7.8. Test for communication function
Set and test it according to the communication function of the software of
the upper monitor.
8.1. Outline of the menu.
1) LED display means the3 digital tube on control Panel from left to right.
2) 4 buttons are in too line. There is only the SET button on the first line.
There are INC, STOP, DEC, SET buttons on the second line from up to down.
SET button is for entering or exiting the menu. INC button is for increasing
the parameter. DEC button is for decreasing the parameter. STOP button is for
keep the parameter after exiting equipment. If user needs to return to the
setting status, press SET button.
8.2. setting to enter or exit the menu.
1) normal working mode. When the turnstile works, P00 appears on the LED
display. When the user faces the turnstile and adjust the function for the
turnstile and there is no need to read the card, press INC button. The boom
will turn 20 degrees in the left direction. Press SET button, then the boom will
turn 20 degrees in the right direction.
2) When turnstile works normally, press SET button to enter the setting of
menu. P10 appears on the LED display. Press SET button again, P20 appears
on the LED display, Continue to press SET button, P30 appears. It works the
same way as other “ PXX ” till it reaches “000”. Then it exit the setting of the
menu.
3) 15 functions for setting on the menu.
P10:semi-automatic ( it is not opened normally. It can be opened according
to the clients' needs )
P11:full-automatical
P20:on-line mode
P21 off-line mode
P22: for testing the card-reading and unlocking the turnstile
P30: speed of the motor ( slow )
P31:speed of the motor(middle)
P32:speed of the motor ( fast )
Attention: there are no the three P30-P32 functions on this turnstile.
P40: time for unlocking and then locking ( short )
P41: time for unlocking and then locking ( middle )
P42: time for unlocking and then locking ( long )
P50: time for unlocking and then locking jamming (long )
P51: time for jamming ( long )
P52: time for jamming ( long )
P60: data canceling left machine ( press INC button )
P60: data canceling right machine ( press DEC button )
P70: Left can read the card , while right can be forbidden to pass
P71: Right can read the card , while left can be forbidden to pass
P72: Bi-directional forbidden pass
P73: Bi-directional card reading and staff limiting
4) Exit the setting of the menu: continue to press SET button for a cycle time.
Then “ 000 ” appears, or press STOP button exit the menu design.
8.3. Setting function instruction
1) Enter into menu, press "set" key, after hear "dip", loose "set" key, and the
screen display "P10" means already in the menu setting status, Either press
"INC" key or "DEC" key are all only can change the present setting status
function. In the status of no card reader, the arm does not run. Press "INC"
key, the screen display "P11" , and press "SET" key, the press display "P10" ,
If need to save the setting, press "SET" key, until the screen display "000" ,
which means the setting has been saved and exit the setting.
2) Under the normal working status, press twice "SET" key, enter into the
working model setting, the screen display "P20" , either press "INC" key or
"DEC" key are all only can change the present setting status function. In the
status of no card reader, the arm does not run. Press "INC" key, the screen
display "P21", and press "DEC" key, the screen display "P20". If need to
save the setting, press "SET" key, until the screen display "000", which
8. Instruction for adjusting the function for setting
the menu.
3) when the card is read in the left: when the card is read in the left, the
turnstile will self-unlock automatically. The transit direction indication will
turn to the green light. After the person transit and the booms rotate for 120
degrees Then the photo electricity restoring switch will respond to it and
turn. Then the motor will be started and lock the turnstile. The transit
indication will turn to the red light and the calculate will count the flow rate.
It works the same way in the right!
The longest time for the transit is 10 seconds( this regulated time can be
fixed by the user, the following regulated time is supposed as 10 seconds.)
When the regulated is over and no one transit, then the turnstile will restore
and no number will be counted into the flow rate.
4) Lower the boom when electricity is cut off. When the turnstile run right
and suddenly the electricity is cut off. Then the turnstile will lower the
booms and permits the transit
7.7. Restoring function
When the card is read effectively, the boom will rotate for 15 degrees and
stop. Then the transit direction indication will turn to the green light and
permits transit. The system will restore and cancel the transit right for this
time after the regulated time. And no number will be counted into
the flow rate.
Attention: when restoring, the rotating booms in the left and the right
should be even.
