STC-HD853HDMI

Product specifications and User’s guide 1/81

16:9 Format 2160p (4K UHDTV)

Color CMOS Camera

STC-HD853HDMI

Product Specifications and User’s guide

No. 17S142-00

STC-HD853HDMI

Product specifications and User’s guide 2/81

Table of Contents

1 Product Precautions ............................................................................................ 6

2 Warranty ................................................................................................................ 6

3 Introduction .......................................................................................................... 7

3.1 Features .................................................................................................................................... 7

3.2 Peripheral Equipment .............................................................................................................. 7

4 Specifications ....................................................................................................... 8

4.1 Electronic Specifications ......................................................................................................... 8

4.2 Spectral Sensitivity Characteristics ..................................................................................... 10

STC-HD853HDMI ............................................................................................................................. 10

IR Cut Filter ..................................................................................................................................... 10

4.3 Mechanical Specifications ..................................................................................................... 11

4.4 Environmental Specifications ............................................................................................... 11

4.5 External Control Specification .............................................................................................. 11

5 Dimensions ......................................................................................................... 12

6 Camera instruction guide .................................................................................. 13

6.1 Push Button ............................................................................................................................ 13

6.2 External Switch (Remote Controller) .................................................................................... 14

Camera Setting through Switch that has 3.5φStereo Pin Jack .................................................... 14

Menu on screen with External Switch ........................................................................................... 15

7 Control Software User’s Guide.......................................................................... 27

7.1 System Requirements ............................................................................................................ 27

7.2 Basic Operating Procedure ................................................................................................... 27

7.3 Button Descriptions ............................................................................................................... 28

7.4 The Difference of uCOM register and DSP register ............................................................. 28

No. 17S142-00

STC-HD853HDMI

Product specifications and User’s guide 3/81

7.5 Functional Description........................................................................................................... 29

8 The communication protocol specifications .................................................... 57

8.1 Communication settings........................................................................................................ 57

8.2 Communication format .......................................................................................................... 57

8.3 Camera control commands ................................................................................................... 58

The command list for the communication .................................................................................... 58

Slave address for the ICs (8 bits) list ............................................................................................. 60

Error code list ................................................................................................................................. 60

8.4 uCOM register mapping list ................................................................................................... 61

Push button function for OSD ........................................................................................................ 67

Push button function list ................................................................................................................ 67

8.5 DSP register mapping list ...................................................................................................... 68

8.6 OSCD (On Screen Character Display) Command ................................................................ 78

2 Bytes Command ........................................................................................................................... 78

2 Bytes consecutive Command ..................................................................................................... 79

9 Revisions ............................................................................................................ 80

No. 17S142-00

STC-HD853HDMI

Product specifications and User’s guide 4/81

Precautions for safe use

Please read carefully this “Precautions for safe use” before use the camera. Then the camera uses correctly with

agreeing with below notes.

In this “Precautions for safe use”, notes divides into “Warning” and “Caution” to use the camera safety and prevent to

harm and damage.

Warning This shows, assumption for possibility of serious accident leading death or

serious injury if ignore this note and camera uses incorrectly.

Caution This shows, assumption for possibility of bear the damage or physical

damage if ignore this note and camera uses incorrectly.

About Graphic

symbols

This symbol shows general prohibition.

This symbol shows completion or instruction.

[Environment / condition]

Warning

Do not use flammable or explosiveness

atmospheres.

This will cause of personal injury or fire.

Do not use for “safety for human body” related

usage.

This camera is designed for use “do not harm

human body immediately” if by any chance the

camera has malfunction.

Caution

Use and store under specified environmental

conditions (Vibration, shock, temperature,

humidity) in the specifications for this camera.

This will cause of fire or damage the camera.

[Installation and cable wiring]

Warning

Do not use with out of power voltage range

that is specified in the specifications for this

camera.

This will cause of fire, electrification or

malfunction.

Do not wrong wiring.

This will cause of fire or malfunction.

No. 17S142-00

STC-HD853HDMI

Product specifications and User’s guide 5/81

Caution

The camera housing is not connecting to 0 V

Line of camera inside circuit.

There is a risk of short circuit between camera

inside ciurcuit and frame ground through other

devices.

This will cause of malfunction.

It is necessary to wiring and mounting that is

specified in the specifications for this camera.

This will cause of fire or malfunction.

It is necessary to wiring with turn off the camera.

This will cause of electrification or malfunction.

It is necessary to mounting the camera without

stress for the cable.

This will case of electrification or fire.

[Usage instruction]

Warning

Do not touch the terminal and PCB board

While turn on the camera.

This will cause of electrification or accident

caused by malfunction.

Do not put combustibles near the camera.

This will cause of fire.

Do not use without usage that is specified in

the specifications for this camera.

This will cause of personal injury or malfunction.

Do not push metals including screw driver into

radiation holes.

This will cause of electrification or malfunction.

Caution

Do not push contamination into opening of

the camera.

This will cause of electrification or malfunction.

Do not block the radiation holes.

This will cause of fire due to increase the

camera inside temperature.

[Maintenance]

Caution

Do not disassemble or repair the camera.

This will cause of fire, electrification or

malfunction.

It is turn off the camera when maintaining or

inspecting the camera.

This will cause of electrification.

[Disposal]

Caution

It is necessary to dispose as industrial waste.

]

No. 17S142-00

STC-HD853HDMI

Product specifications and User’s guide 6/81

1 Product Precautions

 Do not give shock to the camera.

 Do not haul or damage the camera cable.

 Do not wrap the camera with any material while using the camera. This will cause the internal camera

temperature to increase.

 When the camera moving or using the place that temperature difference is extreme, countermeasure for dew

condensation (heat removal / cold removal) is necessary.

 While the camera is not using, keep the lens cap on the camera to prevent dust or contamination from getting

in the sensor or filter and scratching or damaging it.

Do not keep the camera under the following conditions.

・ In wet, moist, high humidity or dusty place

・ Under direct sunlight

・ In extreme high or low temperature place

・ Near an object that releases a strong magnetic or electric filed

・ Place with strong vibrations

 Apply the power that satisfies the specified in specifications for the camera.

 The defective pixels may appear due to the sensor characteristics.

 Use below recommend materials (or equivalent materials) to clean the surface of glass.

・ Air dust: Non Freon air duster (NAKABAYASHI Co., LTD.)

・ Alcohol: Propan-2-ol (SAN’EI KAKO Co., LTD.)

・ Non-woven: nikowipe clean room (NKB)

 Use a soft cloth to clean the camera.

2 Warranty

■Warranty period

One year after delivery (However, the camera had malfunction with camera uses correctly)

In below case for a fee even within warranty period.

・The malfunction caused by incorrect usage, incorrect modify or repair.

・The malfunction caused by external shock including the camera dropping after delivery the camera.

・The malfunction caused by fire, earthquake, flood disaster, thunderbolt struck, other natural disaster or

wrong voltage.

■Warranty coverage

Exchange or repair the malfunction camera if the malfunction is occurred by our responsibility.

“Warranty” mean is warranty for the delivered camera itself. Please accept the induction damage by the

camera malfunction is not included.

No. 17S142-00

STC-HD853HDMI

Product specifications and User’s guide 7/81

3 Introduction

This document describes the specification of the following camera:

STC-HD853HDMI

3.1 Features

 2160p or 1080p output is selectable

 HDMI Output

 CMOS rolling shutter

 C mount

 OSCD (On Screen Character Display) through Remoter Controller (Option)

 Configurable many parameters through Control Software

 Eight configurable DSP can be saved

 Defective Pixel Correction (KPACtrl is required)

3.2 Peripheral Equipment

OMRON SENTECH provides as follow peripheral equipment as option.

(1) +12V DC Power Supply: UN310-1210

(2) Remote Controller: RC-HD133

(3) Communication Tool (PC can communicate through USB port): JIG-USB-HD

(4) Control Software: KPACtrl

(1) (2) (3)

No. 17S142-00

STC-HD853HDMI

Product specifications and User’s guide 8/81

4 Specifications

4.1 Electronic Specifications

Product STC-HD853HDMI

Image Sensor 1/2.5" 8.51M Progressive CMOS (SONY)

Shutter Type Rolling shutter

Active Picture Elements 3,840 (H) x 2,160 (V) (QFHD),

1,920 (H) x 1,080 (V) (Full HD)

Chip Size 8.365 (H) x 6.615 (V) mm

Cell Size 1.62 (H) x 1.62 (V) µm

Sensitivity 1,070 Lux (*1)

Sync. System Internal

Video output HDMI (RGB 8bit 4:4:4)

2160P59.94 / 2160P60 / 2160P50 / 2160P29.97 / 2160P30 / 2160P25,

1080P59.94 / 1080P60 / 1080P50 / 1080P119.88 /1080P120 / 1080P100

(Default: Auto) (*2)

Camera Functions

ALC ALC mode (auto electronic shutter and AGC) is configurable via UART communication

(Default: ALC ON)

Shutter Speed Auto shutter or Fixed shutter selectable via UART communication (Default: Auto)

2160P59.94: 1/21737.3 seconds (46.0 μseconds) to 1/60.2 seconds (16.62 mseconds),

2160P60: 1/21737.3 seconds (46.0 μseconds) to 1/60.2 seconds (16.62 mseconds),

2160P50: 1/18218.6 seconds (54.9 μseconds) to 1/50.1 seconds (19.95 mseconds),

2160P29.97: 1/10959.9 seconds (91.2 μseconds) to 1/30.1 seconds (33.25 mseconds),

2160P30: 1/10959.9 seconds (91.2 μseconds) to 1/30.1 seconds (33.25 mseconds),

2160P25: 1/9173.1 seconds (109.0 μseconds) to 1/25.1 seconds (39.90 mseconds),

1080P59.94: 1/31266.9 seconds (32.0 μseconds) to 1/60.2 seconds (16.61 mseconds),

1080P60: 1/31266.9 seconds (32.0 μseconds) to 1/60.2 seconds (16.61 mseconds),

1080P50: 1/26383.3 seconds (37.9 μseconds) to 1/50.2 seconds (19.93 mseconds),

1080P119.88: 1/61071.4 seconds (16.4 μseconds) to 1/120.4 seconds (8.31 mseconds),

1080P120: 1/61071.4 seconds (16.4 μseconds) to 1/120.4 seconds (8.31 mseconds),

1080P100: 1/51724.1 seconds (19.3 μseconds) to 1/100.3 seconds (9.97 mseconds)

Gain AGC or Fixed gain selectable via the UART communication

0 to 27 dB

Gamma 8 preset gamma can be selectable (Manual / 0.30 / 0.45 / 0.50 / 0.60 / 0.70 / 0.80 / 0.90 / 1.00)

Gamma is selectable via UART communication (Default: Manual)

White Balance Auto white balance / manual white balance / push to set white balance

White balance is selectable via the UART communication (Default: Auto white balance)

Mirror Image Normal image / horizontal flip / vertical flip / horizontal vertical flip (180 deg. rotation)

(Default: Normal image)

DSP Preset Selectable 8 user preset modes can be selectable

User preset mode is selectable via UART communication (Default: Preset 0)

Line Generator Both horizontal and vertical with all available colors (Line number: 2)

Color, thickness and position for individual line are adjustable via UART communication

(Default: Disable)

Communication +3.3V UART communication via Φ 3.5 mm stereo jack

(Baud rate: 38,400 bps, 19,200 bps, 9,600 bps) (Default: 38,400 bps)

Character Generator Built-in character generation function via UART communication

Defective Pixel Correction

Up to 512 points (Default: ON)

Power Input voltage +9 to +15 Vdc (Typical: +12 Vdc)

Consumption 6.0 W

No. 17S142-00

STC-HD853HDMI

Product specifications and User’s guide 9/81

Precautions

(*1) The sensitivity is measuring the luminance when white level achieved 100 % in below conditions.

(*2) When selecting “Auto” at video output, video output format is selecting automatically based on connected

monitor supported format.

e.g. If the monitor supports up to 2160P30, video output format of camera selects 2160P30 automatically.

Camera Setting Environment

Parameter Setting Parameter Setting

Gain Up 0 dB Light Source Light Box (White)

AGC Off Color temperature

5,100K

White Balance Optimum Lens

Electrical Shutter

1/30 seconds F on Lens F5.6

Black Level Optimum Target Luminance

IM-600 (Topcon)

Gamma Factory Setting

No. 17S142-00

STC-HD853HDMI

Product specifications and User’s guide 10/81

4.2 Spectral Sensitivity Characteristics

STC-HD853HDMI

IR Cut Filter

Wave Length (nm)

Transmittance

(%)

Spectrum Transmittance (Reference)

Table des matières

Autres manuels Omron Appareil photo numérique

Omron

Omron FQ2-S4 Manuel utilisateur

Omron

Omron STC-MBS202POE Instructions d'installation

Omron

Omron STC-MBS322U3V Instructions d'installation

Omron

Omron CoaXPress STC-LBGP251BCXP124 Instructions d'installation

Omron

Omron STC-MBA1002POE Instructions d'installation

Omron

Omron STC-LBS132CL-SWIR Instructions d'installation

Omron

Omron STC-SBA503POE Instructions d'installation

Omron

Omron FZ-SQ100N Manuel utilisateur

Omron

Omron STC-MBE132U3V Instructions d'installation

Omron

Omron FZ-SF Manuel utilisateur

Omron

Omron STC-SBE132POE Instructions d'installation

Omron

Omron Sysmac FHV Series Guide de l'utilisateur

Omron

Omron STC-LBS34U3V-SWIR Instructions d'installation

Omron

Omron FS-C4KU7DGES-F Instructions d'installation

Omron

Omron FH-SM02 Manuel utilisateur

Omron

Omron FHV Series Guide de l'utilisateur

Omron

Omron STC-MBS2041POE Instructions d'installation

Omron

Omron Sysmac F430-F Series Mode d’emploi

Omron

Omron STC-BBS2041POE-BC Instructions d'installation

Omron

Omron STC-OSB250CL Instructions d'installation

Omron

Omron MicroHAWK F320-F Manuel utilisateur

Omron

Omron STC-S133 Series Manuel utilisateur

Omron

Omron STC-SBS312POE Instructions d'installation

Omron

Omron STC-MBS202POE-BPF Instructions d'installation

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
