Nokia M5122 Manuel utilisateur
Nokia M5122
T66250
USER MANUAL
ADSL Bridgeā
ECopyright Nokia Networks Oy
C33874002SE_A0 1
Nokia M5122
ADSL Bridge
User Manual
C33874.21B0
02.11.2000
1 Introduction to Nokia M5122
Nokia M5122 is an ADSL bridge which enables high-speed Internet
access and LAN interconnection. It increases the capacity of the
already installed telephone lines used traditionally for telephone
services. M5122 enables high-speedconnections for homesandsmall
offices.
Figure 1 Nokia M5122
NokiaM5122allowsmultiplePCsequippedwitha10Base-TEthernet
interface to be connected to a remote network via a Digital Subscriber
Line Access Multiplexer (DSLAM) and an ATM access network. It
acts as a bridge between the Ethernet LAN and ADSL/ATM network
interfaces. An in-built 4-port hub allows easy home and small office
network installation.
Nokia M5122 User Manual
ECopyright Nokia Networks Oy C33874002SE_A0
2
2 Installing M5122
Before installing M5122, you may want to familiarise yourself with
the interfaces and indicator lights of M5122. From section 2.3, you
will find a step-by-step installation procedure, which shows the
physical installation of M5122.
2.1 Interfaces
M5122 has one ADSL line interface and four Ethernet interfaces
(10Base-T). It also has a Command Line Interface (CLI) for
management purposes. The ADSL line interface is compatible with
ITU-T G.992.1 specification.
ADSL line (DSL)
Ethernet ports
(ETH-1, ETH-2,
ETH-3, ETH-4)
Command line interface (CLI)
Mains connector
Power switch
Figure 2 M5122 back panel
2.2 Indicator lights
M5122 has eight indicator lights on the front panel: PWR, STA, COL,
ETH-1, ETH-2, ETH-3,ETH-4, and DSL.STA indicator is red. Other
indicators are green.
ECopyright Nokia Networks Oy
C33874002SE_A0 3
Figure 3 M5122 front panel indicators
DSL GREEN
Off ADSL link is down.
Blinks ADSL connection is being established.
On ADSL link is up.
ETH- GREEN
Off Ethernet is down.
On 10Base-T Ethernet is functional.
Blinks Receives traffic from Ethernet.
COL GREEN
Blinks Collisions on the Ethernet. Note, that it is normal that some
collisions occur on the Ethernet.
STA RED
Off OK
On Hardware malfunction during startup.
PWR GREEN
Off Power off.
On Power on.
Nokia M5122 User Manual
ECopyright Nokia Networks Oy C33874002SE_A0
4
2.3 Step-by-step installation procedures
In this section, we present two installation procedures: ADSL data
servicesandTelephoneandADSLdataservices.Tousebothtelephone
and ADSL services, you will need a POTS splitter. This manual gives
installation example for a Nokia splitter T66270.
In these examples, we assume that you have installed your Ethernet
card properly and that your service provider has provided you with
instructions how to set your PC’s networking options.
ADSL data services
1. 2.
3.
4. 5.
Figure 4 M5122 with cables connected (ADSL services only)
1. Plug the mains power cord to a mains outlet. M5122 can be
connected to an earthed socket outlet only.
2. SwitchonM5122.ThePWRindicatorlightsup.After awhile,the
red STA indicator blinks and then remains unlit. M5122 is now
functional.
3. Connect the Ethernet cable between your PC’s 10Base-T
connector and the Ethernet connector on the M5122 back panel
(ETH-1, ETH-2, ETH-3, or ETH-4).
4. Switchonyour PC. The indicatorcorresponding the Ethernet port
you connected your PC to becomes green when your PC has
started. This indicator blinks when there is traffic in the
corresponding Ethernet port.
ECopyright Nokia Networks Oy
C33874002SE_A0 5
5. Connect the ADSL line cable between the DSL connector on the
M5122 back panel and the wall socket. After a while, the DSL
indicatorstartsblinking.ThisindicatesthattheADSLlineisbeing
established. When the DSL indicator remains lit, the line is
functional.
6. Duringnormal operation PWR and DSL indicators are lit and the
Ethernetindicators of the active Ethernet ports blink or remain lit
dependingwhetherthereistrafficornot.COLindicatormayblink
occasionally during normal operation.
Nokia M5122 User Manual
ECopyright Nokia Networks Oy C33874002SE_A0
6
Telephone and ADSL data services with T66270 splitter
1.1.
2.
3.
4. 5.
6.
7.
Figure 5 M5122 with cables and splitter (T66270) connected
(Telephone and ADSL services)
1. Plug the mains power cord to a mains outlet. M5122 can be
connected to an earthed socket outlet only.
2. SwitchonM5122.ThePWRindicatorlightsup.After awhile,the
red STA indicator blinks and then remains unlit. M5122 is now
functional.
3. Connect the Ethernet cable between your PC’s 10Base-T
connector and the Ethernet connector on the M5122 back panel
(ETH-1, ETH-2, ETH-3, or ETH-4).
4. Switchonyour PC. The indicatorcorresponding the Ethernet port
you connected your PC to becomes green when your PC has
started. This indicator blinks when there is traffic in the
corresponding Ethernet port.
5. Connect the ADSL line cable between the DSL connector on the
M5122 back panel and the splitter’s MODEM connector.
6. Connect the splitter cable between the splitter’s LINE connector
and the wall socket. After a while, the DSL indicator starts
blinking. This indicates that the ADSL line is being established.
When the DSL indicator remains lit, the line is functional.
7. Connect the telephone to the splitter’s PHONE connector.
ECopyright Nokia Networks Oy
C33874002SE_A0 7
8. Duringnormal operation PWR and DSL indicators are lit and the
Ethernetindicators of the active Ethernet ports blink or remain lit
dependingwhetherthereistrafficornot.COLindicatormayblink
occasionally during normal operation.
NowyourM5122hasbeenconnectedandyoucanconfigureyourPC’s
networkingoptionsandcheckthattheserviceworksaccordingtoyour
service provider’s instructions.
2.4 Troubleshooting
This section gives some tips for troubleshooting.
Power (PWR) indicator is unlit.
Make sure that power cord has been connected to a mains outlet and
M5122 has been switched on.
Red status (STA) indicator is lit
Switch power off and then on again. If the STA indicator remains lit,
the unit may be faulty.
ADSL (DSL) indicator is unlit
Make sure that the ADSL line cable has been properly connected
between the DSL connector and the wall socket.
Ethernet (ETH-) indicator is unlit
Make sure that the Ethernet cable has been properly connected
between your PC’s Ethernet interface and the M5122 ETH connector.
Make sure that your PC is ON.
You cannot access the Internet
1. Make sure that your M5122 is ON.
2. Check that the DSL indicator is lit.
3. CheckthatEthernet indicator(ETH-1, ETH-2,ETH-3,orETH-4)
corresponding to the Ethernet interface you are connected to is
ON.
4. Make sure that your PC’s networking functions have been
configured according to your service provider’s instructions.
Nokia M5122 User Manual
ECopyright Nokia Networks Oy C33874002SE_A0
8
2.5 Installing M5122 on the wall
M5122 can also be wall mounted. Figure 6 shows the installation
procedure.
1. Drill two holes (6 mm in diameter) on the wall. The distance
between the holes must be 155 mm. Insert the plugs to the holes
and fix the screws.
2. Mount the modem on the wall as shown in Figure 6.
1.
2.
155 mm
6 mm
Figure 6 Wall installation
ECopyright Nokia Networks Oy
C33874002SE_A0 9
3 Configuring M5122
Your service provider has configured your M5122 for the service. Do
not change settings unless specifically asked by your service
provider. You can change M5122 settings with an ordinary web
browser, such as Microsoft Internet Explorer or Netscape Navigator.
UseaPCconnectedtoanETHportofM5122forconfiguration.Inthis
case the corresponding ETH indicator should be lit.
3.1 Browser management
The web configuration pages of M5122 can be accessed through the
Ethernetand through theADSL/ATM channels of M5122. In order to
access the web management feature, the IP functionality must be
activated and an IP address must be given to the corresponding
interface.
You can use your PC’s web browser software to access the web
configuration pages in M5122. To access the web pages you must
know the IP address of your M5122 or, alternatively, the “name”that
your M5122 recognises.
Note
Before using your web browser for configuration, you must know the
IP address or the name assigned to your M5122.
TherearethreewaystofindoutwhethertouseanameoranIPaddress:
DYour service provider has given you an IP address for M5122.
DYour M5122 uses DynamicHost ConfigurationProtocol(DHCP)
and Domain Name Server. In this case the name is M5122.
DYour M5122 uses DHCP. In this case run winipcfg.exe (Windows
95)oripconfig.exe(WindowsNT).TheIPaddressofM5122isthe
Default Gateway address shown by the ipconfig program.
3.1.1 Opening a connection
To open a connection to the Nokia M5122:
1. Start your web browser.
