HDV-SYSNB2WFL
Wire-Free Network Video Recorder
User Manual
2
3
Contents
CHAPTER 1 SAFETY INSTRUCTION ........................................................................................... 5
CHAPTER 2 WIRE-FREE NVR LIGHTS AND CONNECTORS .......................................................... 7
CHAPTER 3 WIRE-FREE NVR COMMON OPERATIONS .............................................................. 8
3.1 USING THE MOUSE......................................................................................................... 8
3.2 USING THE VIRTUAL KEYBOARD..................................................................................... 8
3.3 PASSWORD ..................................................................................................................... 8
3.1.1 Forgot password..................................................................................................... 9
CHAPTER 4 WIRE-FREE NVR STARTING UP............................................................................. 12
4.1 STARTUP WIZARD ......................................................................................................... 12
4.1.1 Start Wizard.......................................................................................................... 12
4.1.2 Network Configuration......................................................................................... 12
4.1.3 Date/Time............................................................................................................. 13
4.1.4 Disk ....................................................................................................................... 15
4.1.5 Resolution............................................................................................................. 15
4.1.6 Mobile .................................................................................................................. 16
4.1.7 Summary .............................................................................................................. 16
4.2 LIVE VIEW SCREEN........................................................................................................ 17
4.2.1 Camera Quick Toolbar .......................................................................................... 17
4.2.2 Taskbar ................................................................................................................. 18
4.2.3 Start Menu............................................................................................................ 18
CHAPTER 5 WIRE-FREE NVR SYSTEM SETUP .......................................................................... 21
5.1 CHANNEL ...................................................................................................................... 21
5.1.1 Channel................................................................................................................. 22
5.1.2 Video Cover .......................................................................................................... 23
5.1.3 Deterrence............................................................................................................ 24
5.2 TO CONFIGURE RECORD PARAMETERS ........................................................................ 25
5.2.1 Camera stream select........................................................................................... 25
5.2.2 Configure Record Schedule .................................................................................. 25
4
5.3 ALARM .......................................................................................................................... 26
5.3.1 Motion.................................................................................................................. 26
5.3.2 Exception .............................................................................................................. 28
5.4 NETWORK ..................................................................................................................... 29
5.4.1 General ................................................................................................................. 29
5.4.2 Email ..................................................................................................................... 31
5.5 DEVICE .......................................................................................................................... 35
5.5.1 Disk ....................................................................................................................... 35
5.5.2 Cloud .................................................................................................................... 36
5.6 SYSTEM ......................................................................................................................... 36
5.6.1 General ................................................................................................................. 37
5.6.2 Output Configuration ........................................................................................... 40
5.6.3 Multi-user............................................................................................................. 41
5.6.4 Maintenance ........................................................................................................ 45
5.6.5 System Information .............................................................................................. 51
CHAPTER 6 SEARCH, PLAYBACK AND BACKUP ....................................................................... 53
6.1 EVENT SEARCH, PLAYBACK AND BACKUP ..................................................................... 53
6.2 EXTERNAL FILE.............................................................................................................. 54
6.3 TAG................................................................................................................................ 55
CHAPTER 7 REMOTE ACCESS VIA WEB CLIENT....................................................................... 57
7.1 WEB PLUGIN DOWNLOAD AND INSTALLATION............................................................ 57
7.2 WEB CLIENT MANAGER................................................................................................ 60
7.2.1 Live Interface ........................................................................................................ 60
7.2.2 Playback................................................................................................................ 62
7.2.3 Remote Setting..................................................................................................... 64
7.2.4 Local Setting ......................................................................................................... 65
CHAPTER 8 APPENDIX ........................................................................................................... 66
8.1 TROUBLESHOOTING ..................................................................................................... 66
8.2 USAGE MAINTENANCE ................................................................................................. 67
8.3 ACCESSORIES (FOR REFERENCE ONLY) ......................................................................... 68
5
Chapter 1 Safety Instruction
To avoid personal injuries and prevent the equipment and connection devices from being damaged,
please read and follow these safety instruction.
1. Power sources (note: please use the power supply attached or specified by the
manufacturer)
Never operate the equipment by using unspecified power supply.
2. Never push objects of any kind through openings of NVR
Never push objects of any kind through openings of NVR so as to avoid electric shock or other
accidents.
3. Do not install the equipment in the dusty area.
4. Do not install the equipment in rainy or humid environments
Do not place the equipment under humid environment like basement. If the equipment is
accidentally in contact with water, please unplug the power cable and immediately contact your
local dealer.
5. Keep the surface of the equipment clean and dry
Use soft damp cloth to clean the outer case of NVR (do not use liquid aerosol cleaners)
6. Do not operate if any problems are found
If there are any strange smell or sound from NVR, unplug the power cable and contact an
authorized dealer or service center.
7. Do not remove the upper cover
Warning: To avoid electric shock, do not remove the cap from of NVR.
8. Handle with care
If NVR does not work normally because of hitting a hard object, please contact the authorized
dealer for repair or replacement.
9. Use standard lithium battery (Note: Use only the batteries provided or recommended
by the manufacturer)
If the system clock does not continue to work after disconnecting the power supply, replace the
standard 3V lithium battery on the main board.
Warning: To prevent a serious electric shock, disconnect the NVR from its power source before
replacing any battery. Please dispose of the used batteries properly.
6
10. Put the equipment in a place with good ventilation
The NVR system includes an HDD, which produces a heat during operation. Do not block the
ventilation openings on the top, bottom, both sides and the back side. Install the equipment in a
place with good ventilation.
11. The power adapter provided can be used for only one NVR.
Do not connect more equipment to it. This may cause the NVR to restart repeatedly due to
insufficient power.
12. Protect the equipment from water. Do not place objects containing water on the
equipment.
7
Chapter 2 Wire-Free NVR Lights and Connectors
No. Physical interface Connection
1 Power port Connect attached the power supply
2 LAN LAN network interface
3 HDMI Connect with HDMI display devices, such as PC monitor
4 Backup Plug USB Disk
5 Micro SD MicroSD card slot (32GB card installed)
6 Mouse Connect USB mouse
7 Storage Connect USB Disk
8
Chapter 3 Wire-Free NVR Common Operations
3.1 Using the Mouse
Left Button of Mouse Right Button of Mouse
Click once to choose an item in the menus and confirm your
selection.
Click once to open the pop-up
menu in the Live View screen and
to exit from the menus.
Click once on a channel in the Live View screen to open Camera
Quick Toolbar
Double-click
on the channel in the Live View screen to view the
channel in full screen mode. Double-click again to exit the full
screen mode.
Click and hold to drag an area on motion mode or adjust the
values of sliders and scales on menu mode.
3.2 Using the Virtual Keyboard
The virtual keyboard appears when you need to enter data.
3.3 Password
The first time use the Wire-Free NVR, you must set an administrative user password. Save and
protect your administrative user password in a secure place.
Click to delete a
character
Click to enter
Click to toggle the keyboard to
upper case and more punctuation
Move the cursor to left
Move the cursor to right
9
Language:Choose an OSD language.
New Admin name: To set your own administrator name.
New Admin Password: To set your own password. The password must contain 8 characters.
Confirm Password: Enter your own password again.
Click Apply to confirm your settings and go to the login interface. Draw an unlock pattern or Enter
your user name and password to Login to the system.
3.1.1 Forgot password
NOTE: Email settings must be properly configured before using the Forgot Password feature. If you
forget your password, you will be unable to login to the system. Please contact Tech Support to reset
the password.
If you forget the administrator password, you can reset it. Do the following:
1. In the Login menu, click Forgot Password.
10
2. Click OK to send email.
The following message should appear.
