Oki JET 2010 Manuel utilisateur

Page: 1

Service Guide OJ2010

Chapter 0 About This Manual

OKIJET 2010

InkJet Printers

Adobe Acrobat printable reference

copy of the OKIDATA Service Training Manual.

09/17/97

Note: This Adobe Acrobat version of the Okidata Service Training Manual was built with the

pictures rendered at 300 dpi, which is ideal for printing, but does not view on most

displays well.

Partner Exchange (BPX) for any updates to this material. (http://bpx.okidata.com)

Table of Contents Page

Service Guide OJ2010

0 About This Manual

Front Cover 1

1 Product Specifications

1.1 Overview 3

1.2 Physical Specifications 4

1.3 Power Requirements 5

1.4 Environmental Conditions 6

1.5 Agency Approvals 7

1.6 Operational Specifications 8

....1.6.06 Paper Loading 9

........Auto Feed 10

........Manual Feed 11

....1.6.07 Print Method 12

....1.6.08 Print Modes And Print Resolution 13

....1.6.10 Print Speed 14

1.7 Print Media (Paper) Specifications 15

....1.7.02 Length 16

....1.7.05 Weight 17

....1.7.06 Width 18

........Card Stock (Index Cards) 19

........Cut Sheet 20

........Envelopes 21

........Auto Feed 22

........Manual Feed 23

........Orientation 24

........Labels 25

........Transparency 26

1.8 Memory Specifications 27

1.9 Consumables 28

1.10 Options 29

1.11 Reliability 30

2 Principles of Operation

2.1 Electrical Operation 31

....2.1.02 Emulations 32

....2.1.03 Interface 33

....2.1.04 Memory 34

....2.1.05 Operator Panel 35

....2.1.06 Parallel Port 36

....2.1.07 Power On Self Test (Post) Sequence 37

....2.1.08 Power Supply 38

....2.1.09 System Board 39

Table of Contents Page

2.2 Mechanical Operation - Paper Feed 40

....2.2.02 Paper Feed Methods 41

....2.2.03 Paper Feed Path 42

....2.2.04 Paper Loading 43

........Envelope Orientation 44

........Auto Feed 45

........Manual Feed 46

....2.2.05 Printhead Mechanism 47

....2.2.06 Print Modes 48

....2.2.07 Print Resolution 49

....2.2.08 Print Speed 50

....2.2.09 Print Quality Enhancement Technique (PQET) [Edge

Smoothing] 51

....2.2.10 Spacing 52

....2.2.11 Maintenance Station 53

3 Maintenance and Disassembly

3.1 Overview 54

....3.1.02 Maintenance Items 55

....3.1.03 Maintenance Precautions 56

3.2 Disassembly/Assembly Procedures 57

....3.2.01 Preliminary Items 58

....3.2.02 Base Assembly 59

....3.2.03 Carrier Belt 60

....3.2.04 Carrier Frame Assembly 61

....3.2.05 Carrier Transport Motor 62

....3.2.06 Code Module / EPROM 63

....3.2.07 Edge Guide Assemblies And Paper Load Shaft 64

....3.2.08 Ejectors 65

....3.2.09 Encoder Card 66

....3.2.10 Encoder Strip 67

....3.2.11 Feed Arm Assembly 68

....3.2.12 Front Cover 69

....3.2.13 Gutter Pad 70

....3.2.14 Inside Idler Gears 71

....3.2.15 Large Feed Roller 72

....3.2.16 Large Outside Gear 73

....3.2.17 Left Side Frame Assembly 74

....3.2.18 Maintenance Station Assembly 75

....3.2.19 Maintenance Wipers And Caps 76

....3.2.20 Manual Insert Tray 77

....3.2.21 Mid Frame Assembly 78

....3.2.22 Paper Feed Motor 79

....3.2.23 Paper Guide And End Of Form (Eof) Flag Assembly 80

....3.2.24 Paper Load Door 81

Table of Contents Page

....3.2.25 Pick Roll Hub, Shaft, And Envelope Bucklers 82

....3.2.26 Power Supply 83

....3.2.27 Printhead Cable And Paper Deflector 84

....3.2.28 Printhead Carrier Assembly 85

....3.2.29 Printhead Rubber Backer 86

....3.2.30 Rear Cover 87

....3.2.31 Right Side Frame Assembly 88

....3.2.32 Small Feed Roll Shaft, Rollers, And Flap 89

....3.2.33 System Board 90

3.3 Adjustments 91

....3.3.02 Printhead Alignment 92

....3.3.10 Resets 93

3.4 Cleaning 94

....3.4.02 Cleaning Schedule 95

....3.4.03 Cleaning Tools 96

....3.4.04 Areas To Be Cleaned 97

....3.4.04 Nozzle Test 98

........Procedure 99

............Wipe The Nozzles And Contacts 100

............Clean The Carrier Contacts 101

3.5 Lubrication 102

....3.5.02 Lubrication Schedule 103

....3.5.03 Lubrication Types And Amounts 104

....3.5.04 Areas Not Lubricated 105

3.6 Shipping Instructions 106

3.7 Print Cartridge Maintenance 107

....3.7.02 Installation 108

....3.7.03 Replacement 109

....3.7.04 Disposal 110

4 Failure and Repair Analysis

4.1 Overview 111

....4.1.02 Printer Serial Number Identification 112

....4.1.03 Code Level Identification 113

4.2 Reporting Problems 114

....4.2.02 Problem Lists 115

....4.2.03 Reporting Methods 116

4.3 Troubleshooting Updates 117

4.4 Troubleshooting Tips 118

....4.4.02 Problem Categories 119

....4.4.03 Start Here Flowchart 120

....4.4.04 Tips For Preventing Image Problems 121

....4.4.05 Common Problems 122

4.5 Abnormal Output 123

4.6 Fault Alarms 124

Table of Contents Page

....4.6.02 Power On Self Test (Post) Sequence 125

....4.6.03 Symptom Lists 126

4.7 Repair Analysis Procedures (Raps) - Using The Raps 127

....4.7.02 Rap Index 128

........RAP 01: Envelope Feed Service Check 129

........RAP 02: First Print Line Service Check 130

........RAP 03: Maintenance Service Check 131

........RAP 04: Paper Feed Service Check 132

........RAP 05: Paper Path Service Check 133

........RAP 06: Parallel Port Service Check 134

........RAP 07: Power Service Check 135

........RAP 08: Print Quality Service Check 136

........RAP 09: Transport Service Check 137

4.8 Tests 138

....4.8.02 Test Page 139

....4.8.03 Parallel Port Test 140

....4.8.04 Encoder Sensor Test 141

....4.8.05 End Of Forms Sensor Test 142

....4.8.06 Initialize Error Log 143

....4.8.07 Printer Error Log Recovery 144

4.9 Resistance Checks 145

....4.9.02 Checkpoint Locations 146

A Board Diagrams

A.1 Board Diagrams And General Information 147

A.2 Index To Charts 148

....A.2.01 System Board 149

....A.2.02 Power Supply 150

....A.2.03 Encoder Card 151

A.3 Resistance Checkpoints 152

....A.3.02 Checkpoint Locations 153

B Illustrated Parts Listing

B.1 Illustrated Parts Listing - General Information 154

........Format 155

........Current Part Numbers 156

....B.1.02 Definition Of Terms 157

....B.1.03 Parts Ordering Information 158

B.2 Charts 159

....B.2.01 Printer 160

....B.2.02 Covers 161

....B.2.03 Frames 162

....B.2.04 Paper Feed 163

....B.2.05 Electronics 164

....B.2.06 Carrier 165

....B.2.07 Carrier Transport 166

Table of Contents Page

....B.2.08 Sheet Feeder 167

....B.2.09 Maintenance Station 168

....B.2.10 Packing Materials 169

....B.2.11 Consumables 170

....B.2.12 Documentation 171

....B.2.13 Service Training Kit Revision List 172

Page: 2

Service Guide OJ2010

Chapter 0 About This Manual

This document may not be reproduced without the written permission of Okidata Sales and Product

Training. Every effort has been made to ensure the accuracy of the information contained in this training

course. Okidata is not responsible for errors beyond its control.

First Release P/N 59269701 June, 1995

Second Release P/N 59269702 July, 1995

Written by Okidata Sales and Product Training

Please address any comments on this publication to:

Okidata

Sales and Product Training

532 Fellowship Road

Mount Laurel, NJ 08054-3499

Okilink Login Name: Technical Training

OKIDATA is a registered trademark of Oki Electric Industry Company, Ltd.; marques deposee de Oki

Electric Industry Company, Ltd.; marca registrada, Oki Electric Industry Company, Ltd.

OkiJet is a trademark of Oki Electric Industry Company, Ltd.

Okilink II is a trademark of Oki Electric Industry Company, Ltd.

ZIP Code is a registered trademark of the United States Postal Service.

Partner Exchange (BPX) for any updates to this material. (http://bpx.okidata.com)

Page: 3

Service Guide OJ2010

Chapter 1 Product Specifications

1.1 OVERVIEW

1.1.01 General Information

The OkiJet 2010 is the first thermal inkjet product to wear the Okidata name badge.

The unit is a fully featured Windows-based, inkjet printer.

This product is a Graphics Device Interface (GDI) printer. Data leaving the computer is "preformatted" for

the printer. Very little printer circuitry is required for data handling. The received data is already formatted

for the GDI printer. RAM in the printer is minimized.

There is NO operator panel. The unit is controlled via software in the computer.

The units print resolution is 600 by 300 dots per inch. Dual printhead design allows the unit to print color

and true black without changing printheads.

The unit utilizes an edge smoothing technique called Print Quality Enhancement Technique (PQET). This

technique reduces the "jaggies" seen in slanted (italics) character set printouts.

The OkiJet 2010 printer is a "Windows Based Host Printer". The printer can print from a DOS based

program running in a Windows "DOS-based session", but it is not the best possible configuration. DOS is

a very non-graphical based operating system. The OkiJet 2010 is a GDI printer.

A parallel interface cable IS NOT shipped with the unit. The end user must purchase the interface cable

separately. It must be capable of supporting bi-directional communications to connect the printer to the

computer. This cable CANNOT be more than six (6) feet long.

Partner Exchange (BPX) for any updates to this material. (http://bpx.okidata.com)

Page: 4

Service Guide OJ2010

Chapter 1 Product Specifications

1.2 PHYSICAL SPECIFICATIONS

1.2.01 Dimensions

Width: 17.2 inches (43.6 centimeters)

Depth: 23.3 inches (59.1 centimeters)

Height: 13.5 inches (34.3 centimeters)

1.2.02 Printer Weight

9.4 pounds (4.3 kilograms) with no ink cartridges installed

9.75 pounds (4.42 kilograms) with two ink cartridges installed

UPS Shippable

Partner Exchange (BPX) for any updates to this material. (http://bpx.okidata.com)

Page: 5

Service Guide OJ2010

Chapter 1 Product Specifications

1.3 POWER REQUIREMENTS

1.3.01 Input Power

90 to 259 volts, AC

1.3.02 Power Consumption

Voltage Range: 120/220/240

The numbers listed below are estimates.

less than 2 W - Power OFF

7.5 W - Idle Mode

12 W - Printing Mode Average

25 W - Printing Mode Peak

1.3.03 Power Frequency

50/60 Hz

1.3.04 Energy Star Rating

The product qualifies for the Environmental Protection Agency (EPA) Energy Star Program, a cooperative

effort between the EPA and computer and peripheral manufacturers to promote energy efficient

equipment and to reduce air pollution caused by power generation.

The Energy Star emblem does not represent EPA endorsement of any product or service.

Partner Exchange (BPX) for any updates to this material. (http://bpx.okidata.com)

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Oki Imprimante

Oki

Oki 4600 Manuel utilisateur

Oki

Oki ES7411 Instructions d'installation et d'entretien

Oki

Oki C8800dn Manuel utilisateur

Oki

Oki Microline 520 Manuel utilisateur

Oki

Oki Teriostar LP-2060 Series Manuel utilisateur

Oki

Oki Okipage8z Manuel technique

Oki

Oki B4200 Manuel de la liste des pièces

Oki

Oki IP-5620 Manuel utilisateur

Oki

Oki C542DN Manuel utilisateur

Oki

Oki proColor pro900DP Manuel utilisateur

Oki

Oki ML 186 Manuel de service

Oki

Oki MB491MFP Manuel utilisateur

Oki

Oki B4250 Series Manuel utilisateur

Oki

Oki C3400n Manuel utilisateur

Oki

Oki C5800Ldn Series Manuel du propriétaire

Oki

Oki C911dn Manuel utilisateur

Oki

Oki OKIPAGE 14i Manuel utilisateur

Oki

Oki LP470b Manuel utilisateur

Oki

Oki C110 Guide de démarrage rapide

Oki

Oki ES5430 Manuel utilisateur

Oki

Oki C610dtn Manuel utilisateur

Oki

Oki C8800dn Manuel utilisateur

Oki

Oki C6000dn Instructions d'installation

Oki

Oki B6200 Series Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur
