Olympus Camedia C-750 Ultra Zoom Manuel utilisateur

zThis manual contains guidelines for using Olympus C-750 Ultra Zoom.

zIn the interest of continually improving products, Olympus reserves the

right to update or modify information contained in this manual.

DIGITAL CAMERA

MANUAL FOR DIRECT PRINTING

Manual outlining new features added to the camera with firmware update.

C-750 Ultra Zoom

About this manual

Update the camera’s firmware to enable PictBridge on your camera. This will

allow you to print pictures directly from the camera by connecting it to a printer

that supports PictBridge with the USB cable.

This manual explains additional functions, and different operations that are

available when the camera’s firmware has been updated. These functions

and operations are different than what is stated in the Reference Manual that

originally provided with your camera.

What is PictBridge? … It is the standard for connecting digital cameras and

printers of different makers and printing out pictures directly.

Indications used in this manual

Important information on factors which may lead to a

malfunction or operational problems. Also warns of operations that

should be absolutely avoided.

Useful information and hints that will help you get the most out of

your camera.

Reference pages describing details or associated information.

Reference pages describing details or associated information in

the CD reference manual. See the ENGLISH Reference manual.

Note

Contents

1 Functions changed by updating the

firmware 4

Camera display language . . . . . . . . . . . . . . . . . . . . . . . 4

Connection to a computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Direct printing function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2 Direct printing 7

Using the direct printing function . . . . . . . . . . . . . . . . . . . . . . . . 7

Connecting the camera to a printer . . . . . . . . . . . . . . . . . . . . . . 8

Printing pictures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

PRINT mode/MULTI PRINT mode . . . . . . . . . . . . . . . . . . . 9

ALL PRINT mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

ALL INDEX mode/PRINT ORDER mode . . . . . . . . . . . . . 15

Trim the picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Exiting direct printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

If an error code is displayed . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

1 Functions changed by updating the firmware

Camera display language

Since you selected ENGLISH for the camera’s display on the web site’s

firmware update page, only ENGLISH is displayed. It is not possible to

switch to other languages (see below).

Before updating “Menu List” (P.184 to 187)

After updating

Top menu Tab Function Setting

MODE

SETUP ENGLISH, FRANCAIS,

DEUTSCH, ESPAÑOL

Top menu Tab Function Setting

MODE

SETUP ENGLISH

Connection to a computer

When the USB cable is used to connect the camera to a computer, follow

the procedure below to select PC in the camera settings.

1Insert the marked end of the provided USB cable into the

USB port on your computer as shown below.

• The location of the USB port varies depending on the computer.

For details, refer to your computer’s manual.

2Set the camera’s mode dial to q.

3Plug the other end of the USB cable

into the camera’s USB connector.

4Press the power switch to turn the

camera on.

5The selection screen for the USB

connection (shown right) is

displayed on the monitor. Press

ac to select PC and press e.

6The computer recognizes the

camera as a new device.

• When you connect the camera to the computer for the first time, the

computer automatically recognizes the camera. Click “OK” when the

message saying that the installation is completed appears.

• The computer recognizes the camera as a “Removable Disk”.

Look for this mark.

USB port

Terminal

Note

SELECt

Power switch Mode dial

Direct printing function

After updating the camera’s firmware to enable PictBridge, pictures can be

printed directly from the camera. By connecting the camera directly to a

printer that supports PictBridge with the USB cable, you can print pictures

stored on the card inside the camera without a need to use a computer.

For details of printing instructions, see “Direct printing” (gP.7).

2 Direct printing

Using the direct printing function

By connecting the camera to a PictBridge-compatible printer with the USB

cable, you can print out recorded pictures directly without the use of a

computer. With the camera connected to the printer, select the pictures you

want to print and the number of prints on the camera’s monitor. It is also

possible to print out pictures using the print reservation data. “Print

setting” (P.163)

To find out if your printer is compatible with PictBridge, refer to the printer’s

instruction manual.

What is PictBridge? … It is the standard for connecting digital cameras and

printers of different makers and printing out pictures directly.

<STANDARD … All printers that support PictBridge have standard print

settings. Selecting <STANDARD on the settings screens (gP.10 to 15),

images are printed according to the default settings. See the instruction

manual for your printer for its standard settings or inquire with the printer

manufacturers.

TIPS

• For details of printing paper types, ink cassettes, etc., refer to the

printer’s instruction manual.

• You are recommended to use the optional AC adapter when

printing pictures. If you use rechargeable batteries, make sure that

they are fully charged. If you are using alkaline batteries, make

sure that you use new batteries. If the camera stops operating

while communicating with the printer, the printer may malfunction

or image data may be lost.

• Images recorded movies cannot be printed.

• The camera will not enter sleep mode when connected to the USB

cable.

Note

Connecting the camera to a printer

Use the USB cable provided to connect the camera to a PictBridge-

compatible printer.

1Turn the printer on and plug the

printer end of the USB cable into

the printer’s USB port.

• For details of how to turn the printer on

and the position of the USB port, refer to

the printer’s instruction manual.

2Set the camera’s mode dial to q

and plug the USB cable into the

camera’s USB connector.

3Press the power switch to turn the

camera on.

• The monitor turns on and the selection

screen for the USB connection is

displayed.

4Press ac to select PRINT, then

press e.

• ONE MOMENT is displayed and the

camera and printer are connected. The

PRINT MODE SELECT screen is

displayed on the monitor. Make the print

settings on the camera’s monitor.gGo

to “Printing pictures” (P.9).

• If PC is selected in step 4, the PRINT mode screen is not

displayed. If the screen is not displayed after several minutes, turn

off the camera and start again from step 1.

Power switch

SELECt

Note

Printing pictures

When the camera is connected to a PictBridge-

compatible printer, the PRINT MODE SELECT

screen is displayed on the monitor. Use this

screen to select the print mode. You can choose

from the following print modes.

PRINT Prints the selected picture.

g“PRINT mode/MULTI PRINT mode” (P.9)

ALL PRINT Prints all the pictures stored on the card.

g“ALL PRINT mode” (P.13)

MULTI PRINT * Prints one picture in multiple layout format.

g“PRINT mode/MULTI PRINT mode” (P.9)

ALL INDEX * Prints an index of all the pictures stored on the card.

g“ALL INDEX mode/PRINT ORDER mode” (P.15)

PRINT ORDER * Prints the pictures according to the print reservation data

on the card. If no print reservations (P.163) have been

made, this option is not available.

g“ALL INDEX mode/PRINT ORDER mode” (P.15)

* This option may not be available depending on the type of printer.

PRINT mode/MULTI PRINT mode

1In the PRINT MODE SELECT

screen, press ac to select

PRINT or MULTI PRINT, then press

• The print size settings screen is

displayed.

SELECt

EXIt

Zoom lever

OK button

Arrow pad

Printing pictures

2Press ac to select the paper

size, then press d.

•PRINT mode: Go to Step 3.

•MULTI PRINT mode: Go to Step 4.

• The available paper size settings vary

depending on the type of printer.

• When the PRINT PAPER screen is not

displayed, SIZE, BORDERLESS and

PICS/SHEET are set to < STANDARD. Go to step 5.

3Use ac to select framed or

unframed, then press e.

Go to step 5.

OFF ( ) The image is printed

inside a blank frame.

ON ( ) The image is printed filling

the entire page.

4Press ac to select PICS/SHEET,

then press e.

• PICS/SHEET depends on the paper size

set in Step 2 and the capabilities of your

printer.

5Press bd to select the picture you

want to print.

• Turn the zoom lever toward Wto display

the pictures in index format. You can then

select the pictures you want to print from

the index.

6Select the print reservation method.

SINGLE PRINT Makes a single-frame print reservation for the

selected picture according to standard settings.

MORE Sets the number of prints of the selected picture in

the print reservation data. You can also add the date

or file name, and trim the picture.

PRINt PAPER

SIZE

BORDERLESS

CANCEL

SELECt

StANDARD

PRINt PAPER

SIZE

BORDERLESS

StANDARD

SELECt

SIZE

StANDARD

SELECt

PRINt PAPER

PICS/SHEEt

SELECt

SINGLE PRINt

PRINT MODE screen
