Operating Instructions

5“ Coin Validator

with ccTalk/S1 interface

Table of conTenTs

BA_v2_eagle_serial_EN_2-1 3

Table of contents

1 Revision protocol 7

2 About ... 8

2.1 About these operating instructions 8

2.1.1 Text conventions 8

2.1.2 Additional useful technical documentation 9

2.2 About the v2eagle 9

2.2.1 The v2eagle features 9

2.2.2 Models 10

2.2.2.1 Coin entry and return area 10

2.2.2.2 Internal 4-fold/5-fold sorting mechanism 11

2.2.2.3 Communication protocol 11

3 Safety instructions 12

3.1 Proper use 12

3.2 Protecting persons and equipment 12

4 Design 13

4.1 Overview 13

4.1.1 v2eagle with 5-fold in-line sorting mechanism (standard) 13

4.1.2 v2eagle with 5-fold cross-way sorting mechanism 14

4.1.3 v2eagle with 4-fold sorting mechanism 15

4.2 Coin path 16

4.3 Product label 17

4.3.1 Model number decoding 18

4.3.2 Data block decoding 18

4.4 Switch block 19

4.4.1 Switch functions on v2eagle ccTalk 19

4.4.2 Switch functions on v2eagle S1 19

4.5 Coin return lever 19

4.6 Status LED 20

4.7 Interfaces 20

Table of conTenTs

4BA_v2_eagle_serial_EN_2-1

5 Function 21

5.1 Coin acceptance and coin channels 21

5.2 Memory blocks 22

5.3 Accepted coin sensor and sorting control 22

5.4 Coin inhibition/activation of narrow coin channels 23

5.4.1 Inhibiting all coins/individual coin channels via machine

control system 23

5.4.2 Inhibiting a coin channel/coin channel group using the switch

block (only v2eagle ccTalk) 23

5.5 Sorting accepted coins (option) 24

5.5.1 Sorting principle of 5-fold in-line sorting (Ex8xxx. ..) 24

5.5.1.1 ccTalk sorting 24

5.5.1.2 Sorting with NRI 4-way manifold 25

5.5.2 Sorting principle of 5-fold cross-way sorting (E19xxx. ..) 26

5.5.2.1 ccTalk sorting 26

5.5.3 Sorting principle of 4-fold sorting (E17xxx. ..) 27

5.5.3.1 ccTalk sorting 27

5.5.3.2 Sorting with Money Controls 4-way manifold 28

5.5.3.3 Sorting with active Money Controls 8-way manifold 29

5.5.4 Additional s2HSD-3000 high-speed sorter

(option, not for 4-fold sorter) 30

5.6 Teach mode (option) 30

5.7 String recognition (option) 30

6 Start-up 32

7 Operation 33

7.1 Selecting the memory block ... 33

7.2 Inhibiting coins/activating narrow coin channel (only c2eagle ccTalk) 33

7.3 Teaching coin channels in teach mode (optional) 34

7.3.1 ... using the switch block on the coin validator 34

7.3.2 ... using ccTalk commands/machine service menu 35

8 Maintenance and service 36

8.1 Cleaning measurement and validation area 36

8.2 Troubleshooting 38

Table of conTenTs

BA_v2_eagle_serial_EN_2-1 5

9 What subsequent settings can be made? 39

9.1 Serviceandcongurationtools 39

9.1.1 PCcongurationsoftwareheartbeat 39

9.1.2 On-site service tool HENRI+39

9.2 Which device functions can be set? 39

10 Technical data 40

10.1 Device data 40

10.2 Interfaces 42

10.2.1 Pin assigment 42

10.2.1.1 v2eagle – machine (ccTalk) 42

10.2.1.2 v2eagle – machine (S1) 42

10.2.1.3 v2eagle – s2HSD-3000 high-speed sorter (option) 43

10.2.1.4 v2eagle – 8-way manifold (option) 43

10.2.1.5 v2eagle – BCR applications (option) 43

10.3 Accessories 44

10.3.1 Front plates 44

10.3.2 Sorters 45

10.3.3 Service tools 46

11 Index 47

Revision pRotocol

BA_v2_eagle_serial_EN_2-1 7

1 Revision protocol

Version Revision Chapters/sections concerned

_0-2 No optional on-board RS-232 interface

(only using adapter)

• 4.3.1 "Model number decoding"

• 4.3.2 "Data block number decoding"

_0-3 String recognition amended 5.7 "String recognition (option)"

_1-0 • Current consumption supplemented

• New optional sensors for measuring system

• 10.1 "Device data"

• 4.3.1 "Model number decoding"

_1-1 Revised model number decoding 4.3.1 "Model number decoding"

_1-2 Revised model number decoding 4.3.1 "Model number decoding"

_1-3

• 4-way sorting mechanism added

• Enhanced accessories

• 2.2.2 "Models"

• 4.1 "Overview"

• 4.3.1 "Model number decoding"

• 5.5 "Sorting accepted coins (option)"

• 10.2.1.3 "Implemented ccTalk com-

mands"

• 10.2.1.4 "ccTalk Error Code Table"

• 10.2.3 "Pin assignment, v2eagle – bcr-

applications" (option)

• 10.3 "Accessories"

_1-4 • Revised model number decoding

• Revised data block number decoding

• 4.3.1 "Model number decoding"

• 4.3.2 "Data block number decoding"

_1-5 Corrected order number 10.3 "Accessories"

_1-6 Corrected order numbers 10.3 "Accessories"

_2-0

• New status LED

• New options and accessories of v2eagle with

4-fold sorting mechanism

• New product label

• Revised cleaning measures

• ccTalk commands, error messages & set-

tings deleted (to be found in the separate

v2eagleccTalkprotocolspecication)

• 4 "Design"

• 8.2 "Troubleshooting"

• 2.2 "About the v2eagle"

• 4 "Design"

• 5.5 "Sorting accepted coins

(option)"

• 6 "Start-up"

• 10.2 "Interfaces"

• 10.3 "Accessories"

• 4.3 "Product label"

• 8.1 "Cleaning measurement and

validation area"

• 10.2 "Interfaces"

_2-1

• Revised model number decoding

• Revised data block number decoding

• Added cover picture

• 4.3.1 "Model number decoding"

• 4.3.2 "Data block number decoding"

• Cover

abouT ...

8BA_v2_eagle_serial_EN_2-1

2 About ...

This chapter is intended to provide a general overview of the advantages and options of the

coin validator v2eaglewithserialccTalkorS1interface.Therstsection,however,isdesigned

to help you navigate easily within these operating instructions.

2.1 About these operating instructions

These operating instructions describe the design and operation of the electronic 5" coin validator

v2eagle with serial ccTalk or S1 interface. Afterwards, chapters 6 and 7 explain the necessary

steps for starting up and operating the coin validator. Chapter 8 describes how to clean the coin

validator and remedy the cause of any malfunction.

Chap. 10 "Technical data" and the appended "Index" reduce the search for specific

explanations.

2.1.1 Text conventions

To make it easier for you to navigate within these operating instructions and to operate the

device, the following accentuations were made in the text:

Safety instructions which you must observe in order to protect operators

and equipment.

Special notes intended to facilitate the use of the coin validator.

At the beginning of each chapter you will nd a short "guide" which summarizes

the contents of the chapter.

Device functions which are set or prepared by the manufacturer according

to customer specications and can be set or changed using our service and

conguration tool (cp. Chap. "9 What subsequent settings can be made?", p. 39).

1 2 3 ... Requests to perform an action are numbered in another typeface.

[Fig. 1/2] Reference to a gure. The number preceding the slash indicates the number

of the gure, the number following the slash is the number of the item in the

gure.

abouT ...

BA_v2_eagle_serial_EN_2-1 9

2.1.2 Additional useful technical documentation

Apart from the operating instructions you already have, further documentation is available for the

v2eagle,e.g.documentationconcerningthecommunicationprotocol,congurationandspare

parts. All documentation can be downloaded from the Crane Payment Solutions home page

(www.craneps.com, Support)aspdfle.TheccTalkprotocolspecicationisavailableuponrequest.

2.2 About the v2eagle

The v2-eagle coin validator with serial ccTalk or S1 interface in the standardized 5“ format uses

thepatentedmulti-frequencytechnology(MFT)forreliablecoinvalidation.Communicationwith

the vending machine control system takes place either via the ccTalk-specied 10-pin AWP

connectingplugorviatheNRI-specied10-pinS1connectingplug.Duetotheseinterfacesand

its compact design the v2-eagle is ideally suited for slot and amusement machines; however it

is also used in the transportation sector.

For coin acceptance the coin validator has 32 coin channels which – divided into 2 x 16 coin

channels  – can be managed in two memory blocks with different coin congurations and

selected individually.

Dependingontheapplicationthecoinvalidatorcanoptionallybeequippedwithdifferentsorting

mechanisms.

Tobeabletoreactasquicklyaspossibletonewfalsecoinsandtomakeyourindividualsettings,

thecoinvalidatorcanbeconguredonsiteinthemachineusingaservicetoolorintheworkshop

via a PC programming station.

Any coins or tokens not taken into account by the manufacturer can be programmed in the

optionalteachmodedirectlyonthecoinvalidatorwithoutanycongurationsoftwarebyinserting

the coins.

2.2.1 The v2eagle features

• Reliable acceptance of genuine coins and rejection of false coins due to MFT multiple

sensing of the coins inserted and evaluation of 24 measuring parameters

• Operating and manipulation safety provided by optical accepted coin sensors and sorting

control in the coin validation and coin outlet area

• Acceptance speed of two coins per second

• 32coinchannelsmanagedintwoindependentlyconguredandindividuallyselectable

memory blocks (2 x 16 coin channels)

• Serial interface

–exibleandextensivecommunicationwiththemachinecontrol

–easy transmission and control of device functions

–possibilitytoconnecttoadditionalperipheralequipment

–economical device design

• Service interface for PC programming station or on-site service tool

• Flashtechnologyforeasyandtime-savingrmwareupdates(CXash)

abouT ...

10 BA_v2_eagle_serial_EN_2-1

• Options

–Teach mode for three coin channels

–String sensor

–Top or front entry, front or bottom return

–Front plate

–4-fold sorting mechanism

–5-fold in-line or cross-way sorting mechanism

–Passive 4-way or active 8-way manifold

–Interface for s2HSD-3000 high-speed sorter (2 additional sorting chutes)

–Four different return levers depending on machine type

–LicenceforupdatingthecompleteccTalkcoinanddevicecongurationonmachines

with PC-based control (remote block upload)

2.2.2 Models

The v2eagle is available in different models. They mainly differ

• in the coin insert and return area

• in the sorting mechanism and

• in the communication protocol.

2.2.2.1 Coin entry and return area

• Top entry and bottom return (E1xxxx. ../E2xxxx. ..)

The coin is inserted into the device from the top and returned, if not

accepted, via the return area at the bottom.

• Front entry and bottom return (E3xxxx. ..) (not in combination with

5-fold cross-way sorting)

The coin is inserted into the device from the side and returned, if not

accepted, via the return area at the bottom. The coin validator with

frontentrygenerallyhasanNRIfrontplatettedtotheleft-handside

of the device (cp. Chap. "10.3 Accessories", p. 44). However, this model is

also available without front plate.

• Front entry and front return (E4xxxx. ..) (not in combination with

5-fold cross-way sorting)

The coin is inserted into the device from the side and returned, if not

accepted, via the return area also located on the side. The coin validator

withfrontentryandfrontreturngenerallyhasanNRIfrontplatetted

to the left-hand side of the device (cp. Chap. "10.3 Accessories", p. 44).

However, this model is also available without front plate.

Autres manuels pour v2 eagle

Table des matières

Autres manuels NRI validateur de billets de banque

NRI

NRI G-13.6 Series Mode d’emploi

Manuels validateur de billets de banque populaires d'autres marques

Alberici

Alberici BILLYONE UN1 Manuel utilisateur

Kolibri

Kolibri Bishop Manuel utilisateur

Royal Sovereign

Royal Sovereign RCD-2000 Manuel utilisateur

Innovative Technology

Innovative Technology BV100 Manuel utilisateur

Innovative Technology

Innovative Technology NV4 Manuel utilisateur

Innovative

Innovative NV200 Manuel utilisateur

Inves

Inves Secureuro Plus Manuel utilisateur

ICT

ICT Bill Validator S7 Series Manuel utilisateur

Kolibri

Kolibri Domino Manuel utilisateur

CUMMINS ALLISON

CUMMINS ALLISON JetScan Manuel utilisateur

Hamilton

Hamilton XE Guide de démarrage rapide

CashCode

CashCode AMZ-154 Manuel utilisateur

Innovate Technology

Innovate Technology NV10 Manuel utilisateur

JCM

JCM iVIZION Manuel

Innovative Technology

Innovative Technology NV10 Family Manuel utilisateur

Amrotec

Amrotec MIB-11F Manuel utilisateur

Crane

Crane NRI G-13.mft Standard Manuel utilisateur

CASH TECHNOLOGY

CASH TECHNOLOGY CCE 20 Manuel utilisateur

NRI v2 eagle Manuel utilisateur

Manuels validateur de billets de banque populaires d'autres marques
