Nokia N 80 Manuel utilisateur

Quick Start Guide

for Nokia N80

Keys and parts (front)

11 Sliding keypad

10 Clear key deletes text and items.

9Multimedia key is a shortcut to

multimedia content.

8Menu key opens the main menu.

7Edit key opens a list of commands

when you edit text.

6End key

5Call key

3Selection keys to select commands and items.

2Secondary camera

(lower resolution than the main camera)

1Infrared port

4Scroll key to move around the menus.

Press the scroll key in the middle ( )

to select, accept, or activate.

To access the keypad, take hold of the back part of the

device, and push the front part up to open the slide.

Model number: Nokia N80-1 Internet Edition.

Hereinafter referred to as Nokia N80.

107

You can use a compatible miniSD card as extra storage space. Before you

remove the memory card from the slot, press the power key, and select

Remove mem. card. All applications are closed.

Important: Do not remove the memory card in the middle of an

operation when the card is being accessed. Removing the card in the middle

of an operation may damage the memory card as well as the device, and

data stored on the card may be corrupted.

Keys and parts (back)

12 Power key ( )

14 3 megapixel (2048 x 1536) main

camera for high resolution image

capture and video recording

15 LED flash

16 Close-up switch to activate the

close-up mode of the main camera

17 Memory card slot for a miniSD card

19 Capture key for using the main camera

21 Charger connector

20 Pop-Port™ connector for compatible

enhancements

13 GSM/WCDMA antennas

18 Bluetooth & WLAN antenna

(U)SIM card and battery

Insert the (U)SIM card and battery

1. With the back of the device facing you,

press the release button, slide the cover,

and lift it up (fig. 3.1).

Always switch the device off, and disconnect

the charger before removing the battery.

2. To release the (U)SIM card holder, slide the

holder, and lift the holder up (fig. 3.2).

3. Insert the (U)SIM card into the holder (fig. 3.3).

Make sure that the bevelled corner on the card is

facing upward from the holder, and that the

contact area on the card is facing the connectors

on the device.

4. Close the holder, and slide it to lock

it into place.

5. Insert the battery (fig. 3.4).

6. Replace the back cover.

Keep all SIM cards out of the reach of small children.

fig. 3.1

fig. 3.2

fig. 3.3

fig. 3.4

Get started 4

Charge the battery

1. Connect a compatible charger to a wall outlet.

2. Connect the power cord to the device.

If the battery is completely discharged, it

may take a while before the charging

indicator starts scrolling.

3. When the battery is fully charged, disconnect

the charger from the device, then from the

wall outlet.

Switch the device on

1. Press and hold the power key ( ).

2. If the device asks for a (U)PIN code or lock code,

enter it, and press ( ). The factory setting for

the lock code is 12345.

Your device has two internal antennas.

Note: As with any other radio transmitting device,

do not touch either of the antennas unnecessarily when the

device is switched on. Contact with the antenna affects call

quality and may cause the device to operate at a higher power

level than otherwise needed. Not touching the antenna area

during a phone call optimizes the antenna performance and

the battery life.

Camera

Your Nokia N80 has two cameras, a high resolution main camera on the back of the

device, and a lower resolution secondary camera on the front. Both cameras can be

used to take still pictures and video.

Take pictures with the main camera

1. To start the camera, press and hold the capture key (fig. 5.1a)

for more than 1 second.

2. The viewfinder opens in landscape mode.

To take a picture, press the capture key.

To record video, select Options > Video mode.

To use the secondary camera,

select Options > Use secondary camera.

The viewfinder opens in portrait mode.

fig. 5.1

Connectivity 6

Your device supports wireless local area networks (wireless LAN). With wireless

LAN, you can connect your device to the Internet and compatible devices that

have wireless LAN.

In your home wireless LAN, you can create a home network, and connect

compatible Universal Plug and Play devices that support wireless LAN to it. In the

home network, you can view or play compatible media files in Gallery on the

other connected devices, for example, view images stored on your Nokia N80 on a

compatible TV. You can also copy media files between the compatible devices, and

print images on a compatible printer. For more information, see the user guide.

With your Nokia N80, you can also transfer data with compatible devices using

infrared, the USB data cable, or Bluetooth connectivity.

Help

The help function provides instructions when using

the device. To access it from an application, select

Options Help.

Tutorial

The tutorial gives you information about some of

the features of your device. To access it in the menu,

User Guide

Further detailed information is given in the separate

user guide. Do not use this get started guide in

place of the complete user guide, which provides

important safety and maintenance information.

Online

and Pop-Port are trademarks or registered trademarks of Nokia Corporation.

Other product and company names mentioned herein may be trademarks or

tradenames of their respective owners. Reproduction, transfer, distribution or

storage of part or all of the contents in this document in any form without the

prior written permission of Nokia is prohibited.

Support

www.nokia-asia.com/N80/support

press ( ), and select My own Tutorial.
