Omron CJ2 - 02-2010 Manuel utilisateur

Cat. No. W473-E1-06

CJ2 CPU Unit Software

SYSMAC CJ Series

CJ2H-CPU6_-EIP

CJ2H-CPU6_

CJ2M-CPU_

USER’S MANUAL

OMRON, 2008

by any means, mechanical, electronic, photocopying, recording, or otherwise, without the prior written permission of

OMRON.

No patent liability is assumed with respect to the use of the information contained herein. Moreover, because OMRON is con-

stantly striving to improve its high-quality products, the information contained in this manual is subject to change without

notice. Every precaution has been taken in the preparation of this manual. Nevertheless, OMRON assumes no responsibility

for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained in

this publication.

SYSMAC CJ Series

CJ2H-CPU6@-EIP

CJ2H-CPU6@

CJ2M-CPU@@

CJ2 CPU Unit Software

User’s Manual

Revised February 2010

CJ2 CPU Unit Software User’s Manual

Introduction

Thank you for purchasing a CJ-series CJ2H-CPU6@(-EIP) or CJ2M-CPU@@ Programmable Controller.

This manual contains information required to use the CJ2H-CPU6@(-EIP) or CJ2M-CPU@@. Please

thoroughly read and understand this manual before you use the CJ2H-CPU6@(-EIP) or CJ2M-CPU@@.

This manual is intended for the following personnel, who must also have knowledge of electrical sys-

tems (an electrical engineer or the equivalent).

• Personnel in charge of installing FA systems

• Personnel in charge of designing FA systems.

• Personnel in charge of managing FA systems and facilities.

CJ-series CJ2 CPU Units

• CJ2H-CPU6@-EIP

• CJ2H-CPU6@

•CJ2M-CPU3@

•CJ2M-CPU1@

In this manual, the following notation is used to indicate the CPU Units.

• CJ2H-CPU6@(-EIP): Indicates the CJ2H-CPU6@-EIP and CJ2H-CPU6@CPU Units.

• CJ2M-CPU@@: Indicates the CJ2M-CPU3@and CJ2M-CPU1@CPU Units.

Intended Audience

Applicable Products

CJ2 Series

CJ1H-CPU@@H-R

CJ1H-CPU@@H

CJ1G-CPU@@H

CJ1G -CPU@@P

(Loop CPU Units)

CJ1-H CPU Units

CJ1 CPU Units

CJ1G-CPU@@

CJ1M CPU Units

CJ1M-CPU@@

CJ-series Power Supply Units

CJ-series Basic I/O Units

CJ-series CPU Bus Units

CJ-series Special I/O Units

CS1H-CPU@@H

CS1G-CPU@@H

CS1-H CPU Units

CS-series Power Supply Units

CS-series Basic I/O Units

CS-series CPU Bus Units

CS-series Special I/O Units

CS Series

CS1 CPU Units

CS1H-CPU@@(-V)

CS1G-CPU@@(-V)

CS1D CPU Units

for Duplex Systems

CS1D-CPU@@H

CS1D-CPU@@S

CS1D-CPU@@P

NSJ5-TQ@@(B)-G5D

NSJ5-SQ@@(B)-G5D

NSJ8-TV@@(B)-G5D

NSJ10-TV@@(B)-G5D

NSJ12-TS@@(B)-G5D

NSJ Controllers

NSJ-series Expansion Units

NSJ Series

NSJ5-TQ@@(B)-M3D

NSJ5-SQ@@(B)-M3D

NSJ8-TV@@(B)-M3D

NSJ Controllers

CJ2H-CPU6@-EIP

CJ2H-CPU6@

CS1D CPU Units

for Simplex Systems

CS1D Process-control CPU Units

Note: A special Power Supply Unit must

be used for CS1D CPU Units.

CJ2 CPU Units

CJ2H CPU Units

CJ2M CPU Units

CJ2M-CPU3@

CJ2M-CPU1@

2CJ2 CPU Unit Software User’s Manual

CJ2 CPU Unit Manuals

Information on the CJ2 CPU Units is provided in the following manuals. Refer to the appropriate manual

for the information that is required.

Wiring

This Manual

Mounting

and Setting

Hardware

Connecting

Online to

the PLC

Software

Setup

Creating the

Program

Checking

and

Debugging

Operation

Maintenance

and

Troubleshooting

Error codes and

remedies if a problem

occurs

CJ-series CJ2 CPU Unit

Hardware User’s Manual

(Cat. No. W472)

CJ-series CJ2 CPU Unit

Software User’s Manual

(Cat. No. W473)

• Unit part names and

specifications

• Basic system

configuration

• Unit mounting

procedure

• Setting procedure for

DIP switch and rotary

switches on the front of

the CPU Unit

For details on built-in

EtherNet/IP port, refer to

the EtherNet/IP Unit

Operation Manual (W465)

• Wiring the Power

Supply Unit

• Wring Basic I/O Units

and external I/O

devices

CX-Programmer Support

Software Connecting

Cables

Procedures for connecting

the CX-Programmer

Support Software

Software setting methods for the

CPU Unit (including I/O memory

allocation, PLC Setup settings,

Special I/O Unit parameters,

CPU Bus Unit parameters, and

routing tables.)

For details on built-in EtherNet/IP

port, refer to the EtherNet/IP Unit

Operation Manual (W465).

• Program types and basic

information

• CPU Unit operation

• Internal memory

• Data management using

file memory in the CPU

Unit

• Built-in CPU functions

• Settings

• Checking I/O wiring, setting the

Auxiliary Area settings, and

performing trial operation

• Monitoring and debugging with

the CX-Programmer

Detailed information

on programming

instructions

CS/CJ/NSJ Series

Instructions Reference

Manual (Cat. No. W474)

CJ2 CPU Unit Software User’s Manual

The CJ2 CPU manuals are organized in the sections listed in the following tables. Refer to the appropri-

ate section in the manuals as required.

Manual Configuration

Hardware User’s Manual (Cat. No. W472)

Section Content

Section 1 Overview This section gives an overview of the CJ2 CPU Units and describes the features and

specifications.

Section 2 Basic System Configu-

ration and Devices This section describes the system configuration for the CJ2 CPU Unit.

Section 3 Nomenclature and

Functions This section describes the part names and functions of the CPU Unit and Configuration

Units.

Section 4 Support Software This section describes the types of Support Software to use to perform programming and

debugging and how to connect the PLC to the Support Software.

Section 5 Installation This section describes the installation locations and how to wire CPU Units and Configu-

ration Units.

Section 6 Troubleshooting This section describes how to check the status for errors that occur during system opera-

tion and the remedies for those errors.

Section 7 Inspection and Mainte-

nance This section describes periodic inspection, the service life of the Battery and Power Sup-

ply Unit, and how to replace the Battery.

Section 8 Backup Operations This section describes the procedure to back up PLC data.

Appendices

The appendices provide Unit dimensions, details on fatal and non-fatal errors, informa-

tion on connecting to serial ports on the CPU Unit, the procedure for installing the USB

driver on a computer, and information on load short-circuit protection and line disconnec-

tion detection.

Software User’s Manual (Cat. No. W473) (This Manual)

Section Content

Section 1 Overview This section gives an overview of the CJ2 CPU Units and describes the features and

specifications.

Section 2 Internal Memory in the

CPU Unit This section describes the types of memory in the CPU Unit and the data that is stored.

Section 3 CPU Unit Operation This section describes the internal operation of the CPU Unit.

Section 4 CPU Unit Initialization This section describes the initial setup of the CPU Unit.

Section 5 Understanding Pro-

gramming This section describes program types and programming details, such as symbols and

programming instructions.

Section 6 I/O Memory Areas This section describes the I/O memory areas in the CPU Unit.

Section 7 File Operations This section describes the files that can be stored in the CPU Unit, the storage destina-

tion for those files, and file operations.

Section 8 I/O Allocations and

Unit Settings This section describes the I/O allocations used to exchange data between the CPU Unit

and other Units.

Section 9 PLC Setup This section describes details on the PLC Setup settings, which are used to perform

basic settings for the CPU Unit.

Section 10 CPU Unit Functions This section describes functions that are built into the CPU Unit.

Section 11 Programming Devices

and Communications This section describes the procedure for connecting the CJ2 CPU Unit to the CX-Pro-

grammer or other Support Software and to other devices.

Section 12 CPU Unit Cycle Time This section describes how to monitor and calculate the cycle time.

Appendices

The appendices provide information on programming instructions, execution times, num-

ber of steps, Auxiliary Area words and bits, a memory map of the continuous PLC mem-

ory addresses, I/O memory operation when power is interrupted, and a comparison of

CJ-series and CS-series PLCs.

4CJ2 CPU Unit Software User’s Manual

Instructions Reference Manual (Cat. No. W474)

Section Content

Section 1 Basic Understanding

of Instructions This section provides basic information on designing ladder programs for a CS/CJ/NSJ-

series CPU Unit.

Section 2 Summary of Instruc-

tions This section provides a summary of instructions used with a CS/CJ/NSJ-series CPU

Unit.

Section 3 Instructions This section describes the functions, operands and sample programs of the instructions

that are supported by a CS/CJ/NSJ-series CPU Unit.

Section 4 Instruction Execution

Times and Number of Steps This section provides the instruction execution times for each CS/CJ/NSJ-series CPU

Unit instruction.

Appendices The appendices provide a list of instructions by function code and by mnemonic and an

ASCII table for the CS/CJ/NSJ-series CPU Units.

CJ2 CPU Unit Software User’s Manual

Manual Structure

The following page structure is used in this manual.

Special information in this manual is classified as follows:

Page Structure

Special Information

Precautions for Safe Use

Precautions on what to do and what not to do to ensure using the product safely.

Precautions for Correct Use

Precautions on what to do and what not to do to ensure proper operation and performance.

Additional Information

Additional information to increase understanding or make operation easier.

Level 1 heading

Level 2 heading

Level 3 heading

Level 2 heading

A step

in a procedure

Manual name

Level 3 heading

Page tab

Gives the current

headings.

Gives the number

of the section.

This illustration is provided only as a sample and may not literally appear in this manual.

Special Information

(See below.)

5-13

5 Installation

CJ2 CPU Unit Hardware User’s Manual

noitallatsnI2-5

stnen

opmoCCL

gnitcennoC1-2-5

5-2 Installation

The Units that make up a CJ-series PLC can be connected simply by pressing the Units together and

locking the sliders by moving them toward the back of the Units. The End Cover is connected in the

same way to the Unit on the far right side of the PLC.

1. Join the Units so that the connectors fit exactly.

2. The yellow sliders at the top and bottom of each Unit lock the Units together. Move the sliders

toward the back of the Units as shown below until they click into place.

Precautions for Correct UsePrecautions for Correct Use

If the locking tabs are not secured properly, the connectors may become loose and not function

properly. Be sure to slide the locking tabs until they are securely in place.

5-2-1 Connecting PLC Components

Connector

Hook Hook holes

Slider

Lock

Release

Move the sliders toward the back

until they lock into place.

6CJ2 CPU Unit Software User’s Manual

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Omron Logiciel

Omron

Omron NS-CXDC1-V3 Manuel utilisateur

Omron

Omron CX-Supervisor Manuel utilisateur

Omron

Omron NS-CXDC1-V3 Manuel utilisateur

Omron

Omron CX-MOTION-MCH Manuel utilisateur

Omron

Omron CX-Supervisor Manuel utilisateur

Omron

Omron WS02-LCTC1-E - V2.60 REV 12-2003 Manuel utilisateur

Omron

Omron CX-MOTION-NCF - V1.8 Manuel utilisateur

Omron

Omron CX-SUPERVISOR - V2.0 Manuel utilisateur

Omron

Omron CX-SUPERVISIOR - GETTING STARTED V2.0 Manuel utilisateur

Omron

Omron NS-CXDC1-V1 Manuel utilisateur

Omron

Omron SYSMAC WS02-NSFC1-E Guide de l'utilisateur

Omron

Omron NT - SUPPORT TOOL FOR WINDOWS V4 Manuel utilisateur

Omron

Omron CX-SUPERVISOR - SCRIPT REFERENCE REV2.0 Manuel utilisateur

Omron

Omron WS02-CXPC1-V9 - V9 Manuel utilisateur

Omron

Omron FLEXXPECT-PHARMA Manuel utilisateur

Omron

Omron MCH Manuel utilisateur

Omron

Omron CJ2 CPU - REV 10-2010 Manuel utilisateur

Omron

Omron CX-SUPERVISOR 3.1 - NET INTERFACE Manuel utilisateur

Omron

Omron ZEN-SOFT01-V4 - 12-2008 Manuel utilisateur

Omron

Omron WS02-SIMC1-E - V1.9 REV 12-2009 Manuel utilisateur

Omron

Omron WS02-SIMC1-E - V1.9 REV 02-2009 Manuel utilisateur

Omron

Omron THERMOTOOLS Manuel utilisateur

Omron

Omron CX-DESIGNER V2.1 - 07-2007 Manuel utilisateur

Omron

Omron CX-PROCESS TOOL V5.2 - 12-2009 Manuel utilisateur

Manuels Logiciel populaires d'autres marques

COMPRO

COMPRO COMPROFM Manuel utilisateur

Muratec

Muratec OFFICEBRIDGE ONLINE Manuel utilisateur

Oracle

Oracle Contact Center Anywhere 8.1 Manuel utilisateur

Adobe

Adobe 65007312 - Photoshop Lightroom Manuel

Avaya

Avaya NULL One-X for RIM Blackberry Manuel utilisateur

HP ProLiant BL420c Manuel utilisateur

PS Audio

PS Audio PowerPlay Manuel du propriétaire

Brady

Brady LOCKOUT PRO 3.0 Manuel de service

Avaya

Avaya Interaction Center Manuel utilisateur

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manuel

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manuel utilisateur

Oracle

Oracle Application 9i Manuel utilisateur

Acer

Acer RDM Manuel utilisateur

Canon

Canon Vixia HF21 Manuel utilisateur

Canon

Canon ZR950 Manuel utilisateur

Samsung

Samsung Auto Backup Manuel utilisateur

Polycom

Polycom Vortex EF2201 Instructions d'installation et d'utilisation

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manuel utilisateur
