NVIP-5H-6711/TA/3

Quick start guide

NVIP-5H-6711/TA/3 Quick start guide version 1.1

IMPORTANT SAFEGUARDS AND WARNINGS

THE PRODUCT MEETS THE REQUIREMENTS CONTAINED IN THE FOLLOWING DIRECTIVES:

Exclusion of liability in the event of damage to data contained on disks or other devices or media:

The manufacturer is not liable in the event of damage or loss of data contained on disks or other

devices or carriers during the operation of the Product.

Obligation to consult the Manufacturer before performing any action not provided for in the

instruction manual or other documents:

Before performing an action that is not provided for a given Product in the user manual, other

documents attached to the Product or does not result from the normal purpose of the Product, it is

necessary, under pain of exclusion of the Manufacturer's liability for the consequences of such action,

to contact the Manufacturer.

Pictures in this publication showing camera views can be simulations. Actual camera

images may vary depending on the type, model, settings, observation area, or

environmental conditions.

DIRECTIVE 2014/30/EU OF THE EUROPEAN PARLIMENT AND OF THE

COUNCIL of 26 February 2014 on the harmonization of the laws of the Member States

relating to electromagnetic compatibility (OJ L 96, 29.3.2014, p. 79–106, with changes).

DIRECTIVE 2012/19/EU OF THE EUROPEAN PARLIAMENT AND OF THE

COUNCIL of 4 July 2012 on waste electrical and electronic equipment WEEE)

(OJ L 197, 24.7.2012, p. 38–71, with changes).

DIRECTIVE 2011/65/EU OF THE EUROPEAN PARLIAMENT AND OF THE

COUNCIL of 8 June 2011 on the restriction of the use of certain hazardous substances in

electrical and electronic equipment (OJ L 174, 1.7.2011, p. 88–110, with changes).

COMMISION DELEGATED DIRECTIVE (EU) 2015/863 of 31 March 2015 amending

Annex II to Directive 2011/65/EU of the European Parliament and of the Council as regards

the list of restricted substances.

DIRECTIVE (EU) 2017/2102 OF THE EUROPEAN PARLIAMENT AND OF THE

COUNCIL of 15 November 2017 amending Directive 2011/65/EU on the restriction of the

use of certain hazardous substances in electrical and electronic equipment.

NVIP-5H-6711/TA/3 Quick start guide version 1.1

IMPORTANT SAFEGUARDS AND WARNINGS

1. Please read this manual carefully before installation and operation;

2. Please keep this manual for the lifespan of the device in case referring to the contents of this

manual is necessary;

3. It is necessary to comply with the safety requirements described in the manual, as they have a

direct impact on the safety of users and the durability and reliability of the device;

4. All activities performed by installers and users must be carried out as described in the manual;

5. The device should be disconnected from power sources during maintenance procedures;

6. It is not allowed to use any additional devices, components or accessories not provided for and not

recommended by the manufacturer;

7. Do not install this device in places where proper ventilation cannot be provided (e.g. closed

cabinets, etc.), as this may cause heat build-up and may result in damage;

8. Do not place the device on unstable surfaces. Installation must be carried out by qualified

personnel with appropriate permissions in accordance with the recommendations provided in this

manual;

9. The device may be powered only from sources with parameters compliant with those indicated by

the manufacturer in the technical data;

Before using the device, read the instruction manual in order to ensure proper and safe operation

of the device. Failure to comply with the instructions may lead to damage to the device and/or

safety violations.

The user may not repair the device himself. Repairs and maintenance of the device may only be

performed by qualified service personnel.

The device, which is an element of a professional CCTV system used for supervision and

control, is not intended for self-assembly in households by persons without specialist

knowledge.

As the product is constantly improved and optimised, some of its parameters and functions may have

changed from those described in this manual. If in doubt, please refer to the user manual at

www.novuscctv.com

The user manual located at www.novuscctv.com is always the most up-to-date version.

NVIP-5H-6711/TA/3 Quick start guide version 1.1

TABLE OF CONTENTS .................................................................................................... 4

1. FOREWORD INFORMATION................................................................................... ..5

1.1. General characteristics......................................................................................... 5

1.2. Technical specification .................................................................................... ...6

1.3. Camera dimensions .......................................................................................... ...7

1.4. Package contents .............................................................................................. ...7

2. START-UP AND INITIAL IP CAMERA CONFIGURATION ................................. 8

2.1. Description of connectors and control tools........................................................ 8

2.2. Ethernet cable connecting .................................................................................. 9

2.2. Power connection ................................................................................................ 9

2.3. Camera mounting .............................................................................................. 10

2.4. Starting the IP camera ....................................................................................... 11

2.5. Initial configuration via the web browser.......................................................... 12

2.6. Security recommendations for network architecture and configuration ......... 13

3. NETWORK CONNECTION USING WEB BROSWER ......................................... 14

3.1. Recommended PC specification for web browser ............................................. 14

3.2. Connection with IP camera via web browser..................................................... 14

4. WWW INTERFACE - WORKING WITH IP CAMERA......................................... 19

4.1. Displaying live video. ........................................................................................ 19

5. ELECTRIC CONNECTORS AND ACCESORIES ................................................. 20

5.1. MicroSD card installation ................................................................................. 20

6. FACTORY SETTINGS RESTORING ...................................................................... 21

6.1. Software factory settings restoring via web browser ......................................... 21

6.2. Software factory settings restoring via NMS IPTool………... ………………..21

6.3. Hardware factory settings restoring ...................... ………………..…………...22

TABLE OF CONTENTS

NVIP-5H-6711/TA/3 Quick start guide version 1.1

1. FOREWORD INFORMATION

1.1. General Characteristics

General:

• Dual camera - thermal/visual

• FPA - thermal image sensor that allows observation of objects in total darkness

• Thermo dual vision - a feature that allows to overlay a thermal image on a video image

• Advanced image analysis features based on Deep Learning available in both thermal and video

modules

• Ability to use two different image analysis functions at the same time

• Temperature measurement at any point or area

• Temperature alarm - alarming if the temperature threshold is exceeded at any point or area

• Fire detection - alarming about the appearance of fire in the field of view of the camera

• 10 Temperature measurement zones (polygon, line, point)

• Active deterrence: LED warning lamp, white flashing or continuous light

• Audio speaker built into the camera with the ability to use custom voice messages

Thermal module:

• FPA - uncooled microbolometer

• Number of effective pixels: 256 x 192

• Fixed-focal lens: f=3.2 mm/F1.1

• Object detection range: 133m - human, 409m - vehicle

• Object recognition range: 33m - human, 102m - vehicle

• Detection temperature: -20°C ~ 150 °C

• Temperature Measurement Accuracy ± 2°C - for the range from -40°C to 100°C

• Video content analysis: line cross, intrusion detection

Video module:

• 5 MPX CMOS sensor 1/2.7” OmniVision

• Fixed-focal lens: f=4 mm/F1.6

• Stream resolution up to: 2592 x 1944

• Compression: H.264, H.265, MJPEG / G.711

• Video content analysis: tamper, line cross, zone entrance, zone exit, cross counting, scene

change, video blurred, video color cast, intrusion detection

Others:

• MicroSD card support up to 256 GB

• Onvif protocol support

• Ability to define compression, resolution, speed and quality for each stream

• Power supply 12 VDC/PoE

FOREWORD INFORMATION

NVIP-5H-6711/TA/3 Quick start guide version 1.1

1.2. Technical specification

FOREWORD INFORMATION

IMAGE - THERMAL MODULE

Image Sensor Uncooled FPA Microbolometer

Number of Eecve Pixels 256 (H) x 192 (V)

Pixel Size 12 µm

Spectral Range 8 - 14 µm

Thermal Sensivity 50 mK

Thermovision Modes White Hot, Black Hot, Rainbow, Iron Oxide Red, Lava Color

Detecon Temperature -20°C ~ 150°C

LENS - THERMAL MODULE

Lens Type f=3.2 mm/F1.1

Object Detecon Range 133m - human , 409m - vehicle

Object Recognion Range 33m - human , 102m - vehicle


Image Sensor 5 MPX CMOS sensor 1/2.7” OmniVision

Number of Eecve Pixels 2688 (H) x 1944 (V)

Min. Illuminaon 0.02 lx/F1.6 - color mode

Electronic Shuer auto/manual: 1/3 s ~ 1/100000 s

Digital Slow Shuer (DSS) up to 1/3 s

Digital Noise Reducon (DNR) 2D, 3D

Defog Funcon (F-DNR) yes

Highlight Compensaon (HLC) yes

Back Light Compensaon (BLC) yes

Reducon of image icker (Anicker) yes

LENS

Lens Type xed focal, f=4 mm/F1.6

DAY/NIGHT

Switching Type mechanical IR cut lter

Switching Mode auto, manual, me, external

Switching Level Adjustment yes

Switching Delay 2 ~ 120 s

Switching Schedule yes

Visible Light Sensor yes

NETWORK

Stream Resoluon 2592 x 1944, 2592 x 1520, 2560 x 1440 (QHD), 2304 x 1296, 1920 x 1080 (Full HD),

1280 x 720 (HD), 704 x 576, 480 x 240, 352 x 288 (CIF)

for thermal module: 704x576, 352 x 288 (CIF), 1280x720, 480x240

Frame Rate 30 fps for each resoluon

Mulstreaming Mode 3 streams

Video/Audio Compression H.264, H.265, MJPEG/G.711

Number of Simultaneous Connecons max. 10

Bandwidth 50 Mb/s in total

Network Protocols Support HTTP, IPv4, IPv4/v6, UDP, HTTPS, FTP, DHCP, DDNS, NTP, RTSP, RTP, UPnP, SNMP, QoS,

IEEE 802.1X, PPPoE, SMTP, RTCP, ICMP, HTML5

ONVIF Protocol Support Prole S/G/T

Camera Conguraon from Internet Explorer, Firefox, Chrome, Opera, Edge browser

languages: Polish, English, and others

Compable Soware NMS, N Control 6000

Mobile applicaons SuperLive Plus (iPhone, Android)

NVIP-5H-6711/TA/3 Quick start guide version 1.1

FOREWORD INFORMATION

1.3. Camera dimensions (mm)

Camera NVIP-5H-6711/TA/3

OTHER FUNCTIONS

Temperature Measurement yes

Temperature Alarm yes - for thermal module

Temperature Measurement Zones 10 - for thermal module polygon, line, point

Temperature Measurement Accuracy +-2°C - for the range from -40°C to 100°C

Privacy Zones 4 video mask type: single color

Moon Detecon yes

Region of interest (ROI) 8

Video Content Analysis (VCA) tamper, line cross, zone entrance, zone exit, cross counng, scene change, video blurred,

video color cast, intrusion detecon

Image Processing sharpening, vercal ip, horizontal ip, lens distoron correcon

Prealarm/Postalarm up to 6 s/up to 120 s

System Reacon to Alarm Events e-mail, e-mail with aachment, saving le on FTP server, saving le on SD card, alarm

output acvaon, playback of the audio message

Determent LED warning light, white, ashing/connuous mode, ,

acousc signaling device, built-in speaker (pre-dened or self-recorded voice messages)

Restoring default sengs via web browser, using reset buon, via NMS IPTool soware

IR LED

Smart IR yes (soware support)

INTERFACES

Audio Input/Output 1 x Jack (3.5 mm)/ - built-in speaker

Alarm Input/Output 1 (NO/NC)/1 relay type (max. 12VDC/300mA)

Network Interface 1 x Ethernet - RJ-45 interface, 10/100 Mbit/s

Memory Card Slot microSD - capacity up to 256GB

INSTALLATION PARAMETERS

Dimensions (mm) with bracket: 81 (W) x 81 (H) x 220 (L)

Weight 0.73 kg

Degree of Protecon IP 66 (details in the user’s manual)

Enclosure aluminium, white, fully cable managed wall mount bracket in-set included ,

IK10 impact rang

Power Supply 12 VDC, PoE (IEEE 802.3af, Class 3)

Surge protecon TVS 4000 V

Power Consumpon 9 W

Operang Temperature -30°C ~ 60°C

Humidity max. 95%, relave (non-condensing)

81 cm

220 cm

NVIP-5H-6711/TA/3 Quick start guide version 1.1

START-UP AND INITIAL IP CAMERA CONFIGURATION

1.4. Package contents

After opening the package make sure that the following elements are inside:

• IP camera

• Accessories bag

• Short version of user’s manual

If any of this elements has been damaged during transport, pack all the elements back into the original

box and contact your supplier for further assistance.

CAUTION!

It is forbidden to use – as the camera power source – PoE equipment (adapters, etc.) not com-

patible with IEEE 802.3af standard (items called “passive PoE power supply”). Damages caused

by the usage of improper power supply source are not covered by the warranty.

2. START-UP AND INITIAL IP CAMERA CONFIGURATION

CAUTION!

If the device was brought from a location with lower temperature, please wait until it reaches

the temperature of location it is currently in. Turning the device on immediately after bringing it

from a location with lower ambient temperature is forbidden, as the condensing water vapour

may cause short-circuits and damage the device as a result.

Before starting the device familiarize yourself with the description and the role of particular

inputs, outputs and adjusting elements that the device is equipped with.

2.1 Description of connectors and control tools

10 11

1. 100 Mb/s Ethernet port

(PoE RJ-45 connector)

2. Audio input „MIC” (Jack 3.5mm)

3. Alarm input/output

4. Power supply connector 12VDC

5. Base of camera

6. Counter nut

7. Light sensor

8. White light and IR illuminator

9. Speaker

10. MicroSD card slot

11. RESET button

NVIP-5H-6711/TA/3 Quick start guide version 1.1

START-UP AND INITIAL IP CAMERA CONFIGURATION

2.2. Power supply connection

The camera can be powered from a commercially available DC power supply, provided that it meets

the technical requirements of the camera. The source must provide stabilized 12VDC voltage, must

allow the consumption of at least 9W of power, and have a barrel DC 2.1/5.5 plug with the correct

polarity of the contacts:

It is also possible to power the camera via the RJ45 network socket, using PoE technology (IEEE

802.3af, Class 3).

Caution!

Do not use power supplies and POE adapters that do not comply with the IEEE 802.3at stand-

ard, the so-called "passive POE" power supplies. Damage resulting from the use of an unsuita-

ble adapter is not covered by the warranty!

2.3 Protection against water ingress

The declared degree of protection applies only to camera housing and the location where the connec-

tion cable enters the inside of the housing.

This means that the connection cable, including sockets, connectors, switches, buttons, and other ele-

ments on this cable, as well as other camera equipment/construction elements (such as hoods, brack-

ets, supports, etc.), are not waterproof. It is the responsibility of the person installing the camera to

protect the elements that require it (and in any case the connection cable) against moisture.

The manufacturer is not responsible for any damages or camera malfunctions resulting from failure to

comply with the above obligation, which also means that they are not covered by the warranty repairs.

The RJ-45 socket cover included in the camera accessories (depending on the version/model) is not a

water protection element. Its purpose is to protect against the ingress of dust and atmospheric moisture

into the socket and prevent accidental disconnections by mechanically stabilizing the network plug in

the RJ-45 socket.

Illustrative drawing

Water protected area Area that needs to be sealed

during installation

NVIP-5H-6711/TA/3 Quick start guide version 1.1

2.4. Camera mounting

To mount a camera please follow the instructions below:

• Unscrew the counter nut (2).

• Put the bracket to the wall in a desired mounting place (with cable hole). Take the drill pattern

and mark future drilling holes for screws and wires.

• Drill holes for screws, wires and base.

• Mount the camera base (1) using the supplied plugs and screws.

• If necessary, unscrew the service panel (3) located on the bottom of the camera, paying special

attention to the cable leading to the speaker located in the service panel, then insert the

memory card (4) and screw the service panel back.

• Connect the camera wires.

• Adjust camera position.

• Tighten to the stop counter nut (2).

Caution!

Pay particular attention to the surface to which is attached the camera to have the appropriate capacity.

Caution!

It is recommended to install the camera using one of the dedicated adapters. The use of an adapter

allows for an aesthetic camera installation, facilitates later servicing and provides a water-protected

space for hiding cables.

START-UP AND INITIAL CAMERA CONFIGURATION

Adapters are additional equipment, to be purchased separately. The characteristics and functions

of the adapter (such as mounting method, space for cables, etc.) depend on its model. The list of

dedicated adapters and their specifications can be found on the camera’s catalog card under the

“Related Products” tab

Table des matières

Langues :

Autres manuels Novus Caméra de sécurité

Novus

Novus NVAHD-1DN5100C-1 Manuel utilisateur

Novus

Novus NVDN-601V/IR-white Manuel utilisateur

Novus

Novus NVC-230C Manuel utilisateur

Novus

Novus NVIP-4H-6511/F-II Manuel utilisateur

Novus

Novus 5000 VSS MULTI HD Manuel utilisateur

Novus

Novus NVIP-2VE-4231 Manuel utilisateur

Novus

Novus NVIP-4H-4201 Manuel utilisateur

Novus

Novus NVIP-TDN2401D/IR/MPX1.0 Manuel utilisateur

Novus

Novus NVIP-3DN7000V/IRH-2P Manuel utilisateur

Novus

Novus NVIP-5DN3614V/IR-1P/F Manuel utilisateur

Novus

Novus NVIP-3DN7500V/IRH-2P Fiche d'information produit

Novus

Novus NVAHD-2DN5106MH/IR-1 Manuel utilisateur

Novus

Novus NVAHD-2DN5103MV/IR-1 Manuel utilisateur

Novus

Novus NVAHD-2DN5504MH/IR-1 Manuel utilisateur

Novus

Novus NVIP-2H-8002M/LPR Manuel utilisateur

Novus

Novus NVDN-861H/IRH-2 Manuel utilisateur

Novus

Novus VSS MULTI HD 6000 Manuel utilisateur

Novus

Novus NVIP-2VE-6601-II Manuel utilisateur

Novus

Novus NVAHD-2DN5501MV/IR-1 Manuel utilisateur

Novus

Novus NVAHD-2ATM-4011 Manuel utilisateur

Novus

Novus NVIP-2VE-6502M/F Manuel utilisateur

Novus

Novus NVIP-3DN3011H/IR-1P Manuel utilisateur

Novus

Novus NVIP-5DN2004H/IR-1P-II Manuel utilisateur

Novus

Novus NVIP-2DN3031H/IR-1P Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
