Ohlins SD 021 Manuel utilisateur

Steering damper for Kawasaki ZX6R/ ZX10R

SD 021

Mounting Instructions

Note!1

Please note that there can be small differences

between your product and the images in

these instructions.

Note!1

Please note that during storage and transport,

especially at high ambient temperature, some

of the oil and grease used for assembly may

leak and stain the packaging. This will not

cause damage to the product, wipe off the

excessive oil or grease with a cloth.

Note!1

Before you install this product, check the kit

contents. If anything is missing, please contact

an Öhlins dealer.

Warning!⚠

Before you install this product, read the Öhlins

Owner’s manual. This product is an important

part of the vehicle and the vehicle stability.

Kit Contents

Description Part No Pcs

Shock absorber SD021 1

Sticker Öhlins 00192-01 2

Owners’ manual 07261-02 1

Remove the original steering damper.

Install the Öhlins steering damper in the same

position as the original steering damper. Use

the original attachment parts.

Caution!✋

Make sure that you tighten all screws to the

correct torque and that nothing fouls or restricts

movement of the shock absorber/front fork/

steering damper when the suspension is fully

compressed or extended.

MOUNTING INSTRUCTIONS

Warning!⚠

We strongly recommend to let an Öhlins dealer

install this product.

Warning!⚠

If you work with a lifted vehicle, make sure that it

is safely supported to prevent it from tipping over.

Note!1

When you work with this product, see the

vehicle service manual for vehicle specic

procedures and important data.

Note!1

Before you install this product clean the vehicle.

MOUNTING INSTRUCTIONS

This page intentionally left blank

Öhlins Racing AB

Box 722

S-194 27 Upplands Väsby, Sweden

Phone +46 8 590 025 00

fax +46 8 590 025 80

reserved. Any reprinting or

unauthorized use without the written

permission of Öhlins Racing AB

is prohibited.

Öhlins products are subject to

continuous improvement and

development, therefore, although

these instructions include the most

up-to-date information available at

the time of printing, minor updates

may occur.

To nd the latest information

contact an Öhlins distributor.

Please contact Öhlins if you have

any questions regarding the

contents in this document.

SETUP DATA

Adjuster

knob

Warning!⚠

Before you ride/drive, always make sure that the

setup is according to the recommended setup

data. Read about adjustments and setting up

in the Öhlins Owner’s Manual before you make

any adjustments. Contact an Öhlins dealer if

you have any questions about setting up.

ADJUSTMENTS

Part no. MI_SD021_3

Issued 2016-03-14

Recommended setup 10 clicks
