Nyrius NY-GS10 Manuel utilisateur
5.8GHz 4 Channel Wireless Audio/Video Sender
Émetteur audio/vidéo sans l 5,8 GHz à 4 canaux
NYRIUS.COM/SUPPORT NY-GS10
INSTRUCTION MANUAL
MANUEL D’INSTRUCTION
NY-GS10 Manual.indd 1 7/3/2013 9:50:20 AM
- 2 -
FCC STATEMENT
IC STATEMENT
This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
This class B digital apparatus complies with Canadian ICES-003.
WARNING:
This equipment has been tested and is found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
WARNING:
Changes or modications not expressly approved by the party responsible for
compliance with the FCC Rules could void the user’s authority to operate
this equipment.
Industry Canada Statement
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of the device.
NY-GS10 Manual.indd 2 7/3/2013 9:50:21 AM
- 3 -
1. Read all instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third
prong are provided for your safety. If the provided plug does not t into your
outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched, particularily at plugs,
convenience receptacles and the point where they exit from the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. Unplug this apparatus during lightning storms or when unused for long periods
of time.
13. Refer all servicing to qualied service personnel. Servicing is required when
the apparatus has been damaged in any way. Damages include power-supply
cord or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
14. Apparatus shall not be exposed to dripping or splashing, and that no objects
lled with liquids, such as vases, shall be placed on the apparatus.
15. The battery shall not be exposed to excessive heat such as sunshine, re or
the like.
16. The direct plug-in adapter is used as disconnect device, the disconnect device
shall remain readily operable.
17. WARNING: To reduce the risk of re or electric shock, do not expose this
apparatus to rain or moisture.
This marking indicates that this product should not be disposed with
other household wastes throughout North America. To prevent possible
harm to the environment or human health from uncontrolled waste
disposal, recycle it responsibly to promote the sustainable reuse of
material resources. To return your used device, please use the return
and collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe recycling.
SAFETY INFORMATION
NY-GS10 Manual.indd 3 7/3/2013 9:50:21 AM
- 4 -
FCC Statement............................................................................................... 2
IC Statement................................................................................................... 2
Safety Information......................................................................................... 3
What’s Included ............................................................................................. 4
Buttons and Connections ............................................................................ 5
Setup................................................................................................................. 6
Transmitter .......................................................................................... 6
Receiver................................................................................................ 7
Proper Orientation of Devices ........................................................ 8
Operating Remote Control .............................................................. 9
Troubleshooting............................................................................................10
Specications .................................................................................................11
Nyrius Warranty............................................................................................ 12
5.8GHz Wireless
Receiver
5.8GHz Wireless
Transmitter
• External IR Extender
• 2 x 100-240V AC Power
Adapters
• 2 x RCA Audio/Video
Composite Connection Cables
• Quick Start Guide
• 1 Year Warranty
• Lifetime Customer Support
VIDEO IN
AUDIO IN
LEFT RIGHT
DC 12V VIDEO OUT
AUDIO OUT
LEFT RIGHT
DC 12V
DISCLAIMERS
Maximum line of sight transmission range is 225 feet. Obstacles decrease
transmission distance. Microwave ovens (when in use) may cause signal disruption
at close range. Buildings with metal frames may also cause signal disruption.
This unit should only be used with the power adapters included in this package.
We reserve the right to change models, conguration, or specications without
notice or liability. Product may not be exactly as shown.
©2013 NYRIUS®. All rights reserved. NYRIUS®, the NYRIUS® logo, and other
NYRIUS® marks may be registered. All other Trademarks are the property of their
respective owners.
WHAT’S INCLUDED
TABLE OF CONTENTS
NY-GS10 Manual.indd 4 7/3/2013 9:50:21 AM
- 5 -
1IR Remote Output (for Infrared Extender)
2 & 5 ON / OFF Switch
3 & 6 Channel Selector
4IR Frequency Selector (A - 38KHz, B - 56KHz)
7 & 11 DC 12V Adapter Input
8Audio IN - Left
9Audio IN - Right
10 Video IN
12 Audio OUT - Left
13 Audio OUT - Right
14 Video OUT
4 3 2 1
RECEIVER
4 3 2 1
REMOTE CH
A B
IR
TRANSMITTER
1 2 3 4 56
BUTTONS & CONNECTIONS
VIDEO IN
AUDIO IN
LEFT RIGHT
DC 12V
TRANSMITTER
ÉMETTEUR
7 8 9 10
VIDEO OUT
AUDIO OUT
LEFT RIGHT
DC 12V
RECEIVER
RÉCEPTEUR
11 12 13 14
NY-GS10 Manual.indd 5 7/3/2013 9:50:21 AM
- 6 -
VIDEO IN
AUDIO IN
LEFT RIGHT
DC 12V
TRANSMITTER
VIDEO OUT
AUDIO OUT
LEFT RIGHT
4 3 2 1
REMOTE ON
A B
IR
TRANSMITTER
4 3 2 1
ON
4 3 2 1
REMOTE ON
A B
IR
TRANSMITTER
IR
IN FRONT
NOTE: Maximum line of sight transmission range is 225 feet.
Obstacles decrease transmission distance.
Transmitter
• Connect the power supply
to the Transmitter.
• Slide ON/OFF switch to ON
• Select a channel.
• Connect IR Remote Extender
and place it in front of, but
not on the IR window of the
media source.
• Connect one end of the RCA cable to the RCA inputs on
the Transmitter.
• Connect the other end of the RCA cable to the outputs on
the media device you would like to transmit wirelessly.
SETUP
NY-GS10 Manual.indd 6 7/3/2013 9:50:21 AM
- 7 -
VIDEO OUT
AUDIO OUT
LEFT RIGHT
DC 12V
RECEIVER
4 3 2 1
RECEIVER
4 3 2 1
ON
VIDEO OUT
AUDIO OUT
LEFT RIGHT
DC 12V
RECEIVER
Receiver
• Connect the power supply
to the Receiver.
• Slide ON/OFF switch to ON
• Place Channel Selector
on same channel as
Transmitter.
• Connect one end of the RCA cable to the RCA outputs on
the Receiver.
• Connect the other end of the RCA cable to the RCA
inputs on the back of your TV.
• Ensure that you keep the IR window pointed in the
direction that you will be using the remote control.
SETUP
NY-GS10 Manual.indd 7 7/3/2013 9:50:21 AM
- 8 -
4 3 2 1
REMOTE CH
A B
IR
TRANSMITTER RECEIVER
FRONT
Proper Orientation of Devices
Orienting the 5.8GHz A/V Antennas
• This system delivers high quality audio and video by
using directional antennas, which must be oriented
properly to get the best results. The antennas are
designed to rotate in almost any direction.
WARNING: Antennas do not rotate 360° freely. Rotating past the
point where resistance is felt will result in permanent damage to
the device.
Orient the two antennas to face each other.
SETUP
NY-GS10 Manual.indd 8 7/3/2013 9:50:22 AM
- 9 -
Be sure to angle or rotate antennas toward each other.
Operating Remote Control - Receiver
• Please be sure to point the Remote
Control at the IR Sensor Window.
• Please be sure there are no
obstructions in front of the IR
Sensor Window.
• Keep Remote Control at a 15° angle.
• Optimum distance is not less than one
foot away and no more than 16 feet
away from the IR Sensor Window.
SETUP
1ft 16ft
IR SENSOR
WINDOW
NY-GS10 Manual.indd 9 7/3/2013 9:50:22 AM
- 10 -
Problem Media Source Receiver/Transmitter
No Picture/
Sound
• Media source/device is
not connected to the
transmitter
• The AC adapter is not
plugged in
• Power switch is not in
ON position on either
the media source or one
of the devices
• AC adapter is not
plugged in
• Power switch is not in
ON position
• TV or Monitor is not
powered ON
• Improper A/V cable
connection
Poor Reception • Video source/device is
not connected to the
sender
• The AC adapter is not
plugged in
• Adjust antenna direction
• Improper channel
selection
Flickering
• Check that all
connections are secure
& connected properly
• Check for any strong
light or IR interference
to IR windows
• Check that all
connections are secure
& connected properly
• Adjust the brightness
control on TV/monitor
• Select alternate channel
on NY-GS10
Picture too
Bright or Dark
• Strong spotlight in the
eld of view
• Lighting source in the
eld of view
• Adjust the brightness
control on TV/monitor
Flickering
or Video is
Scrambled
• Adjust the antenna
direction if applicable
• Connect to another
device (like a TV)
to ensure the media
device is working
properly
• Adjust the antenna
direction
• Check that all
connections are secure
& connected properly
• Select alternate channel
on NY-GS10
Support & Live Web Chat NYRIUS.COM/SUPPORT
TROUBLESHOOTING
NY-GS10 Manual.indd 10 7/3/2013 9:50:22 AM
Autres manuels pour NY-GS10
2
Table des matières
Langues :
Autres manuels Nyrius Récepteur
Nyrius
Nyrius SONGO HiFi BR50 Manuel utilisateur
Nyrius
Nyrius NAVS500 Manuel utilisateur
Nyrius
Nyrius NAVS500 Manuel utilisateur
Nyrius
Nyrius Songo BR40 Manuel utilisateur
Nyrius
Nyrius WS54 Manuel utilisateur
Nyrius
Nyrius WTX001A Manuel utilisateur
Nyrius
Nyrius NPCS650 Manuel utilisateur
Nyrius
Nyrius SONGO Tap Manuel utilisateur
Nyrius
Nyrius NAVS500 Manuel utilisateur
Nyrius
Nyrius TB72 Manuel utilisateur
