9728.
•1 Scan labels
•2 Scroll data
•3 System menu
•3-1 (back)
•3-2 Barcode
•3-2-1 (back)
•3-2-2..16 enable barcode types
•3-3 Communicate
•3-3-1 (back)
•3-3-2 Baudrate
•3-3-2-1(back)
•3-3-2-2..8 select baudrate
•3-3-3 Protocol
•3-3-3-1 (back)
•3-3-3-2..3 select protocol
•3-4 Battery volt
•3-5 Memory
•3-6 Date / time
•3-7 Standby time
•3-7-1 (back)
•3-7-2..9 select standby time
•3-8 Backlight
•Delete data
•Send data
•Version
SCAN QUANTITY DEMO APPLICATION - PAGE 6
SCAN QUANTITY DEMO OPL9728 OPTICON
2.1 Scan Labels
No data on RAM disk.
By pressing the trigger button the laser line
emits and it is possible to scan a barcode.
Data present on RAM disk.
By pressing the trigger button the laser line
emits and it is possible to scan more
barcodes.
Barcode can now be scanned be pressing the
trigger button. Keyboard input is also possible.
To enter alpha data press the shift button en
while keeping it pressed press any of the
numeric keys. To enter the input data press
the ENT key.
To return to the main menu the key or
the CLR key can be pressed.
Data in display after scanning or entering a
barcode.
The total value is the found quantity in the
database. If the entered data does not exist in
the database the total value is 0.
The value within the rectangle is the default
value. Any numeric input smaller then 4 digits
could overwrite the default value. To input a
negative value, keep the pressed and
press the . To make a negative value
positive, repeat the same process.
To enter the input press the ENT or trigger
key.
If the Total + Add quantity is 0 (zero) the
record is deleted from the database.
SCAN QUANTITY DEMO APPLICATION - PAGE 7
SCAN QUANTITY DEMO OPL9728 OPTICON
If the entered quantity is not a valid value this
message box will appear. By pressing any key
the OPL9728 returns to the quantity input.
A 0 (zero) is a valid input then the changes
are not stored in the database.
If the total quantity in the database with the
newly added quantity exceeds 999999 or
–999999 then this message appears. The
added quantity is stored in the database.
After pressing a key the scan barcode menu
appears.
After entering the quantity the application
returns to the scan barcode. Shown on screen
is now the previous scanned barcode with the
quantity in the database.
Pressing the Q2 key will open a special menu
item that can perform some operations on the
previous scanned barcode.
will return to the scan barcode menu.
deletes this record item from the
database.
By pressing the button the quantity that
is stored in the database can be changed.
Changing the quantity happens the same way
as the add quantity input. The default value is
the value that is stored in the database.
If the default value is changed to a new value
this message appears on the display.
enables the new input value and stores it
in the database.
cancels the input, the dtabase keeps
unchanged.
SCAN QUANTITY DEMO APPLICATION - PAGE 8
SCAN QUANTITY DEMO OPL9728 OPTICON
Before deleting the record this message
appears. If the question is acknowledged .
The record will be removed from the
database, this action cannot be undone.
When is pressed the record will not be
deleted.
2.2 Scroll data
When no data is available the option select
will result in a message that there is no data
on the RAM disk.
When selecting this menu item it is possible to
scroll through the inputted data.
To navigate through the inputted data use the
and keys. When pressing the
and the first record in the database is
displayed. and will display the last
record of the database.
SCAN QUANTITY DEMO APPLICATION - PAGE 9
SCAN QUANTITY DEMO OPL9728 OPTICON
2.3 System menu
The System menu contains a submenu where special terminal options can be
viewed or set. The navigation of this menu is the same as navigating the main
menu.
The system menu consist of 8 items:
•(back)
•Barcodes
•Communicate
•Battery volt
•Memory
•Date / time
•Standby time
•Backlight
When the (back) menu item is selected the
application returns to the main menu.
SCAN QUANTITY DEMO APPLICATION - PAGE 10
SCAN QUANTITY DEMO OPL9728 OPTICON
The barcode menu enables or disables
barcode types that are supported by the
OPL9728. More barcodes can be enabled at
the same time.
Checked = enabling barcode
Unchecked = disabling barcode
Supported barcode types are:
•Code 39
•EAN
•UPC
•Interleaved 2 of 5
•Industrial 2 of 5
•Codabar
•Code 93
•Code 128
•MSI plessey
•Telepen
•UK plessey
•IATA
•Scode
•Matrix 2of5
•All Addons
By enabling all addons the addons for all
supported barcode types are enabled.
