NovaStar MCTRL4K Manuel utilisateur

MCTRL4K

Independent Controller

Product Version:

V1.0.3

Document Number:

NS110100428

Specifications

XI'AN NOVASTAR TECH CO.,LTD.

www.novastar.tech

No part of this document may be copied, reproduced, extracted or transmitted in any form or by any

means without the prior written consent of Xi’an NovaStar Tech Co., Ltd.

Trademark

is a trademark of Xi’an NovaStar Tech Co., Ltd.

Statement

You are welcome to use the product of Xi’an NovaStar Tech Co., Ltd. (hereinafter referred to as

NovaStar). This document is intended to help you understand and use the product. For accuracy and

reliability, NovaStar may make improvements and/or changes to this document at any time and

without notice.Any problem in use or any good suggestion, please contact us through ways provided

in the document. We will do our utmost to solve the problems and adopt the suggestions after

evaluation as soon as possible.

XI'AN NOVASTAR TECH CO.,LTD.

Independent Controller MCTRL4K

Specifications

Change History

www.novastar.tech

Change History

Version

Release Date

Description

V1.0.3

2018-02-08

HDR function is added.

V1.0.2

2017-11-16

Web control is supported.

V1.0.1

2016-10-31

Document style is updated.

V1.0.0

2016-06-06

First release

XI'AN NOVASTAR TECH CO.,LTD.

Independent Controller MCTRL4K

Specifications

Contents

www.novastar.tech

iii

Contents

Change History................................................................................................................................ ii

1 Safety ...............................................................................................................................................1

1.1 Storage and Transport Safety...................................................................................................................... 1

1.2 Installation and Use Safety.......................................................................................................................... 1

2 Overview.........................................................................................................................................3

3 Features ...........................................................................................................................................4

4 Appearance.....................................................................................................................................6

5 Dimensions ....................................................................................................................................8

6 Specifications.................................................................................................................................9

XI'AN NOVASTAR TECH CO.,LTD.

Independent Controller MCTRL4K

Specifications

1 Safety

www.novastar.tech

1 Safety

This chapter illustrates safety of the MCTRL4K independent controller to ensure the

product’s storage, transport, installation and use safety.

Safety instructions are applicable to all personnel who contact or use the product.

First of all, pay attention to following points.

Read through the instructions.

Retain all instructions.

Comply with all instructions.

1.1 Storage and Transport Safety

Pay attention to dust and water prevention.

Avoid long-term direct sunlight.

Do not place the product at a position near fire and heat.

Do not place the product in an area containing explosive materials.

Do not place the product in a strong electromagnetic environment.

Place the product at a stable position to prevent damage or personal injury

caused by dropping.

Save the packing box and materials which will come in handy if you ever have to

store and ship the product. For maximum protection during storage and shipping,

repack the product as it was originally packed at the factory.

1.2 Installation and Use Safety

Only trained professionals may install the product.

Plugging and unplugging operations are prohibited when the power is on.

Ensure safe grounding of the product.

Beware of electric shock hazards.

Always wear a wrist band and insulating gloves.

Do not place the product in an area having frequent or strong shake.

Perform dust removing regularly.

XI'AN NOVASTAR TECH CO.,LTD.

Independent Controller MCTRL4K

Specifications

1 Safety

www.novastar.tech

Contact NovaStar for maintenance at any time, rather than have the product

disassembled and maintained by non-professionals without authorization.

Replace faulty parts only with the spare parts supplied by NovaStar.

XI'AN NOVASTAR TECH CO.,LTD.

Independent Controller MCTRL4K

Specifications

2 Overview

www.novastar.tech

2 Overview

The MCTRL4K is a 4K×2K independent controller developed by NovaStar. With up to

3840x2160@60Hz loading capacity of a single unit, it can support any custom

resolution within this range as required, thus meeting the on-site configuration

requirements of super-long or super-large LED displays.

In Multi-card mode, the MCTRL4K can be used as two independent controllers,

making the images of two input sources perfectly displayed on the screen.

What's more, the MCTRL4K supports HDR function and can work withA8s/A10s to

greatly enhance the image quality of the screen, presenting more vivid and clearer

images.

The MCTRL4K is mainly applied to concert control centers, live events, security

monitoring, Olympic Games and various sports centers.

XI'AN NOVASTAR TECH CO.,LTD.

Independent Controller MCTRL4K

Specifications

3 Features

www.novastar.tech

3 Features

Provides complete input connectors, including 1 ×DP 1.2, 2 ×dual-link DVI and

1 ×HDMI 2.0.

Supports 16 ×Gigabit Ethernet ports and 4 ×fiber optical outputs.

Supports 3 video bit depths: 8-bit, 10-bit and 12-bit.

Supports both Mosaic and Multi-card modes when dual-link DVI is used.

Supports HDR10 which can greatly enhance the image quality of the screen,

presenting more vivid and clearer images.

Supports super high resolution settings with NVIDIAgraphics card.

Adopts innovative architectural design to enable smart configuration, which can

greatly shorten the stage preparation time.

Adopts NovaStar G4 engine to realize a perfect image display with no flickering

and scanning lines, but fine quality and good sense of depth.

Supports the new generation of pixel level calibration technology of NovaStar to

bring a fast and efficient calibration process.

Implements white balance calibration and color gamut mapping to ensure colors

are faithfully reproduced.

Supports screen configuration at any time without a PC.

Supports easy and quick manual adjustment of screen brightness.

Supports screen configuration via Web interface.

Supports cascading multiple controllers for uniform control.

Supports various video formats. For details, see Table 3-1.

Table 3-1 Supported video formats

Resolution

Format

3840x2160@60Hz

3840x1080@60Hz

1920x1080@60Hz

8Bit

RGB444



YCbCr444



YCbCr422



YCbCr420



10Bit

RGB444





XI'AN NOVASTAR TECH CO.,LTD.

Independent Controller MCTRL4K

Specifications

3 Features

www.novastar.tech

YCbCr444





YCbCr422



YCbCr420



12Bit

RGB444





YCbCr444





YCbCr422



YCbCr420



XI'AN NOVASTAR TECH CO.,LTD.

Independent Controller MCTRL4K

Specifications

4 Appearance

www.novastar.tech

4 Appearance

Front Panel

No.

Name

Description

①

Power button

Pressing it powers on the device, while holding it down

for 4–5seconds powers off the device.

②

USB

Connects a USB drive only (PC cannot be connected).

③

LCD screen

Displays the menu.

④

Knob

Pressing the knob enters a menu or confirms an option

or operation, while rotating the knob selects a menu

item or adjusts a parameter.

⑤

BACK

Returns to the parent menu.

XI'AN NOVASTAR TECH CO.,LTD.
