NTI ST-C5HDA-600 Manuel utilisateur

MAN079 Rev Date 4/13/2007

ST-C5HDA-600

ST-C5HDTV-600

EXTENDERS

Installation and Operation Manual

XTENDEX®Series

ST-C5HDA-600

HD Video/Digital

Audio Extender

TRADEMARK

XTENDEX is a registered trademark of Network Technologies Inc in the U.S. and other countries.

in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,

without the prior written consent of Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202.

CHANGES

The material in this guide is for information only and is subject to change without notice. Network Technologies Inc reserves the

right to make changes in the product design without reservation and without notification to its users.

Shielded CAT 5,5e, or 6 cable must be used to connect to the CAT5 ports in order to meet CE emission and immunity

requirements.

CE Statement

We, Network Technologies Inc, declare under our sole responsibility that the ST-C5HDA-600 and ST-C5HDTV-600 are in

conformity with European Standard EN55022.

Note: CAT5 connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series products

should not be run underground, outdoors or between buildings.

WARNING: Outdoor or underground runs of CAT5 cable could be dangerous and will void the warranty.

TABLE OF CONTENTS

Introduction...................................................................................................................................................................... 1

Materials .......................................................................................................................................................................... 2

Features and Functions................................................................................................................................................... 3

Limitations ....................................................................................................................................................................... 5

Preparation for Installation .............................................................................................................................................. 5

Installation ....................................................................................................................................................................... 6

Installing The Local Unit .............................................................................................................................................. 6

Connect The CAT5 Cable............................................................................................................................................ 7

Installing The Remote Unit .......................................................................................................................................... 8

Connect the CAT5 cable.............................................................................................................................................. 8

Plug-in and Power Up.................................................................................................................................................. 9

Video Quality ................................................................................................................................................................... 9

Technical Specifications................................................................................................................................................ 10

Interconnection Cable Wiring Method ........................................................................................................................... 10

Troubleshooting............................................................................................................................................................. 11

TABLE OF FIGURES

Figure 1- Connect the Local Unit to audio/video source ....................................................................................................................6

Figure 2- Connect the local television and speakers to the Local Unit............................................................................................... 7

Figure 3- Connect CAT5 cable to Local Unit...................................................................................................................................... 7

Figure 4- Connect the Extended Components to the Remote Unit ....................................................................................................8

Figure 5- Connect the CAT5 cable to the Remote Unit......................................................................................................................8

Figure 6- Connect the AC adapter to the Remote Unit ......................................................................................................................9

Figure 7- View looking into RJ45 female.......................................................................................................................................... 10

NTI EXTENDEX Extenders

INTRODUCTION

The XTENDEX Series ST-C5HDA-600 CAT5 Extender (XTENDEX) is designed to enable the signals from one high-definition

(HD) video and digital (coax / SPDIF) audio source to be seen and heard through two high-definition televisions (HDTV) and

digital audio devices, one of each local and one of each remote. Possible digital video and audio sources include a DVD player,

cable television box, home entertainment system, etc.. Digital audio devices include a HDTV, Home Theater System, Digital

Audio Receiver, or Digital Speaker set, etc.. The remote HDTV and audio device can be located as much as 600 feet away from

the source via Category 5 unshielded twisted-pair cable. The local HDTV and audio device will be located near the source.

The XTENDEX Series ST-C5HDTV-600 CAT5 Extender is the same as the ST-C5HDA except that it is compatible with a stereo

line-level audio source and devices (HDTV Speakers, Home Theater or Stereo System, Stereo Amplifier, Headphones, Computer

Speakers, etc..) instead of a digital audio source and devices.

The XTENDEX Series Extender is extremely simple to install and has been thoroughly tested to insure reliable performance.

Through the use of Category 5 cable it is possible to economically increase the flexibility of an entertainment system. Here are

some of the features and ways this can benefit the user:

•Allows the placement of a HDTV and audio devices in a location where only these parts are needed without having the

audio/video source there too, taking up valuable space

•Allows an audio/video source (DVD player, cable television box, stereo amplifier, home entertainment system, etc), to

be seen and heard by both a local and/or remote set of devices (up to 600 feet away)

•Compatible with component video

•Provides crisp and clear 1080i resolution up to 1920x1080 with a 30MHz bandwidth and 720p resolution up to 1280x720

with a 37 MHz bandwidth

•Video quality adjustment, for varying lengths of cable, is automatic providing optimum image quality

•Digital transmission of audio signals reduces any loss in quality

•HDTV connections are dedicated connectors for YPbPr

•Hot-plugging of all video and audio connections is supported

NTI EXTENDEX Extenders

MATERIALS

Materials Included with this kit:

9NTI XTENDEX ST-C5HDA or ST-C5HDTV Local Unit

9NTI XTENDEX ST-C5HDA or ST-C5HDTV Remote Unit

92- 120VAC or 240VAC at 50 or 60Hz-9VDC/1.0A AC Adapters

9This owner's manual

Additional materials may need to be ordered, depending upon the configuration:

¾CAT5/5e/6 unshielded twisted-pair cable(s) terminated with RJ45 connectors wired straight thru- pin 1 to pin 1, etc. (see pg.

10 for proper EIA/TIA 568 B wiring method)

Note: CAT5/5e/6 shielded twisted-pair cable(s) must be used to meet CE emission and immunity requirements.

Contact your nearest NTI distributor or NTI directly for all of your KVM needs at 800-RGB-TECH (800-742-8324) in US & Canada

or 330-562-7070 (Worldwide) or at our website at http://www.networktechinc.com and we will be happy to be of assistance.

Cables needed

Audio and Video cables with RCA connectors will be required for connecting the HDTV and audio devices to the XTENDEX Local

and Remote Units.

Purpose Cable needed

Video for ST-C5HDA-600 and ST-C5HDTV-600 75 ohm coax cable with 3 RCA connectors on each end (red,green,blue)

Audio for ST-C5HDA-600 Coax cable for digital audio

Audio for ST-C5HDTV-600 Standard stereo audio cable with RCA connectors

NTI EXTENDEX Extenders

FEATURES AND FUNCTIONS

1a. Orange RCA jack- for connection of local dIgital (coax / SPDIF) audio device's "audio in"

1b. Red RCA jack- for connection of local right line level stereo audio device

1c. White RCA jack- for connection of left local line level stereo audio device

2. Green RCA jack- for connection of "Y" component lead from local HD television

3. Blue RCA jack- for connection of "Pb" component lead from local HD television

4. Red RCA jack- for connection of "Pr" component lead from local HD television

Note: Local device

connections (items 1-4) are

not required for Remote

Unit o

eration

S T - C 5 H D A - 6 0 0 L o c a l U n i t

( R e a r V i e w )

R C A C o n n e c t o r s

( F r o n t V i e w )

N T I

N e t w o r k T e c h n o l o g i e s I n c

X T E N D E X

N T I

N e t w o r k T e c h n o l o g i e s I n c

X T E N D E X

1 a

( O r a n g e )

( R e d )

( B l u e )

( G r e e n )

S T - C 5 H D T V - 6 0 0 L o c a l U n i t

( F r o n t V i e w ) ( R e a r V i e w )

N T I

N e t w o r k T e c h n o l o g i e s I n c

X T E N D E X

N T I

N e t w o r k T e c h n o l o g i e s I n c

X T E N D E X

R C A C o n n e c t o r s

( R e d )

( B l u e )

( G r e e n )

( W h i t e )

( O r a n g e )

1 c

1 b

NTI EXTENDEX Extenders

5. Cat 5- RJ45 female- for connecting the CAT 5 cable

6. Yellow LED- traffic indicator- illuminates when there is traffic between the local and remote units

7. Green LED- power indicator- illuminates when power has been supplied to the unit

8. 9VDC- 1.0A- connection jack for the AC adapter

9. A/V Input- for connecting to audio/video signal source:

A/V Cable Connections

Connector

Color

Connect to

Red "Pr" on video source

Blue "Pb" on video source

Green "Y" on video source

Digital audio source (coax / SPDIF) (ST-C5HDA ONLY)Orange

Right channel of stereo audio source (ST-C5HDTV ONLY)

White Left channel of stereo audio source (ST-C5HDTV ONLY)

10a. Orange RCA connector- for connecting remote digital audio device's "audio in"

10b. Red RCA connector- for connecting remote right line level stereo audio device

10c. White RCA connector- for connecting remote left line level stereo audio device

11. Green RCA connector- for connecting "Y" component lead from remote HD television

12. Blue RCA connector- for connecting "Pb" component lead from remote HD television

13. Red RCA connector- for connecting "Pr" component lead from remote HD television

S T - C 5 H D A - 6 0 0 R e m o t e U n i t

( F r o n t V i e w ) ( R e a r V i e w )

N T I

N e t w o r k T e c h n o l o g i e s I n c

X T E N D E X

N T I

N e t w o r k T e c h n o l o g i e s I n c

X T E N D E X

10a

1 1

1 3

S T - C 5 H D T V - 6 0 0 R e m o t e U n i t

( F r o n t V i e w ) ( R e a r V i e w )

N T I

N e t w o r k T e c h n o l o g i e s I n c

X T E N D E X

N T I

N e t w o r k T e c h n o l o g i e s I n c

X T E N D E X

10b

10c

1 1

1 3

NTI EXTENDEX Extenders

LIMITATIONS

•The audio output of the XTENDEX is compatible with self-powered stereo speakers. Otherwise, connect the audio outputs

to an audio receiver.

PREPARATION FOR INSTALLATION

•Locations should be chosen for the HDTV and speakers that also have space to connect the Remote and Local Units within

the distance provided by the cables.

•The CAT5 cables must be run to the locations where the Remote and Local Units will be connected. Be careful to route the

cables away from any sources of magnetic fields or electrical interference that might reduce the quality of the video and audio

signals (i.e. AC motors, welding equipment, etc.).

•All cables should be installed in such a way that they do not cause stress on their connections to the equipment. Extended

lengths of cable hanging from a connection may interfere with the quality of that connection. Secure cables as needed to

minimize this.

Note: CAT5 connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series products

should not be run underground, outdoors or between buildings.

WARNING: Outdoor or underground runs of CAT5 cable could be dangerous and will void the warranty.

NTI EXTENDEX Extenders

INSTALLATION

Installing The Local Unit

1. Plug the cables of the Local Unit into the audio/video source. (See Fig. 1) as per the chart below.

Connector

Color

Connect to

Red "Pr" on video source

Blue "Pb" on video source

Green "Y" on video source

Digital audio source (ST-C5HDA ONLY)Orange

Right channel of stereo audio source (ST-C5HDTV ONLY)

White Left channel of stereo audio source (ST-C5HDTV ONLY)

Figure 1- Connect the Local Unit to audio/video source

S T - C 5 H D A - 6 0 0 L o c a l U n i t

T o p V i e w R C A C o n n e c t o r

C o n n e c t t o

H D V i d e o S o u r c e

C o n n e c t t o

D i g i t a l A u d i o

S o u r c e

( R e a r V i e w )

N T I

N e t w o r k T e c h n o l o g i e s I n c

X T E N D E X

S T - C 5 H D T V - 6 0 0 L o c a l U n i t

( R e a r V i e w )

N T I

N e t w o r k T e c h n o l o g i e s I n c

X T E N D E X

T o p V i e w R C A C o n n e c t o r

C o n n e c t t o

H D V i d e o S o u r c e

C o n n e c t t o

S t e r e o A u d i o

S o u r c e

L e f t

R i g h t

NTI EXTENDEX Extenders

Green Power LED

Yellow Traffic LED

CAT5 Cable to

Remote Unit

ST-C5HDA-600 Local Unit

(Rear View)

NTI R

Netw ork Tech nolo gies Inc

XTENDEX

To Audio/

Video Source

2. Connect 75 ohm RCA cables between the local HDTV and the RCA connectors marked "Y", "Pb", and "Pr" on the local unit

as shown in Fig. 2.

3. Connect coax cable for digital audio (ST-C5HDA-600 only) or stereo audio cable (ST-C5HDTV-600 only) between the audio

connection(s) and the audio device. See Fig. 2.

(Note- Connecting devices to the Local Unit is optional. A local HDTV and audio device is not required for the Remote

Unit to work)

Figure 2- Connect the local television and audio device to the Local Unit

Connect The CAT5 Cable

Connect the CAT5 cable to the “Cat 5” port on the Local Unit. (See

Fig. 3.) When properly inserted the cable end should snap into

place.

Note: If an RJ45 wall outlet is

being used, connect the other end of the

extension cable to the RJ45 wall outlet.

WARNING: Never connect the XTENDEX

to an Ethernet card, Ethernet router, hub or

switch or other Ethernet RJ45 connector of an

Ethernet device. Damage to devices

connected to the Ethernet may result.

Figure 3- Connect CAT5 cable to Local Unit

L o c a l T e l e v i s i o n

0 , 6 8

( F r o n t V i e w )

N T I

N e t w o r k T e c h n o l o g i e s I n c

X T E N D E X

S T - C 5 H D T V - 6 0 0 L o c a l U n i t

S t e r e o

S p e a k e r s

S e l f - P o w e r e d

A m p l i f i e r

7 5 o h m R C A

c a b l e s

s t e r e o

a u d i o

c a b l e

( F r o n t V i e w )

S T - C 5 H D A - 6 0 0 L o c a l U n i t

N T I

N e t w o r k T e c h n o l o g i e s I n c

X T E N D E X

0 , 6 8

L o c a l T e l e v i s i o n

D i g i t a l A u d i o

R e c e i v e r

7 5 o h m R C A

c a b l e s

c o a x c a b l e f o r

d i g i t a l a u d i o

Autres manuels pour ST-C5HDA-600

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels NTI Extenseur

NTI

NTI VOPEX-C5USBVA-4 Manuel utilisateur

NTI

NTI XTENDEX ST-C5USBVA-300M Manuel utilisateur

NTI

NTI Xtendex ST-C5KVM-300 Manuel utilisateur

NTI

NTI USB-C5-200 Manuel utilisateur

NTI

NTI XTENDEX ST-FO4K18GB-RSLA-LCV2 Manuel utilisateur

NTI

NTI XTENDEX ST-C6DVIA-IR-R-300 Manuel utilisateur

NTI

NTI ST-C5KVM-600 Manuel utilisateur

NTI

NTI ST-FOVARS-LC Manuel utilisateur

NTI

NTI Xtendex ST-C5USB2V2ARST Manuel utilisateur

NTI

NTI ST-IP4K18GB-L-RS Manuel utilisateur

NTI

NTI USB-IP-4LC Manuel utilisateur

NTI

NTI XTENDEX Series ST-C5RS-LCRS232 Manuel utilisateur

NTI

NTI XTENDEX Series Manuel utilisateur

NTI

NTI XTENDEX Series Manuel utilisateur

NTI

NTI XTENDEX Series Manuel utilisateur

NTI

NTI XTENDEX USB-C5 Manuel utilisateur

NTI

NTI XTENDEX ST-C5USBV Manuel utilisateur

NTI

NTI XTENDEX Series Manuel utilisateur

NTI

NTI XTENDEX Series Manuel utilisateur

NTI

NTI XTENDEX ST-C5KVM2ARS-1000S Manuel utilisateur

NTI

NTI XTENDEX ST-C5USBV Manuel utilisateur

NTI

NTI USB2-C5-LCND492 Manuel utilisateur

NTI

NTI XTENDEX Series Manuel utilisateur

NTI

NTI ST-UP4K18GB-L-RS Manuel utilisateur

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

Atlona

Atlona RS232 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur
