Oce im2020 Manuel utilisateur
IP Scanner
4514-7704-01
im2020, im2520, im2520f, im3520
Contents
IP Scanner i
Contents
1 Introduction
1.1 Welcome ........................................................................................1-1
Trademark Acknowledgements ..................................................1-1
1.2 Precautions....................................................................................1-2
General precautions ...................................................................1-2
1.3 Enclosed Accessories ..................................................................1-3
1.4 Preparing the LAN Cable and IP Address...................................1-3
1.5 Acceptance of the End User License Agreement ......................1-3
1.6 Compatible Operating Systems...................................................1-4
1.7 Operating Environment of Utilities..............................................1-4
1.8 Specifying the IP Address............................................................1-5
2 Making Connections
2.1 LAN Connection ............................................................................2-1
Connecting the LAN cable..........................................................2-1
LED indicators ............................................................................2-2
2.2 Installing IP Scanner.....................................................................2-3
Utilities disk.................................................................................2-3
Installing IP Scanner
(Windows Me, 98/95, XP, 2000 and NT4.0) ...............................2-3
Uninstalling (Windows Me, 98/95 and NT4.0) ............................2-7
Uninstalling (Windows XP and 2000) .........................................2-8
3 Using IP Scanner
3.1 IP Scanner......................................................................................3-1
Using a dial-up router .................................................................3-2
Using a modem or terminal adapter ...........................................3-2
3.2 IP Scanner Window and Dialog Boxes........................................3-3
Main window...............................................................................3-3
Main window (menu bar) ............................................................3-5
Scanner Settings dialog box.......................................................3-8
Sort Settings dialog box............................................................3-11
Divided Settings dialog box ......................................................3-14
Notify Settings dialog box .........................................................3-17
ViewWindow .............................................................................3-20
im2020, im2520, im2520f, im3520
Contents
ii IP Scanner
3.3 Basic Transmission.................................................................... 3-21
Programming the scanner button (from the computer) ............ 3-21
Scanning documents (from the copier) .................................... 3-24
Viewing the scanned image (from the computer) .................... 3-25
im2020, im2520, im2520f, im3520
Introduction 1
IP Scanner 1-1
1 Introduction
1.1 Welcome
This manual provides descriptions on the use of IP Scanner.
For precautions concerning the use and safety of the main device, refer to
the User Manual provided with the device.
Store the User Manual and utilities disk in a safe place.
Trademark Acknowledgements
Windows®, Windows NT®, Microsoft® and its logo are registered
trademarks of Microsoft Corporation in the United States and other
countries.
Network FAX is a registered trademark of Comuse Co., Ltd.
All other company names and product names mentioned in this manual
are trademarks or registered trademarks of their respective companies.
im2020, im2520, im2520f, im3520
1Introduction
1-2 IP Scanner
1.2 Precautions
General precautions
1. The reproduction of the content of this manual, either partially or in full,
is prohibited without prior permission.
2. The content of this manual is subject to change without notice.
3. Unauthorized duplication or modification is strictly prohibited.
4. This manual was created with careful attention to content; however, if
inaccuracies, errors or omissions are noticed, please contact your
sales or service representative.
5. Some network application functions may not be supported, depending
on the operating environment or other software.
The actual performance of network application functions is determined
by various factors, such as the system configuration, customer data
and operator controls.
Since the operating environment of network application functions
differs depending on the customer, the configuration of specific
products and the suitability of the application software should be
determined specifically for the customer.
6. We assume no responsibility for consequences arising from use,
regardless of items 4 and 5 mentioned above.
7. The software provided with the device, the software included on the
CD-ROM and information such as the design of and materials related
to this manual are the sole property of NEC Corporation, NEC Access
Technica and their licensors.
NEC Corporation, NEC Access Technica and their licensors own all
patents, copyrights and titles to this manual, from the design,
production and duplication to the use and marketing rights. However,
these limitations do not apply if written permission to transfer the
above-mentioned rights to another company is received.
8. The touch panel screens and computer windows and dialog boxes
shown in this manual may differ slightly from the actual products.
im2020, im2520, im2520f, im3520
Introduction 1
IP Scanner 1-3
1.3 Enclosed Accessories
Internet Fax & Network Scan Kit
GCD-ROM containing electronic manuals
GUtility Disk (CD-ROM)
✎
Tip
In order to use the IP Scanner, the Network Interface Card and the
Internet Fax & Network Scan Kit must be installed.
CAUTION
Only use the CD-ROM in a player that is CD-ROM-compatible.
➜If a player not compatible with the CD-ROM format is used, your ears
or speakers may be damaged by the loud noise produced.
1.4 Preparing the LAN Cable and IP Address
In order to use the IP Scanner, a LAN cable and a registered IP address
are required.
The LAN cable is not included; it must be prepared by the user.
✎
Note
The LAN cable should be a cable for Fast Ethernet 100BASE-TX
(Category 5).
1.5 Acceptance of the End User License Agreement
In order to use the network functions, you must agree not to make illegal
copies of or pass to unlicensed persons the software provided with the
device or the software included on the CD-ROM. Before using these
functions, you must read the enclosed End User License Agreement and
agree to the terms of use for the software.
im2020, im2520, im2520f, im3520
1Introduction
1-4 IP Scanner
1.6 Compatible Operating Systems
1.7 Operating Environment of Utilities
* 64 MB or more (128 MB recommended) for Windows®XP or Windows®2000
Utility Operating System
IP Scanner Windows®Me/Windows®98/Windows®95/Windows®2000/
Windows®NT4.0/Windows®XP
IP Scanner
Processor Pentium 133 MHz or higher
Memory 32 MB or more (64 MB recommended)*
Hard disk free space 50 MB or more
im2020, im2520, im2520f, im3520
Introduction 1
IP Scanner 1-5
1.8 Specifying the IP Address
Be sure to specify the IP address of the copier before using the IP
Scanner.
Specify the IP address from the Basic Settings screen.
✎
Note
After changing the settings, turn the unit off, then on again.
Parameter Description
DHCP Specify whether to automatically retrieve the IP
address from the DHCP server or to specify a
fixed IP address.
IP Address Type in the IP address of this unit.
*Type in the IP address only if the “DHCP”
parameter is set to “IP Input”.
Subnet Mask Type in the subnet mask of the connected
network.
*Type in the subnet mask only if the “DHCP”
parameter is set to “IP Input”.
Gateway Type in the default gateway address of the
connected network.
*Type in the default gateway address only if the
“DHCP”parameter is set to “IP Input”.
im2020, im2520, im2520f, im3520
1Introduction
1-6 IP Scanner
1Press the [Utility] key on the copier control panel.
2Touch [Administrator Management].
3Use the keypad to type in the administrator access code, and then
touch [Enter].
4Touch [Admin. 2].
5Touch [Network Set].
6Touch [Basic Setting].
7Specify the settings described above.
8Touch [Enter].
✎
Note
In order to apply the new settings, the unit must be turned off, then on
again.
im2020, im2520, im2520f, im3520
Making Connections 2
IP Scanner 2-1
2 Making Connections
2.1 LAN Connection
This copier can transmit with the TCP/IP protocol on a LAN. Therefore, the
LAN cable must be connected.
Connect to the LAN by using a LAN cable (cable for Fast Ethernet
100BASE-TX).
Connecting the LAN cable
Insert one plug on the LAN cable into the connector (marked LAN) at the
back of the machine, and then insert the other plug into the hub.
✎
Tip
The connector is at the back of the machine.
The LAN cable should be a cable for Fast Ethernet 100BASE-TX
(Category 5).
The LAN cable is not included as an accessory.
Connector for LAN cable
USB printer connector (optional)
•For more details, refer to the manual for
the printer controller.
Power cord connector
LAN USB
LED indicator
im2020, im2520, im2520f, im3520
