CS-V720
SERVICE MANUAL
SERVICE MANUAL
RC-640S
DVD RECEIVER SYSTEM
Silver model
MODEL CS-V720(S)
120V AC, 60Hz
120V AC, 60Hz
S MDD1N
S MDS4N
Ref. No. 3906
102005
- - - DR-UN7(S) - - -
- - - D-720(B) - - - - - - D-720(B) - - -
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK ON THE
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
CS-V720
PACKING PROCEDURE
Do more with your ipod
CS-V720(S)
TOP
BOTTOM
F
R
A805
A806
A803
A804
A802
A901
A902
A603
A603
A801
A904
A903
A610
A612
A601
(F & R)
S02
A612
A905
A613
A603
A603
S09
S06
S05
S06
S01
S07
S08
S07
S13
S12
S10
1.8 m
x 2 pcs.
S11
(4 pcs.)
x 2 sheets
S03
S08
Front side
<F>
Front side
marking
Top side
marking
Rear side
marking
Bottom side
marking
<R>
Front side
CS-V720
ONKYO EUROPE UK Office
Suite 1, Gregories Court, Gregories Road, Beaconsfield, Buckinghamshire, HP9 1HQ
UNITED KINGDOM Tel: +44-(0)1494-681515 Fax: +44(0)-1494-680452
ONKYO U.S.A. CORPORATION
18 Park Way, Upper Saddle River, N.J. 07458, U.S.A.
Tel: 201-785-2600 Fax: 201-785-2650 http://www.us.onkyo.com/
ONKYO EUROPE ELECTRONICS GmbH
Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY
Tel: +49-8142-4401-0 Fax: +49-8142-4401-555 http://www.eu.onkyo.com/
Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN
Tel: 072-831-8023 Fax: 072-831-8124
ONKYO CORPORATION
http://www.onkyo.com/
HOMEPAGE
ONKYO CHINA LIMITED
Units 2102-2107, Metroplaza Tower I, 223 Hing Fong Road, Kwai Chung,
N.T., HONG KONG Tel: 852-2429-3118 Fax: 852-2428-9039
http://www.ch.onkyo.com/
1/1 PAGE
CS-V720
PACKING PROCEDURE PARTS LIS
T
<Notes>
<MDD1N> : USA model
<MDS4N> : South American model
DVD RECEIVER SECTION (DR-UN7)
REF. NO. PART NAME DESCRIPTION QT'Y PART NO. (SN) REMARKS
PACKING A601 PAD (F & R / 1set) 1 29092300B
PACKING A603 TAPE NITTO NO.29 W18 (Yellow) (1) 29110149
PACKING A610 POLY BAG POLY BAG (430 x 550) 1 29100123C
PACKING A612 LABEL (DES) DR-UN7, 2sheets 1 29364272 <MDD1N>
PACKING A612 LABEL (DES) DR-UN7, 2sheets 1 29364300 <MDS4N>
PACKING A613 SHEET 300 x 300 (For AC cord) 1 29095862
PACKING A801 POLY BAG 350 x 250 1 29100097-1A
PACKING A802 PIN CORD AS RCA-1P(Y) 1.5M 1 2010398
PACKING A803 ANT COIL NMA-3057 1 232140
PACKING A804 FM ANT AS Type W 1 292191
PACKING A805 REMO CON RC-640S 1 24140640
PACKING A806 BATTERY R6/AA(UM-3) 2 3010054
PACKING A901 INS MANUAL En(DR-UN7) 1 29344125
PACKING A902 INS MANUAL Es(DR-UN7) 1 29344127 <MDS4N>
PACKING A903 WRNTY CARD (ONKYO) 1 29365102
PACKING A904 HANDBILL (DS-A1) 1 29380140
PACKING A905 INST SHEET XM RADIO(E) 1 29355538 <MDD1N>
SPEAKER SECTION (D-720)
REF. NO. PART NAME DESCRIPTION QT'Y PART NO. (SN) REMARKS
PACKING S01 CARTON BOX CS-V720(S)MDD 1 730-00D720-00 <MDD1N>
PACKING S01 CARTON BOX CS-V720(S)MDS 1 730-720MDS-00 <MDS4N>
PACKING S02 POLYFOAM TOP 1 720-0D720T-00
PACKING S03 POLYFOAM BOTTOM 1 720-0D720B-00
PACKING S05 HD BAG 0.025t x 565 x 435 (For SPEAKER) 2 700-820017-10
PACKING S06 TAPE NITTO NO.29 W18 (Yellow) (1) 29110149
PACKING S07 PP TAPE or W50 (1) 29110071 or
PACKING S07 PP TAPE or W48 OPP TAPE (1) 29110148 or
PACKING S07 PP TAPE NITTO 3703 SUPER W50L100 (1) 29110176
PACKING S08 SN LABEL (No Serial Number printing) (2) 635-00D720-00
PACKING S09 POLY BAG 350 x 250 1 29100097-1A
PACKING S10 SPEAKER CABLE AWG#20 L=1.8m RED LINE 2 319-0DN500-00
PACKING S11 FOOT CORK Dia. 15 x t1.0 x 4 pcs. 2 441-901104-00
PACKING S12 INS MANUAL En(D-720) (29344070) 1 650-00D720-00
PACKING S13 LAYER PAD BF 419 x 323 1 742-310001-00
