Instruction manual

OLYMPUS LC35

Digital Microscope Camera

Optical Microscope Accessory English

Contents

1 Safety 4

1.1 Intended use 4

1.2 Avoiding personal injury and device damage 4

1.3 Explanation of the symbols used 6

2 The OLYMPUS LC35 camera 7

2.1 Scope of supply 7

2.2 System diagram 8

2.3 LED status indication 9

2.4 Specifications 10

2.5 Operating and storage conditions 11

3 System environment 12

3.1 Microscope and camera adapter 12

3.2 Recommended computer and monitor configuration 13

3.3 Restrictions on use 13

4 Assembly 15

4.1 Attaching the camera 15

4.2 Connecting the USB camera cable 16

4.3 Installing the software 17

5 Acquiring images 18

6 Cleaning the camera 19

7 Troubleshooting 20

7.1 Possible problems 20

7.2 Contacting Customer Service 24

8 Declarations of conformity and notes on disposal 25

AdressSticker_08042022 29

About the camera

The OLYMPUS LC35 is a CMOS color camera with a high frame rate.

It was developed for acquisitions using light microscopy. The camera

can be connected to all common types of light microscopes using a

C-mount.

About this instruction manual

This instruction manual is for the OLYMPUS LC35 microscope digital

camera.

Information about the operation of the microscope, computer or

software can be found in the instruction manuals for the

corresponding device or software.

Trademark

Microsoft and Windows are registered trademarks of Microsoft

Corporation, USA. All other brand names and product names

mentioned in this manual are registered trademarks or trademarks

of their respective owners.

1 Safety

The camera has been developed and produced in conformity with

recognized safety regulations. However, it is not possible to entirely

rule out possible hazards for the user, damage to the camera or

microscope, or impairments of the camera's functionality. For this

reason, always read and follow the general safety instructions and

warnings before and during installation.

1.1 Intended use

This camera is intended to be used for the acquisition of digital

images, but not for medical diagnostic purposes.

1.2 Avoiding personal injury and device damage

WARNING - Avoiding personal injury

Electric shock due to damaged cable

When a cable is frayed or damaged, a person touching it risks

receiving an electric shock. Shut off the hardware and replace the

cable immediately.

Poisoning due to toxic gases

In the event of a fire, the material of the camera can give off toxic

gases. When these are inhaled, it can cause irritation or damage to

the respiratory tract. Wear respiratory protection when fighting the

fire.

OLYMPUS LC35

CAUTION - Avoiding personal injury

Tripping hazard

Cables laid across a room can be a dangerous tripping hazard. This

can cause injuries to people and damage to equipment. Wherever

possible, lay cables along the wall or behind furniture. Fix and label

cables that run across the room.

ATTENTION - Avoiding device damage

Never open the camera

The camera's CMOS chip is extremely sensitive. Electrostatic

discharge can permanently damage the camera. Therefore, never

open the camera housing.

Use only the supplied USB camera cable

Operate the camera only with the supplied USB camera cable. Only

then will the functionality of the camera and compliance with the

EMC basic standards be ensured.

Don't touch the protective glass

The protective glass over the CMOS chip is extremely sensitive and

must not come into contact with bare hands or any other objects,

otherwise the acquired images will be impaired by fingerprints or

scratches.

Avoid vibration shocks

Mechanical shocks and strong vibrations can damage the camera.

Don't drop the camera during assembly. Make sure the camera is

securely mounted on the microscope. When the camera is not in

use, store it in a safe place.

1 Safety

Comply with operating and storage conditions

Exposure to high temperatures or humidity can damage component

parts of the camera. Always observe the operating and storage

conditions (see page 11).

1.3 Explanation of the symbols used

WARNING

Indicates a potentially hazardous situation which, if not avoided, may

result in major injury.

CAUTION

Indicates a potentially hazardous situation which, if not avoided, may

result in minor or moderate injury.

ATTENTION

Indicates a situation which, if not avoided, may damage the

equipment or other property.

OLYMPUS LC35

2 The OLYMPUS LC35 camera

2.1 Scope of supply

Camera

USB camera cable

Safety and warning

information

A printed copy of the safety and warning information are supplied

with the camera.

2 The OLYMPUS LC35 camera

The complete instruction manual is available for download. You can

download the manual from the following web pages

https://www.olympus-lifescience.com/support/instruction-manual-

downloads/

https://www.olympus-ims.com/user-manuals/

2.2 System diagram

To use the OLYMPUS LC35 with a light microscope, you need

suitable software and a computer as well as a monitor. For the

recommended computer and monitor configuration, refer to page

13.

You can use the following Olympus software applications:

Software application Minimum version

cellSens* Life science image analysis

software 3.2

OLYMPUSStream* Image analysis software 2.5

OLYMPUS LC35

Software application Minimum version

PRECiV* Image and measurement

software 1.1

DP2-TWAIN** Free image acquisition software 10.2

LCmicro** Free image acquisition software 2.3

* Perform the available service updates.

** This software is available only as a download from the following

web pages.

https://www.olympus-lifescience.com/support/downloads

https://www.olympus-ims.com/service-and-support/downloads

2.3 LED status indication

There is an LED on the camera which indicates the following

statuses.

LED Status

The LED flashes green. The camera is being initialized.

The LED lights up

continuously green.

The camera is successfully connected to the

USB 3.1 port.

The LED flashes red/orange. There is a camera error. Contact Customer

Service (see page 24).

The LED lights up orange.

The camera is not connected to the USB 3.1

port. If this is the case, you will receive a

corresponding error message.

2 The OLYMPUS LC35 camera

2.4 Specifications

The OLYMPUS LC35 is a CMOS color camera with a high frame rate.

It was developed for acquisitions using light microscopy. The camera

can be connected to all common types of light microscopes using a

C-mount.

Chip type CMOS color sensor

Chip size 1/2.5 Inch

Recording area 5.702 mm x 4.277 mm

7.13 mm diagonal

Maximum resolution 2160 x 1620 pixels

3.5 million pixels

Camera port of the microscope C-Mount

Input / output On the camera:USB 3.1 type C

On the computer: USB 3.1 type A

Resolution Frame rate* Exposure

time

2160 x 1620 Full resolution 19 fps

25 µs - 1534

1296 x 972 Fast mode 40 fps

1920 x 1080 Full HD 25 fps

* The maximum achievable frame rate is listed. The frame rate depends,

among other things, on the computer being used.
