Power Supply & Connections
A permanent 12-24 VDC supply is required to operate the touchless series of Exit
Buttons.
Product Features & Technical Specications
NO/NC/COM Single pole architrave switch with LED Status
• Sensor: infrared adjustable 3-15cm
• Input Power: 12-24vdc
• Contact Rating: 24vdc 2A
• Output Contact: Single Pole
NO/NC/COM
• Mechanical Life – 500,000
• IP rating: IP68( (Optional))
• Surface mount
• Operating temperature: -20°C to 55°C
• Operating humidity: 0-95%
• LED Status
Blue = Standby
Green = Activated
R
Your Safety , We Care
www.chinanordson.com
NF-C3 Surface Mount Metal
Infrared Exit Button Use Manual
Blue Adapter
12V DC
2
Activation Distance
Note: DO NOT face the infrared sensor directly into the sunlight, as this will
affect the performance of the unit.
The Exit button has sensitivity adjustment from 3-15cm this can be adjusted as follows:
Activation Distance
Turn left to reduce activation distance
Turn right to increase activation distance
R
Your Safety , We Care
www.chinanordson.com
