OfiTE MudChecker Manuel utilisateur

MudChecker

#365-21-ES - MudChecker v1.5 ES

Instruction Manual

Updated 2/5/2024

Ver. 2

OFI Testing Equipment, Inc.

11302 Steeplecrest Dr. · Houston, Texas · 77065 · U.S.A.

Tele: 832.320.7300 · Fax: 713.880.9886 · www.ote.com

©Copyright OFITE 2023

OFITE, 11302 Steeplecrest Dr., Houston, TX 77065 USA / Tel: 832-320-7300 / Fax: 713-880-9886 / www.ote.com 1

Introduction.....................................................................................2

Battery .............................................................................................3

Test Setup .......................................................................................4

Device Navigation ..........................................................................6

Testing .............................................................................................7

Standalone..................................................................................7

With Software..............................................................................9

Cleaning the Probe.......................................................................10

Software ........................................................................................ 11

Introduction ............................................................................... 11

Architecture...............................................................................12

Installation.................................................................................14

Layout .......................................................................................18

Results / Analysis......................................................................19

Reports .....................................................................................23

Tips ................................................................................................24

Safety.............................................................................................25

Warranty and Return Policy ........................................................27

Table of

Contents

OFITE, 11302 Steeplecrest Dr., Houston, TX 77065 USA / Tel: 832-320-7300 / Fax: 713-880-9886 / www.ote.com 2

The MudChecker is a portable, battery-powered device encased in a robust

IP 64 enclosure that measures the composition of drilling uids. It uses radio

frequency sensor technology to detect and track the oil, water, solids, and sa-

linity content of drilling uids. The MudChecker is a handheld probe intended

to be dipped into undiluted and diluted mud samples contained in a suitable

non-metallic container.

The MudChecker ES is designed to measure the percentage Oil/Water/

Solid content and can also detect the salinity of drilling uids during a second

measurement step. The MudChecker KS requires the user to manually input

the salinity value, before measuring the oil, water, and solids content. The KS

mode can also be selected on the ES models to expedite the measurement

process if the salinity of the sample is known.

Computer software is provided with all MudChecker models. The software

interfaces with the device via a USB cable and is required for the process-

ing of measurements for the 1.0 models of the device. The 1.5 version can

recall measurement results on the device or via the accompanying software.

The software also allows customers to setup the unit, choose the mode of

operation (KS or ES), enter parameters used in the calculation (such as mud

density, oil density), log results, view results and download previous records.

Records may be exported as spreadsheets.

Introduction

OFITE, 11302 Steeplecrest Dr., Houston, TX 77065 USA / Tel: 832-320-7300 / Fax: 713-880-9886 / www.ote.com 3

The MudChecker is not fully charged when shipped for safety reasons. It is

recommended that the unit is charged for at least two hours before initial use.

Charge the unit using the USB cable provided. If the unit is being charged

from a computer, the USB cable must be attached directly to the computer,

NOT via a USB hub. In general, the USB interface does not work via a USB

hub. Note that USB sockets in the body of monitors are generally part of a

hub.

Checking the Battery

The battery status is shown briey when the device is powered on. You can

see the battery status at any time by powering the device o󰀨 and then on.

Recharging the Battery

The battery will charge automatically if plugged into a PC via the USB cable.

Ensure the probe is turned o󰀨 after charging from the PC by turning it on and

o󰀨 again.

Powering On/O󰀨

To turn the device on, hold and release the power button. It is recommended

that the unit should be fully charged before use. To turn o󰀨 the device press

and hold the power button for 3 seconds until the Power O󰀨 message ap-

pears then release. Please ensure the unit is turned o󰀨 after use to ensure

the battery is not drained during storage.

Battery

OFITE, 11302 Steeplecrest Dr., Houston, TX 77065 USA / Tel: 832-320-7300 / Fax: 713-880-9886 / www.ote.com 4

Before taking a measurement, you must connect the MudChecker to the host

PC and enter the required inputs into the software. The software will then

save those settings to the MudChecker device.

1. Connect the MudChecker to the host PC and start the software.

2. Click the “New Measurement” button to start a new test.

3. Enter the required inputs:

• Test Description: comments regarding the test or any other relevant

information

• Mud ID: short description of the mud (maximum of 17 characters)

• Mud Density: density of the whole drilling uid in lb/gal

• Weighted Mud: species whether the mud contains barite. If un-

weighted mud is being tested with no barite, uncheck this selection

• HGS Density: the specic gravity of HGS or barite (if used) in SG or

gm/cc

• LGS Density: the specic gravity of low-gravity or drill solids in uid in

SG or gm/cc

• Base Fluid: the type of base uid in the drilling uid. Select the type

from the drop-down selection. Base uids can be added to this list via

the “Base Fluid Calibration” screen. See page 6 for details.

• Base Density: specic gravity of the base uid

• Oil Calibrated: for informational purposes only since all devices are

always calibrated with diesel by default or user-selected base uids

Test Setup

OFITE, 11302 Steeplecrest Dr., Houston, TX 77065 USA / Tel: 832-320-7300 / Fax: 713-880-9886 / www.ote.com 5

• Oil Calibration Date: shows the date the base uid was calibrated

• Known Salinity: this check-box is used to determine if the test is go-

ing to be run in “Known Salinity” or “Estimated Salinity” mode.

○Known Salinity Mode: In this mode, basic information about the

salinity of the brine phase in the drilling uid is used to estimate

the oil, water, and solids fraction in the uid. Currently it is as-

sumed that the brine is only comprised of calcium chloride. The

user inputs the brine salinity based on their Silver Nitrate titration.

There are 4 choices for the salinity input:

- mg Cl-ions per liter of mud (comes directly from the volume of

Silver Nitrate used for titration)

- mg CaCl2 per kg of brine (or part per million)

- weight percent CaCl2in brine

- mg Cl-ions per liter of brine

In “Known Salinity” mode, only one stage of measurement on the

whole drilling uid is required. It is not required to perform the sec-

ond stage of measurement on the diluted mud sample.

○Estimated Salinity Mode: In this mode, the salinity data for the

brine is estimated using the data and no information on the brine

is required. In this mode, 2 stages of measurement are required:

- In the rst stage, measurement is performed on the whole drill-

ing uid sample

- In the second stage, the software will prompt to run this stage

using the diluted mud sample. This requires mixing 20 mL of

whole drilling uid with 205 mL of the DSX7 surfactant solution

(#365-20-4).

OFITE, 11302 Steeplecrest Dr., Houston, TX 77065 USA / Tel: 832-320-7300 / Fax: 713-880-9886 / www.ote.com 6

All MudChecker units already include calibration data for Diesel as base uid.

If other base uids are used in your drilling uids, the device must be calibrat-

ed using the base uid. The Base Fluid Calibration utility can be accessed

from the main program screen using the button on the top right-hand corner.

1. Make sure the device probe and probe cover (shield) are clean. If neces-

sary clean with Iso-Propyl Alcohol.

2. Connect the MudChecker device to the host computer.

3. Start the MudChecker software. Then click the “Base Fluid Calibration”

button to display the Base Fluid Calibration screen

4. Insert the MudChecker probe into the base uid. Make sure the probe is

properly inserted into the uid such that the 4 horizontal slots in the probe

shield are fully submerged

5. Input the name of the Base Fluid and the density (g/cc or SG).

6. Click the Run button and wait for the measurement to be completed

7. Acknowledge the conrmation dialog box. Once acknowledged, the base

uid calibration data is saved to the local database on the host PC and is

now available for selection in the “New Measurement” window. The win-

dow will automatically close once “OK” is clicked.

Calibration

OFITE, 11302 Steeplecrest Dr., Houston, TX 77065 USA / Tel: 832-320-7300 / Fax: 713-880-9886 / www.ote.com 7

The MudCecker device has four navigation buttons:

Device

Navigation Power / Scroll / Hold to Cancel or Power O󰀨

Navigate Down One Level in Menu / Enter

Increase or Decrease Parameter Value / Hold Both to

Go Back One Level

OFITE, 11302 Steeplecrest Dr., Houston, TX 77065 USA / Tel: 832-320-7300 / Fax: 713-880-9886 / www.ote.com 8

In standalone mode, the test input data can be downloaded to the device to

perform o󰀨-line testing. After the input data is downloaded to the device, it

can be disconnected from the host PC and measurements can be performed

o󰀨-line. Once the measurement is completed, the device can be plugged

back into the PC and all test data will be downloaded from the device into the

PC and results analyzed automatically. The image below shows the conrma-

tion dialog for settings updated on the device and also instructions on next

steps. Once the OK button is clicked, the software returns to the main screen.

In standalone mode, no analysis is performed on the device. All analyses are

performed on the PC. Multiple tests (100 max) can be performed in this mode

before results are downloaded to the host PC.

If multiple tests are performed, the same set of input data will be used for

all tests. If di󰀨erent input data are required for each test, the device must be

connected to the PC to update input data before each test.

1. Ensure the mud sample is homogenous. Mix the sample thoroughly using

a blender if necessary. Ensure there are no air bubbles in the sample be-

fore inserting the probe. Immerse the probe so that the slots in the probe

shield are submerged.

2. Power on the device using the power button.

3. Navigate to the “Measure” menu option using the navigation keys and use

the Enter key to select it.

4. The device will present the input parameters selected during set up.

Ensure these are correct and use the enter key to continue. Mud Density

can be adjusted on the device using the navigation and +/- keys.

Testing

Standalone

OFITE, 11302 Steeplecrest Dr., Houston, TX 77065 USA / Tel: 832-320-7300 / Fax: 713-880-9886 / www.ote.com 9

5. Attach the probe to the MudChecker device. Then press the enter key

and insert the probe into your drilling uid sample.

6. Once the probe is fully submerged in your drilling uid sample, press the

enter key to initiate the measurement process. The device will make an

audible tone once measuring is complete.

7. If you are testing in Known Salinity mode, your test is complete. If you are

testing in Estimated Salinity mode, continue with the next steps.

8. Open a packaged container of DSX7 (#365-20-4) dilution solution. Pour

the contents of the DSX7 container into a blending cup. Using a syringe,

measure out 20 mL of undiluted drilling mud and inject the mud into the

DSX7 solution. Blend the contents. It is recommended:

○ Use a quality blender.

○To avoid splashing, blend at the slowest speed and gradually increase

to the highest speed.

○ Ensure the vortex is half the height of the uid level in the cup while

blending.

○Blend for two minutes to ensure the emulsion has been thoroughly

broken.

9. Attach the probe to the MudChecker device. Then press the enter key

and insert the probe into the diluted drilling uid sample.

10. The device will make an audible tone once the measurement process is

complete.

11. If operating the MudChecker v1.5, press the enter key to calculate and

recall your measurement results. MudChecker v1.0 models require the

device to be connected to the software to recall results.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels OfiTE Instrument de mesure

OfiTE

OfiTE 130 Manuel utilisateur

OfiTE

OfiTE 1100 Manuel utilisateur

OfiTE

OfiTE HTHP 100 Manuel utilisateur

OfiTE

OfiTE 175-65 Manuel utilisateur

OfiTE

OfiTE 120-53 Manuel utilisateur

OfiTE

OfiTE 152-95 Manuel utilisateur

OfiTE

OfiTE 2040 Manuel utilisateur

OfiTE

OfiTE 130-85 Manuel utilisateur

OfiTE

OfiTE 4005 Manuel utilisateur

OfiTE

OfiTE 800 Manuel utilisateur

OfiTE

OfiTE HTHP Manuel utilisateur

OfiTE

OfiTE 900 Manuel utilisateur

OfiTE

OfiTE 2025 Manuel utilisateur

OfiTE

OfiTE 150-80 Manuel utilisateur

OfiTE

OfiTE 131-50 Manuel utilisateur

OfiTE

OfiTE 120-75 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
