8 Integrated program routines 9
Routine 11: Switching point hysteresis SP1 Pre-alarm
The hysteresis is set in W/m.2
Routine 12: Switching point hysteresis SP2 Alarm
The hysteresis is set in W/m.2
Routine 15: Set relay function of SP1 pre-alarm
Routine 16: Set relay function of SP2 alarm
Each relay can act as a normally closed or normally open contact when the respective
switching point is reached.
001: Opener
000: N/O contact
NC contact = the relay opens the circuit when the switching point is reached.
Normally open = the relay closes the circuit when the switching point is reached.
Routine 17: Timed pickup or dropout delay of SP1 pre-alarm
When the threshold value is reached, the relay function is triggered with a time delay.
The time delay is proportional to the number of measuring cycles (max. 1999 cycles).
The measuring rate is 2.5 measurements per second.
Number of measuring cycles: time delay
Routine 18: Timed on-delay or off-delay of SP2 alarm
When the threshold value is reached, the relay function is triggered with a time delay.
The time delay is proportional to the number of measuring cycles (max. 1999 cycles).
The measuring rate is 2.5 measurements per second.
Number of measuring cycles: time delay
Routine 19: Querying the maximum measured value
The maximum value is continuously determined and stored since the last RESET. The
reset is carried out when the min. or max. value is displayed by pressing the SP1 pre-
alarm and SP2 alarm keys simultaneously for 3 seconds.
