Olympus CAMEDIA C-2020 Zoom Guide de configuration

OLYMPUS DIGITAL CAMERA

PRINTING

PICTURES

140

PRINTING PICTURES

There are two types of printing available with this camera.

One is Card-Print, which stores data conforming to the “Design rule for

Camera File system/DCF” standard in the card for making prints using a

printer or lab that supports this system. (p. 141 ~ 145)

The other is Direct-Print, which is for use with the Olympus P-330N, P-

330 or P-300 printer.

●When using the P-330N/P-330 printer, simply insert a card that

contains images into the printer and direct-print them. No cables are

necessary.

(The procedure for making prints must be performed on the printer.

See the printer instructions for details.)

●When using the P-300 printer, connect the camera to the printer to

make prints. (p. 146 ~ 156)

141

CARD-PRINT

PRINT-RESERVE (CARD)

You can store data for making prints with a printer or at a lab that

supports this system. (p. 140)

Set the Mode dial to .

Display the picture you want

to print, then press the

Shutter release button.

•appears on

the LCD monitor.

• To cancel, press the Shutter

release button again.

Press the right/left arrows on

the Jog dial to select the

number of pictures to be

printed.

Press the OK button.

•appears on the LCD

monitor.

Repeat until all the selections

are made.

Note:

•With the P-330N/P-330 printer, the number of pictures to be printed must

be set on the printer. Pictures with a frame number greater than 256

cannot be printed.

• The data will remain in the card until the setting is changed.

•To cancel all of the selections, select in the Print-All (card) mode.

(p. 143)

• Functions may not work fully depending on the printer or the lab used.

• It may take a while to store data in the card.

A/S/M

OFF

’99.12.23 21:56 32

0123456

142

Monitor display

Use

For storing data for Print-All (card). (p. 143)

For storing data for Date-Print (card). (p. 144)

For storing data for Index-Print (card). (p. 145)

CARD

INDEX

➠

* When the Mode dial is set to and a still picture is displayed on the

LCD monitor. (Page 2/2 of the Menu.) (p. 39)

STILL PICTURE DISPLAY MENU

(CARD-PRINT)

143

PRINT-ALL (CARD)

You can store data for printing all the pictures in the card. (p. 140)

Set the Mode dial to , and

display a still picture.

Press the Menu button to

display the Menu.

Press the top/bottom arrows

on the Jog dial to select .

•To cancel, press the Menu

button.

Press the right arrow on the

Jog dial, then press the

top/bottom arrows to select

ON.

Press the left arrow on the

Jog dial to confirm the setting.

Press the OK button to save

the setting and cancel the

Menu.

• Make sure to press the OK

button while is displayed

on the LCD monitor.

Note:

•The last number set for the number of pictures to be printed in Print-

Reserve (p. 141) will be used for printing all the pictures.

• Pictures taken after this function is selected will not be printed.

• cancels all the settings made for Card-Print. (p. 141 ~ 145)

• The data will remain in the card until the setting is changed.

•With the P-330N/P-330 printer, pictures with a frame number greater

than 256 cannot be printed.

• It may take a while to store data in the card.

543

SHQ

[2/2]

OFF

CARD

INDEX

A/S/M

OFF

144

DATE-PRINT (CARD)

You can store data for printing the date with pictures. (p. 140)

Set the Mode dial to , and

display a still picture.

Press the Menu button to

display the Menu.

Press the top/bottom arrows

on the Jog dial to select .

• To cancel, press the Menu

button.

Press the right arrow on the

Jog dial, then press the

top/bottom arrows to select

TIME or DATE.

Press the left arrow on the

Jog dial to confirm the setting.

Press the OK button to save

the setting and cancel the

Menu.

• Make sure to press the OK

button while is displayed

on the LCD monitor.

Note:

• Set the date beforehand.

• Pictures taken after this function is selected will not be printed.

•Unless OFF is selected in All Reset, the setting will be canceled when

the power is turned off. (p. 172)

•When using the P-330N/P-330 printer, Date-Print must be set on the

printer.

•It may take a while to store data in the card.

543

SHQ

[2/2]

CARD

INDEX

OFF

TIME

DATE

A/S/M

OFF

145

INDEX-PRINT (CARD)

You can store data for making index prints. (p. 140)

Set the Mode dial to , and

display a still picture.

Press the Menu button to

display the Menu.

Press the top/bottom arrows

on the Jog dial to select CARD

INDEX.

• To cancel, press the Menu

button.

Press the right arrow on the

Jog dial, then press the

top/bottom arrows to select

ON.

Press the left arrow on the

Jog dial to confirm the setting.

Press the OK button to save

the setting and cancel the

Menu.

• Make sure to press the OK

button while CARD INDEX is

displayed on the LCD monitor.

Note:

• The print format varies depending on the printer or lab used.

• Pictures taken after this function is selected will not be printed.

•Unless OFF is selected in All Reset, the setting will be canceled when

the power is turned off. (p. 172)

•When using the P-330N/P-330 printer, Index-Print must be set on the

printer.

•It may take a while to store data in the card.

543

SHQ

[2/2]

CARD

INDEX

OFF

A/S/M

OFF

146

DIRECT-PRINT

PRINTING WITH THE P-300

By connecting the camera to the P-300 printer with the direct connect

cable, pictures can be printed directly from the camera.

Make sure that the power of the printer and the camera are off before

connecting.

Remove the lens cap.

Connect the computer connector of the camera to the serial

port of the printer with the provided RS-232C cable and

conversion connector for Mac. Turn on the printer.

Serial port

Computer connector

P-300

147

Set the Mode dial to to

turn on the LCD monitor.

Select the picture you want to

print using the Jog dial.

Enter the number of copies to

be printed on the printer, then

press the DIRECT PRINT

button on the printer to start

printing.

Note:

•The power of the printer and the camera must be OFF in order to be

connected.

•If the printer does not start printing when the DIRECT PRINT button is

pressed, turn off the printer, connect the cables correctly, turn on the

printer and press the DIRECT PRINT button again.

•The LCD monitor display goes off during printing, and other operations

are disabled.

• The date can be printed as well. (p. 156)

• The use of the optional AC adapter is recommended.

• Images taken in TIFF (non-compression) cannot be printed.

A/S/M

OFF

148

INDEX PRINT (P-300)

Index prints can be made.

Connect the camera to the

printer, then set the Mode dial

to .

• See page 146 for connection to

the printer.

Select the Index-Display

mode. (p. 95)

Enter the number of copies to

be printed on the printer, then

press the DIRECT PRINT

button to start printing.

• After printing, the display

advances to the next group of

index pictures.

• The date will be always printed

in Index Print. Set the date

beforehand.

49 50 51

52 53 54

55 56 57

A/S/M

OFF
