OWNER’S

MANUAL

Keys

0HQX 1DPHV

Dials the number

on the display.

Volume button

Adjusts volume of

earpiece or

speaker.

Softkeys

Their current

function is

displayed

above the key

(for example,

here their

functions are

“Menu” and

“Names”).

Press this key to

end a phone

call, or to return

to the start

screen when no

in a call.

Scroll

button

Scroll through

menus,

submenus, and

phone book.

Press and hold

for continuous

scrolling.

Power key

Press and hold to

turn your phone on

or off.

Fixed

antenna

Do not

attempt to

extend or

remove!

Indicators and Icons

Line 1 is selected for outgoing calls (see page 53).

Line 2 is selected for outgoing calls (see page 53).

You have an active call.

The phone is waiting for you to enter a response.

Ringing option is set to 6LOHQW and keypad tones,

warning tones, and message alert tone are turned off.

Keyguard has been activated. Your phone will not

accept any keypresses. To deactivate, press 8QORFN,

then .

Your phone has been set to forward all incoming

voice calls to another number.

You have forwarded all voice calls that are received on

line 1 (see page 45).

You have forwarded all voice calls that are received on

line 2 (see page 45).

You have forwarded all voice calls that are received on

lines 1 and 2 (see page 45).

You have one or more voice messages waiting.

You have one or more text messages waiting.

Analog mode is active. See “Optional Analog Module”

on page 84.

Your phone is roaming outside of its home system.

Any characters you enter will be upper-case letters.

Press the # key to switch letter case.

Any characters you enter will be lower-case letters.

Press the # key to switch letter case.

Any characters you enter will be numbers.

You are in “special character” mode; select a special

character and press ,QVHUW. (When entering letters,

switch to this mode by pressing the key.)

The alarm clock is set.

Contents

1. For Your Safety . . . . . . . . . . . . . . 3

FCC/Industry Canada Notice . . . . . . . . . . . . . . . . . . . . .4

Using this Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

2. Getting Connected . . . . . . . . . . . 5

Installing the SIM card . . . . . . . . . . . . . . . . . . . . . . . . . .5

Battery information . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

When is a good time to charge? . . . . . . . . . . . . . . .8

3. The Very Basics . . . . . . . . . . . . 10

Switching on the phone . . . . . . . . . . . . . . . . . . . . . . . .10

Checking signal strength . . . . . . . . . . . . . . . . . . . . . . .10

Making a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Ending a call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Answering a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Switching off the phone . . . . . . . . . . . . . . . . . . . . . . . .12

Keyguard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

4. Working The Menu . . . . . . . . . . 13

Navigating tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

What is the ‘start screen’? . . . . . . . . . . . . . . . . . . . . . .14

The main menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Help text. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Summary of Menu Items . . . . . . . . . . . . . . . . . . . . . . .16

5. Features A-Z . . . . . . . . . . . . . . . 18

6. Optional Analog Module . . . . . . 84

Analog features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85

Analog system selection . . . . . . . . . . . . . . . . . . . . . . . .85

Digital/analog selection. . . . . . . . . . . . . . . . . . . . . . . . .87

Module security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88

7. Call Forwarding Codes . . . . . . . 89

8. Accessories . . . . . . . . . . . . . . . 91

Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91

Charging Times . . . . . . . . . . . . . . . . . . . . . . . . . . .92

Talk and Standby Times. . . . . . . . . . . . . . . . . . . . .92

Chargers and other accessories . . . . . . . . . . . . . . . . . .93

9. Reference Information . . . . . . . 97

10. Technical Information . . . . . . 103

1. For Your Safety

Read these simple guidelines before using your

phone. Failure to comply with these guidelines

may be dangerous or illegal.

For more detailed safety information, see “Impor-

tant Safety Information” on page 97.

Road Safety Comes First

Don’t use a hand-held phone while driving; park

the vehicle first.

Switch Off In Hospitals

Follow any regulations or rules. Switch phone off

near medical equipment.

Switch Off On Aircraft

Wireless phones can cause interference. Using

them on aircraft is illegal.

Switch Off When Refueling

Don’t use phone at a refueling point. Don’t use

near fuel or chemicals.

Switch Off Near Blasting

Do not use the phone where blasting is in

progress. Observe restrictions, and follow any

regulations or rules.

Interference

All wireless phones may get interference which

could affect performance.

Use Sensibly

Use only in the normal position (to ear). Don’t

touch the antenna unnecessarily.

Qualified Service

Only qualified service personnel must install or

repair equipment.

Accessories and Batteries

Use only approved accessories and batteries.

Do not connect incompatible products.

FCC/Industry Canada Notice

Your phone may cause TV or radio interference (e.g. when

using a telephone in close proximity to receiving equipment).

The FCC/Industry Canada can require you to stop using your

telephone if such interference cannot be eliminated. If you

require assistance, contact your local service facility.

This device complies with part 15 of the FCC rules. Operation

is subject to the condition that this device does not cause

harmful interference.

Using this Guide

The wireless phone described in this guide is approved

for use in GSM 1900 and AMPS networks.

Network services

A number of features included in this guide are called

network services. They are special services provided

by wireless service providers. Before you can take

advantage of any of these network services, you must

subscribe to the service(s) from your home service

provider and obtain instructions for their use.

Updates

The latest version of this Owner’s Manual may be

found on Nokia’s World Wide Web site at

www.NokiaUSA.com.

Compliance with EU Directive 89/336/EEC

This Nokia-manufactured product complies

with the European Union EMC Directive

89/336/EEC.

This product does not operate in European GSM net-

works but can be purchased and then used with an

appropriate SIM card in GSM 1900 networks in North

America or Latin America.

2. Getting Connected

So you’ve just bought your new phone, taken it out of

the box, and you’re wondering what to do next. To get

started, just follow a few easy steps.

1) Install the SIM card

2) Attach and charge the battery

3) If you purchased an optional analog module,

attach it to the phone

See “Optional Analog Module” on page 84.

Note: The analog module is a separate accessory that may be

purchased from your service provider. It allows you to make

and receive calls in analog networks.

Installing the SIM card

Before you can use your phone, you need to put a

valid miniature SIM card in the phone. The card comes

from your network operator or service provider.

Before installing the SIM card, switch off the phone and wait

for a few seconds before removing the battery.

The SIM card and its contacts can be easily damaged by

scratches or bending, so be careful when you handle, insert or

remove the card.

Note: Keep all miniature SIM cards out of small children’s

reach.

1) If the battery is already attached, remove it. See

“Removing the battery” on page 9.

2) Open the SIM card

holder: slide the latch

toward the top of the

phone, then lift it up

3) Place the SIM card in its

slot. Make sure that the bev-

elled corner is top right and

the gold contacts of the card

face into the phone.

4) Close the holder

5) Slide the SIM card

holder toward the bottom

of the phone until it locks

into place

6) Attach the battery (see below)

Battery information

Attaching the battery

To attach the battery, place

it on the back of the phone

as shown and slide it

toward the top of the

phone until it clicks into

place.

Attaching the battery when using optional

analog module

1) Place the analog

module on the back of

the phone

2) Slide the module

toward the top of the

phone until it clicks into

place

3) Place the battery on

top of the analog

module

4) Slide the battery toward the top of the phone until

it clicks into place

Charging your new battery

Your phone is powered by a rechargeable Li-Ion or

NiMH battery. Note that a new NiMH battery’s full per-

formance is achieved only after two or three complete

charge and discharge cycles.

Note: Use only batteries approved by the phone manufacturer

and recharge your battery only with the chargers approved by

the manufacturer.

Also, see “Important Battery Information” on page 100 for

important battery usage information and “Talk and Standby

Times” on page 92 for approximate battery operation times.

With your phone on or off, simply connect the lead

from the charger to the bottom of your phone or to a

charging stand. Then connect the charger to a

standard 120V AC outlet.

Note: If you have purchased an optional analog module, be

sure to remove it and replace the battery before placing the

phone in a charging stand. Although the phone will fit in the

stand with the analog module attached, charging will not take

place.

When the battery is charging, the battery-strength

indicator on the right side of the display will scroll.

When you charge the battery for the first time, the

battery-strength indicator will not scroll the entire time;

this is normal.

If your phone displays#1RW#FKDUJLQJ, charging is sus-

pended. Check that the battery is connected to an

approved charging device. If the battery is very hot or

cold, wait for a while; charging will automatically

resume after the battery is restored to its normal oper-

ating state. If charging still fails, contact your dealer.

When is a good time to charge?

Actually, you can charge anytime. If you have a NiMH

battery, you should allow it to discharge once in a while

(see “Discharging NiMH batteries” on page 9).

Whenever your phone beeps once and displays

%DWWHU\#ORZ, you only have a couple of minutes of talk

time remaining. The repetition rate of these battery-low

warnings depend on the remaining battery capacity

and the battery condition. These warnings are more

frequent when you’re in a call.

Note: The phone will not give you the warning tone under

certain conditions. See “Warning and game tones” on

page 82.

Once all the power has drained from your battery,

you’ll hear three beeps with the message 5HFKDUJH#

EDWWHU\ on your display. At this point, your phone will

switch itself off and you’ll need to recharge your

battery.

When is charging complete?

When the charge indicators stop scrolling,

your phone is considered fully charged.

However, a slight increase in charge may

occur if your phone is left connected to the

charger. This is called “trickle charge.”

Charging times depend on the type of battery and

charger used. For approximate charging and oper-

ating times, see “Batteries” on page 91.

If the battery is too hot or cold, charging may be

interrupted until the battery reaches its normal

operating temperature.

Autres manuels pour 6190 - Cell Phone - GSM

Table des matières

Autres manuels Nokia Téléphone portable

Nokia

Nokia N95 Fiche technique

Nokia

Nokia E62 Manuel utilisateur

Nokia

Nokia 3310 Manuel utilisateur

Nokia

Nokia 2310 RM-189 Manuel utilisateur

Nokia

Nokia TA-1063 Manuel utilisateur

Nokia

Nokia 6310 Manuel utilisateur

Nokia

Nokia 6760 Manuel utilisateur

Nokia

Nokia Communicator 9210 Manuel utilisateur

Nokia

Nokia 6300b Manuel utilisateur

Nokia

Nokia C1 Plus Manuel utilisateur

Nokia

Nokia N91 Manuel utilisateur

Nokia

Nokia 8800 - Cell Phone 64 MB Manuel utilisateur

Nokia

Nokia Communicator 9290 Guide de l'utilisateur

Nokia

Nokia NAVIGATOR 6210 Manuel utilisateur

Nokia

Nokia 8110 4G Manuel utilisateur

Nokia

Nokia 9300 Manuel utilisateur

Nokia

Nokia Asha 311 Manuel utilisateur

Nokia

Nokia 1280 RM-647 Manuel utilisateur

Nokia

Nokia 2310 - Cell Phone - GSM Manuel utilisateur

Nokia

Nokia 2116i Manuel utilisateur

Nokia

Nokia 6215i Manuel utilisateur

Nokia

Nokia 6131 - Cell Phone 32 MB Manuel utilisateur

Nokia

Nokia RH-44 Series Manuel utilisateur

Nokia

Nokia 6260 - Smartphone 6 MB Manuel utilisateur

Manuels Téléphone portable populaires d'autres marques

Zte

Zte BLADE A520 Manuel utilisateur

Blackbe;rry

Blackbe;rry KEYone Manuel utilisateur

Bea-fon

Bea-fon X5 Premium Manuel utilisateur

Blackbe;rry

Blackbe;rry 8707 Series Manuel utilisateur

Blackbe;rry

Blackbe;rry Storm Mode d'emploi

LG LM-X420QN Manuel utilisateur

LifeWatch

LifeWatch V Manuel utilisateur

Bea-fon

Bea-fon SILVER LINE SL860 Manuel utilisateur

IKI Mobile

IKI Mobile KF4.5i Manuel utilisateur

Hitech

Hitech HT-850 Manuel utilisateur

Yezz

Yezz Fashion F10 Manuel utilisateur

Point Mobile

Point Mobile PM60 Manuel utilisateur

Blackbe;rry

Blackbe;rry Q10 Manuel utilisateur

Blackbe;rry

Blackbe;rry Bold 9900 Manuel utilisateur

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuel utilisateur

LG LM-K420EMW Manuel utilisateur

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuel utilisateur

LG Thrive Manuel utilisateur
