Omron NS-CXDC1-V3 Manuel utilisateur

USER’S MANUAL

Cat. No. V099-E1-04

NS-Series

CX-Designer

Ver. 3.@

NS-CXDC1-V3

CX-Designer

Ver. 3.@

NS-CXDC1-V3

User’s Manual

Revised April 2009

Notice:

OMRON products are manufactured for use according to proper procedures by a qualified operator

and only for the purposes described in this manual.

The following conventions are used to indicate and classify precautions in this manual. Always heed

the information provided with them. Failure to heed precautions can result in injury to people or dam-

age to property.

!DANGER Indicates an imminently hazardous situation which, if not avoided, will result in death or

serious injury. Additionally, there may be severe property damage.

!WARNING Indicates a potentially hazardous situation which, if not avoided, could result in death or

serious injury. Additionally, there may be severe property damage.

!Caution Indicates a potentially hazardous situation which, if not avoided, may result in minor or

moderate injury, or property damage.

OMRON Product References

All OMRON products are capitalized in this manual. The word “Unit” is also capitalized when it refers to

an OMRON product, regardless of whether or not it appears in the proper name of the product.

The abbreviation “Ch,” which appears in some displays and on some OMRON products, often means

“word” and is abbreviated “Wd” in documentation in this sense.

The abbreviation “PLC” means Programmable Controller. “PC” is used, however, in some Program-

ming Device displays to mean Programmable Controller.

Visual Aids

The following headings appear in the left column of the manual to help you locate different types of

information.

Note Indicates information of particular interest for efficient and convenient opera-

tion of the product.

1,2,3... 1. Indicates lists of one sort or another, such as procedures, checklists, etc.

Terminology

NS-series PT A Programmable Terminal in the NS Series manufactured by OMRON.

PLC A Programmable Logic Controller manufactured by OMRON.

Host A PLC, factory computer, personal computer or other controller controlling an NS-

series PT.

NS-Designer The NS-NSDC1-V@NS-Designer produced by OMRON. The NS-Designer is an

applications software package that enables creating screen data for NS-series PTs.

CX-One The CXONE-AL@@C-V3/AL@@D-V3 CX-One FA Integrated Tool Package produced

by OMRON. This applications software package provides all of the software packages

for OMRON PLCs and components.

CX-Designer The NS-CXDC1-V3 CX-Designer produced by OMRON.

NS-Runtime The NS-Runtime software runs on Windows XP and provides the same functionality

as an NS-series PT.

OMRON, 2008

by any means, mechanical, electronic, photocopying, recording, or otherwise, without the prior written permission o

OMRON.

No patent liability is assumed with respect to the use of the information contained herein. Moreover, because OMRON is con-

stantly striving to improve its high-quality products, the information contained in this manual is subject to change without

notice. Every precaution has been taken in the preparation of this manual. Nevertheless, OMRON assumes no responsibility

for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained in

this publication.

vii

TABLE OF CONTENTS

SECTION 1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

1-1 Features of the CX-Designer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

1-2 Basic Operation Procedures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

SECTION 2

Setting Up the CX-Designer. . . . . . . . . . . . . . . . . . . . . . . . . . 11

2-1 Preparations for Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2-2 Installing the CX-Designer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

2-3 Uninstalling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

2-4 Installing USB Drivers for NS-Series PTs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

SECTION 3

Basic Operations of the CX-Designer . . . . . . . . . . . . . . . . . . 21

3-1 Starting and Exiting CX-Designer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

3-2 Menu Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

3-3 User Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

SECTION 4

Useful Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

4-1 Creating Screens Using Symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

4-2 Using Screens from Other Projects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

4-3 Classifying Screens by Application. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

4-4 Checking and Changing Functional Object Properties

without Opening Property Setting Dialog Boxes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

4-5 Listing and Editing Functional Object Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

4-6 Editing Overlapping Objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

4-7 Creating Multi-language Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

4-8 Checking Address Usage Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

4-9 Searching for Embedded Macros. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

4-10 Transferring Only Edited Data to PT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

4-11 Creating Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

4-12 How to Use Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

4-13 Integrated Simulation for the Entire System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

4-14 Setting Security for Data Transfers with the PT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

4-15 Setting Symbol Names and I/O Comments for Use as Labels . . . . . . . . . . . . . . . . . . . . . . . 63

4-16 Executing Multiple Functions with a Single Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

4-17 Replacing a Lamp with a Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

4-18 Creating Polygonal Lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69

4-19 Registering Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

4-20 Using Machine Navigator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73

4-21 Enlarging Objects Proportional to Screen Size during Data Conversion . . . . . . . . . . . . . . . 77

4-22 Batch-setting Label Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78

viii

TABLE OF CONTENTS

Appendices

A Comparison of Functions with NS-Designer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

B Shortcut Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

C Exchanging Data between NS-series Products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

About this Manual:

The CX-Designer is a software package that enables creating screens for OMRON Programmable Ter-

minals. Please be sure you understand the functions and performance of the CX-Designer to ensure

correct application of the Programmable Terminals.

Please read this manual and related manuals carefully and be sure you understand the information

provided before attempting to use the CX-Designer.

Section 1 provides an overview of the CX-Designer and its features and explains basic operating

methods.

Section 2 describes how to install and uninstall the CX-Designer.

Section 3 describes the CX-Designer menus and basic procedures.

Section 4 describes convenient functions of the CX-Designer.

The Appendices provide a comparison between the CX-Designer and NS-Designer, tables of short-

cut keys, and data transfer procedures between different versions of NS-series PT.

!WARNING Failure to read and understand the information provided in this manual may result in per-

sonal injury or death, damage to the product, or product failure. Please read each section

in its entirety and be sure you understand the information provided in the section and

related sections before attempting any of the procedures or operations given.

Guide to Version Upgrade

From CX-Designer Version 1.0 to Version 2.0

Item Previous versions New version

CX-Designer Version 1.0 (NS-CXDC1-V1) Version 2.0 (NS-CXDC1-V2)

NS system software Version 6.2 or 6.5 Version 6.6

Integrated simulation The only function available was simulated

testing of PT screen operations on a per-

sonal computer.

Using a personal computer, a virtual PT

can be connected to a virtual PLC (CX-

Simulator) or to an actual PLC, and the

operation of the entire PT-PLC system can

be simulated. This makes it possible to

reduce the total time involved in debugging.

Symbol programming without

addresses

Symbol names, addresses, and comments

were entered in symbol tables. Then the

required symbols were selected from the

symbol tables when creating screens.

Symbol names and comments can be input

for symbol tables with no addresses. This

allows screens to be created using symbol

names without inputting addresses. Enter-

ing symbols in screen designs without

addresses makes it possible to reduce the

total time involved in design.

Multi-vendor connectivity Not supported. It is now possible to connect OMRON NS-

series PTs to Mitsubishi FX-series PLCs,

A-series PLCs, and Siemens S7-series

PLCs.

Data security The following two types of data transfers

are possible between CX-Designer (run-

ning on a personal computer) and a PT:

•Data transfers with the PT.

•With data transfers using a Memory Card,

data can be uploaded and downloaded by

any user.

A password can now be set for creating

data. When data with a set password is

transferred to a PT, the password is then

required in order to upload the data. This

prevents users who do not know the pass-

word from obtaining that data from the PT.

In addition, a password can be required to

transfer data to the PT. This prevents data

from being accidentally overwritten.

User security Any of five levels of passwords could be set

for each functional object. A dialog box ask-

ing for the password was displayed each

time an attempt was made to use a func-

tional object for which a password had

been set, and the object could not be used

unless the password was input.

Once a user inputs the password to use a

functional object for which a password has

been set, the password does not have to be

input again as long as the user continues

using only functional objects for which

lower level passwords have been set. Func-

tional objects with a higher-level password

cannot be manipulated. (A warning mes-

sage will be displayed if an attempt is

made.) This makes it possible to create

applications that permit only the necessary

operations by users who have entered

passwords, and thus helps prevent faulty

operations.

Consecutive line drawing Not available. Data in memory is treated as X and Y coor-

dinates, and straight lines are drawn

between the applicable coordinates to cre-

ate consecutive line drawing. This makes it

possible to handle applications involving

the drawing of various graphics in two-

dimensional space that could not be drawn

using the existing graph components.
