User Guide for the Nokia Wireless
GPS Module (LD-1W)
0903389
Issue 1
EN_LD-1W_0903389_3Mar05.fm Page 1 Friday, March 4, 2005 10:10 AM
DECLARATION OF CONFORMITY
We, NOKIA CORPORATION, declare under our sole responsibility that the product
LD-1W is in conformity with the provisions of the following Council Directive:
1999/5/EC.
A copy of the Declaration of Conformity can be found at
http://www.nokia.com/phones/declaration_of_conformity/.
Part No. 0903389, Issue No. 1
Copyright © 2005 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this
document in any form without the prior written permission of Nokia is prohibited.
Nokia, Nokia Connecting People, Nokia LD-1W, and the Nokia Original
Enhancements logos are trademarks or registered trademarks of Nokia
Corporation. Other product and company names mentioned herein may be
trademarks or tradenames of their respective owners.
Printed in the Unites States of America. November 2004
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
The information contained in this user guide was written for the Nokia LD-1W
product. Nokia operates a policy of ongoing development. Nokia reserves the right
to make changes and improvements to any of the products described in this
document without prior notice.
UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS OF
DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, AND CONSEQUENTIAL OR
INDIRECT DAMAGES HOWSOEVER CAUSED. THE CONTENTS OF THIS DOCUMENT
ARE PROVIDED "AS IS." EXCEPT AS REQUIRED BY APPLICABLE LAW, NO
WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT
EN_LD-1W_0903389_3Mar05.fm Page 2 Friday, March 4, 2005 10:10 AM
LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY AND
RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO
REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.
EXPORT CONTROLS
This device may contain commodities, technology, or software subject to export
laws and regulations from the U.S. and other countries. Diversion contrary to law is
prohibited.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example, when using a
telephone in close proximity to receiving equipment). The FCC or Industry Canada
can require you to stop using your telephone if such interference cannot be
eliminated. If you require assistance, contact your local service facility. This device
complies with part 15 of the FCC rules. Operation is subject to the condition that
this device does not cause harmful interference.
For availability of approved enhancements, please check with your dealer.
Unauthorized changes or modifications to this device may void the user’s authority
to operate the equipment.
EN_LD-1W_0903389_3Mar05.fm Page 3 Friday, March 4, 2005 10:10 AM
Contents
4
Contents
For your safety........................................................................................ 5
Introduction 6
Global positioning system (GPS) .......................................................................................... 6
Bluetooth wireless technology.............................................................................................. 8
Bluetooth passcode.................................................................................................................. 8
External antenna....................................................................................................................... 8
1. Overview.............................................................................................. 9
2. Get started ........................................................................................ 10
Batteries and chargers .......................................................................................................... 10
Install the battery ................................................................................................................... 11
Charge the battery ................................................................................................................. 12
Pair the GPS module .............................................................................................................. 13
3. Use the GPS module ......................................................................... 14
Power key functions............................................................................................................... 14
Carrying the GPS module ..................................................................................................... 15
Pairing with multiple phones .............................................................................................. 15
Disconnect and reconnect.................................................................................................... 16
Reset the GPS module........................................................................................................... 16
Troubleshooting....................................................................................................................... 17
4. Battery information.......................................................................... 18
Care and maintenance.......................................................................... 20
FCC notice ............................................................................................. 21
Limited warranty .................................................................................. 22
EN_LD-1W_0903389_3Mar05.fm Page 4 Friday, March 4, 2005 10:10 AM
For your safety
5
For your safety
Read these simple guidelines. Not following them may be dangerous or illegal.
Read the complete user guide for further information.
INTERFERENCE
All wireless devices may be susceptible to interference, which
could affect performance.
BATTERIES AND CHARGERS
Use only approved batteries and chargers. Do not connect
incompatible products.
CONNECTING TO OTHER DEVICES
When connecting to any other device, read its user guide for
detailed safety instructions. Do not connect incompatible products.
QUALIFIED SERVICE
Only qualified personnel may repair this device.
EN_LD-1W_0903389_3Mar05.fm Page 5 Friday, March 4, 2005 10:10 AM
Introduction
6
Introduction
The Nokia Wireless GPS Module is a battery operated device that uses
Bluetooth wireless technology to communicate positioning information
to compatible mobile phones, PCs, PDAs, and other devices. With the GPS
module, you can determine your current position and direction.
Read this user guide carefully before using the GPS module. Check also
http://www.nokia.com/support or your local Nokia Web site for the latest
version of this guide, additional information, downloads, and services
related to your Nokia product.
Note: There may be restrictions on using Bluetooth devices in some
locations. Check with your local authorities or service provider.
Using Bluetooth features, or allowing them to run in the background
while using other features, increases the demand on battery power and
reduces the battery life.
■Global positioning system (GPS)
The GPS is a worldwide radio navigation system that includes 24 satellites
and their ground stations that monitor the operation of the satellites.
A GPS terminal (such as the Nokia Wireless GPS Module) receives low-
power radio signals from the satellites and measures the travel time of
the signal. From the travel time, the GPS terminal can calculate its
location to an accuracy of 82 feet (25 meters). In optimal conditions, the
accuracy may be within a few feet.
EN_LD-1W_0903389_3Mar05.fm Page 6 Friday, March 4, 2005 10:10 AM
Introduction
7
The accuracy can be affected by poor satellite geometry. The more
satellites the GPS module can detect, the better the accuracy. The internal
antenna of the GPS module, located on the same side as the Nokia logo,
should face upwards for proper functioning. Some car windshields and
windows may contain metal for heat reflection or defogging purposes,
that may block or attenuate the satellite signals.
In addition, the GPS determines your direction on the basis of your
movement. Therefore, the GPS cannot detect which way you are facing if
you are not moving.
Note: The GPS is operated by the United States government, which is
solely responsible for accuracy and maintenance of the system. The
accuracy of location data can be affected by adjustments to GPS
satellites made by the United States government and is subject to
change with the United States Department of Defense civil GPS policy
and the Federal Radionavigation Plan. Accuracy can also be affected
by poor satellite geometry.
Availability and quality of GPS signals may be affected by
buildings and natural obstacles as well as weather conditions.
The GPS receiver should only be used outdoors to allow reception
of GPS signals.
Therefore, GPS should not be used for precise location
measurement and you should never rely solely on location data
from the GPS receiver. This GPS receiver does not support location
of the phone by emergency operators.
EN_LD-1W_0903389_3Mar05.fm Page 7 Friday, March 4, 2005 10:10 AM
Introduction
8
■Bluetooth wireless technology
The Bluetooth wireless technology makes it possible to connect compatible
communication devices without using cables. Please refer to the user guide of
your phone for a more detailed description of Bluetooth wireless technology.
■Bluetooth passcode
You need a passcode for pairing the GPS module with a compatible device
using Bluetooth connectivity. The passcode is 0000.
■External antenna
Sometimes the performance of the GPS module may be unsatisfactory
because of nearby obstacles blocking the satellite signals. The
performance of the GPS module may be improved by using an external
antenna with a male MCX-connector and a 3-V input.
Plug the external antenna into its connector (5) on the GPS module. See
page 9.
EN_LD-1W_0903389_3Mar05.fm Page 8 Friday, March 4, 2005 10:10 AM
Overview
9
1. Overview
Note: The use of wireless devices may be restricted in some
situations. Observe any restrictions and obey all instructions
concerning the use of wireless devices.
Your device may contain small parts. Keep them out of reach of small children.
The GPS module contains the following parts:
Power key (1)—Switches the GPS module on and off, and resets the
Bluetooth connectivity settings of the GPS module.
Release button (2)—Unlocks the back cover.
Indicator lights (3)—Displays the current status of the GPS module. The
indicator lights are red, green, blue, and white. Red and green lights
indicate the status of the battery and charging, or resetting of the
module. The blue light indicates an active Bluetooth connection. The
white light indicates that the GPS module is receiving satellite data and is
able to determine its position.
Connector for a
compatible charger (4)
Connector for an
external antenna (5)
EN_LD-1W_0903389_3Mar05.fm Page 9 Friday, March 4, 2005 10:10 AM
Get started
10
2. Get started
Before you can start using the GPS module, you must perform the
following steps:
1. Install a compatible software application on the phone.
2. Fully charge the battery of the GPS module.
3. Pair the compatible phone with the GPS module.
Note that some Nokia phone models (for example, Nokia Model 9500 and
Nokia Model 9300) have a Location Privacy setting in the Control Panel
menu. This setting must be set to Accept all in order to provide GPS
location data to software applications.
■Batteries and chargers
The GPS module has a removable and rechargeable BL-5C battery. For
availability of approved new batteries and chargers, please check with
your local dealer.
Check the model number of any charger before using it with this product.
The following chargers are intended for use with the GPS module:
Mains chargers: AC-1 and ACP-12
Mobile chargers: LCH-12
EN_LD-1W_0903389_3Mar05.fm Page 10 Friday, March 4, 2005 10:10 AM
Autres manuels pour LD-1W - GPS Module
2
Table des matières
Langues :
Autres manuels Nokia GPS
Nokia
Nokia HAIP Tag LD-6T Manuel utilisateur
Nokia
Nokia LD-1W - GPS Module Manuel utilisateur
Nokia
Nokia Go Manuel utilisateur
Nokia
Nokia LD-3W - Wireless GPS Module Manuel utilisateur
Nokia
Nokia 330 Manuel utilisateur
Nokia
Nokia Go Manuel utilisateur
Nokia
Nokia Go Manuel utilisateur
Nokia
Nokia LD-4W Manuel utilisateur
Nokia
Nokia LD-1W - GPS Module Manuel utilisateur
Nokia
Nokia LD-3W - Wireless GPS Module Manuel utilisateur
