User's Manual

Scanning Monochromator

MonoScan-2000

Ocean Optics GmbH - Maybachstraße 11 - D-73760 Ostfildern - Tel: +49 (0)711 3416960 - Fax: +49 (0)711 34169685

e-Mail: info@ oceanoptics.eu

Safety Instructions

Instructions: All the safety and operating instructions should be read before the unit is

operated. Before using the power supply for the first time check for transport damage.

Warning: All warnings on the unit and in the operating instructions should be

adhered to.

Use this instrument in a clean laboratory environment.

Moisture

The unit is designed for operation in dry rooms only.

Heat

The unit should be situated away from radiators, hot bodies, ovens or other heat

sources.

Power Sources

The unit should be connected to a power supply only of the type described in the

operating instructions or as marked on the unit.

Object and Liquid Entry

Care should be taken that objects do not fall, or liquids spilled into the enclosure

through openings.

ATTENTION:

There are no warranties if motor parameters are changed!

Unpacking Instructions

Your package should contain:

1x MonoScan-2000

1x Power supply 12VDC

1x RS-232 connection cable

1x Software CD

1x This manual

1 Unpack your MonoScan-2000 carefully. Dropping this instrument may cause permanent

damage.

2 Inspect the outside of the instrument and make sure that there is no damage to your

unit. In case of damage contact the dealer immediately and DO NOT USE THE

INSTRUMENT!

Ocean Optics GmbH - Maybachstraße 11 - D-73760 Ostfildern - Tel: +49 (0)711 3416960 - Fax: +49 (0)711 34169685

e-Mail: info@ oceanoptics.eu

Functions of Panel controls

Front Panel

Power indicator

SMA input SMA output Power switch

Ocean Optics GmbH - Maybachstraße 11 - D-73760 Ostfildern - Tel: +49 (0)711 3416960 - Fax: +49 (0)711 34169685

e-Mail: info@ oceanoptics.eu

Rear Panel

Remote connector

RS232

Typesign

Serialnumber

Power connector

12V DC

Ocean Optics GmbH - Maybachstraße 11 - D-73760 Ostfildern - Tel: +49 (0)711 3416960 - Fax: +49 (0)711 34169685

e-Mail: info@ oceanoptics.eu

Quick Start:

1. Install the software delivered with the MonoScan-2000 (doubleclick on Setup.exe)

2. Connect the Powersupply to mains connection

3. Connect Powersupply to MonoScan-2000

4. Connect your PC to the MonoScan-2000

5. Switch on the MonoScan-2000

6. Start the MonoScan-2000 software

7. Goto Menu “Connection settings” and select the Comport to which the MonoScan is

connected

8. Goto menu “Connection settings” and select “Connect” to establish a connection between

the PC and the MonoScan (the MonoScan-2000 will run to its internal reference and will be

set to 250nm)

9. If the device is found on the chosen Comport the following message appears:

All buttons will be enabled after that

10. Set another wavelength by clicking on one of the buttons (<10nm, <1nm, 1nm >, 10nm >)

or enter a wavelength and click “Goto”.

11. When the measurements are done close the connection between the PC and the

MonoScan-2000 in the menu “Connection settings – Disconnect”

Ocean Optics GmbH - Maybachstraße 11 - D-73760 Ostfildern - Tel: +49 (0)711 3416960 - Fax: +49 (0)711 34169685

e-Mail: info@ oceanoptics.eu

Specifications

Wavelength Range 300nm - 700nm

Connectors SMA 905

Holographic grating 1250 l/mm, Blaze 350nm

FWHM 4...9 nm (200....1000µm fiber)

Interface RS-232

Dimensions (L x W x H) 148 x 112 x 132 mm

Weight 1,2kg

Temperature Range 5°C – 35°C

Power Requirements 12VDC, 400mA

Ocean Optics GmbH - Maybachstraße 11 - D-73760 Ostfildern - Tel: +49 (0)711 3416960 - Fax: +49 (0)711 34169685

e-Mail: info@ oceanoptics.eu

Warranty

Mikropack GmbH warrants to the Original User of this instrument that it shall be free of any defects

resulting from faulty manufacture of this instrument for a period of 12 months from the original data

of shipment.

This instrument should not be used for any Clinical or Diagnostic Purposes. Data generated is

not warranted in any way by Mikropack GmbH. Any defects covered by this Warranty shall be

corrected either by repair or by replacement, as determined by Mikropack GmbH.

There are no warranties which extend beyond the description herein.

This Warranty is in lieu of, and excludes any and all other warranties or representation, expressed,

implied, or statutory, including merchantability and fitness, as well as any and all other obligations

or liabilities of Mikropack GmbH, including, but not limited to special or consequential damages. No

person, firm, or corporation is authorized to assume for Mikropack GmbH. Any additional obligation

or liability not expressed provided for herein except in writing duly executed by an officer of

Mikropack GmbH.

Warranty Handling

Clear with your local distributor the problem or fault.

In case of warranty your local distributor will give you a RMA number.

Send your instrument free of charge and insured to your local distributor.

Please take care of secure and proper packaging.

Your distributor will inform you on delivery time. If there is repair out of warranty you will be

informed about repair cost. The system will be on hold till you have officially ordered the repair.

The system will be send back to you free of transport cost and insured (in case of warranty)
