Nyrius Songo BR40 Manuel utilisateur
Wireless Bluetooth® Music Receiver
Récepteur de musique Bluetooth® sans l
NYRIUS.COM/SUPPORT BR40
INSTRUCTION MANUAL
MANUEL D’INSTRUCTION
SONGO™
- 2 -
FCC STATEMENT
IC STATEMENT
This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
This class B digital apparatus complies with Canadian ICES-003.
WARNING:
This equipment has been tested and is found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
WARNING:
Changes or modications not expressly approved by the party responsible for
compliance with the FCC Rules could void the user’s authority to operate
this equipment.
Industry Canada Statement
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of the device.
- 3 -
1. Read all instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third
prong are provided for your safety. If the provided plug does not t into your
outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularily at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. Unplug this apparatus during lightning storms or when unused for long periods
of time.
13. Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged. Liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
14. Apparatus shall not be exposed to dripping or splashing, and that no objects
lled with liquids, such as vases, shall be placed on the apparatus.
15. The battery shall not be exposed to excessive heat such as sunshine, re or
the like.
16. The direct plug-in adapter is used as disconnect device, the disconnect device
shall remain readily operable.
17. WARNING: To reduce the risk of re or electric shock, do not expose this
apparatus to rain or moisture.
This marking indicates that this product should not be disposed with
other household wastes throughout North America. To prevent possible
harm to the environment or human health from uncontrolled waste
disposal, recycle it responsibly to promote the sustainable reuse of
material resources. To return your used device, please use the return
and collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe recycling.
SAFETY INFORMATION
- 4 -
FCC Statement............................................................................................... 2
IC Statement................................................................................................... 2
Safety Information......................................................................................... 3
What’s Included ............................................................................................. 4
Buttons and Connections ............................................................................ 5
Setup................................................................................................................. 6
Connecting your Bluetooth Music Receiver ............................... 6
Pairing .............................................................................................................. 7
Pair & Connect .................................................................................... 7
To Disconnect ..................................................................................... 8
Pairing multiple devices ................................................................... 8
Reconnecting your device ............................................................... 9
Understanding the LEDs................................................................... 9
Troubleshooting............................................................................................ 10
Specications ................................................................................................ 10
Nyrius Warranty............................................................................................ 11
• Bluetooth Music Receiver
• Power Adapter with micro USB
connection
• 3ft 3.5mm Auxiliary Cable
• Quick Start Guide
• 1 Year Warranty
• Lifetime Customer Support
DISCLAIMERS
Maximum line of sight for Bluetooth transmission range is 33 feet. Obstacles may decrease
transmission distance.
Certain Bluetooth features, including those listed, may not be supported by all compatible
Bluetooth-enabled devices, and/or the functionality of such features may be limited in certain
devices, or by certain wireless carriers.
This unit should only be used with the power adapter included in this package.
We reserve the right to change models, conguration, or specications without notice or
liability. Product may not be exactly as shown.
©2014 NYRIUS®. All rights reserved. NYRIUS®, the NYRIUS® logo, and other NYRIUS® marks
may be registered. All other Trademarks are the property of their respective owners.
WHAT’S INCLUDED
TABLE OF CONTENTS
- 5 -
1LED indicator
2Audio Output
3 DC 5V Power Input
BUTTONS & CONNECTIONS
1 2 3
TOP BOTTOM
FRONT BACK
DC 5VAUDIO OUT
- 6 -
NOTE: Maximum line of sight for Bluetooth transmission range is
33 feet. Obstacles may decrease transmission distance.
Connecting your Bluetooth Music Receiver to your Home Theater
Receiver/Audio Device:
• Connect the power supply to the Bluetooth Receiver.
• The LED light will ash once to show the unit is powered and
ready to be paired.
Using 3.5mm Auxiliary Audio Cable
• Connect one end of the 3.5mm Auxiliary Cable to the Audio
output on the Bluetooth Receiver.
• Connect the other end of the 3.5mm Auxiliary Cable to the Aux
IN input on your Home Theater Receiver/Audio Device.
SETUP
DC 5VAUDIO OUT
DC 5VAUDIO OUT
AUX IN
- 7 -
PAIRING
Pairing Bluetooth® enabled Smartphones
Congure
Play any Smartphone or Bluetooth enabled device wirelessly
through your Home Theater Receiver/Audio Device.
Certain Bluetooth features, including those listed, may not be supported by
all compatible Bluetooth-enabled devices, and/or the functionality of such
features may be limited in certain devices, or by certain wireless carriers.
For Bluetooth® enabled Smartphones
PAIR & CONNECT
1. Go to SETTINGS to turn
on Bluetooth.
2. A list of Bluetooth devices
will appear.
3. Tap on "Nyrius BR40".
4. Click YES if asked to connect.
You can now control your music using your Smartphone through
your Home Theater Receiver/Audio Device. The "Bluetooth Active"
icon will appear on the main screen when connected.
How you access your Bluetooth Settings may vary from one
manufacturer to another.
- 8 -
TO DISCONNECT
You can turn off the Bluetooth function on
your Smartphone or:
1. Go to SETTINGS and into your
Bluetooth settings.
2. A list of Bluetooth devices will appear.
3. Tap on "Nyrius BR40".
4. Select YES if asked to disconnect. The
LED on the Bluetooth Receiver will
turn off when disconnected.
The "Bluetooth Active"icon will disappear from the main screen
once disconnected.
PAIRING
NOTE: Maximum line of sight for Bluetooth transmission range is
33 feet. Obstacles may decrease transmission distance.
Pairing multiple devices
Although the Bluetooth Receiver can only play music from one
device at a time, it can memorize up to 8 device proles.
Switching from one device to another:
1. Access the SETTINGS and turn Bluetooth function of the
device OFF.
2. The Bluetooth Music Receiver can now be connected to a
different device.
3. Follow the "PAIR & CONNECT"instructions to pair a new device.
- 9 -
Reconnecting your device
If you move out of range or turn
off the Bluetooth feature on
your device, the Bluetooth Music
Receiver will disconnect from your
device. To reconnect, simply:
1. Go to SETTINGS to turn on Bluetooth.
2. A list of Bluetooth devices will appear.
3. Tap on “Nyrius BR40”.
4. Click YES if asked to connect.
UNDERSTANDING THE LEDS
No light, but
power adapter
is plugged in
• Power is ON or
• Pairing in progress
• Waiting for
connection
Solid white light • Connected
• Device and
Bluetooth Receiver
are connected
PAIRING
FOR BEST SIGNAL/
MAXIMUM LINE OF SIGHT FOR BLUETOOTH TRANSMISSION RANGE IS 33 FEET
* OBSTACLES MAY DECREASE TRANSMISSION DISTANCE.
.
Support & Online live web chat NYRIUS.COM/SUPPORT
- 10 -
Problem Device Bluetooth Receiver
No music
from stereo
speakers
• Conrm that Bluetooth
function is ON
• Conrm you are
connected via Bluetooth
with the Bluetooth
Receiver
• Conrm you are playing
music from your device
• Conrm the volume is
set to a comfortable
listening level
• Conrm you are within
range of the Bluetooth
Receiver
• Conrm Bluetooth
Receiver is powered
• Conrm audio cable
is correctly and rmly
connected to the Bluetooth
Receiver
• Conrm the stereo volume
is set to a comfortable
listening level
• Conrm you are within
range of the Receiver
• Conrm that the audio
source selection of your
amplier is correct with
your audio connection
(Auxiliary audio)
TROUBLESHOOTING
SPECIFICATIONS
Bluetooth Prole 4.0 A2DP EDR (Enhanced Data Rate)
Outputs 3.5mm Auxiliary Output
Range 33 feet (line of sight)
Number of Devices Memorized 8
Frequency (transmission) 2,402 ~ 2,480MHz
3.5mm AUX Frequency Response 20 Hz to 20kHz
Power Supply Micro USB; 100~240V, 5V / 0.3A
Dimensions 2.3 x 2.3 x 0.6 inches /
6 x 6 x 1.6 cm (LxWxH)
Weight 0.07 lbs / 0.032 kg
Audio Format Compatibility MP3, WAV, FLAC, OGG, AAC,
ALAC, M4A, M4P, WMA, AMR, AIFF,
HE-AAC
Table des matières
Langues :
Autres manuels Nyrius Récepteur
Nyrius
Nyrius SONGO Tap Manuel utilisateur
Nyrius
Nyrius ARIES Matrix Manuel utilisateur
Nyrius
Nyrius TB72 Manuel utilisateur
Nyrius
Nyrius WTX001A Manuel utilisateur
Nyrius
Nyrius SONGO PORTABLE Manuel utilisateur
Nyrius
Nyrius SONGO HiFi BR50 Manuel utilisateur
Nyrius
Nyrius WS54RX Manuel utilisateur
Nyrius
Nyrius NAVS500 Manuel utilisateur
Nyrius
Nyrius WS54 Manuel utilisateur
Nyrius
Nyrius NAVS500 Manuel utilisateur
