Nokia OZO camera Manuel utilisateur
MAKING VIRTUAL REALITY
Index
Box Content 4 - 5
WARNINGS
Ventilation 7
Overheating 8
Operating and Storage Temperature 9
Protective Cover 10
Safety and Handling 11
General Warnings 12 - 13
BASICS
Device Handling 15
Mounting 16
Changing the Tripod Adapter 17
Connector Cap Removal 18
Connecting SDI 19
Connecting Power 20
Cartridge Replacement 21
Charging Battery 22
Extracting Data 23
OZO Applications 24
Basic Operation 25 - 26
WARRANTY AND LEGAL
Warranty 28 - 29
Regulatory and Safety Notices 30 - 31
Recycling 31
Box Content
11 12
10
8
2
1
4
9
The Protective NANUK 950 carrying case is intended for normal transportation
of OZO and included accessories. Please keep the cardboard shipping box and
packing, and reuse when transporting the camera by courier or shipping agent.
7 6
3
5
1. ProtectiveCover(comesttedtocamera)
2. Largetripodadapter(comesttedtocamera)
3. OZO Professional VR Camera PC-01
4. 3G-SDI adapter card in protective ESD bag, for external recording/
monitoring
5. T6 tool, for removing Connector Cap of power/SDI slot
6. Digital Cartridge DC-01, including 33Wh Li-Ion rechargeable battery
7. Media Module MM-01, including 500GB solid state storage
8. Docking Station DS-01, for battery charging and data transfer
9. Media Cable MC-01, for USB3 data transfer to computer directly from Media
Module or cartridge in Docking Station.
10. Small tripod adapter
11. Camera External AC power supply and AC cables
12. Docking Station AC power supply and AC cables
NOTE:Duetothesizethecaseshouldtravelasholdluggagewhenyingwith
OZObutthecartridges(containingLi-Ionbatteries)shouldberemovedand
carried as hand luggage according to international regulations.
5
WARNINGS
Ventilation
Do not cover the ventilation opening
(A).
TheDeviceiscooledbyairowing
between the outer and inner
structure.
Keep the device ventilation upright
(B).
Covering the opening or mounting
the device in a way that the
openings are not vertically on top
of each other would prevent the air
fromowing.
7
B
A
Overheating
Capture or broadcast will stop on
overheat
The Device is protected against
overheating by switching to standby
when the temperature of the device
exceeds a set limit (A).
Switching to standby discontinues any
kind of capturing because the sensors
are powered down.
If the temperature continues to
rise even after switching to standby
a second threshold triggers full
shutdown (B).
Do not use near heat sources or in a
space with insucient ventilation.
These may cause the device to
overheat, and stop capture.
Direct sunlight may also cause the
device to heat up more quickly.
8
BA
Operating and Storage Temperature
Operating Temperature
The device should only be used
between +32°F and +86°F (0°C and
+30°C).Donotuseoutsidethisrange.
Storage Temperature
The device should be stored between
-4°Fand+122°F(-20°Cand+50°C).
Do not store outside this range.
9
+32°F / +86°F 0°C / +30°C
-4°F / +122°F -20°C / +50°C
Protective Cover
Do not remove the protective cover
until the device is fully mounted.
Keeping the protective cover on
the device for as long as possible
decreases the risk of lens damage
signicantly.
To remove or attach the cover, open
it only the necessary amount.
Avoid contact with the lenses as
much as possible.
1
10
2 2
