Oki LP-2050-MF Manuel utilisateur

Wide Format Printer

Teriostar LP-2050 Series

LP-2050

Multifunction Model

Printer Model

LP-2050-MF

User's Manual for Basic Printer Operation

U00121376205

Chapter

Before Use

Chapter

Basic Operations

Chapter

Menu Functions

Chapter

TroubleshootingAppendix

Authentication

function

U00121376200 August, 2010

U00121376201 January, 2011

U00121376202 July, 2011

U00121376203 July, 2013

U00121376204 April, 2015

U00121376205 December, 2015

The contents of this manual may be changed without prior notice.

This product displays fonts created by TypeBank Co., Ltd. and ARPHIC TECHNOLOGY.

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant

to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used

in accordance with the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference in which case the

user will be required to correct the interference at his own expense.

The CE mark, that shows that the products sold in the EU are conformed to the requirements of EC directive,

is statutorily obliged to be axed to the products.

In each directive, the scope of directive to be applied to equipment is explicitly dened. Our company’s

product LP-2050 series conforms the EMC directive, low voltage directive and RoHS Directive.

Inquiry of CE mark:

OKI Europe Ltd.

Wide Format Division

Siemensstrasse 9 , D-63263 Neu-Isenburg

Germany

Tel: +49 (0)6102 297 400

Fax: +49 (0)6102 297 50 400

OKI Data Infotech Corporation

8 Nakase 1-chome, Mihama-ku, Chiba-shi, Chiba 261-8507, Japan

Phone : +81 43 211 1363

Fax : +81 43 211 8709

LP-2050/LP-2050-MF User's Manual for Basic Printer Operation

Your Printer is a Teriostar LP-2050 Series wide format Printer (Referred

to as the Printer in this manual), and this manual describes the general

handling methods for the Printer, the Printer functions, and the operating

methods. They are written on the assumption that the Printer has already

been installed.

For details about the copy, scan, and submission functions in the

multifunction models, see the separate User's Manual for Multifunction

Printer Operation.

To handle the Printer safely and correctly, be sure to read the Safety

Precautions carefully before use. Keep this manual in a place where you

can easily read it when required.

Preface

4LP-2050/LP-2050-MF User's Manual for Basic Printer Operation

Safety Precautions

In this manual, the following symbols are used to alert the user to information that

will prevent damage to the Printer, and ensure its safe and correct use.

These symbols are explained below. Make sure that you thoroughly understand

the information. Always follow the instructions marked by these symbols.

Symbol Examples

Warning

If this information is ignored and the Printer is

handled incorrectly, it may result in serious injury or

death.

Caution

If this information is ignored and the Printer is

handled incorrectly, it may result in injury or machine

damage.

UThis symbol indicates that caution is required (includes dangers and

warnings).

The example on the left indicates a safety Warning or

Precaution.

This symbol indicates a prohibited action.

The example on the left means Do not disassemble.

This symbol indicates required actions or instructions.

The example on the left means Disconnect the power plug from

the outlet.

LP-2050/LP-2050-MF User's Manual for Basic Printer Operation

Warning

Be very careful not to touch the fuser unit labeled HIGH TEMPERATURE inside

the Printer.

Burn injuries may result.

Do not disassemble or modify the Printer.

An accident or malfunction may result.

Do not heat a toner cartridge or a waste toner bottle containing waste toner, nor

place it into a ame.

It may burst or ignite, resulting in an accident or re.

Never use the Printer in a location exposed to abnormally high humidity

or moisture.

A re, electric shock, or malfunction may result.

Do not drop metal pieces such as staples, or spill water, or other liquids inside

the Printer or through gaps.

A re, electric shock, or malfunction may result.

Do not connect or disconnect the power cord or other parts with wet hands. An

electric shock may result.

In the following situations, turn o the power, and disconnect the power plug

from the outlet. If you continue using the Printer in an abnormal condition, an

accident or re may result.

When cleaning

When an abnormal odor, noise, or smoke is emitted

When foreign matter such as metal pieces or water get inside the Printer

or through gaps

When a problem that must be repaired by the service representative oc-

curs

Connect the power plug separately to a power socket with a rated voltage

of 120V and a rated current of 16A or more, or to a power socket with a rated

voltage of 230V and a rated current of 9A or more. To prevent a re or electric

shock, avoid the sharing of power with other equipment.

6LP-2050/LP-2050-MF User's Manual for Basic Printer Operation

Be sure to remove the dust on the power plug and the socket. Do not use a

dusty plug as a current leak due to humidity on its surface may heat the plug

and result in re.

Do not x, twist, bind, modify, stretch, or bend excessively the power cord. Do

not put heavy object on it. A damaged power cord may heat and result in re or

electrical shock.

If the power cord is cut or if the wires are exposed, ask a service representative

for replacement.

Using a damaged power cord may result in re or electrical shock.

Caution

Do not disassemble or modify the toner cartridge.

The toner on your skin will have a negative eect.

If ink stains your skin or clothing, wash with soap and water immediately.

To prevent a toner leakage, do not drop the toner cartridge nor expose it to

strong impacts.

If toner gets into your eyes, do not rub your eyes, and wash the toner out. Visit a

doctor immediately.

As the roll paper is heavy, handle it carefully to make sure that you do not drop

it.

Dropping the roll paper on your feet may result in injury.

When installing the roll paper, use the cutter to cut the end of the paper. At this

time, be careful not to injure yourself on the cutter.

Install the Printer close to a power outlet. Make sure the outlet is easy to reach in

case the power plug needs to be disconnected in an emergency.

When connecting and disconnecting the power cord, hold it by the plug or

connector.

To prevent a re, electric shock, or malfunction, avoid pulling the cord.

LP-2050/LP-2050-MF User's Manual for Basic Printer Operation

If you use a power strip, change it for a new one at least once a year.

Do not use an extension cable or an adapter plug.

Once a month, turn the power switch o and inspect the followings. Contact

your service representative if you detect any problem.

The plastic insulator at the base of the plug's pins does not suer from

heat deformation.

The plug's pins are not bent or covered by rust.

There is no dust between the plug's pins.

The power cord is not frayed and the energized wires are not exposed.

The plug is rmly plugged into the socket.

There is no dust on the plug or the socket.

Before moving the Printer from its current installation location to another

location, contact your service representative.

In addition to the items above, observe the warnings and precautions in each

section of the manual.

8LP-2050/LP-2050-MF User's Manual for Basic Printer Operation

Warning Labels

Warning labels are axed to the Printer in the locations shown in the gure below.

Make sure you understand the information on the warning labels before handling

the Printer.

(3) Caution label to prevent hands

from being stuck MF

(1) HIGH TEMPERATURE

caution label

(1) HIGH TEMPERATURE

caution label

(1) HIGH TEMPERATURE

caution label

(2) Instruction label to remove jams

LP-2050/LP-2050-MF User's Manual for Basic Printer Operation

(1) HIGH TEMPERATURE caution label, affixed inside, seen when the fuser unit

door is opened.

This label warns against touching heated parts.

The fuser unit becomes very hot. Be careful not to touch this area inside the

Printer, while the cover is opened, e.g., to remove a paper jam.

U00120740500

SEE MANUAL

取扱説明書を参照

䇋খ䯙Փ⫼䇈ᯢк

(2) Instruction label to remove jams

This label indicates the removal direction for jammed paper when a jam occurs

in the fuser unit.

Remove the paper by following the instruction on the label.

(3) Caution label to prevent hands from being stuck MF

This label raises your caution to prevent your hands from being stuck between

the Printer and the scanner.

On closing the scanner, do not place your hands near this label.

10 LP-2050/LP-2050-MF User's Manual for Basic Printer Operation

Reading the Manual

Manual Structure

This manual is comprised of 4 chapters and an appendix.

Chapter 1 describes information such as the printer features and part names. These

should be known before starting operations. First, read Chapter 1 to understand

the basic information about the Printer.

Chapter 2 describes the items that are required for operating the Printer, such as

turning the power on, and o, and setting the paper. Read this chapter to learn

about the basic methods for handling the Printer.

Chapter 3 describes the Printer's functions and their setup procedure.

Chapter 4 describes the authentication function for the Printer.

Chapter 5 describes the action to solve a Printer problem. Take appropriate action

by following the instructions in this chapter.

The Appendix contains the Printer's basic specications, command lists, and menu

structure.
